BLUES II
USER MANUAL
®
Norsk
English
Français
Deutsch
Nederlands
Español
Svenska
Dansk
Suomi
1
2
3
4
5
7
8
9
10
6
BLUES II
1 2
BLUES II
3
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
EN
Congratulations! 4
About Blues II 4
Functions of the Blues II 5
Charging the Blues II 6
Switching the Blues II on and off 6
Pairing the Blues II with a mobile phone 6
How to... 7
adjust the volume … 7
answer a telephone call … 8
end a telephone call … 8
make a call … 8
use voice-dialling … 8
use the Speed-Dial … 8
listen to music on your mobile phone … 8
programming the Blues II … 8
Description of light diodes and colours 9
Factory default settings 9
Trouble shooting and FAQ 10
Storage and maintenance 1 1
English
Certification and safety approvals (english) A
Declaration of conformity (english) B
4
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
EN
Congratulations!
Congratulations on your new Blues II. We hope you get a lot of
pleasure from the solution which will give you really good sound from
your mobile phone. This user manual will ensure you get started, so
that you get the most pleasure from your new solution. Your local dealer
offers a range of accessories which will further enhance the functionality
of this product.
Before use, the unit must be fully charged (see page 6 for
instructions). Charge time is approximately 2 hours.
Be aware!
Together with the connected headset/earbuds, the neck loop (Blues II)
can emit audio of a high volume. Exposure to this may cause permanent
hearing damage. Be careful when increasing the volume to avoid such
injuries.
Be careful when using the unit while engaged in activities which demand
your full attention.
Never attempt to dismantle the product yourself. Only approved local
dealers or service centres may open the products. Contact your local
dealer if any parts of the unit need replacing.
Keep out of reach of children:
The plastic packaging of the product and accessories are not children’s
toys. The packaging or the small parts it contains may cause choking if
swallowed.
Ignition of flammable atmospheres
Do not use the Blues II in environments where there is a danger of
igniting combustible gasses.
About Blues II
Blues II is a neck loop for hearing aid/CI users which have
telecoil. They will be able to receive sound from mobile phones with
Bluetooth. The neck loop can also receive music from the mobile phone
if the mobile phone supports it.
5
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
EN
See the illustrations on page 1 for an explanation of the points below
Answer button •
1
Used to answer incoming phone calls.
Socket for charging and accessories •
2
:
The accompanying power supply cable is connected here, as well as
other accessories with 2.5mm jacks.
USB socket •
3
:
For charging the unit via USB cable connection to a computer.
Headset socket :•
For connecting the accompanying earbuds with microphone,
standard headsets (accessories) and headsets with microphone
(accessories). Used when you are not using a hearing aid.
Microphone •
5
Battery indicator light •
6
:
Shows the battery level of the Blues II. See the table on page 9 for an
explanation of the light signals.
On/Off button.•
7
Switches unit on and off.
Volume control •
8
:
Push upwards for higher volume and downward for lower volume.
Pairing button •
9
:
Sets the Blues II to pairing mode. This happens the first time you
establish a connection between the devices.
Speed-Dial button •
10
:
Calls a pre-programmed number from a paired mobile phone.
The numbers are easily programmed via a computer with internet
access and standard Bluetooth connection.
You will only hear sound from the Blues II if you set the hearing aid/CI to
the T or MT setting and wear the neck loop around the neck, or by using
the earbuds/headset.
Functions of the Blues II
Blues II is an amplifier for mobile phones. It also transfers high quality
music (A2DP) from mobile phones. The Blues II has a Speed-Dial button
for clear and simple access to a pre-programmed number.
6
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
EN
Charging the Blues II
Make sure the Blues II is fully charged before you use it.
You can charge the Blues II in the following ways:
By cable from the wall outlet•
Directly from a computer by USB cable•
Through the Audiostreamer (accessory)•
Through the Twin Charger Cradle (accessory)•
With the Car Charger (accessory).•
During charging the Battery indicator light
6
will flash red.
When the Blues II is fully charged the Battery indicator light
6
will
illuminate solid blue. When the battery is low the Battery indicator light
6
will blink red and you will hear an audio signal from the Blues II.
NOTE: The lifetime of the battery will be significantly reduced if the
device is left uncharged for long periods. We advise you charge the
device at least once a month.
When the operation time on the battery begins to decrease, and you wish
to replace it, please send it to your local dealer. The article number of
the battery is: 956-001
Switching the Blues II on and off
How to switch the Blues II on:
Keep the On/Off button •
7
pressed until you see the Battery
indicator light
6
turn blue. At the same time you should hear a
signal via the T-Loop or via the earbuds.
Note:• The first time you switch on your Blues II, it will
automatically turn into pair mode. The Battery indicator light
6
then flashes alternately red and blue.
Go to chapter Pairing the Blues II with a mobile phone and
skip step 1 to finish the pairing.
How to switch the Blues II off:
Keep the On/Off button •
7
pressed until you see the Battery
indicator light
6
turn red. At the same time you should hear a signal
via the T-Loop or via the earbuds.
Pairing the Blues II with a mobile phone
The Blues II must be programmed to communicate with other Bluetooth
devices, e.g. mobile phones. This is done by connecting these together
wirelessly (pairing).
7
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
EN
NOTE: It is important that the Blues II and the Bluetooth devices it is
paired with are within one meter of one another during pairing and that
the units to be paired are fully charged.
How to set the Blues II to pairing mode:1.
Switch on the Blues II•
Press and hold the pairing button •
9
until the Battery indicator
light
6
flashes alternately red and blue and you hear a double
tone. The Blues II is now ready to pair for approximately 3
minutes.
How to configure the mobile phone so it detects the Blues II:2.
Follow the mobile phone’s user manual. Usually this involves •
finding the setup, connection or the Bluetooth menu on the
mobile phone and choosing discover or add a Bluetooth device.
See an example of a typical mobile phone below.
The mobile phone finds Blues II!3.
The mobile phone asks if you wish to connect to it. •
Accept by pressing Yes or OK on the telephone and confirm with
the pin code, which is 0000 (4 zeros).
The mobile phone will confirm if the pairing has been •
successful.
If the pairing was unsuccessful, repeat steps 1 to 3.•
If you wish to pair the Blues II with a Bluetooth product without a
display, the product must be set to pairing mode and use password 0000
so that the pairing can be performed.
The Blues II can only be paired with 1 device at the same time.
How to...
adjust the volume …
The volume can be adjusted gradually (press once for each volume •
level) or by pressing the volume button
8
in the desired direction
until the desired audio level has been reached.
0000
Connectivity
Push to talk
Infrared
Bluetooth
Modem
Synchronization
Data cable
Select Back
0000
Devices found
Blues II
Select Cancel
0000
Blues II
Passcode:
****
Ok
0000
0000
Devices found
Maestro
Ok
Blues II
Paired.
The handsfree
is now ready
for use
Cancel
8
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
EN
You will hear a signal when the volume has reached the lowest or •
highest level.
The Blues II remembers its last volume position, so that when •
switched off and on it will start at the same volume position.
answer a telephone call …
Press the answer button •
1
to answer a telephone call
end a telephone call …
Press the answer button •
1
to end a telephone call.
make a call …
When you call from your mobile phone, the telephone call •
(depending on the setup of the phone) is automatically transferred
to the Blues II. If this function is not available on your phone, press
the answer button
1
once to transfer the telephone call to the
Blues II.
use voice-dialling …
This function is dependant if the mobile phone supporting this •
function.
Press the answer button •
1
once.
Say the pre-recorded voice tag into the microphone
5
.
You will achieve best results if you record the voice tag via the •
Blues II.
See the phone’s user manual for more information on this function.•
use the Speed-Dial …
NOTE: For this function to work, the phone must be within range of •
the Blues II.
The Blues II must be programmed before using this function. •
See the section: Programming the Blues II on page 8.
Press and hold the speed-dial button •
10
until you hear a tone.
The phone will then call the pre-programmed number.
listen to music on your mobile phone …
The Blues II must be paired with a mobile phone with an A2DP •
profile before you continue (see page 6 for instructions).
Start the player on the mobile phone.•
The mobile phone will automatically transfer the music to your •
Blues II (this is dependent on your mobile phone, read the user
manual of your mobile phone if this does not work)
programming the Blues II …
Go to www.commidt.com to download both the operating •
instructions and the programme (CIBS Interface).
The CIBS Interface programme offers the following options:•
9
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
EN
Set up Speed-Dial number Turn on or off monitoring voice (enables you to hear your own voice)
Locate the serial number -
Useful tips:
Using the accompanying shirt/blouse clip can reduce noise caused by the
device rubbing off clothing. The clip can be attached to the rear of the
Blues II, in the slot on the desired side
By using the external microphone (accessory, article no: 901-001) you
can use the Blues II under your clothing, offering even better sound to
your audience. These and other microphones are connected at the
socket
Description of light diodes and colours
Battery indicator light 6:
What you see What this implies for the Blues II
Solid blue light The battery level is between 100% - 20%
Flashing blue light Incoming call (the mobile phone is ringing)
Flashing red light The battery level is below 20%
Solid blue light (while
charging)
Charging complete
Flashing red light (while
charging)
The Blues II is charging
Alternate blue and red
light
The Blues II is ready to pair
Factory default settings
This function will delete the stored pairing to the Blues II.•
Any settings made after you received the device will also be deleted.
Press and hold the pairing button •
9
. First you will hear a double
tone which indicates the device is set to pairing mode. You must
keep the button pressed until you hear the second double tone.
The flashing red and blue ligth will still flash •
10
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
EN
Switch off the Blues II. When you switch the device on again, it will •
automatically go into pairing mode (the battery indicator light
6
will
flash alternately red and blue). This indicates that the device has
been reset to factory settings.
Trouble shooting and FAQ
The Blues II will not switch on!
Charge the battery•
The Blues II will not charge!
Make sure the charge plug is connected correctly in the Blues II and •
that the power supply is working.
I hear crackling!
For best possible quality the Blues II must be within range of the •
mobile phone.
If you are using the headset, make sure the plug to the headset is •
correctly connected.
I cannot hear anything from the Blues II!
Increase the volume of the Blues II.•
Check that the Blues II is paired to the mobile phone.•
If you are using the headset, make sure the plug to the headset is •
correctly connected.
If you are using the hearing device, make sure the coil is lying cor-•
rectly around the neck and that the hearing device is set to T or MT.
I have connection problems even though the mobile phone
says different!
You may have deleted the pairing from the mobile phone. •
Follow the instructions for pairing on page 6.
Will the Blues II work with other Bluetooth devices?
The Blues II is made to work with most mobile phones. This depends •
on the mobile phone being compatible with Bluetooth version 1.1, 1.2
or 2.0, supporting headsets, handsfree and/or A2DP profile.
I cannot use voice-dialling!
These functions are accessible if the telephone supports them. •
See the telephone’s user manual for more information.
11
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
EN
Storage and maintenance
Always store the Blues II in a safe place with the power switched off.•
Do not store the Blues II in extreme temperatures (over 45°C/113°F, •
in direct sunlight, or below -10°C/14°F). This can shorten the
lifetime of the battery and affect use. High temperatures can also
reduce performance.
Do not expose the Blues II to rain or other liquids•
Clean the device with a dry cloth.•
A
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
Certifi cation and safety approvals
CE
This product is CE marked accordingly to the provisions of the
R & TTE Directive (99/55/EC), COMMidt AS, declares that this product is in
compliance with the essential requirements and other relevant
provisions of Directive 1995/5/EC.
For further information, please consult: http://www.commidt.com
Bluetooth
The Bluetooth word® and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by COMMidt AS is under licence. Other trademarks and trade
names are those of their respective owners.
Electrical and electronic equipment (EEE) contains materials,
components and substances which can be dangerous and
detrimental to human health and the environment if waste
electrical and electronic equipment (WEEE) is not disposed of
correctly. Products marked with the “crossed-out waste bin”
symbol shown below are electrical and electronic equipment.
This symbol indicates that waste electrical and electronic
equipment must not be discarded along with unsorted household waste, but must
be collected separately. In the development and manufacture of your COMMidt
product, high-quality materials and components have been used which can
be recycled.When disposing of electrical and electronic equipment you should
therefore make use of a collection arrangement intended for this purpose, which
may involve either delivery at your local collection point or recycling station or
collection at your home. Further information should be obtained from your local
dealer.
Batteries contain substances that may be harmful to human health
and the environment if not handled properly.
Batteries are labelled with a crossed dustbin as shown.
It symbolizes that waste batteries must not be disposed of as
unsorted municipal waste, but must be collected separately.
Some batteries are also labelled with the chemical symbol Hg (mercury), Cd
(cadmium) or Pb(lead). This is particularly harmful substances, and therefore it is
important that these batteries will be collected.
It is important that you hand your waste batteries to the collection systems which
are established. On this way you help to ensure that batteries are recycled in
accordance with the law and will not unduly impact the environment.
When disposing of waste batteries you must use a collection system established
for that purpose whether it be handed in at your local collection point or recycling
or collected directly from the household. Detailed information must be obtained
from the local authorities.
B
User manual Blues II (NO_EN_F_D_NL_ES_SE_DK_SU) 1l
NO
EN
F
D
NL
ES
SE
DK
SU
Removal of the battery:
Unscrew the screw on the rear of the unit1.
Remove the front cover2.
Unscrew the screw on the circuit board.3.
Remove the circuit board4.
Unplug the battery5.
Declaration of conformity
We COMMidt, Kirkegata 57-59, 7600 Levanger, Norway declare
under our own responsibility that the Bluetooth products to which this declaration
refers conforms withthe relevant standards or other standardised documents.
•93/42/EØF
•NS-EN12182
•ETSIEN301489-1V1.4.1(2002-08)
•ETSIEN301489-17V1.2.1(2002.08)
•EN300328V1.6.1(2004-11)
•EN61000-4-3,5.1
•EN61000-4-2,5.2
According the regulations in Radio Equipment and Telecommunications Terminal
Equipment (R&TTE) Directive 1999/5/EC
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
This device is a class 2 Bluetooth device (max 2 mW EIRP). Due to the low level
of transmit output power the device is not subject to the routine RF exposure
valuation as per Section 2.1093 of the FCC rules.
Levanger 2009-04-24
Roar Austvik
Managing Director, COMMidt
Loading...
