NURSE CALL SYSTEM JNS-36(Series)

POWER

VOLUME

TONE

BUSY

LOCK

TALK

• Thank you for purchasing COMMAX products.

• Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

• The company is not responsible for any safety accidents caused by abnormal operation of the product.

Introduction

Established in 1968 Jung Ang Electronics Co., Ltd. has specialized in the field of

intercommunication system for 27 years, and and now it is our greatest pleasure to present a

highly advanced hospital communication network system which we assure to level up your

hospital culture.

Nurse call system introduction

We have three types of unrse sall system as below table.

System

Features

System type Analogue Analogue Digital

Nurse Stations JNS-12/24/36

Patient Station JNS-101 JNS-102 JNS-1050M/1050S

Central controller

wire

Max

acconmodation

Available

functions

JNS-36 Series JNS-600 Series JNS-1000 Series

JNS-6012M/6028M/6044M/6060M

JNS-6012, 6060 JNS-1060, 1108

2 common+ 1 common+

1 individual 2 individual

Max 36 beds

(36 stations call

communication)

a. Corridor light

a. Max 36 beds

(30 ststions call &

communication)

b. 8 rooms of public

toilets(emergency)

a. Corridos light

b. Master to Master talk

(Max 6 stations)

c. Call cord only.

d. Guiding light

JNS-1060M/1108M

5pair(10wires)common

a. Max 29wards of 108 beds

(1080 stations call & communication)

b. Max 29 ward's shower room &

toilets. (emergency function)

c. 16 rooms of public toilets

(emergency function)

a. Corridor light/Guiding light b. Master to Master talk

(max 90 stations) c. Presence switch. d. Staff call e. Emergency switch. f. Call cord & pillow speaker g. Compatible with TP-90AN

upto 90 station's communication

of nurse and staff stations.

Effective distance Max 1,000m Max 500m Max 500m

- 1-

Table of Contents

Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1

Nurse call System introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1

Contents table - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2

Manual of JNS-36 Series - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3

1. Model No - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3

2. Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3

3. Structure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4

4. System Working diagram - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

5. Figure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

6. Connection Diagram - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6

7. Operating Instruction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6

8. Specification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7

9. Warranty Service - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7

- 2-

Manual of JNS-36 Series

1. Model No

The model No of the nurse call system would be devided by it's accomodating interphone station

number as belows;

No Wiring station No MODEL No ETC

1 8wire 6 station JNS-6 Basic Case

2 14 wire 12 station JNS-12 Basic Case

3 20 wire 18 station JNS-18 Basic Case

4 26 wire 24 station JNS-24 Basic Case

5 32 wire 30 station JNS-30 Basic Case

6 32 wire 36 station JNS-36 Basic Case

7 44 wire 42 station JNS-42

additional case

(order made)

station number

+ 2wire

add ed. up

by 6 stations

JNS-

station No.

2. Features

2-1. Clear communicating line.

2-2. You can adjust each call volume and talk volume separatly.

2-3. When a call receiving. LED lamp turn off automatically.

2-4. When a communicating, the lamp of the line will be on.

2-5. Two way communication.

2-6. Hands-fred talk function.

- 3-

3.STRUCTURE

3-1. MASTER STATION

POWER

VOLUME

BUSY

TONE

LOCK

TALK

①

HAND SET :

② POWER LED : To check the Power Switch's condition.

③ POWER S/W : To provide a power.

④ C-MIC : To transmit a message.

⑤ BUSY LEN : To indicate busy line by lamp On.

⑥ LOCK BUTTON : Only to transmit a message in one way, the lamp is on.

⑦ TALK BUTTON : To press the button for talking. (during H/F communicating)

⑧ VOICE : To adjust receiving volume by three stage, High, Mid & Low.

⑨ TONE : To adjust receiving signal by three stage, High, Mid & Low.

⑩ SPEAKER : To output the message.

- 4-

3-2. SUB STATION

CALL

ALL CORD

4. System working diagram

TALK

MIC

① SPEAKER :

②

CALL JACK : Can be connected with

call cord CC-200.

③ CALL BUTTON : To call a master.

④ C-MIC :

CANCEL BUTTON : To cancel a call.

⑤

⑥

CALL LAMP : LED's off in calling.

⑦ TALK LAMP : LED's on in talking.

5. Figure

MASTER STATION (JNS-36) SUB STATION

(W/ARM SWITCH)

- 5-

6. Connection diagram

•common two wire and individual one wire

7. Operating Instruction

7-1. When call a sub station in master.

① Please press a select button that you want then a LED in the button is "ON".

② With hand-set communicating you can talk in two way communication.

③ Under using a intercom way of communication, You can talk through talk button.

7-2. When call a master in substation.

With pressing the call button in substation the LED Lamp in master is "ON" and Melody is

①

transmited.

② The call Lamp & corrider lights will be "OFF" at same time.

③

Please press the master button or lift up the hand set to talk.

④ Please return the select button after finishing a talk.

- 6-

8. SPECIFICATIONS

Divison

Wiring Common 2 wires and individual 1 wire

Power 110-220V~ (60Hz)

Power consumption in standdoy 24V (22mA)

Max power consumption 24V (190mA) in one line

Communication Way Two way communication system

Distance 600m/0.65mm

Station Number Max 36 sub stations

Dimension 360(W) x 232(D) x 105(H)mm

Model No

JNS-36(Series)

9. WARRANTY SERVICE INSTRUCTIONS

If you experience a problem with your JNS-36 Nurse Call System, please refer to the

"Operating Instructions" sections of this Owner's Manual to review the proper operation. Check

the power source to insure adequate power available to operate the JNS-36 System.

If the JNS-36 still will not function, please return the unit (with proof of purchase) to the place of

purchase.

FOR YOUR RECORDS

Purchase Date:

Purchased From:

Serial Number:

KEEP THIS INFORMATION

IN A SAFE PLACE.

- 7-
