• Thank you for purchasing COMMAX products.
• Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
• Thank you for purchasing COMMAX products.
• Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
Fineview Video Phone CDV-70MH/CDV-70MH(M)
User Manual
2
2
Table of Contents
1. Warnings and Cautions...........................................................................2
Part Names and Functions ....................................................................3
Package Contents ..................................................................................3
Wiring and Connection Instructions. .......................................................4
Operation .....................................................................................................
4
Settings ...................................................................................................
...
5
Installation...............................................................................................
Specifications and Features....................................................................7
2.
3.
4.
5.
6.
7.
8.
Please follow the things described below in order to prevent any danger or
property damage.
1.
Warnings and caution
Wa
rni
ng
Cau
tio
n
Prohibition.
No disassembly
No touch
Must follow strictly.
Shows plugging out the power cord
without an exception
Shows the warning and caution for an electric shock.
Shows the warning and caution for a fire.
It may cause a serious damage or
injury if violated.
It may cause a minor damage or
injury if violated.
6
Please
don’t disassemble,
repair or rebuild this product
arbitrarily (please contact the
service center if a repair is
needed.
·It may cause an electric
shock or fire.
When cleaning the product,
please rub it with a soft and
dry cloth after plugging out
the power cable. (Please don’t
use any chemical products
such as wax, benzene, alcohol
or cleanser.)
If an abnormal sound, burning
smell or smoke is coming out
of the product, please plug out
the power cable and contact a
service center.
·It may cause an electric
shock or fire.
Please don’ t insert any
metallic or burnable materials
into the ventilation hole.
·It may cause an electric
shock or fire.
Cleaning & Use
Warning &
Caution
3
Power & Installation
Please don’t use several
products at the same time on
one power socket.
·It may cause a fire due to an
abnormal overheating.
Please don’t bend the power
cable excessively or it may
cause an electric shock.
·fire when using a damaged
power cable.
Please don’t handle the power
cable with a wet hand.
·It may cause an electric
shock.
Please plug out the power
cable from the socket when
not using it for a long period
of time.
·It may shorten the product
lifespan or cause a fire.
Please don’t install the
product in the place where
there is much oil, smoke or
humidity.
·It may cause an electric
shock or fire.
Please don’t install the
product with the lightening
and thunder.
·It may cause an electric
shock or fire.
Please don’t use and connect
this product with other
products with different rated
voltage
·It may cause a disorder or
fire.
When installing the product
that generates heat, please
install the product away from
the wall (10cm) for the
ventilation.
·It may cause a fire due to
the increased internal
temperature.
Warning &
Caution
Parts Names
2.
User Manual
(1EA)
Wall bracket mounting
screw
(4EA)
Monitor fixing
screw
(1EA)
Wall bracket
for monitor
(1EA)
Connector
(2EA)
3. ckage ContentsPa
Handset
Monitor
Power LED
Monitor Button
Interphone Button
Door Open Button
Menu Button
Power Switch
