Smart logistics traceability platform user
guide
Smart Tracker
Introduction
Smart Tracker is the latest logistics traceability equipment of Shenzhen
comma Technology Co., Ltd. The device is developed on the basis of
GPRS technology, and integrates sensor modules such as temperature,
humidity, light perception, vibration and GPS/ Beidou positioning module.
It is suitable for the field of warehousing and logistics such as constant
temperature warehouse environmental monitoring, zero load goods
tracing, cold chain transportation, medical transportation and so on.
Through the seamless docking of equipment and comma intelligence
logistics traceability platform, the real-time and full range tracing of the
position of order / vehicle / goods in the logistics field, environment state,
unbox state, delivery time and so on is realized.
Shenzhen comma technology Co., Ltd.
info@smartcomma.com
一、About equipment
Smart Tracker is a multi-functional logistics traceability equipment
developed based on GPRS transmission technology. The equipment
integrated temperature, humidity, light sense, vibration and other sensing
functions and GPS/ Beidou dual mode positioning function, suitable for
zero load goods traceability, vehicle tracing, cold chain logistics traceability,
medical logistics traceability and many other logistics scenes.
Smart Tracker can easily monitor the real-time position of goods and
vehicles and all kinds of sensor data through the docking with the
intelligent logistics traceability platform, so as to achieve efficient and
visual logistics control. At the same time, the intelligent logistics
traceability platform provides Open API, which can be connected with the
enterprise's own WMS, TMS and other systems.
1、Introduction and functional description of the appearance
Functional interpretation of various parts of equipment
Mark
Name
Meaning
① Power query button Press to check the power of the device
② Electric indicator lamp It is used to indicate the power of the device.
Explain in detail the meaning of the device
indicator.
③ Temperature and
Humidity sensor
For collecting environmental temperature and
humidity information
④
Light sensor
To collect light sense information
⑤ Equipment SN Unique identification code for equipment
⑥ USB interface
For equipment updating and equipment
charging
Interpretation of the meaning of equipment indicator
LED Meaning
Green battery level＞70%
Yellow 70%≥battery level≥30%
RED battery level≤30%，need to be recharged
2、Charging description
Connect to the Smart Tracker USB port with standard Micro USB interface
and connect the charger to charge.
Interpretation of the meaning of charging indicator
3、Product parameters
Smart Tracker Product parameters
Equipment In charging full
Smart Tracker Red LED on Green LED on
Product name
Smart Tracker
Dimention 120×80×20mm
Weight 186g
Standby Power
20 uA type
Battery
3800mAh Polymer cryogenic battery
Endurance time
90days(15 minutes upload interval）
Location interval Minimum 1 minutes, remotely configured
positioning accuracy
GNSS accuracy 1-10m，base station positionin positioning
accuracy depends on the density of the base station
Protection grade IP54 level
Fall grade Free fall of 1.5 meters of cement ground
operating temperature
-30˚C ~+60˚C
4、Packing detail
Name Quantity
Smart Tracker 1
Certificate 1
Warranty card 1
User guide 1
二、On the traceability platform of intelligent logistics
Smart Tracker needs to be used with the smart logistics traceability
platform. You need to use the account and password login platform I
opened for you to experience a complete logistics traceability service. If
you do not have an account, please contact our salesperson or call our
telephone number to open account for you.
Intelligent logistics traceability platform web site：https://www.56nbiot.com
Smart logistics traceability platform use Handbook URL link:
https://www.56nbiot.com/usermanual.pdf
Or please scan the below two-dimensional code to get:
三、About API
The intelligent logistics traceability platform provides standard API
interface for users to connect retrospective functions to the enterprise own
information system. If you need relevant information and technical
support, please contact our sales staff.
四、Maintenance service
1、Smart Tracker mainframe is free for 1 years. Human factors and non
natural disasters are excepted.
2、The warranty period for batteries and other accessories is half a year.
3 、 Maintenance cycle: within 15 working days after receiving the
equipment, the repair is completed and sent back (excluding postage).
Disclaimer:：
Thank you for choosing Smart Tracker and smart logistics traceability
platform. Please be sure to carefully read all the contents of this guide
before using this product to ensure that you are fully aware of how to use
this product in a safe, reasonable and effective way. After reading, please
keep this guide properly for the convenience of inspection next time.
Do not dismantle the terminal by yourself or tear the sealing label on
the terminal. Otherwise, we will not guarantee or replace the equipment.
The pictures in this guide are for reference only, subject to change
without notice. Please take the actual product as the criterion. For the
improvement and renewal of this product, we reserve the right to change
the guide without notice at any time.
All the information contained in this guide is protected by copyright.
We reserve all rights, without any written permission, and no unit or
individual shall, in any way or reason, carry out any form of excerpt, copy,
or binding with other products in any form or part of this document.
The products described in this guide may include software that is
entitled to copyright by our company or third parties. Unless the relevant
rights holder permits, any unit or individual can not copy, distribute,
modify, excerpt, decompile, disassemble, decrypt, reverse engineering,
lease, transfer in any form, in any form. And other violations of software
copyright.
We have the final interpretation of this statement.
FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This
equipment should be installed and operated with minimum distance
between 20cm the radiator your body: Use only the supplied antenna.
FCC ID: 2AKTB-SMARTTRACKER
