IMPORTANT INSTRU CTIONS
PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, an d in jury to perso ns, in cluding the foll owing:
1) Read all instructions before using this heater.
2) Heater is hot when in use. To avoid burns do not let bare skin touch hot
surfaces. Use handle to move heater. Keep combustible materials such as
furniture, papers, clothes, and curtains at least 3 feet from the front of the
heater and keep them away from the sides and rear.
3) Extreme caution is necessary when any heater is used by or near
children or invalids and whenever the heater is left operating and
unattended.
4) Always unplug heater when not in use.
5) Do not operate any heater with a damaged cord or plug or after the
heater malfunctions, has been dropped or damaged in any manner.
Discard heater, or return to authorized service facility for examination
and/or repair.
6) Do not use outdoors.
7) This heater is not intended for use in wet or very humid locations. Never
locate heater where it may fall into water.
8) Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from traffic area and where it will not be
tripped over.
9) To disconnect heater, turn controls to off, then remove plug from outlet.
10) Connect to properly grounded outlets only.
11) Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
12) To prevent a possible fire, do not block air intakes or exhaust in any
manner. Do not use on soft surfaces or unstable surfaces where the heater
may upset or where openings may become blocked.
13) A heater has hot and arcing or sparking parts inside. Do not use it in
areas where gasoline, paint, or flammable liquids are used or stored.
14) Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury
to persons.
15) Always plug heaters directly into a wall outlet/receptacle. Never use
with an extension cord or power strip (power tap). DO NOT CUT OFF
PLUG AND WIRE DIRECTLY.
16) Risk of fire. Do not use as a residential or household heater.
“SAVE THESE INSTRUCTIONS”
PLEASE READ BEFORE OPERATING
PRE-OPERATING INSTRUCTIONS
1. Carefully remove your heater from box. (Please SAVE the
Box for off season storage.
2. Attach the handle using knobs provided.
3. Make sure the heater is switched OFF (FULL counter-clockwise
position) before plugging the heater into the outlet. Connect to
properly grounded outlets onl y. Note
: The power cord has a NEMA
#6-20P plug that will only fit in the outlet one way. If it does not fit
contact your electrician to replace your outlet.
4. Place heater only on a firm level surface, free from obstructions
and at least 3 ft. away from any wall or other objects such as
curtains, plants, etc.
5. Avoid overloading your circuit by not using other high w atta ge
appliances in the same outlet.
HOW TO USE YOUR HEATER
1. Completely uncoil the cord and plug heater directly into a 240 Volt
grounded AC wall outlet. Be sure the plug fits tightly. A loose fit will
cause overheating and damage the plug. Plug and cord may feel
warm during normal usage. DO NOT USE EXTENSION CORDS.
DO NOT CUT OFF PLUG AND WIRE DIRECTLY.
2. Thermostat: Turn to highest setting until room is comfortable. Then
slowly rotate the knob counter clockwise (left) until the heater
cycles OFF. At this SET POINT the heater will cycle On and Off to
maintain this comfort level.
3. It is necessary to allow the heater to cool for 10 minutes before
restarting.
CAUTION
Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause FIRE, ELECTRIC SHOCK
or injury to persons.
Page 2
IMPORTANT SAFETY FEATURES
• This heater is equipped with an AUTOMATIC OVERHEAT SAFETY
DEVICE that will turn off the power to the HEATING ELEMENT should
the internal temperature of the heater exceed normal levels. If this
should happen the heating element will turn off. Should this
condition occur, immediately remove any obstructions and set the
heater on a level surface. When the temperature returns to normal
levels power to the heating element will be restored and the heater
should function normally.
• This heater is for use on 240 volts. The cord has a plug of 6-20P as
shown on the front page. No adapter is available for this blade
configuration, and none should be used. The type outlet is a 240 volt
grounding outlet. When properly installed, it provides a ground
connection through the cord to the heater to protect the operator
from electric shock.
TROUBLE SHOOTING
If your heater fails to operate, please do the following:
• Review these instructions to insure you understand the basic operations
and features of your heater. (Example: Overheat Protection)
• Check your circuit breaker of fuse for proper operation.
• Check for obstructions. Unplug the heater for 30 minutes, clear any
obstructions and restart the heater.
• Do NOT expect the heating coils to glow. A tint of orange may be
noticeable in places on the element away from the main air flow.
CLEANING AND STORAGE
Dust, dirt, pet hair, etc can all diminish your heaters performance and can lead
to unwanted odors. For best performance clean your heater frequently, at least
once per season. ALWAYS TURN OFF AND UNPLUG THE HEATER
BEFORE CLEANING.
• Turn Heater OFF, unplug it and wait for the heater to become cool.
• Use a dry cloth to clean only external surfaces of the heater.
• A vacuum with soft brush may used to clean louvered areas.
• Wrap and tie the cord to protect it from damage.
• Repack the heater in its original carton and store it in dry place.
NEVER attempt to open or service the heater yourself. Doing so may cause
damage or personal injury. (See Warranty Card for more information)
SPECIFICATIONS
Model NO.
EUH1240 (All specifi cations +/ - 10% tolerance)
Voltage
240V
Frequency
60Hz
Output Power (Watts)
4000 W
Electric Current (Amps)
20A
Dimensions ( W x D x H)
16” x 14” x 16”
Net Weight
16.5 lbs.
BTU’s per/Hour
13,650 High
FAN FORCED HEATER
MODEL EUH1240
FEATURES:
4000 Watt Heat Output
Thermostat Heat Control
Heat Circulating Fan
Carr y Handle and Stand
Permanently Lubricated Motor
Comfort Home Products Inc. 12256 William Penn Hwy., Suite A
Huntingdon, PA 16652 Tel: (814) 643-6957
Made in China
