C
U
WI
N
Hardware
Man
u
al
C
WA-070
BR/C
WA-
070
WR/CWA-
102
BR/C
WA-
104
WR
[Version 1.4
]
COMFILE Technology,
Inc.
CWA H/W Manual
CUWIN Series
COMFILE Technology,
Inc. www.comfiletech.com • page 2
1. Hardware Specification
ITEM
MODEL
CWA-070BR
CWA-070WR
CWA-102BR
CWA-104WR
MCU
32Bit RISC CPU(ARM926EJ-S Core) – 400MHz
Memory
SDRAM : 128MB (OS Image: 52MB / User : 76MB)
NAND Flash : 256MB(OS Image:5 2MB / User : 204MB)
LCD
TFT LCD(260,000 Color)
7 Inch (800 x 480)
300cd/m
2
TFT LCD
(260,000 Color)
10.2 Inch(800x480)
300cd/m
2
TFT LCD
(260,000 Color)
10.4Inch(800x600)
300cd/m
2
Backlight
LED Backlight (ON/OFF switchable)
Ethernet
100Base-T (1Port)
Touch
4 wire resistive panel
RTC
MCU-embedded RTC
(1)
(Battery replaceable)
Audio
<0.8W Micro speaker embedded
Stereo audio output (ø3.5 Audio Jack)
USB
Host 1Port
Device 1Port (Support USB Storage)
Serial
COM1 (RS232C / RS485 switchable)
COM2 (RS232C)
COM3 (RS232C)
SDCARD
Support external SD CARD (32GB bytes)
Input Power
DC12V~DC24V
Power
Consumption
<6W (0.5A@12V)
<7.2W (0.6A@12V)
<7.2W (0.6A@12V)
MAX. Current
500mA
600mA
600mA
Dimension
(mm)
216(H)x120(V)x41(D)
222(H)x152(V)x56(D)
284(H)x163(V)x56(D)
280(H)x227(V)x56(D)
Weight
450g
650g
1040g
1700g
Operating
Temperature
0℃~70℃
(1)
The accuracy
of
the
RTC
depends
on circumstances.
COMFILE Technology,
Inc. www.comfiletech.com • page 3
CCMFILE
TECHNCLCGY
CWA H/W
Manual
CUWIN
Series
2. External
Parts
flo1 mmmmmmmm m
P ]1
\ Cl
F
J J
o-
E
-----,.
F--
M-,
0
J
K
A------'
L----
c
COMFILE Technology,
Inc. www.comfiletech.com • page 4
CWA H/W Manual
CUWIN Series
Name
Description
A Power input DC-Jack
φ2.5 DC Power Input Jack for adaptor
B Power terminal
Power terminal for cables
C Power S/W
Power input ON/OFF
D COM3
COM3 (RS232C / Female Type D-SUB 9PIN)
E COM2
COM2 (RS232C / Female Type D-SUB 9PIN)
F COM1_RS232C
COM1_RS232C (RS232C / Female Type D-SUB 9PIN)
G COM1 Mode Switch
DIP Switch for selecting COM1 mode
H COM1_RS485
COM1_RS485 Port (RS485)
I Ethernet
10Base-T Ethernet Port (RJ-45)
J USB_HOST
USB Host Port (USB A Type Connector)
K USB_DEVICE
USB Device Port (USB B Type Connector)
L SD Card Connector
SD Card slot
M Audio Out
Stereo Audio Output Port (φ3.5)
N Boot Mode S/W
DIP Switch for selecting Boot mode
3. Bracket Installation
Mounting screws and brackets are provided with each CUWIN. They are designed to clamp the
CUWIN bezel against a front panel, with the rear portion of the device extending through a panel
cutout.
After assembling the brackets as shown below, insert the side hooks into the appropriate mounting
holes on the top and bottom of the device.
Then tighten the screws enough to hold the CUWIN securely against the front panel. Do not over
tighten, or you will risk damaging the CUWIN.
COMFILE Technology,
Inc. www.comfiletech.com • page 5
CWA H/W Manual
CUWIN Series
4. Dimensions
[CWA-
104WR
]
Back
cover
of
product
Avoid using long bolts
when assembling
VESA mounts or addon board.
The inner
maximum
length is about
9mm.
COMFILE Technology,
Inc. www.comfiletech.com • page 6
CWA H/W Manual
CUWIN Series
[CWA-
102BR]
Back
cover
of
product
Avoid using long bolts
when assembling
VESA mounts or addon board.
The inner
maximum
length is about
9mm.
COMFILE Technology,
Inc. www.comfiletech.com • page 7
CWA H/W Manual
CUWIN Series
[CWA-
070WR
]
Back
cover
of
product
Avoid using long bolts
when assembling
VESA mounts or addon board.
The inner
maximum
length is about
9mm.
COMFILE Technology,
Inc. www.comfiletech.com • page 8
CWA H/W Manual
CUWIN Series
[
CWA-070
BR
]
Back cover of
product
Avoid using long bolts when assembling VESA mounts or addon board.
The inner maximum length is about 7mm.
COMFILE Technology,
Inc. www.comfiletech.com • page 9
CWA H/W Manual
CUWIN Series
5. PANEL CUTOUT
▌ Installation Requ irements
▌ Installation
X: Panel Cutout Width, Y: Panel Cutout Height, T: Panel Thickness
Unit: mm[in.]
X Y T
CWA-104WR
263
[10.36]
210
[8.27]
1.6 to
6.0
[0.06 to
0.24]
CWA-102BR
265
[10.44]
151
[5.95]
1.6 to 50
[0.06 to
0.20]
CWA-070BR
200
[7.88]
110
[4.34]
1.6 to
6.0
[0.06 to
0.24]
CWA-070WR
208
[8.19]
139
[5.48]
1.6 to
4.5
[0.06 to
0.18]
CWA H/W Manual
CUWIN Series
COMFILE Technology,
Inc. www.comfiletech.com • page 10
6. Input/Output Connectors
▌ RS232C Input/Output Connector (COM1_RS232C, COM2, COM3)
Connector Type
Order
Name
Order
Name
*D-SUB 9Pin Female
1
-
6
-
2
TXD
7
-
3
RXD
8
-
4
-
9
-
5
GND
-
-
▌ RS485 Input/Output Connect or (COM1_RS485)
Connector Type
Order
Name
1
D+
2
GND
3
GND
4
D-
▌ COM1 Mode S/W
RS485 Mode Sel.
Order ON
OFF
4
Term Res.
N.C.
3 -Bias
N.C.
2 +Bias
N.C.
COM1 Mode Sel.
Order ON
OFF
1 RS232C
RS485
CWA H/W Manual
CUWIN Series
COMFILE Technology,
Inc. www.comfiletech.com • page 11
▌ Boot Mode S/W
Connector
Type
Order
Setting
1
Boot
Mode
Selection
Normal Boot
Mode
ON
Download
Mode
OFF
2
Auto Run
Mode
Auto Run
Mode
ON
Development
Mode
OFF
3
Reserved
4
Reserved
5
Reserved
6
Reserved
*
Boot Device Selection S/W must be turned
ON
for normal booting.
▌ Power Input Connector
Power
DC_IN(+)
CWA H/W Manual
CUWIN Series
COMFILE Technology,
Inc. www.comfiletech.com • page 12
7. Warranty Policy
▌ Warranty Period
The products are warranted to be free of defects in materials and workmanship for
1 year from the date of purchase.
▌ Warranty Exclusions
The warranty does not cover abrasion and is considered void if the product is
opened by unauthorized person, damaged by abnormal use, heat or humidity, or used
against user manual.
▌ Request of Warranty Repair
If the products have defect(s) during the warranty period, the customer should
inquire at the manufacturer or dispatch the products with the description to the
address the manufacturer provides. If the request is appropriate, the manufacturers
repairs and dispatch it to the customer.
▌ Limitation of Liability
The manufacturer and distributor are not responsible for damages or breakdowns
caused by direct or indirect reasons, and the maximum duty of manufacturer and
distributor are limited to the total amount paid by the customer. The limitations or
exclusions of warranty have priority over any other warranty expressed explicitly,
implicatively, in writing, or orally.
