Before using your washing machine,please read this
manual carefully and keep it for future reference.
2.7 Cu.Ft. Washer and Dryer
Midea America C orp.
300 Kimba ll Drive, Parsipp an y,NJ ,U SA 07054
Custome r Service 1 -866-64 6- 4332
www.mide a.com
OWNER’S MANUAL
CLC27N3 AWW
Read Th is Manual
Insid e you w ill f ind m any helpfu l hin ts on h ow to u se
and mai nta in yo ur wa shing m ach ine p rop erly. Jus t
a littl e pre ven tat ive care on yo ur pa rt ca n sav e you
a great d eal o f tim e and m oney over th e lif e of yo ur
washi ng ma chi ne. You ’ll fin d man y ans wer s to
commo n pro ble ms in t he char t of tr oub les hoo ting
tips. I f you r evi ew th e chart of Trou ble sho oti ng Tips
first , you m ay no t nee d to call for se rvi ce.
Contents Safety And Precautions
Contents Safety and precautions
Safety And Precautions....................................................................................2
Safety and precautions................................................................................
Important safety instructions........................................................................
Grounding instructions................................................................................
Before operating this machine......................................................................
Attention shall be paid to protecting the machine............................................
Cautions during handling machine................................................................
Cautions when washing clothes....................................................................
Installation Requirements................................................................................
Installation Requirements............................................................................
8
Tools and parts...........................................................................................
Location requirements.................................................................................
Installation clearances.................................................................................
Electrical requirements................................................................................
Washer dimensions....................................................................................
Unpacking the washing machine..................................................................
Installation Instructions..................................................................................
Dispose the packing materials....................................................................
11
Remove transport bolts and foam................................................................
Select the location.....................................................................................
Connect inlet pipe......................................................................................
11
Install inlet pipe.........................................................................................
Drain system options..................................................................................
12
Level the washer........................................................................................
Electrical connection..................................................................................
Operating Instructions....................................................................................
Checklist and preparation before washing clothes........................................
View of control panel..................................................................................
Washing clothes at first time.......................................................................
Select the procedure.................................................................................
Table of washing procedures......................................................................
Care And Cleaning ........................................................................................
Troubleshooting Tips.....................................................................................
29
Remove The Problems...................................................................................
Appendix......................................................................................................
Technical Specifications................................................................................
2
3
6
6
6
6
7
8
8
9
9
9
10
10
11
11
11
12
13
13
14
14
18
22
23
24
25
30
31
32
This manual contains important information on the installation, use, and care of your
appliance. Please read this manual carefully before installation and operation of this
machine to prevent injury and property damage.
WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS
Warnings an d Important Safety I nst ructions in this man ual DO NOT cover all possible co ndi tions and
situations that ma y occur. It is your respo nsi bility to use common s ense, caution and ca re wh en installing,
maintaining and op erating your washe r.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
This indicates tha t hazards or unsafe pr act ices may cause
serious personal i njury or death.
WARNING
To reduce the risk of f ire , explosion, elect ric shock, or
personal injury wh en using your washer, t hes e basic safety
precautions SHOU LD be followed.
State of California Proposition 65 Warnings
The California Saf e Drinking Water a nd Toxi c Enf orcement Act requir es the Governor
of California to pub lish a list of substan ces k nown to the State of Cal ifo rnia to cause
cancer, birth defec ts, or other reprodu cti ve harm, and require s business to warn of
potential exposu re to such substance s.
WARNING
This product conta ins a chemical known t o the S tate of California t o cau se cancer,
birth defects, or ot her reproductive h arm . Thi s appliance can caus e low -level
exposure to some of th e substances liste d, in cluding benzene, f ormaldehyde, and
carbon monoxide.
P.01 P.02
Safety And Precautions
Safety And Precautions
Important safety instructions
WARNING - To reduce the risk of fire, electric shock, or injury to persons
when using your appliance, follow basic precautions, including the following:
- Read all instructions before using the appliance.
- Do not wash articles that have been previously cleaned in, washed in, soaked
WARNING
in,or spotted with gasoline, dry-cleaning solvents, or other flammable or
explosive substances, as they give off v apour s that co uld ign ite or explode.
- Do not add gasoline,dry-cleaning solvents, or other flammable or explosive
substances to the wash water. Thes e subst ances g ive off vapours that could
ignite or explode.
- Under certain conditions, hydrogen gas may be produced in a hot-water
system that has not been used for 2 weeks or more. HYDROGEN GAS IS
EXPLOSIVE.If the hot-water system has not been used for such a period,
before using a washing machine, turn on all hot-water faucets and let the
water flow from each for several minutes. This wi ll rele ase any accumulated
hydrogen gas. As the gas is flammable, do not smoke or use an open flame
during this time.
- Always unplug the washing machine from the power supply before attempting
any service. Disconnect the power cord by grasping the plug, not the cord.
- To reduce the risk of fire, clothes, cleaning rags, mop heads and the l ike whi ch
have traces of any flammable substance, such as vegetable oil, cooking oil,
petroleum based oils or distillates,waxes,fats,ect.,must not be placed in the
washing machine.These items may contain flammable substances which ,
even after washing, may smoke or catch fire.
- Never place items in the washer that have been dampened with gasoline or
any combustible or explosive substance. Do not wash or dry anything that
has been soaked in or spotted with any type of oil (including cooking oils).
Doing so can result in fire, explosion, or death.
- Do not allow children to play on or in the appliance. Close supervision of
children is necessary when the appliance is used near children.
- Pets and kids may climb into the machine. Check the machine before every
operation.
- Glass door or protector may be very hot during the operation. Keep kids and
pets far away from the machine during the operation.
- This machine is not intended for use by persons (includi ng kids ) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
machine by a person responsible for their safety.
- Kids should be supervised to ensure that they do not play with the machine.
- When children become old enough to operate the appliance, it is legal
responsibility of the parents or legal guardians to ensure that they are instructed
in safe practices by qualified persons.
SAVE THESE I NSTRU CTION S
Important safety instructions
- Do not machine wash fiberglass materials (such as curtains and window
coverings that use fiberglass materials.) Small particles may remain in the
washing machine and stick to fabrics in subsequent wash loads causing skin
irritation.
WARNING
- Before the appliance is removed from service or discarded, remove the door
and cut off the power cord.
- Do not reach into the appliance if the tub or agitator is moving.
- Do not install or store this appliance where it will be exposed to the weather.
- Do not tamper with controls.
- Do not repair or replace any part of the appliance or attempt any servicing
unless specifically recommended in the user-maintenance instructions or in
published user-repair instructions that you understand and have the skills to
carry out.
- Never stop a tumble dryer before the end of the program and spread out so that
the heat is dissipated.
- Pull out its plug from the power socket before cleaning or maintenance.
- Make sure that all pockets are emptied.
- Sharp and rigid items such as coin, brooch, nail, screw or stone etc. may
cause serious damages to this machine.
- Pull out its plug and cut off wa ter sup ply aft er the operation.
- Please check whether the water inside the drum has been drained before
opening its door. Please do not open the door if there is any water visible.
- Do not try to repair the machine by yourself. The mac hine ma y be dama ged or
more troublesome repair work may be caused and even dangerous operation
may take place if it is repaired by any inexperienced or unqualified staff.
- If the plug (power cord) is damaged, it shall be replaced by the manufacturer
or a service agent to avoid any danger.
- Take care that power voltage and frequency shall be identi cal to th ose of
washing machine.
- Do not use any socket with rated current less than that of washing machine.
Never pull out power plug with wet hand.
- To ensure your safety, power cord plug must be inserted into an earthed three pole socket. Check carefully and make sure that your socket is properly and
reliably earthed.
- This machine shall be repaired only by an authorized ser vice ce nter an d only
authentic accessories can be used.
- An appliance shall be clearly and permanently marked with a warning that the
appliance is intended for use only with fabrics that have been washed with
water as a cleaning agent.
- To reduce the risk of fire, do not dry articles containing foam rubbe r or simi larly
textured rubber like materials.
SAVE THESE I NSTRU CTION S
P.03
P.04
Safety And Precautions Safety And Precautions
Important safety instructions
- If connected to a circuit protected by fuses, use time-delay fuses with this
appliance.
- Do not dry articles that have been previously cleaned in, washed in, soaked in,
or spotted with gasoline, dry-cleaning solvents, or other flammable or explosive
WARNING
substances, as they give off vapours tha t could i gnite o r explo de.
- Do not use fabric softeners or products to eliminate static unless recommended
by the manufacturer of the fabric softener or product.
- Do not use heat to dry articles containing foam rubber or similarly textured
rubber-like materials. The interior of the applian ce shou ld be cle aned
periodically by qualified service personnel.
- Do not place items exposed to cooking oils in your dryer. Items contaminated
with cooking oils may contribute to a chemical reaction that could cause a
load to catch fire.
SAVE THESE I NSTRU CTION S
Grounding instructions
WARNING
Before operating this machine
WARNING
Attention shall be paid to protecting the machine
WARNING
Cautions during Handling Machine
WARNING
- This appliance must be grounded . In the event of a malfunct ion or br eakdo wn,
grounding will reduce the risk of electric shock by providing a path of least
resistance for the electric current. This applianc e is equi pped with a cord that has
an equipment
- Gurounding conductor and a grounding plug. The plug mu st be plu gged in to an
appropriate outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
WARNING-Improper connection of the equipment grounding conductor can result
in electric shock. Connect to individual branch Circuit. Check with a qualified
electrician or serviceman if you are in doubt as to whether the washer is properly
grounded.
DO NOT modify the plug provided wit h the app lianc e if it will not fit the outlet .
Please have a proper outlet installed by a proper outlet installed by a qualified
electrician.
- Packing materials may be d angerous to the kids. Please keep all packing
materials (plastic bag s, foams etc) far away from the kids.
- Washing machi ne shall not be installed in bath room or very wet rooms as well
as in the rooms with explosi ve or caustic gases.
- Make sure that the water and e lectrical devices must be connected by a qualified
technician in accordan ce with the manufacturer's instructions and local safet y
regulations.
- Before operating this ma chine, all packages and transport bolts must be removed.
Otherwise, the washing m achine may be seriously damaged while washing the
clothes.
- Before washing the cloth es at first time, the washing machine shall be operated
in cotton and hot water proc edures without the clothes inside .
- This washing machine is for indoor use o nly.
- Do not climb up and sit on top cover of the machine.
- Do not lean against machine door.
- Please do not close the door with excessive forces. If it is found difficult to close
the door, please check if the excessive clothes are put in or distributed well.
- Transport bolts shall be reinstalled to the machine by a specialized person.
- The accumulated water shall be drained o ut of the m achin e.
- Handle the machine carefully. Ne ver hol d each pr otrud ed part on the machine
while lifting.
Machine door can not be used as the handle during the conveyance.
P.05
P.06
Safety And Precautions
Installation Requirements
Cautions when washing clothes
WARNING
- Cold city water shall be used and hot water may be also connected according to
the local situations.
- Your washing machine is only for home use and is only designed for the textiles
suitable for machine washing.
- Flammable and explosive or toxic solvents are forbidden. Gasoline and alcohol
etc. shall not be used as detergents. Please only select the detergents suitable
for machine washing, especially for front loading .
- It is forbidden to wash carpets.
- Be careful of burning when washing machine drains hot washing water.
- Never refill the water by hand during washing.
- After the program is completed, please open the door after the bell or
disconnect the power supply to the machine.
- Always follow the fabric care instructions recommended by the clothing
manufacturer.
- Do not use the washing machine if it has a worn power cord or loose plug.
Contact an authorized service agent.
- Do not operate the washing machine if any guards, panels and /or fasteners
except transport fixing bolts have been removed. Check the fill hose
connections on a regular basis to ensure that they are tight and not leaking.
- Do not operate the washing machine if parts are missing or broken.
- Do not touch the door if washing at high temperatures.
Note:
- The Important Safeguards and Warnings indicated in this manual do not cover
all possible conditions which may occur. Common sense, caution and care
must be exercised when installing, maintaining or operating the washing
machine.
- Always contact your dealer, distribute, service agent or the manufacturer
about any problems or conditions that you do not understand.
Installation requirements
WARNING
1.This machine must be earthed properly. If there is any sho rt circ uit, ea rthin g can
reduce the danger of electrical shock.
This machine is equipped with power cord , which includes plug, earthing wire at
earthing terminal.
2.Washing machine shall be operated in a circuit separate from other electrical
appliances. Otherwise, power protector may be tripped or fuse may be burned
out.
WARNING – Risk of Fire
Clothes d ry er installation must be performed by a qualified installer.
Install t he clothes dryer ac co rd ing to the ma nu fa ct urer ’s instructions and loc al
codes.
Otherwise, it will ob st ruct clothes dryer airflow and increase the risk of fire.
To reduce the risk of s ev ere injury or d ea th , follow all in st al la tion instruction s.
Save th es e instructions.
Failure to comply with these warnings could result in serious
personal injuries. Note: Environmental Protection
- If you plan to dispose this machine, please comply with the local waste disposal
regulations. Cut off the p ower co rd so tha t it will not be put into reuse.
Remove the door so that kids and animals will not be trapped in the machine.
- Do not use excessive detergents.
- Decontaminant and bleacher can be used to pre-treat the stains on the clothes
only when very necessary.
Tools and parts
Gather the required tools and parts before starting installation. The par ts in the right supplied are in
the washer drum.
1/4 nut driver 3/8 socket with ratchet
″ ″
3/8″ open end wrench
Adjustable wrench or 7/16″ socket with ratchet
Adjustable wrench or 9/16″ open-end wrench
Channel-l ock adj ustab le pliers
Carpenter’s level
-
Water Hoses(2)
Transport Ho le Pl ug
P.07
P.08
Installation Requirements
Installation Requirements
Location requirements
Selecting the proper location for your washer improves performance and minimizes noise
and possible washer “walk.”Your washer can be installed under a custom counter, or in a
basement, laundry room, closet, or recessed area. See “Drain System.”Companion
appliance location requirements should also be considered. Proper installation is your
responsibility.
You will need
1. A water heater set to deliver 111°F (44°C) -129°F(54°C) water to the washer.
2. A grounded electrical outlet located within 6 ft.( 1.8 m) of where the power cord is
attached to the back of the washer. See“Electrical Requirements.”
3. Hot and cold water faucets located within 4 ft.(1.2 m) of the hot and cold water fill
valves, and water pressure of 20-100 psi (137.9-689.6 kPa).
4. A level floor with a maximum slope of 1" (25 mm)under entire washer. Installing the washer
on soft floor surfaces, such as carpets or surfaces with foam backing is not recommended.
5. A sturdy and solid floor to support the washer with a total weight (water and load) of 200lbs.
6. Do not operate your washer in temperatures below 32°F (0°C). Some water can
remain in the washer and can cause damage in low temperatures.
Installation clearances
1. The location must be large enoug h to allo w the washer door to be fully opened.°
2. Additional spacing should be considered for ease of installation and servicing. The door
opens more than 90 and it is nor reversible.
3. Additional clearances might be required for wall, door, and floor moldings.
4. Additional spacing of 25mm (0.98") on all sides of the washer is recommended to reduce noise
transfer.
5. Companion appliance spacing should also be considered.
Electrical requirements
Electrical requirements
1.A 120V~.60Hz, AC only,15-or 20amp,fused electrical supply is required. A time-delay fuse or
circuit serving only this appliance be provided .
2.This washer is equipped with a power supply cord having a 3 prong grounding plug.
3.To minimize possible shock hazard ,the cord must be plugged into a mating, 3 prong,
grounding type outlet, grounded in accordance with local codes and ordinances. If a mating
outlet is not available ,it is the personal responsibility and obligation of the customer to have
the properly grounded outlet installed by a qualified electrician.
4.If codes permit and a separate ground wire is used, it is recommended that a qualified
electrician determine that the ground path is adequate.
5.Do not ground to a gas pipe .
6.Check with a qualified electrician if you are not sure the washer is properly grounded.
7.Do not have a fuse in the neutral or ground circuit.
Washer dimensions
1
1
/2
2
4
(1080 mm)
"
23
(595 mm)
/2
"
(595 mm)
1
/2
"
33
(850mm)
1
/2
"
23
WARNING
Electrical Shock Harzard
Connect to grounde d 3 prong outlet with an i ndi vidual 15 or 20
amp branch circuit p rotected by a 15 or 20 amp c irc uit breaker.
Connect to individ ual branch circuit .
Do not remove ground p rong.
Do not use an adapter.
Do not use an extensio n cord.
Failure to follow th ese instructions c an re sult in electrical
shock, fire, or deat h.
P.09
The dimensions shown are for the recommended spacing.
2
" (50 mm)
1
/2
" min.
33
(850 mm)
1
/2
"
23
1
(25 mm)
Unpacking the washing machine
"
( 595 mm)
1
"
(25 mm)
Unpack your washing machine and check if there is any damage during the transportation.
Also make sure that all the items (water hoses and transport hole plug) in the attached bag are received.
If there is any damage to the washing machine during the transportation, or any item is
missing, please contact the local dealer immediately.
P.10
Installation Instructions
Installation Instructions
Dispose the packing materials
The packing materials of this machine may be dangerous to kids. Please dispose them
properly and avoid easy access by kids or pets. Please dispose the related packing materials
according to the relevant local regulations.
Remove transport bolts and foam
Before using this washing machine, transport bolts
must be removed from the backside of
this machine. Please take the following steps to
remove the bolts:
1.Loosen all bolts with 7/16″ socket to remove bolt 13mm.
2.Cover the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Make sure the small triangle foam is removed with the
bottom one together. If not, lay the uni t down with side
surface, then remove the small foam from the bottom of
the unit manually.
Select the location
Install inlet pipe
1.Connect the elbow to tap and fasten it
clockwise.
2.Connect the other end of inlet pipe to the inlet
valve at the backside of washing machine and
fasten the pipe tightly clockwise.
Note: Please use a standard tap. If there is any leakage after connection, repeat the steps
to connect the inlet pipe.
Drain system options
Standpipe drain sy stem -wall or floor ( views A &B)
The s tandpipe drain req uires a minimum diam ete r
sta ndpipe of 2" (5 0 mm) .
A
Capacity can be no les s than 17 gal.(64 L) per minute.
The top of t he standpipe must be a t lea st 60cm(23.6") hig h and
no higher than 100cm ( 39.4") from the bott om of the washer.
Min 60(23.6")
Max 100(39.4")
B
Before installing the washing machine, the location characterized as follows shall be
selected:
- Rigid, dry, and level surface (if not level , pleas e make it l evel wi th reference to the
following figure “Adjust Leg”)
- Sufficient ventilati on
- Room temperature is above 0℃
- Keep far away from the heat sources such as coal or gas.
Make sure that the washing machine is not on the power cord.
-
Do not install the washing machine on the carpet floor.
-
Connect inlet pipe
Connect the inlet pipe as indicated in the figure.
H
For the model which has hot valve, please connect
the hot vale to hot water tap.
P.11
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal.(76 L)
capacity.The top of the laundry tub must be
at least 60cm(23.6") above the foor.
Floor drain system (view D).The flo or dr ain system require s
C
a siphon break that may be purchased separate ly.
The siphon break mus t be a minimum of 28"(71 0 mm) from the
bottom of the washer .Additional hos es might be needed.
28
" min.
(710 mm)
P.12
C
Max. 100cm
Min. 60cm
D
Installation Instructions
Operating Instructions
Level the washer
1.When positioning the washing machine, please
first check if the legs are closely attached to the
cabinet. If not, please turn them to their original
positions with hand or spanner and tighten the
nuts with spanner.
2.After positioning the washing machine, press
four corners on top cover of washing machine
in sequence. If the washing machine is not
stable when being pressed, this leg shall be adjusted.
3.Ensure the positioning status of washing machine.
Loosen the lock nut with spanner and turn the leg
with hand until it closely contacts with the floor. Press
the leg with one hand and fasten the nut closely to the
cabinet with the other hand.
4.After being locked properly, press fou r corne rs agai n to
make sure that they has been adjusted properly. If it is
still unstable, repeat Steps 2 and 3
5.Put a solid cylinder (e.g. pop cans) oppositely on the
top cover of the washing machine from in the left, right,
front and back directions. If the cylinder keeps stable, the washing machine is
positioned level. If it rolls, the washing machine is not leveled.The rolling direction is
the direction of lower ground surface.Then the two legs in this direction shall be raised at the
same time until the washing machine is level.Steps 1~3 are repeated to make the bottom legs
closely against the ground and the nuts shall be locked tightly. .
Electrical connection
- As the maximum current through the unit is 12A when you are using its heating function,
please make sure the power supply system (current, power voltage and wire) at your
home can meet the normal loading requirements of the electrical appliances.
- Please connect the power to a socket which is correctly installed and properly grounded.
- Make sure power and voltage at install location is same to that in the machine's rating label.
- Power plug must match the socket and chassis must be properly and effectively grounded.
- Do not use multi-purpose plug or socket as extension cord.
- Do not connect and pull out plug with wet hand.
- When connecting and pulling out the plug, hold the plug tightly and then pull it out. Do
not pull power cord forcibly.
- If power cord is damaged or has any sign of being broken, a new power cord must be
selected or purchased from its manufacturer or service center for replacement.
Operating instructions
WARNING – To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
WARNING
Checklist and preparation before washing clothes
Please read Operating Instructions carefully to avoid the troubles of washing machine and
garment damages .
Check if the first-washed clothes will bed discolored.
After a white towel touched with liquid detergent is used to wash the invisible corners of the
clothes, check if the white towel is stained with
clothes' original color.
As for the scarves and those clothes that easily
get discolored among imported clothes, please
wash them separately before washing.
As for the stains on sleeves, collars and pockets,
use the liquid detergent and wash it with brush
gently. Finally put them into the washing m achin e
to achieve ideal washing effects.
As for temperature-sensitive clothes, they shall
be washed as required in the labels. Otherwise,
it may cause color change or distortion.
Keep in Mind:
Never leave clothes to be washed in washing machine for a long period of time.
Otherwise it may get moldy and cause spots. There fore, p lease wash the clothes in time.
The clothes also may get color changed or distorted if they are not washed according to
the stated washing temperature.
Clothes that can not be washed by washing machine
The clothes that may get distorted if being immersed in water:
Tie s, wais tcoat s, western-style clothes, outer garments etc. may have obvious shrinkage
if being immersed in water; the discolored clothes such as blended spinning clothes of
artificial fiber etc.
operating this appliance.
P.13
P.14
Operating Instructions
Operating Instructions
Checklist and preparation before washing clothes
Embossed clothes, resin clothes etc. may get distorted when being
immersed in water. Among cotton and wool materials, the clothes that get easily distorted
are wrinkle-style silk, fur products and fur decorations;
Clothes with decoration, long dress and traditional clothes etc are the products to get
decolorized easily.
Please do not wash the clothes without material labels and washing requirements.
Never wash the clothes stained with the chemicals such as gasoline, petroleum, benzene,
paint thinner or alcohol.
Please pay attention with regard to detergents
“Low bubble” detergent or washing powder or washing powder special for drum washing
machine shall be selected according to fiber types (cotton, synthetic fiber, soft products and
wool products), colors, washing temperatures, soil level and types. Otherwise,
excessive bubbles may be generated and overflowed out of the drawer so that accidents
may take place.
Bleach belongs to alkali type and can damage clothes, so it is suggested to use follow
manufacturer's recommendations.
Powder detergents can easily leave the residues in the clothes that can generate a bad smell,
and needs to be sufficiently rinsed.
Detergent can not easily get dissolved completely if there is too much detergent or water
temperature is rather low. It can remain in clothes, pipes and washing machines to
pollute the clothes.
Washing shall follow the weight of clothes, soil level, local water hardness as well as
the recommendations from the detergent's manufacturer. Please consult the water
company if you are not clear of water hardness.
Note:
Keep detergents an d additives in safe an d dry p laces out of reach to ki ds.
Please take out contents of the pockets.
Please check the pockets of the clothes to be washed, empty the rigid items such as
decorations and coins, otherwise washing machine may be damaged or have abnormal
troubles that may cause damages to the machine.
For the clothes to be washed, they are classified according to the following
characteristics:
The symbol types of care labels: the clothes to be washed are classified into cotton, blended
fiber, synthetic fiber, silk, wool and artificial fiber.
Color: white and other colors shall be identified. All new colorful articles shall be washed
in a separate load.
Checklist and preparation before washing clothes
Size: the articles of diff erent s izes ar e washed together to increase the washing effects.
Sensitivity: soft articles shall be washed separately. As for new pure wool textiles, curtains
and silks, delicate cycle shall be selected. Check the labels in all washing articles.
The clothes shall be sorted before being put into washing machine. As for the curtains with
hooks, the hooks shall be removed before being washed.
The decorations on the clothes may damage the washing machine. As for the clothes with
buttons or embroideries, they shall be turned over before being washed.
Clean up fasteners:
Zips shall be zipped close and buttons or hooks shall be fixed. The l oose ba nd or rib bon shall
be bound together.
It is suggested to put bras into the pillow slip
with zip or buttons sealed to prevent the steel
wire from popping out of bras into the drum and
damaging the machine.
WARNING
Delicate textiles such as laced curtains,
straightjackets, small articles (tight socks,
handkerchiefs, ties etc.) shall be put into string
bag for washing.
When washing a single big and heavy dress such
as jeans, wadded jackets, weight jackets etc.,
it may easily cause out of balance and give
alarm . Therefore it is suggested to add one or
washed together so that draining can be done
smoothly.
Clean away dusts, stains and pet hairs from the clothes.
The clothes may be damaged and disturb washing effects d uring the friction between dusts,
stains and clothes.
To protect baby skin
Baby articles (baby clothes and towels) including napkins shall be washed separately.
Rinsing times shall be increased to ensure the thorough rinsing and cleaning without the
detergent residues.
It is suggested that the parts that are easily stained such as white socks, collars and
sleeves etc. shall be hand washed before being put into washing machine to achieve
ideal washing effects.
Please use powder or liquid detergents. The res idues o f the soap could remain in the gaps of
the clothes if soap is used.
P.15
P.16
Operating Instructions Operating Instructions
Checklist and preparation before washing clothes
View of control panel
The clothes which easily get pill shall be turned over for washing
The clothes which easily get pill shall be washed separately; otherwise the other
articles can be stained with dust and thread residue etc. Preferably, black clothes and cotton
clothes shall be washed separately because they can easily get stained with the
of other colors when being washed together.
Please check before washing.
Washing machine shall not wash water-proof materials (ski suits, outside napkin
pads, curtains).
As for the fiber products that water can not get soaked easily into such as water-proof
cushions, and clothes, it is better not to wash. Otherwise there will be water bursting out
or abnormal vibration to cause danger while rinsing and draining so that the clothes also
may be damaged. (Such as outside napkin pads, raincoats, umbrella, ski suits, car covers,
sleeping sacks etc.)
Cautions during Draining
Draining of water-proof clothes and fiber products:
In the normal washing and draining status, moistures of water-proof clothes and fiber products
may not be drained while water is gathered in one direction so that the eccentricity of washing
machine is too great and vibration or moving is caused.
thread residue
On/Off
Press once to turn the washing
machine on, press again to turn
the washing machine off.
Start/Pause
Press the button to start or
pause the wash cycle
Function setting
P.17
Display
Spin
Rinse
Wash
Child Lock
Air Fluff
Less Dry
More Dry Normal Dry
Time Dry
Steam
Express
P.18
Press the button repeatedly to set the water temp.
washing time,rinse number,spin speed and so on.
Programme
For the convenience of users to washing
clothes with the different programme.
Notes: 1.The Control panel li ne chart is fo r reference only, Please refer to real pr oduct as standard.
2.The Control panel could be ch anged with out written notice. Please vi sit the webs ite of Washing Machine or cal l up the service line for
consultation.
Operating Instructions
Operating Instructions
List of programs / wash cycles
Normal
-
Hard-wea ring texti les, heat-resistant textiles made of cotton or linen.
- Heavy Duty
This progr am is intended for washing heavy clothing like towels.
- Bulky
This progr am is intended for washing large clothing .
- Sports Wear
Washin g the activewear.
- Spin Only
Extra spin w ith adjust able spin speed.
- Rinse & Spin
Extra rins e with spin.
- Washer C lean
This progr am is specially set in this machine to clean the drum and tube. It applie s high
temperat ure sterilization to make the clothes washing more green. When th is procedu re is
performe d, the clothes or other washing cannot be added. When proper amount of
chlorine b leaching agent is put in, the cleaning effect will be improved. The custome r can use
this proce dure regularly to clean as needed.
- Quick Wa sh
Extra shor t program approx, suit able for lig htly soile d washing as
a small amou nts of laundry.
- Delicate s
For delica te, washab le textile s, e.g. made of silk, satin, synthetic
fibres or bl ended fabrics.
- Sanitary
Give full pl ay to its active enzyme washing powder, with Ex. hot wash and Ex. heavy soil level,
suitable f or difficult to wash the clothes.
- Woo l
You can sel ect this procedure to wash wool textiles labeled with “Machine Wash”.
Please sel ect the proper washing temperature according to the label on the articles to be
washed. Fu rthermore, the proper detergent shall be selected for wool textiles.
- Perm Press
Moderate s trength of washing. Th is functio n can be used to r educe the wr inkles of cl othes.
- Baby Wear
Washin g the baby’s clothes, it can make the baby's wear cleaner and ma ke the rinse p erforman ce better
to protect t he baby skin.
- Dry Only
Select it to d ry clothes, the temperature is different .The drying time accordin g to the load.
- My Cycle
Press Temp. 3sec. to set My Cycle to memory the program.
- Wash&D ry
Select it to w ash and dry cl othes. For hard-wearing textiles, heat-resistant textiles made of cot ton or linen .
View of control panel
The Special function
- Child Lock
To avoid children operating the unit, the child lock feature can be turned on. To turn on t he chil d
lock feature: press the soil level and dry buttons together for three seconds. The
except On/Off button can not work , at this s tate, t he mach ine power off when press the key on/off.
Press Function and Select together 3 s
econds during the running procedure, the buzzer
will beep, Start/Pause button as well as the rotary switch are locked. Press the two buttons
for 3 seconds together and buzzer will beep to release to locking. But cut off the power
supply, the kid’s protection is also release to locking. The kid’s protection will not b e
cancelled after all procedures are completed.
- Delay
Delay function can be set with this button, the delaying time is 0-24H.
Set the delay function:
1.Select a program;
2.Press the Delay button to choose the time;
3.Press Start/Pause to commence the Delay operation.
Cancel the Delay function :
Press the Delay button until the display will be 0H . It should be pressed before starting the
program. If the program already started, should press the On/Off button.
Notes: If there is any break in the power supply while the machine is operating, a special
memory stores the selected program and when the power is restarted, press the
Start/Pause button the left time is continues.
- Reload
This operation can be executed during the washing procedure. When the drum of the
washer (dryer) machine is still rolling and there is large amount of water with high temperature
in the drum. The state is unsafe and the door cannot be opened f orcef ully. To press
"Start/Pause"for 3 sec. to reload, and start the clothes adding in the midway function .
Please follow the steps as bellow:
1.Wait until the drum stops rotation.
2.The door lock is unlocked.
3.Close the door when the clothes needs are loaded and repress the"Start/Pause"button.
Notes: Don't use the Reload function when the water surface over the edge of the inner tub
and the temperature is higher.
other buttons
P.19
P.20
Operating Instructions
Operating Instructions
View of control panel
- Express
Press Steam 3 seconds to select Express function.
This option reduces the overall washer cycle time by optimizing the wash, rinse and spin actions
and/or gently raising the wash temperature to get clothes cleaned faster. Option is available on
Normal, Perm press, Heavy Duty, Bu lky, Sports wear cycles. Total wash time will vary based on cycle
chosen and options selected.
- Dry
Press the Dry button continuously to choose the dry level: Time Dry 30,60,9 0min /M ore Dry /
Normal Dry/ Less Dry/ Air Fluff.
Time Dry 30,60,90min : Drying your laundry and finish within given time. (30/60/9 0 minutes)
More Dry : This level leaves the cloths comp letel y dry and r eady to u se.
Normal Dry :This level leaves the cloths ready to fold and store in the wardrobe.
Less Dry : This level leaves the cloths with some humidity. Perfect for ironing.
Air Fluff : To prevent wrin kles. D rum will rotate every half hour and stop half hour, shaking up
the clothes to avoid laundry left in washing machine. Th e fan will also circulate air
through the washer to prevent odors and keep clothes scent fresh. This function lasts
for up to 8 hours.
Note!
Drying hints
•
- Thoroughly spin you laundry before drying.
- To ensure proper drying, please sort your laundry according to the fabric
type and drying temperature.
- Synthstic should be set the proper drying time.
• Clothes not suitable for drying
- Particularly delicate items such as synthetic curtains, woolen and silk,
clothes with metal inserts, nylon stockings, bulky clothes, such as
jackets, bedcovers, quilts, sleeping bags and duvets must not be dried.
- Clothes padded with foam-rubber or materials similar to foam-rubber
must not be machine dried.
- Fabrics containing residues of setting lotions or hair sprays, nail
solvents or similar solutions must not be machine dried in order to avoid
the formation of harmful vapours.
View of control panel
- My Cycle
To save a favorite cycle, set the desired setting for wash cycle, soil level, spin speed and
wash temp settings and hold down the My Cycle button for 3 seconds, A beep will sound t o
indicate the cycle has been saved.
To use your custom cycle, press the My Cycle button before washing a load.
To change the saved cycle, set the desired setting and hold down the My cycle button for 3
seconds.
NOTE:
When using My cycle, wash options cannot be modified after the cycle has been started.
NOTE:
If you change wash options with My Cycle before starting the cycle, the My Cycle light will
turn off and you will be retur ned to th e base cy cle.
-Steam
SteamCare is the function added before main wash, which will generate warm
steam to to sterilize and give performance especially for cold wash.
-Soil level
It is suitable for different level of soil ( from light to heavy).
The default level is , choose the soil level according to needs.
-Temp.
When needed, the washing temperature can be adjusted by pressing the temperature
button in the following steps: Tap Cold - Cold - Warm - Hot - Ex. hot.
-Spin
Press the button to change the spinspeed.
different for the program
Ex. Ex.
Washing clothes at first time
Before washing clothes at first time, the washing machine shall be operated in
one round of the whole procedures without clothes in as follows:
1.Connect power source and water.
2.Put a little detergent into the box and close it.
3.Press the button “On/off”.
4.Press the button “Start/Pause”.
P.21
P.22
Tap Cold
Cold water with no war m wat er added.
Cold
Brightly colored , very lightly soile d ite ms.
Warm
Normal soil level ar ticles (includin g syn thetic and wool)
Hot
Moderate soil leve l, colorful flax, co tto n and synthetic arti cles with certain
discolored degre e (for example: shir ts, n ight pajamas; slig ht soil level, pure
white flax (for exam ple: underwear)
Ex.hot
High soil level, pur e white cotton or flax ( for e xample: coffee table cloth s,
canteen table clot hs, towels, bed shee ts)
Operating Instructions
Washing clothes at first time
The drawer is separated as follows:
I/ : or washing powder,
II Det ergen t softener
bleaching or decontaminating products.
: washing additive, such as fabric softener .
Put detergent into washing machine.
1.Pull out the drawer.
2.Fill detergent into Case II.
I/
Ⅱ
3.Fill softener into Case (when necessary).
Notes:
- As for the powder deter gent or ropy deterge nt or a dditive, before th ey are poured into the d ete rgent box,
it is suggested to use s ome water for diluti on to p revent the inlet of de tergent box from bei ng bl ocked
and overflowing wh ile filling water.
- Please choose suit able type of deterge nt fo r the various washin g temperature to get t he be st washing
eff ect with less water an d ene rgy consumption.
Ⅰ
Start up washing machine
Connect the power. Check if water pipes are connected properly. Open the tap completely.
Put in the clothes to be washed and fill in the detergent and tackifier. Then press the button
“Power”, Select the proper procedures and functions and press the button “Start/Pause”.
Select the procedure
The proper washing procedures shall be selected according to the types, quantities, and
soil level of the clothes to be washed in combination with the following washing
temperature table.
Operating Instructions
Table of washing procedures
Programme
My Cycle
Normal
Perm Press
Heavy Duty
Bulky
Sports Wear
Spin Only
Rinse & Spin
Washer Clean
Wash&Dry
Dry Only
Sanitary
Baby Wear
Wool
Delicates
Quick Wash
Washing/
Drying (kg)Load
12.0
_
12.0
6.0
12.0
6.0
6.0
12.0
12.0
_
6.0
6.0
6.0
12.0
2.0
2.5
2.0
Temp.(°C)
Default
_
Warm
Warm
Hot
Cold
Warm
Ex. hot
Warm
Ex. hot
Hot
Cold
Cold
Tap cold
Default
Time(H)
12.0
1400RPM
_
1:04
0:57
1:40
1:23
0:57
0:13
0:23
1:28
5:43
4:19
2:18
1:37
1:01
0:58
0:36
Steam
--
○
○
○
○
○
--
--
--
○
--
○
○
--
--
○
Express
--
○
○
○
○
○
--
--
--
--
--
--
--
--
--
--
Delay
○○
○
○○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
Soil
Level
Normal
Normal
Ex.heavy
Normal
Ex.heavy
Normal
Ex.heavy
Normal
Normal
Normal
Ex.light
Spin
Speed
Med
High
High
High
Ex.light
High
High
Ex.light
Ex.light
High
High
Med
Med
High
P.23
Mean s must ○ Me ans opt ional
Energy test program: Normal.
“Normal ” is the standard washing programs to which the information in the label and the fiche relates, and they
are suitable to clean normally soiled cotton laundry and that they are the most efficient program in terms of
combined energy and water consumptions for washing that type of cotton laundry, that the actual water temperature
may differ from the declared cycle temperature.
Note!
•
The parameters in this table are only for user's reference. The actual parameters
maybe different with the parameters in above mentioned table.
•
The program with can be choose dry function.
P.24
Care And Cleaning Care And Cleaning
Care and cleaning
Before performing maintenance on the unit, disconnect power and turn off the water.
- Solvents are forbidden to avoid that the washing machine is damaged, and
toxic gases are generated or exploded.
- Do not spray the machine with water.
WARNING
- It is forbidden that the detergents containing PCMX are used to clean the
washing machine.
- Service Personnel- Do not contact the following parts while the appliance is
energized incase of electric shock: Electrical value, Drain Pump, Door Lock,
Dry Heater (Combo), Fan Motor (Combo).
Cleaning and Maintenance of Washing Machine Cabinet
Proper maintenance on the washing machine can extend the life of the unit. The surface can
be cleaned with diluted non-abrasive neutral detergents when necessary. If there is any
water overflow, use the wet cloth to wipe it off immediately.
Notes: formic acid and its diluted solvents or equivalent are forbidden.
Clean Internal Drum
The rusts left inside the drum by the metal articles shall be removed immediately with
chlorine-free detergents.
Never use steel wool.
Dispose a Frozen Washing Machine
When the temperature drops below zero and your washing machine gets frozen, you may:
1.Disconnect the power supply for the washing machine.
2.Wash the tap with warm water to loosen inlet pipe.
3.Take down inlet pipe and immerse it in warm water.
4.Pour warm water into washing drum and wait for 10 minutes.
5.Reconnect inlet pipe to the tap and check whether inlet and outlet are working normally.
Notes: when the washing machine is reused, make sure the ambient temperature is above 0 ℃
Winterizing the unit
If your washing machine is located in the room where it can get frozen easily, please drain
the remaining water inside drain pipe and inlet pipe thoroughly.
Remove the remaining water in inlet pipe:
1.Close the tap.
2.Screw off the inle t pipe fr om tap an d put its e nd into the container.
3.Start up any procedure except single Wash or Drain
procedure. Water will be drained out of inlet pipe if any
for about 40 seconds.
4.Reconnect the inlet pipe to tap.
Care and cleaning
Remove the remaining water in drain pump
To avoid burnin g, it shall be done afte r the h ot water
WARNING
inside the machine c ools down.
Clean detergent box and grooves
Clean detergent drawer and grooves
1.Press down the arrow location on softener cover
inside the drawer.
2.Lift the clip up and take out softener cover and wash
all grooves with water.
3.Restore the softener cover and push the drawer into
position.
Clean inlet filter
Inlet filter shall must be cleaned if there is not any or
insufficient water in when the tap is opened.
Clean the tap filter:
1.Close the tap.
2.Select any procedure except “Wash” or “Drain”
procedure.
3.Press the button “Start/Pause” and keep the
procedure running for about 40 seconds.
4.Remove the inlet pipe from the tap.
5.Use water to wash the filter.
6.Reconnect the inlet pipe.
Washing the filter in washing machine:
1.Screw off the inlet pipe from the backside of the
machine.
2.Pull out the filter with long nose pliers and reinstall
it back after being washed.
3.Reconnect the inlet pipe.
4.Open the tap and make sure there is no water leakage.
5.Close the tap.
P.25
P.26
Care And Cleaning
Care And Cleaning
Care and cleaning
Pull out the power plug to avoid electrical shock before washing.
WARNING
Remove foreign matters
Drain Pump Filter:
Drain pump f ilter can filter the yarns and small foreign matters from the washings.
Clean the fi lter periodically to ensure the normal operation of washing machine.
WARNING
The Service_panel proceed as follows:
Open the cover filter use a flat
blade screwdrive
After using the washing machine, pull out the power cord and close the door
tightly to avoid pinching the kids.
According to the soil level within the cycles and the frequency of the cycles, you have
to inspect and clean the filter regularly.
The pump should be inspected if the machine does not empty and/or spin;
The machine makes an unusual noise during draining due to objects such as safety
pins, coins etc. blocking the pump.
1
Rotate 90° and pull out
the emergency drain hose,
and take off the hose cap
2
Emergency
drain hose
After water runs out,reset
the drain hose
Care and cleaning
Emergency Door Release
In case of power failure or other circumstances and door cannot be opened. If it is
necessary to open the door under this circumstances, please pull down the pull cord
inside emergency door and restore the pull cord after opening the door.
Emergency door pull cord
3
Warning!
The machine is not allowed to use the emergency switch pull cord during washing. If need to run machine
urgently, it is recommended to open door after water is cooled, to avoid getting burn caused by high
temperature residual water outflow from the machine tub.
1.Open filter door
2.Emergency pull cord
4
Open the filter by turning
to the counter clockwise
Warning!
When the appliance is in use and depending on the programme selected there can be hot water
pump. Never remove the pump cover during a wash cycle, always wait until the appliance has finished
the cycle, and is empty. When replacing the cover, ensure it is securely retight end so.
Remove extraneous matter
P.27
5
Close the lower cover cap
in the
6
P.28
Troubleshooting Tips
Remove The Problems
Troubleshooting tips
Troubles
Washing machine
cannot start up
Door cannot be
opened
Heating fault
Water leakage
Water is
overflowed from
the bottom of the
machine
Indicator or
display does
not light.
Detergent
residues in the
box
Washing effects
are not good
Abnormal noise
Great vibration
Machine's safety protection
design is working.
Heating element defective .
The connection between inle t
pipe or outlet hose and tap or
washing machine is not tight.
Drain pipe in the room is blocked .
The inlet pipe is not connected
firmly.
Outlet hose has water leakage.
Power is disconn ect ed.
PC board has probl ems .
Harness has connection
problem.
Washing powder is dampened
and agglomerated.
The clothes are too dirty.
Insuff ici ent d ete rge nt qu ant ity.
Reason
Solution
Check if the door is closed tight ly.
Check if power plu g is in ser ted w ell .
Check if water sup ply t ap is o pen ed.
Check if button “On/Off” i s pre sse d.
Check if button “Star t/P aus e” is p res sed .
Disconnect the p owe r.
Can normally wash the clothes .
Only cannot wash with h eat ing .
Shall contact th e ser vic e cen ter p rom ptl y.
Check and fasten wate r pip es.
Clean up outlet hose and ask a
specialized person to repair it wh en
necessary.
Fix the inlet pipe.
Replace the drain hose.
Check if the power i s shu t dow n and
power plug is connected corre ctl y.
If not, please call up service line.
Clean and wipe the b ox.
Use liquid detergents or the de ter gen ts
special for drum.
Select a proper pr oce dur e.
Add the proper detergent quan tit y
according to the instructions in
detergent package.
Check if the transportation b olt s has b een
removed.If cabinet is installed on the sol id
and level floor.
Check if there are any barrette s or me tal
articles inside.
Check if the legs in the wa shi ng ma chi ne
are adjusted level.
Remove the problems
The start of the appliance does not work or it stops during operation.
First try to find a solution to the problem, If not, contact the service centre.
Description
Washing machine
cannot start up
Door can’t be
opened
Water leakage
Detergent residues
in the box
Indicator or display
does not light
Abnormal noise
Description
Reason
Door is not closed properly
Washer's safety
protection design is working
The connection between inlet
pipe or outlet hose is not tight
Detergent is dampened
or agglomerated
Disconnect the power
PC board or harness has
connection problem
Reason
Door is not closed properly
Water injecting
problem while
washing
Overtime water draining
Water overflow
Others
Solution
Restart after the door is closed
Check if the clothes is stuck
Disconnect the power, restart
the product
Check and fasten water pipes
Clean up outlet hose
Clean and wipe the detergent
box
Check if the power is shut
down and the power plug is
connected correctly
Check if the fixing (bolts) have
been removed
it’s installed on a solid
Check
and level floor
Solution
Restart after the door is closed
Check if the clothes is stuck
Check if the water pressure is
too low
Straighten the water pipe
Check if the inlet valve filter is blocked
Check if the drain hose is blocked
Restart the washer
Please try again first, call up
service line if there are still
troubles
Note!
• or the display
After the check, activate the appliance. If the problem occurs
shows other alarm codes
again, contact the service.
P.29
P.30
Appendix
Technical Specifications
Appendix
Care Lable
Graphic Symbol
CI
WARNING
Illustration
Hand Wash
Washing (inc ludin g Machi ne
Wash and Hand Wash)
Dry Clean
Warmly Dry Cl ean
Bleach
Tumble dry
Iron
Steam Iron
Med ium Tempe rature and
Max . Tempe ratur e 150 C
Line Dry
Graphic Symbol
CI
Illustration
No Machine Wa sh
Do not Wash
No Dry Clean
No Wr ing
No Bleach
Do not Tumble Dry
Do not Iron
Iron with Cloth
Dry after Was h
Line Dry in Shade
To avoid fire, electrical shock and other accidents, please remember the following
reminding:
- Only the voltage indicated in power label can be used. If you are not clear of
the voltage at home, please contact the local power bureau.
- When you are using the heating function, the maximum current through the
washin machine will reach 12A. Th erefo re, please make sure the power
supply units (current, voltage and cable) can meet the normal load
requirements for the machine.
- Protect the power cord properly. Power cord shall be fixed well so that it will
not trip the people or other things and be damaged. Special attention shall be
paid to the socket. It shall be plugged into the sockets easily and attention
shall be paid to the plug location.
- Do not make the wall-mounted socket overloaded or cable extended.
Overloading of the wiring may cause fire or electrical shock. Do not pull out
power plug with wet hand.
- To ensure your safety, power plug shall be inserted into an earthed three-pole
socket. Carefully check and ensure that your socket is properly and reliably
earthed.
Technical specifications
Model:CL C27N3AWW
Pow er Supp ly
Dim ensio n(W* D* H)
Net W eight
Washing Capa cit y
Rat ed Curr ent
Sta ndard Water Pres sure
120 V~ , 60Hz
595 *640*850( 23. 4*25.2*33. 5")
73k g (161I b)
12. 0kg (26 Ib)
9.5 A
0.0 5MPa~ 1MPa( 7.25psi~ 145 psi)
P.31
P.32
P.34P.33
P.35
Loading...
