TOASTER OVEN
INSTRUCTION MANUAL
CFO-BG12(SS)
DIRECTORY
SPECIFICATIONS .....................................................................................................................................
IMPORTANT SAFEGUARDS..................................................................................................................
BEFORE FIRST USE ...................................................................................................................................
CONTROL SETTINGS...............................................................................................................................
HOW TO USE .............................................................................................................................................
CARE AND CLEANING ...........................................................................................................................
DISPOSAL .....................................................................................................................................................
WARRANTY .................................................................................................................................................
EN-2
EN-3
EN-7
EN-8
EN-10
EN-12
EN-13
EN-14
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND
KEEP FOR FUTURE REFERENCE.
If you follow the instructions, your oven will provide you with many
years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY.
SPECIFICATIONS
EN-2
Content
Model
Rated Voltage
Power
Product Size
Package Size
Parameter
CFO-BG12(SS)
120V~ 60Hz
1100W
14.8x11.9x8.9 inch
17.0x14.0x11.6 inch
9.99 lbsGross Weight
IMPORTANT SAFEGUARDS
EN-3
When using electrical appliance, basic safety
precautions should always be followed, including the
followings:
• Read all instructions before using.
• To protect against any electrical hazards, DO NOT
place unit or cord in water or any other liquids.
• Do not touch any hot surfaces. Use oven mitts for
removing or touching any hot parts. Always placing
Toast Oven on heat protected surface.
• Unplug the unit from outlet when not use and before
cleaning. Always allowing to cool down before
attaching or removing any parts.
• The use of accessory attachments are not
recommended by the appliance manufacturer
may cause injuries.
• Always pulling the plug out from the wall and never
pull the cord. Remove the plug from the wall before
moving the appliance. Using both hands to move
the appliance.
• Do not let cord hang over edge of table, or touch
hot surface.
• Do not place the Toaster Oven near the heated
oven, a hot flame or electric burner.
• Do not use outdoors.
• If the electric circuit is overloaded with other
appliances, this appliance may not operate
properly. The Toaster Oven should be operated on
a separate electrical circuit from other operating
appliances.
•
EN-4
The temperature of accessible surfaces may be high
when the appliance is operating.
• If the supply cord is damaged, it must be replaced
by midea customer service center in order to
avoiding a hazard.
• Store only the accessories provided with this unit
inside the oven when not in use. Do not store other
materials.
A fire may occur if the appliance covered or touched
•
the flammable materials, including curtains,
draperies, walls, and so on, when in operation. Do
not put any items on the top of the appliance when
in operation.
Do not place any cardboards, papers or plastic items
•
inside the oven.
• All containers placed inside the oven must not be
airtighted. Also, they need to have enough room to
allow for expansion of fluids.
• Clean this appliance regularly because the grease
may cause a fire. Make sure that this appliance is
not placed near curtains, any drapery, or other
flammable materials.
• Do not clean with metal scouring pads. Pieces can
break off the pad and touch electrical parts
involving a risk of electric shock.
• In order to preventing accidental burns, must use
the handle and knobs to operate this appliance.
• The temperature of the door or outside surface
EN-5
may be high when the appliance operating.
• Oversize foods or metal utensils must not be
inserted in a toast oven as they may create a fire
or risk of electric shock.
• Do not cover crumb tray or any part of the oven
with metal foil. This will cause overheating of the
oven.
• Extreme caution should be exercised when using
containers constructed of other than metal or glass.
• This appliance is not intended for use by persons
including children with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they
do not play with the appliance.
• The appliance is not intended to be operated by
means of an external timer or separate remote control system.
• The surface of appliance shall be placed against a
wall.
SAVE THESE INSTURCTIONS
HOUSEHOLD USE ONLY
Caution : hot surface
SHORT CORD INSTRUCTION (DETA-
EN-6
CHABLE POWER-SUPPLY CORD)
a) A short power-supply cord (or detachable power-
supply cord ) should be used to reduce the risk
resulting from becoming entangled in or tripping
over a longer cord.
b) Longer detachable power-
extension cords are available
care is exercised in their use.
c) If a longer detachable power-supply cord or exten-
sion cord is used:
1) The marked electrical rating of the cord set or
extension cord should be
electrical rating of the appliance.
2) The cord should be arranged so that it will not
drape over the countertop
be pulled on by children or tripped over
unintentionally.
supply cords or
and may be used if
at least as great as the
or tabletop where it can
BEFORE FIRST USE
EN-7
1. Remove all accessories and shipping materials
packed inside the oven.
2. Wash the rack and pan in warm soapy water. Wipe
the inside of the oven with a damp cloth or sponge.
Blot dry with paper towels to be sure the unit is dry
before using.
3. Place oven on a flat counter or other stable surface
DO NOT OPERATE ON THE SAME CIRCUIT WITH ANOTHER
APPLIANCE.
Make sure the crumb tray is properly installed before
4.
using.
For the first time, set the temperature knob to MAX,
the timer setting to 10 minutes. This will burn off
any oils still on the oven.
NOTE
• The oven may smoke during this process. This is normal for a new oven
and will not last more than 10-15 minutes.
NAME OF PARTS
1. Door handle
2. Housing
3. Temperature knob
4. Function knob
5. Timer knob
6. Crumb tray
7. Baking rack
8. Baking tray
9. Indicator light
6
1
2
3
4
9
5
7
8
CONTROL SETTINGS
EN-8
TIME SETTING
0-30 MINUTES: The timer can be set up to 30
minutes.
The oven will not turn on without the timer
being set.
When the time knob is in the "OFF" position,
the oven will not operate. To set the time, turn
the timer knob to the desired time.
Indicator light is lit only when time has been set.
When the timer has reached the "OFF" position,
a bell sound will be heard. Power supply will be
cut off automatically.
TIME ADJUSTING
Timer can be changed during cooking cycle.
Just turn the timer knob to the desired time and
continue cooking.
NOTE
• When setting the timer knob for less than 5
minutes, rotate timer to over 10 minutes
and then rotate back to your chosen time.
Ensure a safe and accurate timer setting.
TEMPERATURE SETTING
Turn the temperature knob clockwise to the
desired temperature setting. The temperature
can be seted from 150
O O
F (65 C) to 450 F (230 C).
O O
STAY ON
EN-9
For using the toaster without time control, turn the timer konb to position
" STAY ON ". In this case, the toaster will work until the timer konb is set to " OFF "
position.
NOTE
• The bread may catch fire if the toasting time is setting too long. Close
supervision is necessary during toasting.
FUNCTION SETTING
This Oven offer three different functions for versatile cooking all in one
appliance.
Bake: The lower heating element is working during this function.
Broil: The upper heating elements is working during this cycle.
Toast: The upper and lower heating elements are working during this function.
It is perfect for baking pizza, bread and cookies and toasting pork,
steaksand toasts.
HOW TO USE
EN-10
CAUTION: THE OVEN SURFACES ARE HOT DURING AND AFTER USE
GENERAL INSTRUCTIONS
1. Place the baking rack in position that will accommodate the height of the
food to be cooked.
2. Set the food on the rack. Make sure that you use an ovenproof container in
the oven, never use plastic or cardboard containers in the oven.
3. Never use glass or ceramic pans or lids.
4. Do not let juices run to the bottom of the oven. Use the baking tray and crumb
tray when cooking.
5. Set the temperature as suggested by the recipe or as desired.
6. Securely shut the door and set the cooking time to begin operating the oven.
BAKE FUNCTION:
Use the bake function for foods such as meats which easy to stew, soups and
vegetables.
1. Place the baking rack to the desired height.
2. Set the function knob to " ".
3. Select the length of time you want to bake the food.
4. Rotate the temperature knob clockwise to desired temperature.
5. Continuing baking for desired length of time.
6. Check food temperatures before moving to ensure that proper internal
temperatures have been reached.
7. Always removing food with oven mitts. Food and oven are very hot.
BROIL FUNCTION:
The broil function is ideal for fish, beef, steak, vegetables, etc.
1. Place the baking rack to the desired height.
2. Set the function knob to" ".
3. Select the length of time you want to broil the food.
4. Rotate the temperature knob clockwise to desired temperature.
EN-11
5. Continuing broiling for desired length of time.
6. Check food temperatures before moving to ensure that proper internal
temperatures have been reached.
7. Always removing food with oven mitts. Food and oven are very hot.
TOAST FUNCTION:
Use the toast function for foods such as corn, bread, cookies and heating food.
1. Place the baking rack to the desired height.
2. Set the function knob to " ".
3. Select the length of time you want to toast the food.
4. Rotate the temperature knob clockwise to desired temperature.
5. Continuing toasting for desired length of time.
6. Check food temperatures before moving to ensure that proper internal
temperatures have been reached.
7. Always removing food with oven mitts. Food and oven are very hot.
ABOUT RACK LEVELS
Rack has two placing modes,which can place different baking layers, and
is suitable for baking different foods.
1. The concave side
of the rack on the
lower layer,which
is suitable for
baking potatoes.
2. The concave side
of the rack on the
upper layer, which
is suitable for
baking bread slices.
3. The convex side
of the rack on the
lower layer,which
is suitable for
baking pizza.
CARE AND CLEANING
EN-12
1. Before cleaning unplug the toaster oven and allow it to cool completely.
2. Wash all the attachments with mild, soaped water including the rack and
the baking Tray.
3. Do not use abrasive cleansers, scrubbing brushes and chemical cleaner
as this will cause damage to the non-stick coating of baking tray.
4. Using a wet cloth to wipe the inner of the oven.
5. Clean the door by using a wet cloth saturated with detergent or soap.
6. Never immerse the unit in water or other liquid.
7. Any other servicing should be performed by mide customer service center.
HOW TO CLEAN THE CRUMB TRAY
1.Turn the oven on back.
2.Push the Crumb Tray knob down and then pull it.
3.Clean the Crumb Tray.
4.After cleaning return the Crumb Tray in its place.
DISPOSAL
EN-13
Do not dispose of electrical appliances as unsorted municipal
waste,use separate collection facilities. Contact your local
government for information regarding the collection systems
available. If electrical appliances are disposed of in landfills or
dumps, hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and wellbeing.
ONE YEAR LIMITED WARRANTY
EN-14
This product carries a warranty stating that it will be free from defects in
material and workmanship for a period of one year from the date of purchase.
This warranty is validfor the original retail purchaser from the date of initial
retail purchase and is not transferable. Keep your original sales receipt.
IMPORTANT
1. This warranty does not cover damages resulting from accident, misuse or
abuse, lack of reasonable care, the affixing of any attachments not
provided with the product, loss of parts, or subjecting the appliance to any
but the specified voltage. ( Read directions carefully. )
2. This warranty is void if this product is ever used for other than private
household purposes.
3. This warranty is void if this product is ever used outside of United State .
If service is required during the warranty period, properly pack your unit.
We recommend using the original carton and packing materials.
If additional assistance is needed, please contact customer assistance at:
Tel.: 866-646-4332
Midea America Corp. expressly disclaims all responsibility for consequential
damages or incidental losses caused by use of the appliance. Some states
do not allow this exclusion or limitation of incidental or consequential losses
so the foregoing disclaimer may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights which may vary from
state to state.
The serial number can be found on the back cabinet. We suggest that you
record the serial number of your unit in the space below for future reference.
Model Number:_______________________
Serial Number:________________________
Product registration is not mandatory. Failure to complete and return the card
or form does not diminish the consumer' s warranty rights.
SAVE THIS FOR YOUR RECORDS
Made in China
PN:16170000A83771
Tel.: 866-646-4332
Loading...
