CP-5NMO
No-holes-to-drill
universal mobile lip mount for
antennas that use an NMO connector
To avoid the problems caused by the coax entering thru the weather seal
from a lip mount, Comet developed a 2-step deluxe coax cable system.
The first 18” is mini RG-188A/U type coax, about 1/8” diameter allowing
easy entry through the weather seal WITHOUT causing the typical wind
noise, water leaks or damage to the coax.
The mini coax is then soldered to low-loss coax, completing the 5 meter
overall length
Connectors: NMO on mount, coax terminates in a PL-259
The PL-259 barrel is removable to fit the coax through a small hole or tight
space. The coax length can shortened to the desired length and the connector
re-assembled.
Features:
• Universal lip mount for
mounting mobile antennas without the need to
drill any holes
• Adjusts in several planes to
adjust the antenna to vertical from virtually any angle
• HF Max power: 200W
• VHF Max power: 75W
• UHF Max power: 45W
• Four large set screws
ground the mount and holds
it securely in place
• 5 meter (16’9”) length of
coax included
• Perfect for leased and private vehicles
• Easily installed and removed
• Soft rubber gasket protects
the vehicle paint
• Footprint: 3.4”x1.25”
Attaches easily to almost
any lip on a vehicle and
adjust to vertical. The
max thickness of the lip
can be 1/4 inch.
Mini RG-188 type coax
easily fits thru the
weather seal.
On the rear door of a Van,
SUV or truck door, the antenna is still above the roof
line for the best pattern but
is easy to reach for car
washes, theft prevention, etc.
Opening the door does not
cause the antenna to hit the
roof line.
NCG Company Ltd, USA
www.natcommgroup.com
800-962-2611 909-393-6133
