Combi Ninna Nanna PA-138V
Soft carrier for cradling, cuddling and back-carrying
Instruction Manual
Please read the user guide and use accordingly. After reading, store the user guide
properly for future reference.
Also attach this user guide when giving the product to the others.
Head support is only used after baby's
neck musclehas developed. Store properly
at a safe place if removed from pocket.
*Head supportisstoredinside pocket in sales package.
Before use
Before use
Thank you for purchasingCombiNinnaNannaPA-138V baby soft carrier .
This product is a generic single-baby carrier designed for cradling,
cuddling or back-carrying a baby during shopping or outdoor activities.
Before use, please read "Name of parts" in P.5 and check out the parts.
● This product can be used for cradling, cuddling or back-carrying
a baby.
Age reference for applicable baby
(Baby's body size may vary accordingto different growing speed.)
Cradling
New born
Weight : below 7.0kg
Age reference: frombirth to around 4 months(neckmuscle has developed)
Cuddling
Weight : below 11.3kg
Age reference: after neck musclehasdeveloped up to around 12 months.
Until neckmuscle has
developed
after neck muscle has
developed
Up to around 12
months (11.3kg)
For safe use of our product
Caution about safety
The caution items mentioned here are about how to use the product
properly and safely so as to prevent any possible injury to user and
baby and any damage to the product. Moreover, the caution items are
categorized according to the degree of injury and damagetotheproduct
which are indicated as "warning" and "caution" respectively.
Caution and using conditions mentioned below are very important.
Please read and follow accordingly.
WARNING
Improper operation may directly cause death or severe damage.
CAUTION
Improper operation may cause injury or damage to the product.
Details of the caution item is written inside the frame.
This sign indicates there is a warning or caution item.
This sign indicates there is a prohibited action.
Back-carrying
after neck muscle has
developed
Up to around 30
months (14.9kg)
Weight : below 14.9kg
Age reference: after neck musclehasdeveloped up to around 30 months.
Applicable waist size for user rangesfrom 55~110cm.
Particular babiesin bigger body sizemay not fit for soft carrier inwinter times when wearing
thicker clothes. Please choose clothes forbaby carefully before usingthe soft carrier.
1
WARNING
Before use
Make sure to secure the following parts when use. Otherwise baby
may fall off from carrier accidentally while in use.
< Cradling >
• Head guard hook (2, left and right)
• Side lock, Side snap
• Safety buckle
※Please attach cradling support
seat to use.
Head guard hook
(2, left and right)
Side lock,
Side snap
Safety buckle
< Cuddling >
• Side lock, Side snap
• Safety buckle
• Combi buckle
Side lock,
Side snap
Safety
buckle
Combi buckle
< Back-carrying >
•Waist buckle
• Side lock, Side snap
• Safety buckle
Please try as much as possible to tighten the
following belts. Any gap in between baby and
user may cause baby to fall off from the carrier
while in use.
• Safety belt
•Waist belt
< Cradling >
Waist belt
Safety belt
< Cuddling >
Waist belt Safety belt
< Back-carrying >
Waist buckle
Side lock,
Side snap
Safety
buckle
Waist belt Safety belt
2
Before use
WARNING
Please seat or unseat baby at a safe place
(a third party aid preferred) to avoid the baby
may falling off accidentally.
Cradle position is not applicable to the
following babies.
● Baby weighing more than 7.0kg.
● Baby whose head protrudes out of head
guard when seated.
● Baby who can turn
around itself without aid.
Failure to do so may cause
injury to baby.
When the carrier is in use, please do not
run, jump, lean forward for more than 45
degree, or lean to the side. Otherwise, baby
may accidentally fall off from the carrier.
In cradle position, make sure baby's head
is in a higher position than its feet, and do
support the baby's head with one hand.
Improper cradling may exhaust the baby or
become cause of injury.
In cradle or cuddle position, always support
baby with your hands. Baby's unexpected
movement may cause it to fall off from the
carrier.
Cuddling is not applicable to baby whose
neck muscle is not yet developed, or
otherwise may exhaust the baby or become
cause of injury.
Head
guard
3
CAUTION
Before use
Remove "Cradling support
seat" when cuddling baby.
Otherwise the support seat
may press on baby's head.
Release the "adjustment zipper"
to use when there is a gap of
more than 4cm in between
baby's armpitandthesafety belt.
Otherwise baby may fall off the
carrier while in use.
Do not try to unpick stitched belt
ends or re-structure the product.
Otherwise, damage or accident
may be caused while in use.
Please do not use the carrier
continuously for more than 2
hours, or within 30minutesafter
breastfeeding. Otherwise,
unexpected burden will be
inflicted to user
or baby.Also,
please stop
using the carrier
immediately in
case of any
pain and
uncomfort.
Please do not leave the product
near a raw fire or unattended
outdoor. Otherwise, buckles or
other fabric parts may be
deteriorated by heat or rain which
may in turn become cause of
accidents.
Stop using the product
immediately in case of any
damage of product is found.
Please do not use this product
for the purposes other than
those advised by this manual
to avoid any damage to the
product.
Safety
belt
4
Before use
Name of parts
Head support
(Detachable)
● Stored inside
pocket
Safety belt
Safety buckle
Pocket
Velcro (female)
Adjusting zipper
● To be used according to
growth stage.Release to
deepen the seat.
Cradling support seat
Head guard
Crotch snaps
Head support hook
(male)
Combi ladder buckle(1)
● For adjustmentofsafety
belt
Cradling support
seat attachment
hook
Adjusting snap
Combi ladder buckle (2)
● For adjustment ofwaist belt
Velcro (male)
Shoulder belt
Combi buckle
● For cuddling. To
be stored when
back-carrying or
cradling.
Waist buckle
● Used in back-
carrying
Hook attachment ring (female)
● Forattachmentof cradling support
seat and head support.
Side lock
Side snap
Waist belt
● Waist belt is
made twisted
to fit baby.
Head guard
hook (male)
Attachment snap Crotch snap
※Pocket shape varies according to models.
ANYO RAKU RAKU pad
5
Preparation for cradling
Adjust waist belt length
Cradle position
Before seating baby ,carrythe soft carrier along
the shoulder as illustrated and adjust waist belt
with Combi ladder buckle
should be in open position and stored inside
shoulder strap.
➁. Combi buckle
Shoulder strap
Combi buckle
● To adjust
Release crotch snap and pull out waist belt
and Combi ladder buckle
Combi ladder buckle ➁ and adjust waist belt
length. Waist belt is made twisted to better fit
user's body.
Store belt ends and buckles inside inner side
of crotch snap and secure crotch snap.
➁. Lift the end of
Waist belt
Crotch snap
Twisted
Combi ladder
buckle ➁
Or
(from birth until neck muscle developed)
Combi ladder
buckle ➁
It is recommended to set baby'sheadclose to
parent's heart position.
After puttingonshoulder strap, shorten theside
closer to the user and baby can be cradled in
a better balanced position.
6
Cradle position
To seat baby whose neck muscle is yet to develop
1
(from birth until neck muscle developed)
6
Release the safety buckle
Safety buckle
Check if the carrier fits baby
Put 2 adult fingers in between carrier and
baby and adjust belt length with safety
buckle and Combi ladder buckle
case of feeling too loose or too tight.
Around 2 fingers
① in
Release the side snap and side
2
lock.
To release side lock, slide the side lock
male toward the bigger end of the side
lock female.
Side lock male
Side snap
Side lock female
Adjust the left and right belt to the same
length
Same length
Seat the baby
3
Open carrier at a safe place and seat
baby inside. Make sure baby's head is
not leaning too tight against head guard.
Set the head guard
7
Secure left and right head guard hooks
to hook attachment rings on shoulder
strap.
Head guard hook
Adjust safety belt regularly according to
different growth stages.
7
Cradle position
If baby's headis being pressed by head guard,
seat baby deeply asmuchas possible into the
seat.
To secure head guard hooks
Lift head guard hook and place it above
hook attachment ring. Press thefrontend
of the hook until it clicks into place.
Hook attachment ring
Secure side lock and side snap
4
To secure side lock, place the side lock
male into the bigger opening on side lock
female and slide upward to secure it.
(Refer to step 2)
Side lock
Click
Side snap
Secure safety buckle
5
Secure safetybuckleuntilheard the "click"
sound.
Click
Safety buckle
WARNING
Check to make sure "side lock", "side
snap" and "safety buckle" are secured to
prevent baby from accidentally falling off
while in use.
(from birth until neck muscle developed)
Head guard hook
8
Cradle position
To cradle baby whose neck muscle is yet to develop
1
(from birth until neck muscle developed)
Advice
In case of baby with smaller body size, it is recommended to secure the adjustment zipper and apply the cradling support seat to
use. (Adjustment zipper is normally open in cradle position.)
Seat and cradle baby
Put on shoulder strap across shoulder
as shown.
It is recommended to set baby's head close
to parent's heart position.
After putting on shoulder strap, shorten the
side closerto the userand babycanbe cradled
in a better balanced position.
WARNING
In cradle position, make sure baby's head
is in a higher position than its feet, and
do support thebaby'sheadwithone hand.
Improper cradling may exhaust the baby
or become cause of injury.
Support baby with hands
2
Use hands to support baby's head and
hip.
When cradling baby by your own, it is
recommended to operate in front of a mirror
to check if baby's head is on thelowerside.
Belt isregarded too long ifthe illustrated angle
of the supporting hand is bigger than 90
degree. Re-adjustthe length withCombi ladder
buckle
➁ on the waist belt.
90 degree
9
To unseat baby from cradle position
Cradle position
Put down baby and then put off
1
shoulder strap
Support baby with handsandputdown
baby at a safe place. Put off shoulder
strap.
Release safety buckle
3
Safety buckle
Release the left and right head
2
guard hooks
Head guard hooks
Release side lock, side snap and
4
then unseat baby.
Side lock
To release head guard hook
Lift the head guard hook to the outer
side. Press on the front end of head
guard hook with a thumb and then
slide the hook attachment rings to the
side to release it.
Hook
attachment
rings
Head
guard
hooks
(from birth until neck muscle developed)
Side snap
10
Cradle position
To remove cradling support seat
Cradling support seat is already attached while in sales package. Follow the steps below to remove cradling support seat for washing, or
when changing to use in cuddle position.
1
Release 2 crotch snaps
Crotch snaps
Release Velcro on pockethooks.
2
Pocket
Release attachment snapR
3
Attachment snaps
(from birth until neck muscle developed)
11
Cradling support seat
Release Velcro on ANYO RAKU
4
RAKU padard hooks.
ANYO RAKU RAKU pad
Velcro
Velcro
Hold on the upper side of seat pad
5
and pull it out
WARNING
When attaching cradling support seat, please
make sure attachment snaps and crotch snaps
are secured to prevent baby from accidentally
falling off while in use.
To attach cradling support seat
Reverse the above steps to attach
cradling support seat. (Step 5 ➜
Step 1)
Before securing crotch snaps,
tighten the waist belt and place
the belt endsandbucklesproperly.
Preparation for cuddling
Cuddle position
Advice
Adjust the length of the waist belt
Adjust seat depth with adjustment zipper.
● Close adjustment zipper to use
When baby is still small and there is not
much gap in between baby's armpit and
safety belt, close adjustment zipper and
secure adjustment snap to use. (For baby
below 6 months)
Adjustment
zipper
※ Release the adjustment zipper to use in
cradle position.
There are 2 ways to cuddle a baby¨: ① seating baby first before putting on carrier, or ➁ putting on carrier first before seating baby.
Please choose whichever way that suits your need.
● Open adjustment zipper to use
Adjustment
snap
When there is a gap of 4cm or more in
between baby's armpit and safety belt,
release theadjustmentsnapandadjustment
zipper to use.
4cm
Safety belt
WARNING
It is dangerous to keep the adjustment
zipper close even when there is a gap of
more than 4cm in between baby's armpit
and safety belt since baby may fall off from
carrier while in use.
Apply head support
● Remove cradling support seat after baby's
neck muscle has developed, and replace
it with head support.
(Baby whose neck muscle has developed
can use head support up to around 7
months)
Head support
(After neck muscle developed up to around 12 months)
Attached status
※Head support is washable.
If safety belt is too tight against baby's armpit even when adjustment zipper is closed, put
few pieces of napkin or towel on the seat before seating the baby to raise baby's sitting
position.
12
Cuddle position
Preparation for cuddling
Seating baby before putting
(After neck muscle developed up to around 12 months)
13
Adjust waist belt length
Adjust waist belt length with Combi ladder buckle ➁ to fit user before seating baby.
Combi
ladder
buckle
➁
Waist belt is made
twisted to better fit user's
body.
Secure Combi
buckle
Click
● To adjust
Lift the end of Combi ladder buckle ➁
and adjust waist belt length.
WARNING
Trytotighten waist belt as much as
possible to prevent baby from accidentally
falling off the carrier.
Waist
Belt
Twisted
Or
Combi ladder buckle
Make sure to adjust the waist belt such that belt
ends on both sides are in same length.
➁
Seat baby into carrier and secure
1
side lock and side snap
Seat baby at a safe place.
Side lcok
Side snap
WARNING
• Check to make sure "side lock", "side
snap" and "safety buckle" are secured
to prevent baby from accidentally falling
off while in use.
•Try to tighten "safety belt" and "waist
belt" as muchaspossibleto use. Acarrier
that is too loose or a carrier of which belt
ends are in different length may cause
baby fall off the carrier upon its sudden
and unexpected movement.
• Seat baby at a safe place. (It is
recommended to have a third person to
assist the operation.) Seating or
unseating baby at an unsafe place may
cause baby to fall off from the carrier.
on carrier
Cuddle position
Secure safety buckle
2
Secure the safety buckle until a "click"
sound is heard.
Safety buckle
Click
Secure Combi buckle
4
Lean forward, put on shoulder strap and
secure Combi buckle at the back until a
"click" sound is heard.
Shoulder strap
Secure Combi
buckle
Click
It is suggested toplace baby on a bed first and
then lean forward to the baby for operation.
Secure head support
3
Secure head support hooks onto the hook
attachment ring on shoulder belt.
(Baby whose neck muscle has developed
can use head support up to around 7
months)
Head support Head support hooks
Hook attachment rings
Adjust carrier to fit user
5
Trytoadjust waist belt such that left and
right belt end are in same length. Set
shoulder strap, waist beltandCombiladder
buckle properly.
Waist belt
Refer to "To seat baby whose neck muscle is
yet to develop" (P.7~8) for how to secure side
lock, side snap and safety buckle,andalso the
way to adjust safety belt length.
To secure head support hooks
Lift head support hook and place it above hook
attachment ring. Press the front end of the hook
until it clicks into place.
Hook attachment ring
Head support hook
(After neck muscle developed up to around 12 months)
When waist buckle is not used, secure it
as shown or leave it open.
Secure waist belt to
the back ifwaistbelt
end is too long.
14
Cuddle position
Putting on carrier before seating baby
(After neck muscle developed up to around 12 months)
WARNING
• Make sure "side lock", "side snap" and
"safety buckle" are secured to prevent
baby from accidentally falling off while
in use.
•Try to tighten "safety belt" and "waist
belt" asmuchaspossibleto use. Acarrier
that is too loose or a carrier of which belt
ends are in different length may cause
baby fall off the carrier upon its sudden
and unexpected movement.
• Seat baby at a safe place.
(It isrecommendedtohave a third person
to assist the operation.) Seating or
unseating baby at an unsafe place may
cause baby to fall off the carrier.
Refer toStep 4, 5and6 of "To seatbaby whose
neck muscle isyetto develop" (P.7~8) for how
to secureside lock, sidesnap and safetybuckle,
and also the way to adjust safety beltlength.
Put on carrier
1
Put on shoulder strap and cross hands
to the back to secure Combi buckle until
a "click" sound is heard..
Secure Combi buckle
Click
Secure safety buckle
4
Secure safety buckle until a "click" sound
is heard.
Safety buckle
Click
Seat baby into carrier
2
User should sit down first. Seat baby into
carrier from either side while holding the
baby with on hand.
Secure head support
5
Secure head support hooks onto the
hooks attachment ring on shoulder strap.
(Baby whose neck musclehasdeveloped
can use head support up to around 7
months)
Head support Head support hooks
15
Hook attachment rings
Refer to"To securehead support hooks" (P.14)
for detailed operation.
Cuddle position
Secure side lock and side snap.
3
Side lock
Side snap
Adjust carrier to fit user
6
Trytoadjust waist belt such that left and
right belt end are in same length. Set
shoulder strap, waist beltandCombiladder
buckle properly.
Waist belt
To unseat baby from cuddle position
Release Combi buckle
1
Sit on a safe place. Support baby with
one hand and release Combi buckle
Release Combi buckle
Release safety buckle
3
Safety buckle
Place baby on a safe place and
2
release head support
Lift the head support hook to the outer
side. Press on the front end of head
support hook with a thumb and then
detach the hook attachment ring.
Hook
attachment
ring
Release side lock, side snap and
4
unseat baby.
Head support hook
Side lock
(After neck muscle developed up to around 12 months)
Side snap
16
Back-carry position
Preparation for back-carrying
Back-carrying
(After neck muscle developed up to around 30 months)
Advice
As baby is not seen in back-carry position, it is recommended to unseat baby and
check baby's status once every 30 mins.
Adjust waist belt length
Store Combi buckle into shoulder strap and adjust
waist belt with Combi ladder buckle
Shoulder strap
Combi buckle
Waist belt is made
twisted to better fit
user's body.
Twisted
➁ to fit user.
Waist belt
Combi
ladder
buckle
● To adjust
Lift the end of Combi ladder buckle
and adjust waist belt length.
Or
WARNING
Please try to tighten waist belt as
➁
much as possible to use. After
adjustment, Combi ladder buckle
should be located at around upper
waist of user .If the gap between user
and baby is too large or too loose,
it may cause baby to fall off carrier
while in use.
Trytoadjust waist belt such that left
and right belt end are in same length.
WARNING
• Make sure "side lock", "side snap" and
"safety buckle" are secured to prevent
baby from accidentally falling off while
in use.
•Try to tighten "safety belt" and "waist
belt" asmuchas possible to use.A carrier
that is too loose or a carrier of which belt
ends are in different length may cause
baby fall off the carrier upon its sudden
and unexpected movement.
• Seat baby at a safe place. (It is
recommended to have a third person to
assist the operation.) Seating or
unseating baby at an unsafe place may
cause baby to fall off from the carrier.
Refer to step 4, 5 and 6 of "To seat baby
➁
whose neck muscle isyetto develop" (P .7~8)
for how to secure side lock, side snap and
safety buckle,and also the wayto adjust safety
belt length.
17
Back-carry position
Seat baby into carrier. Secure side
1
lock and side snap
Side lock
Side snap
Carry baby on the back
4
It is recommended to have a third person
to assist the operation.
Trytoplace the baby on
asofaandholdthe upper
end ofshoulderbelt when
operating on your own.
Secure safety buckle
2
Secure safety buckle until a"Click"sound
is heard.
Safety buckle
Click
Refer to"To securehead support hooks" (P.14)
for detailed operation.
Adjust carrier to fit user
5
Trytoadjust waist belt such that left and
right belt end are in same length. Set
shoulder belt, waistbeltandCombi ladder
buckle
➁ properly.
Waist belt
Set the head support
3
Secure the head support hooks onto the
hook attachment rings on the shoulder
belt.
Head support Head support hook
Hook attachment rings
Secure waist buckle
6
(After neck muscle developed up to around 30 months)
Waist buckle
18
Back-carry position
To unseat baby from back-carry position
(After neck muscle developed up to around 30 months)
Release waist buckle
1
Waist buckle
Release safety buckle
4
Safety buckle
Unload carrier from back
2
Release side lock, side snap and
5
then unseat baby.
Side lock
Side snap
Place baby on a safe place and
3
release head support
Lift the head support hook to the outer
side. Press on the front end of head
support hook with a thumb and then
detach the hook attachment ring.
Hook
attachment
ring
Head
support hook
19
Maintenance
Maintenance
Daily maintenance
Use water or warm water to wash carrier.
After washing, lay it flat on shaded area to
dry.
Use a piece of damp cloth to wipe off small
dirt.
CAUTION
When saliva of baby is adhered to the fabric,
please clean it as soon as possible to avoid
the fabric from becoming hardened.
Hardened fabric may inflict discomfort to the
baby.
Caution about washing
Wash carrier separately from other colored
items to prevent decoloring. Do not soak
carrier in water for a long time.
Do not use bleach or fluorescent brightener
as both of which may become potential
discomfort to baby. It is recommended to
use Combi's detergent series.
Washing symbol
Material
Main parts
Product color
Smart Black
Cool Grey
Champaign Beige
Chocolat Red
Polyester
Cotton
Do not put carrier into washing machine,
spinning machine or drying machine, all of
which may cause damage to buckle.
BuckleOuter fabric Mesh Inner fabric Belt
Cotton Polyester Polyacetal
Polyester
20
Loading...
