i-thru
7100 Series
Instruction Manual
Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC 29708 • www.combi-intl.com
Consumer Affairs 1-800-992-6624
Parts List
Make sure you have all the parts listed below before using your stroller. If any parts are missing,
call Consumer Affairs at 1-800-99-COMBI.
Instruction
Manual
Located on the rear right leg.
Note: Illustrations are only representative and not actual.
Attach copy of sales receipt.
Be sure to carefully read this instruction
manual before using the product to ensure
proper use of the stroller and keep it for
future reference. Record the following
information for quick reference.
Date Purchased: ______________________________________
Model Number: 7100-_______
Color: _________________________________________________
Fabric Pattern: ________________________________________
Body
Canopy
Kid’s
Tray
Stroller
Pack
Boot
Basket
Hooks
Harness
Canopy
Canopy Lock
He
adrest
Seat Release
(Under Cushion)
Basket
Lock
Brake
Seat Cushion
Locking
Mechanism
Kid’s Tray
Footrest
Kid’s Tray Button
Swivel Lock
Side Mesh
Pockets
Boot
Release
Lever
Air Through Window
Back Rest
Re
ar
Stabilizer
Ba
r
Recline Lever
Egg Shock Pad
(for shock absorption)
Rear
Stabilizer
Bar
Questions, concerns check our website
www.combi-intl.com
1-800-992-6624
Name of Parts
WARNING
Before use, make sure stroller locking
mechanism is in the locked position.
Locked
Unlocked
WARNING
Do not use the stroller
on steep slopes, stairs,
escalators, beaches,
rough roads, mud, etc.
WARNING
Do not lift or carry
the stroller while
occupied. The stroller
may fold.
WARNING
Do not allow your
child to stand in or on
the stroller.
WARNING
Do not use seat from
stroller to carry child.
WARNING
Avoid serious injury
from falling or sliding
out. Always use
attachment strap.
WARNING
Always remove child
before detaching,
reattaching stroller
seat.
WARNINGS For your child’s safety:
If your stroller is not used in compliance with these instructions, serious injury may result.
In the event of damage or
problems, discontinue use and
contact Combi Consumer Affairs
for instructions: 1-800-992-6624.
All products speci fications are subject to change without notice. Sizes and weights are intended
as guide s and are approximations. Combi® reserves the right to modify the products in its line during the
course of the year. Non contractual media. Colors are as accurate as the media in which they appear allows.
©Combi USA, Inc. 2004
Note: Illustrations are for reference only
and may not represent the actual product.
CAUTIONS:
1. Improper usage or lack of knowledge regarding
the instructions can result in dangerous situations, personal injury or damage to the stroller.
2. Completely remove all plastic bags and packing
materials before using this product to prevent a
possible choking hazard.
3. Push the stroller at a normal walking speed only.
WARNING
Do not hang items
on the handle or
place items on
canopy. This could
cause the stroller to
become unbalanced
or tip over.
WARNING
Never carry more than
one child in the stroller.
Do not allow a child to
ride or sit on areas of
stroller other than the
seat.
WARNING
Never leave child
unattended.
WARNING
Always engage
both brakes when
parking the stroller.
WARNING
CHILD MAY SLIP INTO LEG OPENINGS AND
STRANGLE. NEVER USE IN RECLINED CARRIAGE
POSITION UNLESS THE PERMANENTLY
ATTACHED SAFETY COVER IS USED.
4
2
1
4
2
4
1
2
Unlocked
Locked
1. Slide indicator to right so that red label is
visible.
2. Press and hold release button while lifting
handle up and snap stroller away from you.
3. Release button can not be pressed if red
label on indicator is not visible.
4. Before use, ensure stroller locking mechanism is in locked position.
Opening the Stroller
1. Pull seat release lever.
2. While pulling release lever place opposite hand behind
seat back and lift seat with both hands.
3. Rotate seat.
4. Center armrest above red arrow labels and press seat
into stroller.
5. You will hear an audible “click” once seat is locked into
position.
6. Pull up on seat to ensure that it is locked into position.
Do not use seat from stroller to carry child.
Always remove child before detaching or reattaching stroller seat.
Changing Seat Direction
Rear Facing Seat
Forward Facing Seat
Note: Illustrations are only representative and not actual.
Hook (2x)
Attaching
Removing
Frame for basket attachment
Do not place more than 11 lbs. in the basket.
Remove all items from basket before folding stroller.
1. Attach sides of basket to frame of stroller using snaps.
2. Snap both basket hooks onto rear stabilizer bar.
3. Insert hook into rear stabilizer bar cover to secure basket.
Reverse the procedure for attaching.
Using the Basket
Reclining the Seat
Recline Lever
Never use seat in reclined position unless the
permanently attached safety cover is used.
Pull the recline lever
and gently adjust
backrest to any three
positions.
CAUTION
Be careful when reclining the backrest while your baby
is in the stroller to prevent abrupt changes in seating
position.
CAUTION
Seat will fold if pushed forward.
Snaps
Hook (2x)
Zippe
r
Ho
ok
Re
ar
St
abilizer
Ba
r
Re
ar
St
abilizer
Axle
Recline Lever
Using the Safety Cover
CAUTION
Before folding the stroller, unfasten and store the safety
cover under the seat. The stroller will not fold with it
attached.
1. Lift the seat cushion and pull the safety cover out.
2. Wrap the velcro straps around the tray belt and route the side velcro straps through the loop underneath the seat cushion. (Located
on the bottom of the Kid’s Tray.)
3. Fasten the velcro straps to secure.
Never use seat in reclined position unless the
permanently attached safety cover is used.
Lock
Unlock
Unlock
Lock
To lock brakes,
push both brake
levers down.
To unlock
brakes, lift both
brake levers up.
CAUTION
Push the stroller forward to ensure that the
brakes are properly engaged.
Using the Brakes Using the Swivel Wheels
To lock swivels, lift both
swivel lock levers up.
To unlock swivels, push
both swivel lock levers
down.
1. Squeeze the release buttons on both sides and
lift up to release,
2. When released, it allows easy access to the
seating area.
3. To attach the Kid’s Tray, slip it over the armrest
pins until you hear the pins click into position.
Using the Kid’s Tray
Seat Extension
Using the Seat Extension
Using the Boot
Seat Extension
Bottom of Boot
Snaps
Kid’s
Tray
Elastic
1. Lift the seat cushion and locate the seat extension.
2. Pull out the seat extension on both sides.
3. Attach snaps on seat cushion to snaps on seat
extension.
When not in use push the seat extension back to
the original position.
1. Pull out seat extension and attach seat cushion.
2. Fit boot onto seat extension
3. Attach snaps on boot to snaps on side of the
stroller.
4. Attach elastic to Kid’s Tray.
To prevent damage to the stroller, never push down
or pull up on tray once it is attached to stroller.
Buckle Tongue
Wa
ist
Belt
Wa
ist
Belt
Release Button
2 inches
1.2
inches
Back
Rest
Crotch
Belt
Folding the Stroller
CAUTION
Folding levers should be operated
only when folding the strollers.
1. Lock both front swivel wheels.
2. Ensure Kid’s Tray is attached at both sides.
3. Fold the canopy toward the handle.
Using the Harness
Unbuckling the Harness
1. Press levers down on right and left harness hooks
to detach from buckle tongues.
2. Press buckle button down (with Combi logo) and
detach buckle tongues from buckle.
Buckling the Harness
1. Place the crotch belt between the baby’s legs.
2. Insert buckle tongues into buckle.
3. Lift buckle with tongues inserted and attach right and
left hook to holes in buckle tongue
4. To adjust the harness or waist belt, loosen the slack on
both sides of each buckle tongue.
Perform the following operations before folding:
Forward Facing Seat
Rear Facing Seat
1. Lock both front swivel wheels.
2. Ensure Kid’s Tray is attached at both sides.
3. Fold the canopy away from the handle.
5. Slide indicator to right so that red label
is visible.
6. Press and hold release button while
lifting handle up and toward front of
stroller.
Avoid serious injury from falling or sliding out.
Always use the 5-point harness.
Unbuckling the Harness
Buckling the Harness
WARNING
Before use, make sure stroller locking
mechanism is in the locked position.
Locked
Unlocked
3
3
CAUTION
Failure to fully secure the canopy holders can
cause the holders to bend. When storing the stroller by laying it down, be sure the canopy is off the
ground to prevent it from bending.
Extending
Attaching
Removing
Folding
Air-Thru Window
Using the Canopy
Fully insert the canopy
holder (male) to the
canopy holder (female)
until a click is heard.
Press lock down to
fully extend canopy.
Pull tab on canopy up
and pull out of canopy
holder.
Push lock up to fold
canopy.
Using the Air-Thru System
Open and close the Air-Thru window using the
zipper located at the rear of the canopy.
Backrest
He
adrest
Removing and Attaching the Seat Cushion and Eggshock Pad
Removing
1. Unbuckle the 5-point harness and pull all the straps
through the seat cushion.
2. Unsnap seat cushion from seat extension.
3. Unhook elastic bands from backrest.
4. Grasp seat cushion and Eggshock foam and remove from
seat.
Attaching
1. Pass the 5-point harness straps through the appropriate
locations in the Eggshock foam and seat cushion.
2. Fit seat cushion over backrest.
3. Attach all elastic bands.
CAUTION
If seat cushion is ripped or torn, do not use.
Do not use the stroller without the seat
cushion.
WARNING
Always ensure at least 1.2 inches of waist
belt is visible after routing is complete.
Routine Maintenance
Trouble Shooting
STORE IN A COOL AND DRY AREA, especially in the summer. Do not store the stroller in the trunk of
a vehicle.
SEAT CUSHION
The seat cushion is machine washable. Set to gentle cycle using cold water and a mild detergent. Do
not use bleach. Lay seat cushion flat to dry in shaded area. Do not machine dry. To prevent color fading, do not leave soaking for a long period. Do not dry in the sun. If the seat cushion is frayed or
unraveling, discontinue use and call Consumer Affairs for further instruction.
EGGSHOCK PAD
The Eggshock pad is not washable. Should pad become damp, lay flat in a shaded area to dry.
CANOPY, WAIST BELT, FIXED SEAT BASE AND BASKET
Hand wash with brush. Wipe out excess water with a dry cloth and dry in a shaded area. For stubborn
dirt, dilute a mild detergent and apply directly to the dirty area. Wipe out the detergent.
MAIN BODY
Briskly wipe off any mud and dirt. To clean the body, wipe with a damp cloth then wipe out any traces
of moisture on the body with a dry cloth. The main body might become moldy and musty if not wiped
dry.
Excessive exposure to the sun could cause premature color fading of stroller
plastic and fabric.
WHEEL ASSEMBLIES
After prolonged normal use, the wheels of your stroller may not swivel or turn as easily as when the
stroller was new. This is usually due to a buildup of dirt in the swivel mechanism. Before adding lubrication, wipe off mud and dirt. Do not use soap and water to wash wheels. Periodically check that all
screws, bolts and nuts are tight.
Avoid lubricating the swivel wheels whenever possible. Excessive lubrication or adding lubricant to
swivel wheels when new may cause them to develop a shimmy or wobble that may quicken their
deterioration. Add silicone* to the wheel assemblies in small amounts.
Do not use lubricants because oil attracts dust and would hinder the movement rather than
improve it.
*Silicone spray is available in varying size cans at most hardware stores.
STROLLER WILL NOT FOLD
- Check to see that the waist belt is not caught in the side.
- Make sure front swivels are locked.
- Make sure the backrest is in the folded position.
- Remove all items from the basket.
DIFFICULT TO STEER/STROLLER PULLS TO ONE SIDE
- Remove any items hanging from the handle.
- Make sure weight in basket is distributed evenly.
- Check that the brakes are not in the locked position.
- Clean and add silicone to wheels, if necessary.
DIFFICULT TO GET UP CURBS
- Pulling stroller backward makes going
up a curb difficult, and could pose a safety hazard.
Pull the handle up to lift the rear wheels
onto the curb, then pull the stroller backward
until the front wheels clear.
DIFFICULT GOING DOWN CURBS
- Turn stroller around, bringing rear wheels toward the edge of the curb. Gently
lower rear wheels onto the surface below. Once the rear wheels have landed, guide
the front portion of the stroller, using the armrest as support.
Parts Order Form
If you would like to place an order for the following parts, please fill out the form below and return
to the following address:
Combi USA, Inc. or Fax this completed form to
Attn: Consumer Affairs Department
1962 Highway 160 W, Suite 100
Fort Mill, SC 29708-8027
IMPORTANT: We must have this information to process your order:
Model Number: 7100 - ______ Color & Pattern of Fabric: ______________________________________________________
Parts List for the i-thru (7100 Series) only.
Price Quantity Total
1. Seat Cushion 40.00
2. Basket 25.00
3. Kid’s Tray 25.00
4. Canopy 45.00
5. Boot 40.00
6. Stroller Pack 25.00
7. Eggshock Pad 40.00
8. Should Pad/Set 15.00
9.
10.
11.
Amount of Order
ADD
Shipping & Handling
Sales Tax (6%)
(SC residents only)
Total
If you need to order other parts for your stroller, please call us toll-free at
1-800-992 -6624.
Shipping and Handling Fees: Add $8.00 for orders $34.99 and under. Add
$13.00 for orders $35.00 and over. Note: Additional shipping charges will apply
outside of the Continental U.S. Combi USA reserves the right to change pricing at
any time.
Ship To:
Customer Name
Street Address
Street Address
City, State, Zip
Telephone Number
0105
803-548-3663
Located on the rear right leg.
i-thru
7100 Series
Instruction Manual
Charge to my credit card:
o VISA o MASTERCARD
o AMERICAN EXPRESS o DISCOVER
Card Number
Expiration Date __________ - ___________ - ____________
Cardholder’s Signature
o Check enclosed
Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC 29708 • www.combi-intl.com
Consumer Affairs 1-800-992-6624
Loading...
