Instruction Manual
Be sure to carefully read this instruction manual before using the product to ensure proper use of the stroller,
and keep it for future reference. Record the following information for quick reference.
Date Purchased: ______________________ Model Number: 2800 - ______ Color ____________________________________
Parts List
Name of Parts
Make sure you have all the parts listed below before using your stroller. If any parts are missing, call
Customer Service at 1-800-992-6624.
Main Body
Canopy
Travel System Guardrail
Fabric Pattern
Stroller Pack
16 Player Storage
Pocket
(
located on
the back of the canopy)
17 Reclining Lever
Located near the rear right leg.
1 Handle
2 Carrying Strap
3 Fold Release Lever
4 Canopy w/Speaker Pockets
5 Canopy Lever
6 Seat Cushion
7 5-Point Harness
8 Standard Guardrail
9 Armrest
10 Basket
11 Seat Extension (
located
under the seat cushion)
12 Brake Lever
13 Auto Folding Latches
(under the seat cushion on
the right and left sides)
14 Footrest
15 Swivel Lock Lever
Back of Seat
Note: Illustrations are only representative and not actual.
Attach copy of sales receipt.
Rear Wheel
x2
Front Wheel
x2
Standard Guardrail
18 Infant Car
Seat/Carrier
Locks
19 Travel System
Guardrail
Warranty
Card
Speakers
in a Box
Instruction
Manual
Ultra Savvy™TS 2800
Travel System Stroller
Patent Pending
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 2 -
WARNINGS For your child’s safety:
If your stroller is not used in compliance with these instructions, serious injury may result.
In the event of damage or problems,
discontinue use and contact COMBI
Customer Service for instructions:
1-800-992-6624.
WARNING
AVOID SERIOUS INJURY FROM
FALLING OR SLIDING OUT.
ALWAYS USE 5-POINT HARNESS.
WARNING
NEVER LEAVE CHILD
UNATTENDED.
WARNING
DO NOT LIFT AND CARRY
the stroller while open with a child
in it. The stroller may slip.
WARNING
Do not use the stroller on
steep slopes, stairs, escalators, beaches, rough roads,
mud, etc.
WARNING
Do not allow your child to stand in
or on the stroller.
WARNING
Do not put or hang things on
the canopy or handle because
it could cause the stroller to
become unbalanced or tip over.
WARNING
Always engage both brakes when
parking the stroller.
WARNING
Never carry more than one child in
the stroller. Do not allow a child to
ride or sit on areas of stroller other
than seat. Maximum weight of
child: 45 lbs. (20 kg)
CAUTIONS:
1. Improper usage or lack
of knowledge regarding the
instructions can result in
dangerous situations,
personal injury or damage to the
stroller.
2. Completely remove all plastic
bags and packing materials
before using this product to prevent a possible choking hazard.
3. Push the stroller at a
normal walking speed only.
WARNING
Excessive weight in basket (or
items placed in basket which
overflow the top or side of basket)
may cause a hazardous condition
to exist.
WARNING
Do not load more than 11 lbs.
(5kg) in the basket. Do not load
more than 2 lbs. (0.9kg) combined
weight in the bottle holder
(including bottles and contents).
WARNING
TO AVOID BURNS, do not place
bottles/cups with hot liquids in the
Stroller Pack. Do not place more
than 2 lbs. in the Stroller Pack.
WARNING
DO NOT ALLOW CHILD TO LEAN
OVER SIDES OF STROLLER. IT
MAY BECOME UNBALANCED
AND TIP OVER.
www.combi-intl.com
Questions, concerns or to enter
our monthly sweepstakes check
our website:
All products specifications are subject to change without notice. Sizes and weights are
intended as guides and are approximations. COMBI® reserves the right to modify the
products in its line during the course of the year. Non contractual media. Colors are as
accurate as the media in which they appear allows.
© COMBI International Corporation 2003
WARNING
Pulling stroller backward makes going up
a curb difficult, and
could pose a safety
hazard. See Page 11
of this manual for more information.
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 3 -
Attaching the Canopy
Attaching the Canopy
1. Confirm the canopy is facing in the proper direction.
2. Fully insert the canopy holder (male) to the canopy holder
(female) until a click is heard.
3. Fasten the canopy velcro on both sides around the handles to the
seat back velcro (2 places.)
Removing the Canopy
Pull the velcro apart and squeeze the bottom of the canopy holder
(male). Lift the canopy until it releases from the female holder.
CAUTION
Failure to fully secure the canopy holders can cause the holders to bend.
When storing the stroller by laying it down, be sure the canopy is off the
ground to prevent it from bending.
Opening the Stroller
2. Grip the handle on each side
and turn outward to open fully.
3. Lift up the handle and snap the
stroller away from you.
Holding the
handle from
underneath will
make it easier.
Lift up
Snap
away
Auto
folding
latch
Attaching & Removing the Front Swivel Wheels
Removing the Swivel
Wheels
Press in the square button
located at the bottom of the
wheel holder while pulling the
assembly off of the swivel
shaft.
Place front swivel wheel
assembly on the swivel shaft.
The assembly is secure when
it locks onto the shaft.
Release Button
Attaching the Rear Wheels
1. Stand behind the stroller.
2. Locate the small opening on each
rear wheel assembly.
3. Locate the small silver pin on each
rear stroller leg.
4. Insert the leg into the wheel assembly until the small silver pin locks
into the opening.
Note:
Attach the rear wheel assemblies to each
stroller leg with the wheel spacer facing
inward.
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 4 -
1. Press the lever at the top of
the seat to the left.
2. Adjust the backrest gently to
any of three positions.
To return the backrest to the
upright position, simply lift the
backrest gently into place.
Using the Reclining Backrest
To lock brakes,
push both brake
levers down.
To unlock
brakes, lift both
brake levers up.
CAUTION
Push the stroller
forward to ensure
that the brakes are
properly engaged.
CAUTION
Be careful when reclining the backrest while your
baby is in the stroller to prevent abrupt changes in
seating position.
Using the Brakes
WARNING:
Never use seat in reclined position unless the
permanently attached safety cover is used.
Using the Safety Cover
CAUTION
Before folding the stroller, unfasten and store the safety
cover under the seat. The stroller will not fold with it
attached.
Installing the Safety Cover
1. Lift the seat cushion and pull safety cover out.
2. Place the safety cover over the guardrail and secure it with the velcro.
1. Insert a speaker
into the small
pockets located
on both sides of
the canopy.
2. Place your
portable CD,
cassette or MP3 player
inside the large storage
pocket on the back of the
canopy.
3. Attach the speaker cords
through the Velcro holders
on both sides of the storage
pocket.
4. Insert
the
(2.8mm)
plug
into
player.
CAUTION
Be sure to test the volume on your player. Set it at a comfortable level so
that it does not startle your baby when turning it on. Loud volume can hurt
your baby’s ears. If you notice that the sound has become weak or distorted or if tracks do not change, this is an indication that your batteries are
low. Replace the batteries and set the volume at a comfortable level.
CAUTION
Before folding your stroller, be sure to remove your
player from the back pocket of the canopy.
This will make it easier to fold the stroller.
When you fold the stroller, you may leave the speakers in
the Acoustic Canopy, but only for short periods of time.
In the summer, the temperature may get as high as
212°F/100°C or more. Do not leave your stroller, with the
speakers in the Acoustic Canopy pockets, in your car trunk
where the temperature may reach high levels. Store
speakers in a cool and dry area.
Installing the Speakers
WARNING:
To avoid serious injury keep stereo
speakers and cords out of reach of
children.
Using the Front Swivel Wheels
To lock swivels, push both swivel
lock levers down.
To unlock swivels, lift both swivel
lock levers up.
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 5 -
Folding the Stroller
Using the Seat Extension
1. Lift the seat cushion and locate the seat extension.
2. Pull out the seat extension.
When not in use, push the seat extension back to the
original position.
Seat extension
CAUTION
Even when the seat belt is
fastened, be careful not to
let the child slip out or
stand.
1. Place the crotch belt between the baby's legs.
2. Insert both waist belt buckles into the middle
plastic piece.
3. Attach each shoulder
strap's hook to the top of
the waist belt clips.
4. To adjust the harness or
waist belt, loosen the slack
on both sides of each
buckle.
Using and Adjusting the 5-Point Harness
WARNING:
Avoid serious injury from
falling or sliding out. Always
use the 5-point harness.
1. Fold the canopy by lifting the canopy levers.
2. Remove your player from the back pocket of
the canopy.
3. Place seat in the upright position.
4. Hold the folding levers up on both sides of
the handle while completing step 5.
5. Tilt the stroller onto its back wheels and roll
forward. Then pull the handle back quickly to
fold front guardrail to backrest.
6. Turn handle inward with an underhand hold
to latch and lock.
Fold
Release
Lever
Auto
Folding
Latch
Turn inward to fold.
Using the Guardrail
1
2
1. Squeeze the guardrail release
buttons on both sides to
release the guardrail.
2. When one side is released,
the guardrail will pivot
to allow easy access to the
seating area.
3. When both sides are released the
guardrail can be removed.
4. To attach the guardrail slip it over the
armrest pins until you hear the pins
click into position.
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 6 -
Using the Basket
Using the Stroller Pack
CAUTION
Do not place more than 11 lbs. in the basket.
Remove all items from the basket before folding the stroller.
Removing
Unfasten clips on front and side of basket.
Attaching
Reverse the procedures for Removing.
Attaching
Hook the clips into the slots on the handle and wrap
the velcro straps around the handle.
Removing
Unfasten the velcro straps and unhook the clips.
Clips
Removing/Attaching the Seat Cushion
CAUTION
If seat cushion is ripped or torn, do not
use.
Do not use the stroller without the seat
cushion.
Removing
1. Unbuckle the 5-point harness
and pull all the straps through
the seat cushion.
2. Grasp the seat cushion at the
top and unfasten from the velcro.
Attaching
1. Pass the 5-point harness waist
belt straps through the appropriate locations of the seat
cushion.
2. Fasten the velcro.
WARNING:
To avoid burns, do not place bottles/cups with hot
liquids in the stroller pack. Do not place more than
2 lbs. in the stroller pack. Remove all items from
the stroller pack before folding.
Seat Base
Velcro
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 7 -
The Travel System Guardrail
WARNINGS
When the COMBI Infant Car
Seat/Carrier is in the stroller,
always lock into the COMBI Infant
Car Seat/Carrier Locks and Travel
System Guardrail.
The Travel System Guardrail is
only to be used when attaching
COMBI’s Infant Car Seat/Carrier.
Do not use for any other purpose.
To assure safety for the baby,
please refer to COMBI’s instructions for use with your COMBI
Infant Car Seat/Carrier.
If unable to securely attach
COMBI’s Infant Car Seat/Carrier
using the Travel System
Guardrail, discontinue use and
contact COMBI Customer
Service.
Do not carry stroller by using
COMBI’s Infant Car Seat/Carrier
handle.
Discontinue use if damage is
noted on the Travel System
Guardrail or the COMBI’s Infant
Car Seat/Carrier Locks on the
stroller.
Do not lean on or hang things
from the Travel System Guardrail.
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 8 -
Using the Travel System Guardrail
1. After removing the Kid’s Tray Guardrail attach the Travel
System Guardrail by slipping it over the armrest pins until
you hear the pins click into position. Gently tug on the
side, to be sure it is secure.
2. Recline the backrest to the middle position or lower.
CAUTION
Pull on each side of Travel System Guardrail to make
sure that it is completely attached.
ATTACHING THE TRAVEL SYSTEM GUARDRAIL
3. Lock the “V” slot of the COMBI Infant Car Seat/Carrier over
the Travel System Guardrail.
4. Rotate until the foot end of COMBI Infant Car Seat/Carrier
locks into the Infant Car Seat/Carrier Locks located on each
side of the handle.
5. Be certain that the COMBI Infant Car Seat/Carrier is
securely attached to the stroller by lifting up on the COMBI
Infant Car Seat/Carrier handle.
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 9 -
Removing the Infant Car Seat from the Travel System Guardrail
2. Lift up the front end of the COMBI
Infant Car Seat/Carrier to release
from the Carrier Locks located on
either side of the handle.
1. Locate the release lever and pull upward to unlock
the back of the COMBI Infant Car Seat/Carrier from the
Travel System Guardrail.
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 10 -
Routine Maintenance
STORE IN A COOL AND DRY AREA, especially in the summer. Do not store the stroller in the trunk of
a vehicle.
SEAT CUSHION
The seat cushion is machine washable. Set to gentle cycle using warm water and a mild detergent. Do not use
bleach. Lay seat cushion and canopy and car seat covers flat to dry in shaded area. Do not machine dry. To
prevent color fading, do not leave soaking for a long period. If the seat cushion is frayed or unraveling,
discontinue use and call customer service for further instruction.
CANOPY, SEAT BELT, FIXED BASE SEAT, TRAVEL BAG, STROLLER PACK AND BASKET
Hand wash with a soft brush. Wipe out excess water with a dry cloth and dry in a shaded area. For stubborn
dirt, dilute a mild detergent then apply directly to the dirty area. Wipe out the detergent.
MAIN BODY
Briskly wipe off any mud and dirt. To clean the body, wipe with a damp cloth then wipe out any traces of
moisture on the body with a dry cloth. The main body might become moldy and musty if not wiped dry.
Excessive exposure to the sun could cause premature color fading of stroller plastic and fabric.
WHEEL ASSEMBLIES
After prolonged normal use, the wheels of your stroller may not
swivel or turn as easily as when the stroller was new. This is
usually due to a buildup of dirt in the swivel mechanism. Before
adding lubrication, remove the swivel wheels by pressing the
release button and wiping off mud and dirt. Do not use soap
and water to wash wheels. Periodically check that all screws,
bolts and nuts are tight.
Avoid lubricating the swivel wheels whenever possible.
Excessive lubrication or adding lubricant to swivel wheels when
new may cause them to develop a shimmy or wobble that may
quicken their deterioration.
Add silicone* to the wheel assemblies in small amounts.
Do not use cooking oil or WD-40 because oil attracts dust and would hinder the movement rather than
improve it.
*Silicone spray is available in varying size cans at most hardware stores.
Front Swivel Wheel
Rear Wheel
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
- 11 -
STROLLER WON’T FOLD
- Check to see that the seat belt is not caught in the side.
- Make sure front swivels are locked.
- Make sure the backrest is in the upright position.
- Remove all items from the basket.
- Remove your player from back pocket of the canopy.
DIFFICULT TO STEER/STROLLER PULLS TO ONE SIDE
- Remove any items hanging from the handle.
- Make sure weight in basket is distributed evenly.
- Check that the brakes are not in the locked position.
- Clean and add silicone to wheels, if necessary.
DIFFICULT TO GET UP CURBS
- Pulling stroller backward makes going
up a curb difficult, and could pose a safety hazard.
Pull the handle up to lift the rear wheels
onto the curb, then pull the stroller backward
until the front wheels clear.
DIFFICULT GOING DOWN CURBS
- Turn stroller around, bringing rear wheels toward the edge of the curb. Gently lower rear
wheels onto the surface below. Once the rear wheels have landed, guide the front portion
of the stroller, using the armrest as support.
Trouble Shooting
COMBI International Corporation • 189-199 Easy St. • Carol Stream, IL 60188 • www.combi-intl.com
Customer Service 1-800-992-6624 • 10:00 a.m. - 5:00 p.m. Central Standard Time • Monday - Friday
Parts Order Form
If you would like to place an order for the following parts, please fill out the form below and return it to the
following address:
COMBI International Corporation or Fax this completed form to us at
Attn: Customer Service Department
189-199 Easy Street
Carol Stream, IL 60188
IMPORTANT:
We must have this information to process your order:
Model Number: 2800 - ____ Color & Pattern of Fabric: __________________________________________
Parts List for the Ultra Savvy™TS 2800.
Price Quantity Total
1. Acoustic Canopy $ 40.00
2. Should Pad Set 5.00
2. Basket 20.00
3. Seat Cushion 35.00
4. Standard Guardrail 15.00
5. Travel System Guardrail 10.00
6. Stroller Pack 15.00
7. Carrying Strap 12.00
8. Acoustic Canopy Speaker Set 10.00
9. Rear Wheel Assemblies (left and right sides) 20.00/set
10. Front Swivel Wheel Assemblies (left and right sides) 20.00/set
Amount of Order
ADD
Shipping & Handling
Sales Tax (7.25%)
(IL residents only)
Total
Ship To:
Customer Name
Street Address
Street Address
City, State, Zip
Telephone Number
■■ Charge to my credit card:
■■ VISA ■■ MASTERCARD
■■ AMERICAN EXPRESS ■■ DISCOVER
Card Number
Expiration Date
■■ ■■- ■■ ■■
Cardholder’s Signature
■■ Check enclosed
9/5/2003
630-871-0606
Located near the rear right leg.
Ultra Savvy™TS 2800
Travel System Stroller
Patent Pending
If you need to order other parts for your stroller, please call us
toll-free at 1-800-992-6624.
Shipping and Handling Fees: Add $5.00 for orders $34.99 and under.
Add $10.00 for orders $35.00 and over. Note: Additional shipping
charges will apply outside of the Continental U.S.
Loading...
