USER MANUAL
RA-7E00 III3 BR QE: 1-0-1
Comba Telecom Ltd.
RA-7E00
____________________________________________________________________________________________
_
The information contained herein is the responsibility of and is approved by the
following, to whom all enquiries should be directed in the first instance:
This is an unpublished work the copyright in which vests in Comba International
("Comba"). All rights reserved.
The information contained herein is confidential and the property of Comba and
is supplied without liability for errors or omissions. No part may be reproduced,
disclosed or used except as authorised by contract or other written permission.
The copyright and the foregoing restriction on reproduction and use extend to all
media in which the information may be embodied.
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 3
0.1 CONTENTS
Section
Page
0.1 CONTENTS ........................................................................................................................... 3
0.2 INDEX TO FIGURES AND TABLES ..................................................................................... 5
0.3 HISTORY ............................................................................................................................... 7
0.4 GLOSSARY OF TERMS ....................................................................................................... 8
0.5 SAFETY NOTICES AND ADMONISHMENTS ...................................................................... 9
1 GENERAL INFORMATION ................................................................................................. 10
2 EQUIPMENT DESCRIPTION .............................................................................................. 13
2.1 SYSTEM DIAGRAM ............................................................................................................ 13
2.2 TYPICAL APPLICATION ..................................................................................................... 14
2.3 MASTER UNIT ASSEMBLY ................................................................................................ 14
2.4 EQUIPMENT INTERNAL LAYOUT DIAGRAM ................................................................... 15
2.5 EQUIPMENT CONSTITUTION ........................................................................................... 16
2.6 KIT OF PART....................................................................................................................... 16
3 INSTALLATION ................................................................................................................... 17
3.1 WARNINGS AND ALERTS ................................................................................................. 17
3.2 SITE PLANNING CONSIDERATIONS ................................................................................ 18
3.2.1 SITE PLANNING ................................................................................................................. 18
3.2.2 SYSTEM INSTALLATION CHECKLIST .............................................................................. 19
3.3 INSTALLATION PROCEDURES ......................................................................................... 20
3.3.1 GOODS INWARDS INSPECTION ...................................................................................... 20
3.3.2 TOOLS ................................................................................................................................. 20
3.3.3 PREPARATION ................................................................................................................... 20
3.3.4 MU CARBINET MOUNTING ............................................................................................... 20
3.3.5 MU Installation ..................................................................................................................... 21
3.3.6 WALL MOUNTING OF RU .................................................................................................. 24
3.3.7 POLE MOUNTING OF RU .................................................................................................. 25
3.3.8 DRIP-LOOP ......................................................................................................................... 26
3.4 EQUIPMENT CONNECTORS ............................................................................................. 27
3.5 EQUIPMENT CONNECTION .............................................................................................. 29
3.5.1 GROUNDING CONNECTION ............................................................................................. 29
3.5.2 MU CONNECTION .............................................................................................................. 29
3.5.2.1. MU connects with BTS ........................................................................................................ 29
3.5.2.2. MU connects with fibre optic distribution box ....................................................................... 30
3.5.3 BTS ALARM CONNECTION ............................................................................................... 30
3.5.4 CONNECT TO PC ............................................................................................................... 31
4 COMMISSIONING ............................................................................................................... 32
4.1 PRE-COMMISSIONING TASKS ......................................................................................... 32
4.2 LED INDICATORS ............................................................................................................... 32
5 OMT ..................................................................................................................................... 33
5.1 LOCAL CONNECTIONS TO OMT ...................................................................................... 33
5.1.1 CONNECTION FROM PC TO OMT .................................................................................... 33
5.1.2 LOCAL CONNECTION TO OMT......................................................................................... 34
5.2 RF INFORMATION .............................................................................................................. 35
5.3 ALARM INFORMATION ...................................................................................................... 39
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 4
5.4 PROPERTIES INFORMATION ........................................................................................... 41
6 TROUBLESHOOTING ........................................................................................................ 46
7 APPENDICES ...................................................................................................................... 47
7.1 APPENDIX A: TOOLS FOR INSTALLATION AND MAINTENANCE .................................. 47
7.2 APPENDIX B: RMA (RETURN MATERIAL AUTHORIZATION) FORM ............................. 48
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 5
0.2 INDEX TO FIGURES AND TABLES
Figure 1: MU Enclosure ........................................................................................................................................... 11
Figure 2: Optical unit Enclosure .............................................................................................................................. 11
Figure 3: Duplexer Unit Enclosure .......................................................................................................................... 11
Figure 4: Front, Side and Bottom Views of RU Enclosure .................................................................................. 12
Figure 5: System Diagram ....................................................................................................................................... 13
Figure 6: Application of one MU with 8 RUs .......................................................................................................... 14
Figure 7: MU Modular Design ................................................................................................................................. 14
Figure 8: RU Layout Diagram .................................................................................................................................. 15
Figure 9: MU Carbinet Mounting ............................................................................................................................. 20
Figure 10: Mounting Rack ........................................................................................................................................ 21
Figure 11: Angle Iron or Laminate Installation ...................................................................................................... 21
Figure 12: MU Installation ................................................................ ................................ ........................................ 22
Figure 13: Fix the Enclosure .................................................................................................................................... 22
Figure 14: Finish Installaiton .................................................................................................................................... 23
Figure 15: Wall Mounting of RU ............................................................................................................................. 24
Figure 16: Mounting rack diagram ......................................................................................................................... 25
Figure 17: Hose Clamp Diagram ............................................................................................................................ 25
Figure 18: Hose Clamp Diagram ............................................................................................................................ 26
Figure 19: MU Front Panel Connectors ................................................................................................................. 27
Figure 20: Rear Panel Connectors (AC 110~220V in)......................................................................................... 27
Figure 21: MU Rear Panel Connectors (DC-48V in) ............................................................................................ 27
Figure 22: RU Connectors ....................................................................................................................................... 28
Figure 23: MU connect with BTS ............................................................................................................................ 29
Figure 24: Fibre Optic Port Connection Diagram ................................................................................................. 30
Figure 25: Pins Allocation for “BTS_ALM” Port .................................................................................................... 30
Figure 26: PC Protocol Setting ................................................................................................................................ 33
Figure 27: Connection Type .................................................................................................................................... 34
Figure 28: Connection via Ethernet ........................................................................................................................ 35
Figure 29: MU Switch ............................................................................................................................................... 35
Figure 30: RU Switch ................................................................................................................................................ 36
Figure 31: MU Alarm Threshold .............................................................................................................................. 36
Figure 32: RU Alarm Threshold .............................................................................................................................. 36
Figure 33: MU Power ................................................................................................................................................ 37
Figure 34: RU Power ................................................................................................................................................ 37
Figure 35: MU Gain................................................................................................................................................... 37
Figure 36: RU Gain ................................................................................................................................................... 38
Figure 37: MU Temperature .................................................................................................................................... 38
Figure 38: RU Temperature..................................................................................................................................... 38
Figure 39: MU Freq Band Config ............................................................................................................................ 39
Figure 40: RU Freq Band Config ............................................................................................................................ 39
Figure 41: MU Master Alarm ................................................................................................................................... 40
Figure 42: RU Master Alarm .................................................................................................................................... 40
Figure 43: MU Channel Alarm ................................................................................................................................. 40
Figure 44: RU Channel Alarm ................................................................................................................................. 41
Figure 45: MU Equipment ID ................................................................................................................................... 41
Figure 46: RU Equipment ID ................................................................................................................................... 42
Figure 47: MU Firmware Info................................................................................................................................... 42
Figure 48: RU Firmware Info. .................................................................................................................................. 42
Figure 49: MU Equipment Info. ............................................................................................................................... 43
Figure 50: RU Equipment Info. ................................................................................................................................ 43
Figure 51: MU Site Location .................................................................................................................................... 43
Figure 52: RU Site Location..................................................................................................................................... 44
Figure 53: MU System Clock ................................................................................................................................... 44
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 6
Figure 54: RU System Clock ................................................................................................................................... 44
Figure 55: MU Comm. Config. ................................................................................................................................ 45
Figure 56: RU Comm. Config. ................................................................................................................................. 45
Table 1: MU Dimension ............................................................................................................................................ 10
Table 2: RU Constitution .......................................................................................................................................... 16
Table 3: MU KOP ..................................................................................................................................................... 16
Table 4: RU KOP ..................................................................................................................................................... 16
Table 5: MU Connections ........................................................................................................................................ 27
Table 6: RU Connections ......................................................................................................................................... 28
Table 7: Pin Definition of “BTS_ALM” Port ............................................................................................................ 31
Table 8: MU LED Indicators .................................................................................................................................... 32
Table 9: RU LED Indicators ..................................................................................................................................... 32
Table 10: IP Setting Quick Look-up Table ............................................................................................................. 35
Table 11: Comm. Config. Parameter ..................................................................................................................... 45
Table 12: Alarms Diagnosis ................................................................ ................................ ..................................... 46
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 7
0.3HISTORY
Change No.
ENU
Details Of Change
1 1-0-0
This user manual first created in Oct 2012 which referred to its
Chinese manual RA-7E002-1001YH.
2
1-0-1
Update MU enclosure and OMT screenshot in Nov 2012.
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 8
0.4 GLOSSARY OF TERMS
ALC
Automatic Level Control
ATT
Attenuation
BS
Base Station
BTS
Base Transceiver Station
dB
Decibel
dBm
Decibels relative to 1 milliwatt
DL
Downlink
DPX
Duplexer
DT
Donor Terminal
EEPROM
Electrically Erasable Programmable Read Only Memory
E/O,O/E
Electrical/Optical, Optical/Electrical
Hz
Hertz
ID
Identification
LNA
Low Noise Amplifier
MCU
Main Control Unit
MHz
Megahertz
MT
Mobile Terminal
MTBF
Mean Time Between Failures
NC
Normally Closed
NF
Noise Figure
NO
Normally Open
OMC
Operation & Maintenance Center
OMT
Operation & Maintenance Terminal
OP
Optical Fiber
PA
Power Amplifier
PLL
Phase Locked Loop
POI
Point of Interconnects
PSU
Power Supply Unit
RF
Radio Frequency
RX
Receive
SMA
Sub-Miniature “A” Connector
TX/RX
Transmit/Receive
UL
Uplink
VAC
Volts Alternating Current
VSWR
Voltage Standing Wave Ratio
WCDMA
Wideband Code Division Multiple Access
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 9
0.5 SAFETY NOTICES AND ADMONISHMENTS
This document contains safety notices in accordance with appropriate standards. In the interests of
conformity with the territory standards for the country concerned, the equivalent territorial admonishments
are also shown.
Any installation, adjustment, maintenance and repair of the equipment must only be carried out by trained,
authorized personnel. At all times, personnel must comply with any safety notices and instructions.
Specific hazards are indicated by symbol labels on or near the affected parts of the equipment. The labels
conform to international standards, are triangular in shape, and are coloured black on a yellow
background. An informative text label may accompany the symbol label.
Hazard labeling is supplemented by safety notices in the appropriate equipment manual. These notices
contain additional information on the nature of the hazard and may also specify precautions.
Warning:
These draw the attention of personnel to hazards that may cause death or injury to the operator or others.
Examples of use are cases of high voltage, laser emission, toxic substances, point of high temperature,
etc.
Alert:
These draw the attention of personnel to hazards that may cause damage to the equipment. An example
of use is the case of static electricity hazard.
Caution notices may also be used in the handbook to draw attention to matters that do not constitute a risk
of causing damage to the equipment but where there is a possibility of seriously impairing its performance,
e.g. by mishandling or gross maladjustment. Warnings and Cautions within the main text do not
incorporate labels and may be in shortened form.
End of Section
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 10
1 GENERAL INFORMATION
The RA-7E00 Dual-band Distributed Antenna System (hereinafter called “RA-7E00”) consists of Master
Unit (MU) and Remote Unit (RU). MU is made up of main unit, duplexer unit and optical unit. The system
supports 800MHz and 1900MHz, suitable for iDEN, GSM, WCDMA signal coverage. It‟s advanced
monitoring function helps users remotely monitor and control the device parameter and status inquery
through Ethernet, at the same time, users can also locally configure the device through PC.
The low signal transmission loss of optical fiber is applicable for long distance transmission. RA-7E00 can
support the optical transmission of up to 10dB signal transmission loss.
Main feature:
Broad band optics system, system bandwidth is 15MHz for 800 band, 5MHz for 1900 band.
Optical fiber transmission with long distance transition at the most path loss of 10dB.
Has AGC function, automatic compensates path loss.
Local Operation and Maintenance Terminal (OMT): operating status and parameters can be set or
monitored by OMT PC locally. And the point-to-point setting and inquiry between MU and RU is
realizable through the integrated wireline/wireless modem, which makes it convenient for on-site
configuration.
Operation Maintenance Center (OMC): real time monitor, set and inquire device status information.
Build-in Li-ion battery ensures that alarm information can automatically report to OMC in case of
equipment power failure.
RU is designed for all-weather outdoor operation - waterproof, damp-proof and omni-sealed.
A dimension for MU is shown in table bellowed.
Table 1: MU Dimension
Item
LxWxH
Main Unit
330 ×439×177
Duplexer Unit
129×88×50
Optical Unit
164×49×26
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 11
The figures below show the equipment enclosure layout of RA-7E00:
PWR
RUN
ALM
MODEM BTS_ALM
LAN
OP OP OP
OP OP OP
Comba
1900MHz
OP
OP
800MHz
Figure 1: MU Enclosure
Figure 2: Optical unit Enclosure
Figure 3: Duplexer Unit Enclosure
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 12
RUN
PWROPALM
OMTOP
ANT
AC 110V-240V
50/60Hz
175
250
740
Figure 4: Front, Side and Bottom Views of RU Enclosure
End of Section
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 13
2 EQUIPMENT DESCRIPTION
2.1 SYSTEM DIAGRAM
Optical Fiber
MU
Distributed
Antenna
System
RU
Figure 5: System Diagram
On the DL, signals from the BTSs converted into optical signals after amplification in the MU.Then the
optical signals are transmitted to the RU via optical fiber. The Optical TX/RX Module of RU converts the
DL optical signals into RF signals. After amplification, the signals are transmitted at the MT port to the
service antenna.
On the UL, the signals transmitted by the mobile are converted into optical signals, and then via the UL
optical fiber. The signals are transmitted to MU, which then converts the optical signals back to RF
signals.
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 14
2.2 TYPICAL APPLICATION
Shown below is a typical application of one MU hosts 8 RUs.
RU
ANT
BTS
MU
OP IN/OUT
RU
OP
ANT
OP_A
OP_A
OP_A
OP_A
OP_A
OP IN/OUT
OP
1900MHz TX/RX
ANT
ANT
OP_A
OP_A
OP_A
RU
OP
RU
OP
RU
OP
ANT
ANT
ANT
RU
OP
RU
OP
RU
OP
OP IN/OUT
OP IN/OUT
OP IN/OUT
ANT
ANT
ANT
ANT
ANT
ANT
OP IN/OUT
OP IN/OUT
OP IN/OUT
800MHz TX/RX
Figure 6: Application of one MU with 8 RUs
2.3 MASTER UNIT ASSEMBLY
RA-7E00 MU is modular design. Below figure shows the assembly of MU.
PWR
RUN
ALM
MODEM BTS_ALM
LAN
OP_A OP_A OP_A
OP_A OP_A OP_A
Comba
Optical Unit
OP_A
OP_A
Main Unit
Duplexer Unit
1900MHz
800MHz
Figure 7: MU Modular Design
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 15
2.4 EQUIPMENT INTERNAL LAYOUT DIAGRAM
The internal layout for RU is shown below:
RX1 RX2
TX2
TX1
Li-ion Battery
GND
IN OK
OUT OK
28V+
JK+
BAT2+
BAT2-
JK-
9V+
9V-
28V-
Optical TX/RX Module
800MHz LNA
1900MHz LNA
800MHz PA
1900MHz PA
MCU
PSU
Arrestor
Combiner
Figure 8: RU Layout Diagram
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 16
2.5 EQUIPMENT CONSTITUTION
RU consists of the following conponents:
Table 2: RU Constitution
Identifier
Function Discription
Power Supply Unit
(PSU)
Converts the input voltage into stable DC to supply power for other modules.
Optical TX/RX Module
Completes optical signal and RF signal convertion, establish fiber-optic
signal link
PA Module
Amplifies the DL signal.
LNA Module
Amplifies the UL signal, has low noise feature.
Duplexer
Filters out the DL/UL signal
MCU
Control and monitor the operation parameter of RU
Li-ion Battery
Provide power supply to MCU after power failure.
2.6 KIT OF PART
Table 3: MU KOP
Identifier
Function Discription
Qty
Power Cable
4m
1
Ethernet Cable
RJ45, 2m
1
Right Angle Iron
RA-0100DE05-5825
1
Left Angle Iron
RA-0100DE05-5826
1
Table 4: RU KOP
Identifier
Function Discription
Qty
Power Cable
1
Masonry Bolt
M10×110
4
Hex Nut
M10
4
Key 2
Hose Clamps
Φ60-Φ260
2
Mounting rack
2
Plain Washer
Φ10
4
Spring Washer
Φ10
4
Fiber Adapter
DLC-06T-LJ
1
GND Wire
BVR10mm2,2m
1
End of Section
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 17
3 INSTALLATION
3.1 WARNINGS AND ALERTS
Laser
Laser light can cause damage to eyes. Laser light is not visible. Viewing it directly does not cause pain.
The iris of the eye will not close when viewing a bright light. Consequently, serious damage to the retina of
the eye is possible. NEVER LOOK INTO THE END OF A FIBER WHICH MAY HAVE A LASER
COUPLED TO IT.
Radio Frequency Energies
There may be situations, particularly for workplace environments near high-powered RF sources, where
recommended limits for safe exposure of human beings to RF energy could be exceeded. In such cases,
restrictive measures or actions may be necessary to ensure the safe use of RF energy.
High Voltage
The equipment has been designed and constructed to prevent, as far as reasonably, practicable danger.
Any work activity on or near equipment involving installation, operation or maintenance must be, as far as
reasonably, free from danger.
Where there is a risk of damage to electrical systems involving adverse weather, extreme temperatures,
wet, corrosive or dirty conditions, flammable or explosive atmospheres, the system must be suitably
installed to prevent danger.
Protective Earthing
Equipment provided for the purpose of protecting individuals from electrical risk must be suitable for the
purpose and properly maintained and used.
Handling Precautions
This covers a range of activities including lifting, lowering, pushing, pulling, carrying, moving, holding or
restraining an object, animal or person. It also covers activities that require the use of force or effort, such
as pulling a lever, or operating power tools.
Electrostatic Discharge (ESD)
Observe standard precautions for handling ESD-sensitive devices. Assume that all solid-state electronic
devices are ESD-sensitive. Ensure the use of a grounded wrist strap or equivalent while working with
ESD-sensitive devices. Transport, store, and handle ESD-sensitive devices in static-safe environments.
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 18
3.2 SITE PLANNING CONSIDERATIONS
3.2.1 SITE PLANNING
Site Considerations
The MU can be located indoors to facilitate coupling of BTS signals and power supply connections. The
ALC range of received BTS signal is -10~10 dBm. Hence, an appropriate coupler must be used according
to the BTS output power.
The site consideration for RU is listed below:
The distance between the service antenna of RU and coverage area should satisfy line of sight
requirements for maximum coverage area.
The maximum fiber length is 20km, with a maximum path loss of 10dB.
The system delay of the optical system must be taken into consideration when there are neighboring
BTS sites overlapping in coverage.
Installation Location
Mounting surface shall be capable of supporting the weight of the equipment.
In order to avoid electromagnetic interference, a proper mounting location must be selected to minimize
interference from electromagnetic sources such as large electrical equipment.
Environmental
Humidity has an adverse effect on the reliability of the equipment. It is recommended to install the
equipment in locations having stable temperature and unrestricted air-flow.
The installation location for the system should be well ventilated. The equipment has been designed to
operate at the temperature range and humidity level as stated in the product specifications.
Powering
The power supply unit (PSU) provides power to all modules within the equipment. Depending on the
product variant, it is recommended that the PSU operates on a dedicated AC circuit breaker or fused
circuit.
Grounding Requirement
Verify that the equipment has been well grounded. This includes antennas and all cables connected to the
system. Ensure lightning protection for the antennas is properly grounded.
Cable Routing
Depending on equipment configuration, a variety of types of cables are connected to the MU and RU:
coaxial cables, optical fibers, power cable, communication cable, and commissioning cable. Where
applicable, ensure cables are properly routed and secured so that they are not damaged.
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 19
Manual Handling
During transportation and installation, take necessary handling precautions to avoid potential physical
injury to the installation personnel and the equipment.
3.2.2 SYSTEM INSTALLATION CHECKLIST
Working space available for installation and maintenance for each mounting arrangement. Ensure
unrestricted airflow.
Ensure earthing point is within reach of the ground wire.
Ensure a power source is within reach of the power cord and the power source has sufficient capacity.
Where appropriate, ensure unused RF connectors are terminated.
Where appropriate, ensure unused optical fiber connectors are protected.
Do not locate the equipment near large transformers or motors that may cause electromagnetic
interference.
Reduce signal loss in feeder cable by minimizing the length and number of RF connections.
Ensure the equipment will be operated within the stated environment (refer to datasheet).
Where needed, couple BTS RF signal with a coupler to prevent damaging the equipment.
Where appropriate, confirm available of suitably terminated grade of RF and optical fiber.
Observe handling of all cables to prevent damage.
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 20
3.3 INSTALLATION PROCEDURES
3.3.1 GOODS INWARDS INSPECTION
RA-7E00 was factory tested, inspected, packed, and delivered to the carrier with utmost care. Do not
accept shipment from carrier which shows damage or shortage until the carrier's agent endorses a
statement of the irregularity on the face of the carrier's receipt. Without documentary evidence, a claim
cannot be processed.
Open and check each package against the packing list. For any shortage, contact Comba Telecom
Systems. Do not remove items from packing materials until installation.
3.3.2 TOOLS
See Appendix B for a full list of tools required for installation and maintenance.
3.3.3 PREPARATION
Optical Fiber:
Fiber optic cables require proper handling. Do not stretch, puncture, or crush the fiber cable(s) with
staples, heavy equipment, doors, etc.
Always maintain the minimum bending radius specified by the cable manufacturer. The minimum
bend radius is usually 10 times as the cable's outer diameter. In the case of single optical fiber that is
not in a cable, the minimum bending radius to be observed is 3cm.
3.3.4 MU CARBINET MOUNTING
Figure 9: MU Carbinet Mounting
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 21
3.3.5 MU Installation
MU is an indoor type device; the installation procedures are shown as below:
Step 1: install right angle iron and left angle iron or laminate in the mounting rack.
Figure 10: Mounting Rack
Figure 11: Angle Iron or Laminate Installation
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 22
Step2: Level MU in angle iron or laminate.
Figure 12: MU Installation
Step 3: Fix the enclosure
Figure 13: Fix the Enclosure
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 23
Step 4: Finish installation.
Figure 14: Finish Installaiton
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 24
3.3.6 WALL MOUNTING OF RU
Wall mounting steps are shown as below.
Step 1: Punch mounting holes of monsery bolts in the wall according to the spacing size of the RU
mounting holes.
Step 2: Fix four monsery bolts (M10×110) in the wall.
Step 3: Hook the enclosure on the mansery bolt, and then tighten four M10 nuts on top and bottom
of the enclosure.
Step 4: Check if the chassiss be firmly installed, ensure the lock and hasp are fastened.
Step 5: Finish installation.
M10 Nut PHI.10 Spring Washer PHI.10 Plain Washer
M10 Monsery Bolt
Figure 15: Wall Mounting of RU
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 25
3.3.7 POLE MOUNTING OF RU
The diagram of mounting rack and hose clamp which used in pole mounting are shown as below.
Figure 16: Mounting rack diagram
Figure 17: Hose Clamp Diagram
Screw
Shell
Zone
circle
Was
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 26
Pole mounting steps are shown as below.
Step 1: Secure the Mounting rack onto the pole using hose clamps.
Step 2: Hook the enclosure up onto the studs of mounting rack, then tighten four M10 nuts (spring
washer and plain washer should be used with nuts together).
Step 4: Check if the chassiss be firmly installed, ensure the lock and hasp are fastened.
Step 5: Finish installation..
M10 Nut PHI.10 Spring Washer PHI.10 Plain Washer
Hose Clamp
Mounting Rack
Pole (PHI.60~110)
Figure 18: Hose Clamp Diagram
3.3.8 DRIP-LOOP
Comba recommends that every horizontal cable entry to the equipment forms a 'U' before it‟s entry to the
equipment. Any accumulated water on the cable will drip down at the bottom of the loop and will not climb
up to the equipment.
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 27
3.4 EQUIPMENT CONNECTORS
RA-7E00 is designed for all cables entries from the bottom of the enclosure. The figures below present the
connectors of RA-7E00.
PWR
RUN
ALM
MODEM
BTS ALM
LAN
Figure 19: MU Front Panel Connectors
AC 100V-240V 50Hz/60HzBATTERY
Figure 20: Rear Panel Connectors (AC 110~220V in)
BATTERY
N
C
0
-48V
Power
Figure 21: MU Rear Panel Connectors (DC-48V in)
Table 5: MU Connections
Identifier
Functional Description
POWER
A power supply cable for power supply
OP
OP uplink/downlink SC/APC optic connector.
MODEM
DB15 female connector, Modem expansion port.
LAN
RJ45 Ethernet connector, OMT commissioning port.
BTS_ALM
DB9 female connector, reports alarm to BTS.
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 28
OP
PWR
RUN
ALM
OP
OMT
AC 110V-240V
50/60Hz
ANT
Figure 22: RU Connectors
Table 6: RU Connections
Identifier
Functional Description
AC100V～240V
AC110/220V Power supply interface
Grounding port
ANT
N-F connectors, antenna system connection port
OP
SC/APC optical fiber access port, for downlink and uplink connection
OMT
RJ45 ethernet connector, connects with PC to fulfill local commissioning
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 29
3.5 EQUIPMENT CONNECTION
3.5.1 GROUNDING CONNECTION
Ground connection
To ensure safe operation of the product, a ground (earth) connection is required. For single phase AC
power source, the product must be grounded by connecting the “earth wire” of the power cord to the
ground terminal of the AC supply. For operating this product with DC power system (such as rectifiers),
the product should not be connected to power systems that switch open the return lead because the
return lead could function as the ground (earth) connection for the equipment.
Protective Ground Connection
The enclosure must be grounded securely by connecting a copper wire (CSA 16mm2) to the grounding
terminal on the equipment/rack, and the other end to a protective ground (i.e. building earth point). An
internationally acceptable colour code of the ground connection wire is green/yellow.
Such a ground connection implements the “Protective Ground Connection”, and must be connected to the
equipment at the designated ground point. In general, do not connect the supply before establishing an
adequate ground (earth) connection.
RA-7E00 Grounding Connection
The equipment must be grounded securely. Connect a copper wire to the grounding terminal on the
mounting tab/enclosure, and connect the other end to a protective ground (i.e. building earth point). An
internationally acceptable coloring code of the ground connection wire is green/yellow.
3.5.2 MU CONNECTION
3.5.2.1. MU connects with BTS
Connect MU with BTS by suitable RF jumper cables as shown in the following figure.
PWR
RUN
ALM
MODEM BTS_ALM
LAN
OP_A OP_A OP_A
OP_A OP_A OP_A
Comba
OP_A
OP_A
1900 BTS800 BTS
1900MHz
800MHz
Figure 23: MU connect with BTS
Note:
MU RF interface is duplex; connect an extra combiner between BTS and MU if the BTS signal is
TX/RX seperately
RF connectors are SMA-F type; use SMA-M for connection.
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 30
The recommended input power is 0~+10dBm, users should calculate BTS signal source input loss
accurately to make sure it is in coverage range.
3.5.2.2. MU connects with fibre optic distribution box
MU is connected with fibre optic distribution box via fiber cables; the connector is SC/APC type. The
connection diagram is shown in the below figure.
PWR
RUN
ALM
MODEM BTS_ALM
LAN
OP_A OP_A OP_A
OP_A OP_A OP_A
Comba
OP_A
OP_A
Fibre Optic Distribution Box
1900MHz
800MHz
Figure 24: Fibre Optic Port Connection Diagram
Note: The length of optical fiber should be larger than the distance between MU and fibre optic distribution
box due to some cable specification requirements.
3.5.3 BTS ALARM CONNECTION
The equipment alarms can be signaled to the BTS via voltage-free relay contacts. The voltage-free relay
connections are connected to the DB-9 port “BTS_ALAM” located on the MU. The following figure and
table shows the pin allocation and definition.
1
2
4
3
5
6
7
9
8
BTS_OPEN
BTS_CLOSE
BTS_ COM
Figure 25: Pins Allocation for “BTS_ALM” Port
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 31
Table 7: Pin Definition of “BTS_ALM” Port
Pin Number
Definition
Description
1
BTS_OPEN
Connects to the open terminal of the voltage free relay.
2
BTS_COM
Connects to the common terminal of the voltage free relay.
3
BTS_CLOSE
Connects to the close terminal of the voltage free relay.
4 ~ 9
NC
Reserved.
Depending on OMT/OMC configuration, alarm to BTS can be signalled equipment by either: a) pin1 and
pin2 „open‟ or b) Pin2 and Pin3 „close‟.
3.5.4 CONNECT TO PC
The local commissioning and management for MU and RU is achieved through connecting to the OMT
PC locally.
Connect MU to PC
Connect ”OMT” port (RJ45) to the serial port of PC with ethernet cable supplied to achieve local
monitoring and management. A build-in wireless modem is available for OMC connection to realize
remote commissioning.
Connect RU to PC
Local commissioning and management of RU is achieved through “OMT” port and the OMT PC via field
commissioning cable supplied.
With the equipment enclosure opened, the engineering OMT can be used to connect internally.
End of Section
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 32
4 COMMISSIONING
4.1 PRE-COMMISSIONING TASKS
After equipment installation, perform the following steps before equipment powering and commissioning,
check that the expected voltage, current, and power levels do not violate any ratings. Double check all
connections including ground before applying power. Do not manipulate circuits or make changes when
power is applied:
Visually inspect the power connection within the equipment. Ensure that the power cable is correctly
and securely connected, including grounding wire, RF cable and optical cable.
Check grounding connection and verify that the ground resistance is less than 5Ω.
Connect the equipment to the PC installed with OMT software.
With the MU switched on, RU installed and all cablings connected, apply power to the RU by switching
on the PSU switch on the integrated PSU.
Monitor the initialization of the MU though the LEDs on the front panel of MCU unit, while for RU, it is
through the LEDs on the MCU unit integrated. Refer to detailed LEDs information in the next section.
4.2 LED INDICATORS
Diagnostic LEDs are located on the MU and RU panel; each indicates the status of a particular function:
Table 8: MU LED Indicators
Identifier
Color
Indication
PWR
Green
It stands in green when power on.
RUN
Green
Operation indicator – power is supplied to the MU. Flashes once every
second to indicate normal system operation.
ALM
Red
Alarm indicator. ON = alarm; OFF = no alarm
Table 9: RU LED Indicators
Identifier
Color
Indication
PWR
Green
It stands in green when power on.
RUN
Green
Operation indicator. Flashes at equal intervals to indicate normal system
operation.
ALM
Red
Alarm indicator. ON = alarm; OFF = no alarm
OP
Green
Optical receiver indicator, lights on when optical power received normal,
lights off when received optical power is less than -10dBm.
End of Section
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 33
5 OMT
The equipment can be monitored and controlled by OMT software running on a local PC with local
commissioning cable.
OMT software running on a local PC with serial connection to the equipment.
This chapter is to introduce how to apply local connection to OMT for the first installation, for the detailed
OMT information, please refer to OMT user manual and other references.
5.1 LOCAL CONNECTIONS TO OMT
After installing OMT software on the PC, connection to the equipment can be done locally.
Double click the OMT explorer icon, the OMT Explorer main screen window will appear.
5.1.1 CONNECTION FROM PC TO OMT
Before accessing to the OMT, physical connection between the OMT software and the equipment must be
made. A straight-through RJ45 cable shall be applied for the connection.
In order to access to equipment by IP protocol, the PC must be set with proper IP address and subnet
mask.
Figure 26: PC Protocol Setting
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 34
5.1.2 LOCAL CONNECTION TO OMT
After database configuration is done successfully, the following window will pop up and select [Local
connection via Ethernet] for local connection.
Figure 27: Connection Type
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 35
Figure 28: Connection via Ethernet
Table 10: IP Setting Quick Look-up Table
Items
Default Value
PC IP Address
192.168.8.X (X=1~100 or 102~254)
Device IP Site Port
NO.
7090 (defaults)
PC Subnet Mask
255.255.255.0
Repeater IP Address
192.168.8.101
Input the IP address and the Port No.and click “Connect”, it will enter into the main window of OMT.
5.2 RF INFORMATION
It is recommended to configure the following RF parameters for the first installation.
Switch
Switch is to enable/disable power for internal modules. When user checks and sets non-RF parameters,
such as checking physical antenna connection, switching off will disable equipment power temporarily to
protect PA in operation.
Figure 29: MU Switch
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 36
Figure 30: RU Switch
Config:
Select the required state in setting columns of RF information window for RF switch, then press [Enter] or
[Config] button to finish the configuration operation.
Alarm Threshold
Users can set alarm threshold according to the specific situation. If the measured value is lower than the
threshold lower limit or more than the threshold upper limit, the appropriate alarm will be generated.
Figure 31: MU Alarm Threshold
Figure 32: RU Alarm Threshold
Config:
Enter the required value in setting columns of RF information window for Alarm threshold, and press
[Enter] or [Config] button to finish the configuration operation.
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 37
Power
Users can read downlink output power of each frequency band in RF information window for Power.
Figure 33: MU Power
Figure 34: RU Power
Gain
Users can adjust gain of each frequency band in RF information window for Gain.
Figure 35: MU Gain
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 38
Figure 36: RU Gain
Config:
Enter the required value in setting columns of RF information window for Gain, and press [Enter] or
[Config] button to finish the configuration operation.
Temperature
Users can get device temperature information in Temerature window.
Figure 37: MU Temperature
Figure 38: RU Temperature
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 39
Freq Band Config
Figure 39: MU Freq Band Config
Figure 40: RU Freq Band Config
[Freq. Band Config]: input frequency band in setting columns of RF information window for Freq. Band
Config, then press [Enter] or [Config] button to finish the configuration operation.
For MU, users should set frequency band according to the band of dupexer Unit insert into the slot of
MU. For RU, the band configuration has been set OK before factory, no need to set on site.
Completion of the band configuration required to reset the MCU.
Wrong set of Freq. Band Config will not cause any inpect to device operation.
When connect with OMC, this paremeters will appear on OMC.
5.3 ALARM INFORMATION
Click any tree node in [Alarm Info] group, [Alarm Information] window will appear in the right side. The
figures below show the alarm information.
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 40
Master Alarm
Figure 41: MU Master Alarm
Figure 42: RU Master Alarm
Channel Alarm
Figure 43: MU Channel Alarm
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 41
Figure 44: RU Channel Alarm
5.4 PROPERTIES INFORMATION
Equipment ID
Equipment ID is to be configured after local commission has been completed.
MU Equipment ID includes Site ID, Site Sub ID and slave site sub ID. Set site ID according to the real
situation, the site sub ID should be 00, the slave site sub ID should be set according to numbers of RU. FF
means null.
RU Equipment ID includes Site ID and Site Sub ID. Site ID should be consistent with MU Site ID, Site Sub
ID should be consistent with the list of MU slave site sub ID, otherwise, MU and RU cannot communicate
successfully.
Figure 45: MU Equipment ID
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 42
Figure 46: RU Equipment ID
Firmware Info.
Figure 47: MU Firmware Info.
Figure 48: RU Firmware Info.
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 43
Equipment Info.
Figure 49: MU Equipment Info.
Figure 50: RU Equipment Info.
Site Location
Figure 51: MU Site Location
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 44
Figure 52: RU Site Location
[Site Location]: input the current longitude and latitude in the blank.
System Clock
Figure 53: MU System Clock
Figure 54: RU System Clock
[System Clock]: it shows the current time/date information. It is settable.
Comm. Config
The Comm. Config information requires to be manually entered by users after successful connection to
the equipment.
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 45
Figure 55: MU Comm. Config.
Figure 56: RU Comm. Config.
Table 11: Comm. Config. Parameter
SMSC NO. (Equipment
SIM Card)
The SMS centre number of SIM card in equipment.
OMC Server IP
OMC IP Address. For equipment which support TCP/IP.
OMC IP Port No.
OMC IP Port No. For equipment which support TCP/IP.
GPRS User Name
Login GPRS network user name.
GPRS Password
Login GPRS network password.
Alarm Notice Phone NO.
The telephone number of alarm receiver.
Alarm Notice Phone NO.
Enable
Enable the telephone number of alarm receiver.
End of Section
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 46
6 TROUBLESHOOTING
Following installation and commissioning, occasional operation tasks to handle alarms may be required:
Table 12: Alarms Diagnosis
Alarm condition
Diagnosis
AC Power Failure Alarm/ DC
Power Fault Alarm
Check AC power cable and verify AC mains supply is normal.
During Power Fault alarm, DC power supply has no output. Check if
DC output power is overloaded or short-circuited. The PSU could be
faulty.
Li-ion Battery Fault Alarm
Check the connection between battery and power supply cable. Or
replace the faulty modules and return it to the factory for repair.
External Alarm
Check to make sure if the external device connected is working
normally
Over- Temperature alarm
Eliminate alarm by correct setting of temperature threshold, if alarm
can not be cleared, apply climatic protection to the system under
severe environment.
Door Open Alarm
Check whether the enclosure door is closed.
Shutdown Alarm
Alarm occurs when automatically shut off the system. Turn on the
system and check if the DL output power overload alarm persists,
adjust the DL output power overload threshold to a proper value.
Optical TX/RX Alarm
The optical power at the TX/RX port of the Optical TX/RX Module is
lower than the minimum requirement, which is resulted by the faulty
of the optical TX/RX part of Optical TX/RX Module or damaged
optical fiber link. If so, replace the optical TX/RX module. If not,
check the working status of the optical fiber to eliminate the alarm.
UL LNA, DL PA alarms
Check power and signal connections of respective modules. If the
power and signal wire connections are OK, then the respective
modules may be faulty. Replace the faulty modules and return it to
the factory for repair.
DL Input Power Overload
Alarm
Eliminate alarm by correct setting of DL Input Power Overload
threshold. If the setting is OK but alarm persists, the DL input power
might be higher than the threshold. Decrease the gain to reduce the
input power or replace the coupler with a new one of high coupling
effect.
DL Output Power Overload
Alarm
Eliminate alarm by correct setting of DL Output Power Overload
threshold. If the setting is OK but alarm persists, the DL output
power might be higher than the threshold. Decrease the gain to
reduce the output power.
DL Output Power Low Alarm
Eliminate alarm by correct setting of DL Output Power Low
threshold. If the setting is OK but alarm persists, the DL output
power might be lower than the threshold. Increase the gain to high
up the output power.
External Alarm
Check to make sure if the external device connected is working
normally
End of Section
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 47
7 APPENDICES
7.1 APPENDIX A: TOOLS FOR INSTALLATION AND MAINTENANCE
The following are the recommended list of tools new installation and routine maintenance:
Electronic drill
Allen Key
Adjustable spanner (Assorted size: 0.31~0.79 inch)
Philips Screwdriver
USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 48
7.2 APPENDIX B: RMA (RETURN MATERIAL AUTHORIZATION) FORM
End of Section
End of Document
USER MANUAL FOR RA-7E00 III3
ENU STATUS : 1-0-1
Copyright - refer to title page
Page 49
Loading...
