ColorMaker T10 User Manual

Introduction

The PX-T10 is the most advanced wireless LED controller on the market today. The PX-T10 design is an
accumulation of years of research and development by ColorMaker inc. The PX-T10 is a microprocessor based
system that can be updated by the user as new software is developed. The hardware was designed with more memory
and features we could ever use so we are only limited by our imagination.

This manual was written by the PX-T10 software developers at ColorMaker. We have tried to explain the numerous
features the PX-T10 has to offer in the simplest terms possible. We understand the user will not think like a software
developer and understand our technical language so we have 9am to 9pm technical support for the confused user. We
have take thousands of technical calls and have a good understanding where users are most confused and have tried to
explain less technical terms in this manual. All we ask is that you take the time to read and the rest will fall into place
with a few phone calls.

The PX-T10 basic functions can be learned in a just a few easy steps and will cover lessons in this manual. The more
complicated features can be mastered is just under an hour. As always we have 9am to 9pm technical support (407)
862-3363 and 24/7 email support [e-mail]. The lessons in this manual have been written to provide the
user with start up information to get up and running is just a few minutes. We will then take you into the fi xture color
editing with the various functions and discuss how each function will work. This will be followed by scene control
and we will teach you how to record and play scenes. The fi nal lesson will be using the ColorRoll features and how it
will senselessly integrate into the controls.

Below is a list of new features that will be covered in detail in this manual

1) Group Control

2) Master Dimmer Controls

3) Full ON/OFF Buttons

4) 10 Color Presets

5) ColorRoll STOP

6) F Save

7) SFCP (Single Fixture Color Programming)

8) Display in Percent or DMX

9) Battery Level Monitor

Keypad buttons and Functions

The PX-T10 has 30 buttons to control up to 90 individual fi xtures. Each button was graphically designed to represent
a function. Some button functions will change when used with multi button press such as the shift button. All these
functions will be covered in detail later in this manual and followed by lessons and procedures.

Master control

This is the UP and Down control of the master dimmer. When pressed
all fi xtures on the remote network address will be dimmed by the
setting from 0 to 100%. When dimmer is not at 100% (Full ON) the
LED indicator marked Master will light.

RGB controls

This is the UP and Down control for the RGB (Red,
Green and Blue) color settings. These will also be
used when a ColorRoll is active to adjust the Roll,
Rate and Flash controls of the ColorRoll

Full Button

This is a one of the multi button controls. When pressed with the RGB
controls the current color will advance to full on or full off.

Preset Button

This is another multi button control. When pressed with the Q1
through Q10 buttons the color in the circle will be the preset color
that will be sent to the controls.

Fixture Select buttons are multi
function buttons. The will be used to
select a fi xture, Change networks and
select a color preset.

ColorRoll Select buttons. These will also be used to make changes to the PX-T10 function
controls.

ColorRoll Stop will be used to terminate a ColorRoll and a single channel. This is also a control button to set
the LED display to read out in Decimal (DMX) or Percentage 0%-100%.

Go Button used to execute a group control feature. This will also be used to display PX-T10 battery power
level.

Play Button use to play a scene

Record Button used to record a scene. This will also be used to command all fi xtures to store its current color

into memory.

SFCP (Single Fixture ColorRoll Programming) This is a multi button control. When pressed along with the
Q1 through Q10 this will also the user to program ColorRolls using a single fi xture. This will also be used to
restore the PX-T10 to default factory settings.

Shift Button used to select multi function controls

Blackout used to turn all fi xtures OFF

1

Display Features

The PX-T10 has 4 LED indicators, 3 digit display and an RGB color
simulator to assist the user in remote navigation. These indicators will be
explained in more details in this manual as we guild you through each of
the features. The 4 LED indicators each with a single word to illustrate
what they will identify during programming. Here is a brief description:

Master indicator will light when master value is below 100%.

ColorRoll indicator will light when the RGB Up and DN buttons are for editing the ColorRoll Rate, Follow and

Flash values.

ALL indicator will light when Q10 (ALL) button was pressed to target all fi xtures on the current network.

Group indicator will light when the user has preselected a group of fi xtures for editing.

RGB Color Simulator is the larger LED just to the left of the 3 digit display. This will emit the same color as the

current fi xture that is being edited. This is useful during programming and allow the user to make changes to fi xture
color without needing a fi xture to visually see the colors.

3 Digit LED Display is a numeric display that will also show alpha characters to guild the user in programming.

Display Power Down is a battery save feature that will turn off the display after 10 minutes of non use. By pressing

any button the display will activate.
