Coleman FC8T060A12UH11, LC8T080A12UH11, FC8T080A12UH11, LC8T080B16UH11, FC8T080B16UH11 Technical Manual

TECHNICAL GUIDE

Echelon
MODELS: FC8T-UH/LC8T-UH

GAS-FIRED
HIGH EFFICIENCY TWO STAGE
UPFLOW/HORIZONTAL FURNACES

STANDARD & Low NOx
80% AFUE

NATURAL GAS
40 - 120 MBH INPUT

EFFICIENCY
RATING
CERTIFIED

ISO 9001

Certified Quality

Management System

Due to continuous product improvement,
specifications are subject to change without notice.

Visit us on the web at www.york.com for the most
up-to-date technical information.

Additional rating information can be found at
www.gamanet.org.

246756-CTG-C-0407

DESCRIPTION

These high efficiency, compact units employ induced com­bustion, reliable hot surface ignition and high heat transfer
tubular heat exchangers. The units are factory shipped for
installation in upflow or horizontal applications.

These furnaces are designed for residential installation in a
basement, closet, alcove, attic, recreation room or garage
and are also ideal for commercial applications. All units are
factory assembled, wired and tested to assure safe depend­able and economical installation and operation.

These units are Category I listed and may be common
vented with another gas appliance as allowed by the
National Fuel Gas Code.

WARRANTY

20-year limited warranty on the heat exchanger.
10-year heat exchanger warranty on commercial applica­tions.
5-year limited parts warranty.

FEATURES

• Two stage heating operation includes:

- Two stage gas valve

- Two stage inducer operation

- Two speed blower operation

• Provides increased comfort level & very quiet unit oper­ation

• Adjustable delay timer allows two stage operation with
single stage thermostat

• Compact, easy to install, ideal height 40" cabinet

• Blower-off delay for cooling SEER improvement.

• Easy to connect power/control wiring.

• Built-in, high level self diagnostics with fault code display.

• Low unit amp requirement for easy replacement applica-

tion.

• Integrated control module for reliable, economical opera-

tion.

• Electronic Hot Surface Ignition saves fuel cost with

increased dependability and reliability.

• Induced combustion system with inshot main burners for

quiet, efficient operation.

• 100% shut off main gas valve for extra safety.

• PSC -four speed, direct drive motor with large, quiet

blower.

• 24V, 40 VA control transformer and blower relay supplied

for add-on cooling.

• Hi-tech tubular aluminized steel primary heat exchanger.

• Timed on, adjustable off blower capability for maximum

comfort.

• Solid removable bottom panel allows easy application.

• Easy access from front of unit for cleaning, maintenance

or service.

• Insulated blower compartment for quiet operation.

• Independent door removal for greater durability and ease

of access.

• Low NOx models have been designed to meet specific

code requirements.

• Low NOx models may not be converted to propane unless

screens are removed.

FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE

246756-CTG-C-0407

B

A

FRONT

3/4

40

26-3/4

20

13-3/4

GAS INLET
1-1/4 x 2-1/2

T’STAT WIRING
7/8” K.O.

30-1/8

LEFT SIDE

1-1/2

1-1/4

4” Diameter

(VENT CONNECTIONS)

POWER WIRING
7/8” HOLE

2-1/2

32-1/2

ACCESS
WIRING
7/8” K.O.

16

8-3/4

20

5-3/8

2

5/8

14

23-1/2

RIGHT SIDE

5/8

14-3/4

2-1/4

1-1/8

BOTTOM IMAGE

RETURN END

C

4” Diameter

D

24-3/4

TOP IMAGE

SUPPLY END

B

CABINET AND DUCT DIMENSIONS

Models CFM Cabinet Size

ABCD

FC8T040A12UH11 1200 A 14 1/2 13 1/4 11 1/2 10 1/8
(F,L)C8T060A12UH11 1200 A 14 1/2 13 1/4 11 1/2 10 1/8
(F,L)C8T080A12UH11 1200 A 14 1/2 13 1/4 11 1/2 10 1/8
(F,L)C8T080B16UH11 1600 B 17 1/2 16 1/4 14 1/2 11 5/8
(F,L)C8T080C16UH11 1600 C 21 19 3/4 18 13 3/8

FC8T100B12UH11 1200 B 17 1/2 16 1/4 14 1/2 11 5/8
(F,L)C8T100C20UH11 2000 C 21 19 3/4 18 13 3/8

FC8T120C16UH11 1600 C 21 19 3/4 18 13 3/8
(F,L)C8T120C20UH11 2000 C 21 19 3/4 18 13 3/8

Cabinet Dimension

RATINGS & PHYSICAL / ELECTRICAL DATA

Blower

Size

Operation

Weight

Models

Input/Cabinet

High/Low

Output BTU/H

High/Low

Nominal

Airflow

Cabinet Width

AFUE

MBH MBH CF M In Hp Amps In

FC8T040A12UH11
(F,L)C8T060A12UH11
(F,L)C8T080A12UH11
(F,L)C8T080B16UH11
(F,L)C8T080C16UH11

FC8T100B12UH11
(F,L)C8T100C20UH11

FC8T120C16UH11
(F,L)C8T120C20UH11

Models

FC8T040A12UH11
(F,L)C8T060A12UH11
(F,L)C8T080A12UH11
(F,L)C8T080B16UH11
(F,L)C8T080C16UH11

FC8T100B12UH11
(F,L)C8T100C20UH11

FC8T120C16UH11
(F,L)C8T120C20UH11

Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.

40/26 32/21 1200 14-1/2 80.0 1/2 7.7 10 x 8
57/42 46/34 1200 14-1/2 80.0 1/2 7.7 10 x 8
80/59 64/48 1200 14 1/2 80.0 1/2 7.7 10 x 8
80/59 64/48 1600 17-1/2 80.0 3/4 11.5 10 x 10

80/59 64/48 1600 21 80.0 3/4 11.5 10 x 10
100/65 80/53 1200 17 1/2 80.0 1/2 11.5 10 x 10
100/65 80/53 2000 21 80.0 1 14 11 x 10
120/78 96/64 1600 21 80.0 3/4 11.5 11 x 10
120/78 96/64 2000 21 80.0 1 14 11 x 11

Input/Cabinet

High/Low

MBH °F °F °F Lbs

Max. Outlet

Air Temp

Low Fire

Air Temp. Rise

High Fire

Air Temp. Rise

Unit

Amps

Max

Over-Current

Protect

40/26 150 15-45 20-50 9.0 20 14 107

57/42 160 25-55 35-65 9.0 20 14 107

80/52 175 30-60 40-70 9.0 20 14 117

80/59 160 25-55 25-55 12.0 20 14 129

80/59 160 25-55 25-55 12.0 20 14 130
100/65 170 25-55 40-70 12.0 20 14 128
100/65 170 25-55 40-70 12.0 20 14 145
120/78 180 25-55 45-75 12.0 20 14 145
120/78 170 25-55 35-65 14.0 20 12 147

Blower

Min. wire Size

(awg) @ 75 ft

one way

2 Unitary Products Group

BLOWER PERFORMANCE CFM - UPFLOW (WITHOUT FILTER) - BOTTOM RETURN

Bottom Airflow Data (SCFM)

Models Speed

High 1610 1540 1460 1360 1290 1200 1110 1020 900 760

FC8T040A12UH11

Medium High 1430 1390 1330 1250 1190 1110 1030 940 840 710
Medium Low 1200 1180 1140 1100 1 050 1000 930 850 750 620

Low 980 980 960 920 890 840 790 720 620 530

High 1570 1490 1420 1340 1250 1180 1090 990 870 700

(F,L)C8T060A12UH11

Medium High 1410 1360 1310 1250 1190 1090 1020 920 810 650

Medium Low 1200 1180 1150 1100 1050 990 920 830 700 580

Low 960 960 950 930 900 840 800 720 610 500
High 1590 1520 1460 1380 1300 1240 1150 1050 930 800

(F,L)C8T080A12UH11

Medium High 1400 1360 1310 1260 1200 1140 1070 960 860 740

Medium Low 1180 1160 1130 1090 1040 990 920 840 750 640

Low 940 940 940 920 880 840 790 710 630 530
High 1850 1820 1790 1750 1690 1630 1570 1500 1430 1330

(F,L)C8T080B16UH11

Medium 1470 1450 1440 1430 1390 1360 1310 1270 1220 1150

Low 1260 1260 1260 1260 1250 1200 1150 1110 1070 1010
High 2077 1992 1922 1830 1727 1617 1507 1355 1219 1050

(F,L)C8T080C16UH11

Medium 1729 1673 1631 1581 1507 1421 1293 1187 1053 907

Low 1448 1452 1432 1390 1324 1264 1176 1058 939 774
High 1700 1620 1560 1480 1390 1300 1210 1110 970 820

FC8T100B12UH11

Medium High 1430 1400 1350 1300 1230 1160 1080 980 870 710

Medium Low 1180 1170 1160 1130 1080 1030 1000 860 750 510

Low 950 950 930 920 880 840 790 720 620 530
High 2590 2500 2400 2280 2180 2080 1970 1840 1720 1560

(F,L)C8T100C20UH11

Medium High 2180 2120 2040 1980 1900 1810 1720 1600 1480 1320

Medium Low 1750 1720 1680 1640 1580 1520 1440 1350 1220 1060

Low 1450 1420 1380 1330 1300 1240 1160 1070 970 860
High 2020 1930 1820 1730 1640 1540 1400 1250 1090 920

FC8T120C16UH11

Medium 1750 1710 1650 1590 1490 1390 1290 1160 1010 810

Low 1540 1500 1460 1410 1350 1260 1180 1060 910 750
High 2500 2400 2320 2220 2110 2000 1870 1750 1610 1450

(F,L)C8T120C20UH11

Medium High 2130 2070 1990 1920 1840 1760 1660 1570 1460 1320

Medium Low 1700 1680 1650 1620 1560 1500 1410 1320 1210 1070

Low 1420 1390 1360 1330 1290 1240 1150 1060 950 840

NOTES:

1. Airflow expressed in standard cubic feet per minute.

2. Motor voltage at 115 V .

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

Ext. Static Pressure (in. H2O)

246756-CTG-C-0407

Unitary Products Group 3

246756-CTG-C-0407

BLOWER PERFORMANCE CFM - UPFLOW (WITHOUT FILTER) - LEFT SIDE RETURN

Left Side Airflow Data (SCFM)

Models Speed

0.10.20.30.40.50.60.70.80.91.0

High 1810 1730 1660 1570 1480 1390 1300 1200 1090 930

FC8T040A12UH11

Medium High 1390 1390 1350 1320 1270 1210 1150 1080 970 790

Medium Low 1120 1120 1120 1110 1080 1080 1020 930 830 690

Low 880 910 920 920 910 870 820 740 650 510

High 1770 1690 1630 1560 1490 1390 1290 1190 1050 920

(F,L)C8T060A12UH11

Medium High 1400 1380 1350 1320 1280 1230 1160 1060 930 780

Medium Low 1120 1130 1150 1130 1120 1080 1000 950 790 630

Low 880 900 900 900 880 850 790 730 660 530
High 1790 1720 1670 1590 1530 1450 1350 1260 1140 1000

(F,L)C8T080A12UH11

Medium High 1420 1370 1350 1320 1280 1230 1170 1090 990 840

Medium Low 1080 1120 1110 1100 1080 1040 1000 920 820 690

Low N/A 900 900 890 870 850 800 730 670 560

(F,L)C8T080B16UH11

High 2000 1960 1930 1900 1800 1760 1710 1640 1550 1460

Medium 1440 1440 1430 1420 1400 1380 1340 1300 1220 1150

Low 1220 1230 1230 1230 1200 1190 1170 1160 1110 1050
High 2172 2101 2028 1943 1854 1732 1621 1503 1344 1144

(F,L)C8T080C16UH11

Medium 1640 1633 1626 1584 1518 1480 1378 1276 1125 965

Low 1388 1404 1412 1396 1362 1311 1222 1144 1001 827
High 1780 1710 1640 1560 1490 1390 1290 1180 1030 820

FC8T100B12UH11

Medium High 1430 1410 1370 1340 1280 1220 1140 1040 890 730

Medium Low 1140 1170 1150 1120 1080 1040 970 890 760 630

Low 920 940 950 940 920 890 850 770 660 560
High 2770 2670 2610 2540 2450 2340 2210 2070 1890 1730

(F,L)C8T100C20UH11

Medium High 2120 2060 2030 2000 1950 1880 1810 1720 1580 1370

Medium Low 1690 1660 1630 1610 1560 1490 1420 1350 1240 1070

Low 1390 1370 1330 1290 1250 1200 1120 1010 910 850
High 2160 2070 1990 1900 1800 1690 1580 1430 1260 1000

FC8T120C16UH11

Medium 1760 1720 1690 1630 1560 1480 1390 1250 1080 890

Low 1510 1490 1470 1440 1380 1300 1210 1110 950 780
High 2740 2650 2560 2480 2380 2280 2170 1990 1840 1650

(F,L)C8T120C20UH11

Medium High 2120 2090 2040 2000 1940 1870 1780 1680 1550 1370

Medium Low 1690 1670 1650 1610 1560 1510 1440 1310 1160 1030

Low 1390 1360 1330 1300 1250 1190 1100 1020 940 840

NOTES:

1. Airflow expressed in standard cubic feet per minute.

2. Return air is through side opposite motor (left side).

3. Motor voltage at 115 V .

4. Airflow through motor side return (right side) maybe slightly less than shown above.

Ext. Static Pressure (in. H2O)

4 Unitary Products Group

HORIZONTAL SIDEWALL VENTING

For applications where vertical venting is not possible, the
only approved method of horizontal venting is the use of an
auxiliary power vent. Approved power venters are Fields
Controls Model SWG-4Y or the appropriate Tjernlund GPAK
model. Follow all application and installation details provided
by the manufacturer of the power vent. This unit may be hori­zontally vented using 4” (10.2 cm) diameter pipe with a mini-

NOTE: The filter pressure drop values i n the “Filter Perfor­mance” table shown below are typical values for the type of
filter listed and should only be used as a guideline. Actual
pressure drop ratings for each filter type vary between filter
manufacturer.

RECOMMENDED FILTER SIZES

Cabinet Size Side (in) Bottom (in)

mum length of 4.5 feet (1.37 m) and a maximum length of

34.5 feet (10.82 m) with up to 4 elbows.

FILTER PERFORMANCE

The airflow capacity data published in the “Blower Perfor­mance” table listed above represents blower performance
WITHOUT filters. To determine the approximate blower per­formance of the system, apply the filter drop value for the fil­ter being used or select an appropriate value from the “Filter
Performance” table shown below.

FILTER PERFORMANCE - PRESSURE DROP INCHES W.C. AND (KPA)

NOTES:

1. Air velocity through throwaway type filters may not exceed 300
feet per minute. All velocities over this require the use of high
velocity filters.

2. Air flows above 1800 CFM require e ither return from two sides or
one side plus bottom.

246756-CTG-C-0407

A 16 x 25 14 x 25
B 16 x 25 16 x 25
C (2) 16 x 25 20 x 25

Airflow Range

CFM

0 - 750 230 0.01 0.01 0.15

751 - 1000 330 0.05 0.05 0.20
1001 - 1250 330 0.10 0.10 0.20
1251 - 1500 330 0.10 0.10 0.25
1501 - 1750 380 0.15 0.14 0.30
1751 - 2000 380 0.19 0.18 0.30

2001 & Above 463 0.19 0.18 0.30

Minimum

Opening Size

2

in

Disposable Washable Fiber Pleated

In W.C. In W.C. In W.C.

Filter Type

UNIT CLEARANCES TO COMBUSTIBLES (ALL DIMENSIONS IN INCHES, AND ALL SURFACES IDENTIFIED WITH THE
UNIT IN AN UPFLOW CONFIGURATION)

Application Top Front Rear

Upflow 1 6 0 0 3 6 Combustible Yes Yes Yes No

Upflow B-Vent 1 3 0 0 0 1 Combustible Yes Yes Yes No

Horizontal

Horizontal B-Vent

1 Line contact only permitted between lines formed by the intersection of the rear panel and si de panel (top in horizontal postion) of the fura nce jacket

and building joists, studs or framing.

1 6 0 0 3 6 Combustible No Yes Yes
1 3 0 0 0 1 Combustible No Yes Yes

Left

Side

Right

Side

Flue

Floor/

Bottom

Closet Alcove Attic

Line

Contact

Yes
Yes

1

1

Unitary Products Group 5

246756-CTG-C-0407

APPLYING FILTER PRESSURE DROP TO
DETERMINE SYSTEM AIRFLOW

To determine the approximate airflow of the unit with a filter in
place, follow the steps below:

1. Select the filter type.

2. Select the number of return air openings or calculate the
return opening size in square inches to determine the
proper filter pressure drop.

3. Determine the External System Static Pressure (ESP)
without the filter.

4. Select a filter pressure drop from the table based upon
the number of return air openings or return air opening
size and add to the ESP from Step 3 to determine the
total system static.

5. If total system static matches a ESP value in the airflow
table (i.e. 0.20 w.c. (50 Pa), 0.60 w.c. (150 Pa), etc,) the
system airflow corresponds to the intersection of the
ESP column and Model/Blower Speed row.

6. If the total system static falls between ESP values in the
table (i.e. 0.58 w.c. (144 Pa), 0.75 w.c. (187 Pa), etc.),
the static pressure may be rounded to the nearest value
in the table determining the airflow using Step 5 or calcu­late the airflow by using the following example.

Example: For a 60,000 BTUH (17.58 kW) furnace with a bot­tom return opening and operating on high-speed blower, it is
found that total system static is 0.58” w.c. To determine the
system airflow, complete the following steps:

Obtain the airflow values at 0.50 w.c. (125 Pa) & 0.60 w.c.
(150 Pa) ESP.

3

Airflow @ 0.50”: 1250 CFM (35.4 m
Airflow @ 0.60”: 1180 CFM (33.4 m
Subtract the airflow @ 0.50 w.c. (125 Pa) from the airflow @

0.60 w.c. (150 Pa) to obtain airflow difference.

1180 - 1250 = -70 CFM (-12 m3/min)
Subtract the total system static from 0.50 w.c. (125 Pa) and

divide this difference by the difference in ESP values in the
table, 0.60 w.c. (150 Pa) - 0.50 w.c. (125 Pa), to obtain a
percentage.

(0.58 - 0.50) / (0.60 - 0.50) = 0.8
Multiply percentage by airflow difference to obtain airflow

reduction.
(0.8) X (-70) = -56
Subtract airflow reduction value to airflow @ 0.50 w.c. (125

Pa) to obtain actual airflow @ 0.58 in. w.c. (144 Pa) ESP.
1250 - 56 = 1194

/min)

3

/min)

ACCESSORIES

PROPANE (LP) CONVERSION KIT ­1NP0347 - All units

This accessory conversion kit may be used to convert natural
gas (N) units for propane (LP) operation. Conversions must
be made by qualified distributor or dealer personnel.

SIDE RETURN FILTER -

1SR0302 - All Models
1SR0200 - All Models

BOTTOM RETURN FILTER -

1BR0114 or 1BR0214 - For 14-1/2” cabinets
1BR0117 or 1BR0217 - For 17-1/2” cabinets
1BR0121 or 1BR0221 - For 21” cabinets
1BR0124 or 1BR0224 - For 24-1/2” cabinets

INTERNAL FILTER WITH FIBER FILTER -

1HF0801 - All Models

HIGH ALTITUDE PRESSURE SWITCHES -

For installation where the altitude is less than 8,000 feet it is
not required that the pressure switch be changed. For alti­tudes above 8,000 feet see kits below. Conversion must be
made by qualified distributor or dealer personnel.

1PS0313 - 040, 060, 080, 100 MBH
1PS0314 - 120 MBH

ROOM THERMOSTATS - A wide selection of compatible
thermosets are available to provide optimum performance
and features for any installation.

1 Heat Stage only, manual, mechanical thermostat. Add sub­base for 1H/1C.

1H/1C, manual change-over electronic non-programmable
thermostat.

1H/1C, auto/manual changeover, electronic programmable,
deluxe 7-day, thermostat.

1H/1C, auto/manual changeover, electronic programmable.
* For the most current accessory information, refer to the

price book or consult factory.

6 Unitary Products Group

246756-CTG-C-0407

Y/Y2

Cool

For additional connection diagrams for all UPG equipment refer to “Low Voltage System Wiring” document available online at
www.upgnet.com in the Product Catalog Section.

(Optional)

C

TWO STAGE

24-Volt Common

AIR CONDITIONING

Y1

Y2

First Stage Cool

Second Stage Cool

R

24-Volt Hot

24V HUMIDIFIER

Interface

Comfort Alert

C

2 STAGE PSC

24-Volt Common

FURNACE CONTROL

C

*PP32U72124

THERMOSTAT

24-Volt Common

C

*DP22U70124

THERMOSTAT

24-Volt Common

C

*DN22C00124 *PP32U71124

THERMOSTAT

24-Volt Common

Y1

First Stage Cool

Single/Second Stage

Y1

Y2

First Stage Cool

Second Stage Cool

Y2

Y1

First Stage Cool

Second Stage Cool

Y

Y2

First Stage Cool

Second Stage Cool

R

24-Volt Hot

R

24-Volt Hot

R

24-Volt Hot

R

24-Volt Hot

G

W2

W/W1

Single/First Stage Heat

E/W1

First Stage Heat

E/W1

First Stage Heat

W

First Stage Heat

Fan

Second Stage Heat

G

W2

Fan

Second Stage Heat

G

W2

Fan

Second Stage Heat

G

W2

Fan

Second Stage Heat

L

HM

Humidistat

Malfunction Light

to MLTI STG

Step 1 of Thermostat User

Configuration Menu must be set

batteries

Connection of the "C"

is optional when used with

Termainal, 24-Volt Common,

batteries

Connection of the "C"

is optional when used with

Termainal, 24-Volt Common,

Features

to ON to use Comfort Alert

Step 16 of Thermostat User

Configuration Menu must be set

set to MS 2

Step 1 of Thermostat User

Configuration Menu must be

Y

C

*PP32U70124

THERMOSTAT

C

*DN22U00124

THERMOSTAT

Y2

First Stage Cool

24-Volt Common

Y

Y2

First Stage Cool

24-Volt Common

AC9 2 Stage Scroll A/C w/2 Stage Furnace, 2 Stage Cooling Ready- PT8/9; (F,L)*8/9T, (G,L)*8/9T, XYG8S-U, XYF8S-U / XYF8S-U*L

Thermostat Chart - AC

Unitary Products Group 7

R

RC

Second Stage Cool

Second Stage Cool

24-Volt Hot (Cool XFMR)

24-Volt Hot (Heat XFMR)

R

RC

24-Volt Hot (Cool XFMR)

24-Volt Hot (Heat XFMR)

W2

E/W1

First Stage Heat

Second Stage Heat

W2

E/W1

First Stage Heat

Second Stage Heat

G

Fan

when used with batteries

24-Volt Common, is optional

Connection of the "C" Termainal,

G

Fan

when used with batteries

24-Volt Common, is optional

Connection of the "C" Termainal,

Multistage Conventional

Thermostat Installer Setup

Number 0170 - System Type -

must be set to 8 - 2 Heat/2 Cool

must be set to 6 -

Number 1 - System Type -

Thermostat Installer Setup

Number 15 - Compressor

Thermostat Installer Setup

2 Heat/2 Cool Conventional

Protection - must be set to 5

C

HEAT PUMP

TWO STAGE

C

PSC-2 STAGE

COOLING READY

FURNACE CONTROL

Y1

Y2 OUT

24-Volt Common

First Stage Heat/Cool

Y1

Y/Y2

First Stage Cool

24-Volt Common

R

Second Stage Cool Output

R

Single/Second Stage Cool

W2 OUT

W1 OUT

24-Volt Hot

First Stage Auxiliary Heat Output

Second Stage Auxiliary Heat Output

W2

W/W1

24-Volt Hot

Second Stage Heat

Single/First Stage Heat

O

G

Fan

Y2

X/L

Malfunction Light

Reversing Valve–Energized in Cool

W

Second Stage Heat/Cool

BSG

Auxiliary Heat

Bonnet Sensor

BS

Bonnet Sensor

(Optional)

Bonnet Sensor

(Optional)

24V HUMIDIFIER

Heat Pump to ON

Change FFuel Jumper on

Set W2 Delay on furnace to OFF

C

*PP32U72124

*PP32U71124

C

*DP22U70124

C

*PP32U70124 *DN22H00124

THERMOSTAT THERMOSTAT THERMOSTAT

Y1

24-Volt Common

First Stage Heat/Cool

Y1

24-Volt Common

First Stage Heat/Cool

Y

RC

24-Volt Common

First Stage Heat/Cool

R

R

R

24-Volt Hot (Cool XFMR)

DHM

24-Volt Hot

24-Volt Hot

24-Volt Hot (Heat XFMR)

Dehumidistat

E

Emergency Heat

G

G

G

L

Fan

Fan

Fan

O

O

O/B

Y2

E/W1

Malfunction Light

Second Stage Heat/Cool

Reversing Valve–Energized in Cool

L

Y2

E/W1

Malfunction Light

Second Stage Heat/Cool

Reversing Valve–Energized in Cool

L

Y2

AUX

Reversing Valve

Malfunction Light

Second Stage Heat/Cool

W2

First Stage Auxiliary Heat

Second Stage Auxiliary Heat

W2

First Stage Auxiliary Heat

Second Stage Auxiliary Heat

Auxiliary Heat

W/031-01996- Series Demand Control; Hot Heat Pump Mode OR Conventional

HM

Humidistat

Menu must be set to Heat Pump 2

Step 1 of Thermostat User Configuration

set to Heat Pump 2

thermostat not necessary

Step 1 of Thermostat User

Configuration Menu must be

Selection of GAS/ELEC switch on

12 - 3 Heat/2 Cool Heat Pump

- System Type - must be set to

Thermostat Installer Setup Number 0170

- O/B Terminal Energized in Cooling
Thermostat Installer Setup Number 0200

Thermostat Installer Setup Number 0190 -

Reversing Valve (O/B) Operation - must be set to 0

Pump Backup Heat Source is Fossil Fuel

Thermostat Installer Setup Number 0210 -

External Fossil Fuel Kit - must be set to 0 -

- Backup Heat Source - must be set to 1 - Heat

Heat Pump Backup Heat

External Fossil Fuel Kit is Controlling

HP23 Two Stage H/P - H*5B, YZE - w/Two Stage Furnace, 2 Stage Cooling Ready - PT8/9, (F,L)*8/9T, (G,L)*8/9T, XYG8S-U, XYF8S-U / XYF8S-U*L

Thermostat Chart - HP

Subject to change without notice. Printed in U.S.A. 246756-CTG-C-0407
Copyright © by York International Corp. 2007. All rights reserved. Supersedes: 246756-CTG-B-0806

Unitary 5005 Norman
Products York OK
Group Drive 73069
