Page 1
Milk Frother MK1900
User Manual
Page 2
Page 3
Table of Contents
GENERAL SAFETY INSTRUCTIONS
PACKAGE CONTENTS AND DESCRIPTION OF THE APPLIANCE
HOW TO USE
TECHNICAL DATA
CLEANING AND CARE
WARRANTY
1-3
4
5-6
7
7
8
Page 4
GENERAL SAFETY INSTRUCTIONS
Read all instructions, and save it for
future reference.
This appliance can be used by children aged from
1.
8 years and above if they have been given
supervision or instruction concerning use of the
appliance in a safe way and if they understand the
hazards involved. Cleaning and user maintenance
shall not be made by children unless they are
older than 8 and supervised. Keep the appliance
and its cord out of reach of children aged less
than 8 years old.
Keep the appliance and its cord out of reach of
2.
children. Always disconnect the appliance from
the supply if it is left unattended and before
assembling, disassembling or cleaning.
Children should be supervised to ensure that
3.
they do not play with the appliance.
Never leave children unsupervised with the
4.
packaging materials. The packaging material
1
Page 5
presents a danger of suffocation. Children often
underestimate dangers. Always keep children away
from the packaging material.
5.
6.
7.
8.
9.
Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Periodically check the supply cord for any damages.
If the supply cord is damaged, it must be replaced
by the manufacturer, an authorized service or by
qualified technician to avoid any hazard.
Never immerse power cord, plug, container and
base in water or other liquids.
Unplug the appliance from electric outlet when not
in use and before cleaning. Allow to cool down
before putting on or taking off accessories.
Only use base provided and never be used for other
10.
11.
12.
than intended use.
Never operate the appliance when empty or it may
damage the heat elements.
Caution with hot surface. Milk heats up
during operation.
Always operate the appliance with lid in place.
2
Page 6
13.
Never place this appliance on or near a hot gas or
an electric burner or where it could touch a heated
appliance.
14.
This appliance is intended to be used in household
and similar applications such as:
- Staff kitchen areas in shops, offices and other
working environments;
- Farm houses;
- By clients in hotels, motels and other residential
type environments;
- Bed and breakfast type environments.
15.
The appliance is designed for heating up and
frothing milk. Do not put other type of liquid or
solid food in the container. Do not use the
appliance for other than intended use.
16.
Never leave the milk frother unattended while in use.
17.
Always observe the minimum (MIN) and maximum
level marks inside the container for each
operation.
3
Page 7
PACKAGE CONTENTS AND DESCRIPTION OF THE APPLIANCE
1. Lid
2. Paddle holder
3. Container
4. MAX level mark
300ml-150ml-75ml
(10.14oz - 5.07oz-2.53oz)
5. Heat button
6. Cool button
7. Handle
8. Base
9. Stirring paddle
10. Frothing paddle
11. Power cord
12. Cleaning brush
MIN
1
2
4
3
7
5
6
12
9
8
11
10
4
Page 8
BEFORE THE FIRST USE
Remove all packaging material and check appliance is
●
complete and undamaged.
Clean the appliance according to chapter CLEANING AND
●
CARE before the first use or after long periods of non-use. Never
immerse the appliance into water. Make sure the base and
bottom of container are completely dry before use.
Note: MAX. capacity is 10.14oz (300ml). Minimum is 2.6oz
(75ml) milk.
HOW TO USE
Place the base on a flat stable non-heat resistant surface.
1.
Remove the lid from container, place one of frothing paddle
2.
and stirring paddle and mount inside container. Another paddle
can be mount on paddle holder.
Stirring paddle
Frothing paddle
Pour milk in container slowly. Add 2.6oz (75ml)- 5.07oz (150ml)
3.
milk for frothing or maximum 10.14oz (300ml) milk for ONLY
heating.
Note: always observe the minimum mark “MIN” and ensure the
container is filled with milk over MIN mark.
Maximum for milk
froth/hot froth only
Maximum for hot
milk
Heating up milk without frothing.
Frothing in Heat and Cool mode.
add milk between MIN and MAX
add milk between MIN and MAX
5
Page 9
Place container onto the base.
4.
Plug the appliance into power outlet.
5.
To make hot froth or hot milk, push heat button “ ”. Button
6.
lights up in red.
To make milk froth only, push froth button “ ”. Button lights
up in blue.
Button light up indicates operation started automatically. Press
7.
the button again to stop.
Button lights off indicated the process is completed. Appliance
8.
motor shut off automatically.
Hold handle and remove container from base. Remove lid
9.
carefully.
Use a spoon to take off milk froth from the container or pour
10.
milk into your beverage carefully.
Unplug the appliance after use.
11.
Allow the appliance cool down completed before cleaning.
12.
Operation Cycle
Minimum 3 minutes rest time must be maintained between 2
continuous cycles, the appliance might enter self-protection state
automatically after working for 5 cycles continuously. Indicator will
flash and switch button will be activated after 5 minutes, the
appliance will be in standby state and you can continue operating
the appliance.
6
Page 10
TECHNICAL DATA
Rated power:
Capacity:
Product size:
Net weight:
120V~, 60Hz 500W
10.14 oz (300ml)
6.3 x 4.3 x 7.7 inches
1.87 lbs
CLEANING AND CARE
Caution: Never immerse the container, base and power cord in water or
any other liquids.
Note: clean your appliance after use for your personal hygiene.
Always disconnect the appliance from power outlet and allow it cool
1.
down completely before cleaning.
Remove lid from the appliance and clean lid with mild detergent and
2.
rinse under clear water.
Remove stirring paddle or frothing paddle and clean with warm water.
3.
Use cleaning brush provided to clean inside of container with warm
4.
water and mild detergent, wipe dry with soft damp cloth.(Fig.1)
Wipe outside of container and the base with soft damp cloth. Make
5.
sure they are dry thoroughly before use.
Store the appliance with lid covered.
6.
Wate r
Fig.1
7
Page 11
WARRANTY
The warranty for this appliance is for 12 months from the date of the
first purchase. The appliance has been manufactured with care and
meticulously examined before delivery. Please retain your receipt as
proof of purchase. In the case of a warranty claim, please make
contact with our Customer Service.
Notice
The warranty covers only claims for the material and manufacturing
defects, but not for the transport damage, wearing parts or for damage
to fragile components.
This product is for domestic use only and is not intended for
commercial use. The warranty is void in the case of the abusive service
branch.
Your statutory right are not restricted in any way by this warranty. The
warranty period is not extended by repairs made under the warranty.
This applies also to replaced and repaired parts.
Warranty claim procedure
To ensure quick processing of your case, please observe the following
instructions:
Please have the till receipt and the item number available as proof of
purchase. You will find the item number as a sticker on the rear or
bottom of the appliance.
If function or other defects occur, please contact the service centre
listed either by telephone or by email.
If you have any further assistance, please contact us:
USA Customer Service:
1-888-849-4440
8
