Code one G, AD Owner's Manual

Smoke Alarm Features

•These smoke alar ms are powered by 120V AC (Model G)
or 120V AC with a 9-volt battery back-up source (Model
AD). AC/DC smoke alarms offer added protection in the
event of a power failure.

•Unique power connector prevents inter connection with
incompatible smoke alarms or security systems.

•This smoke alar m can be interconnected with as many as
17 other specific model smoke alarms.

•Optional tamper-resist featur e can serve as a safeguard
against tampering.

•Unique “batter y missing” signal. The smoke alarm will
not attach to the mounting bracket if a battery is not in
the battery pocket on Model AD.

•Improperly connected or weak batter y signal. The smoke
alarm will sound a shor t beep about once a minute if the
battery is weak or improperly connected on Model AD.

•Multi-purpose green and r ed LEDs indicate that the smoke
alarm is receiving AC power, working under normal opera­tion, and/or in alarm (Model AD only).

•Loud alar m horn-85 decibels at 10 feet-sounds to alert
you to an emergency.

•Test button checks smoke alarm operation.

•Constant green LED indicates the alar m is connected to
and receiving AC Power.

Important Safety Information

•This smoke alar m requires constant 120-volt, AC power
AND (Model AD only) a working 9-volt battery to operate
properly. This smoke alarm WILL NOT work if AC power is
not connected or has failed or been interrupted for any
reason AND (Model AD only) the battery is removed,
drained, or improperly connected. DO NOT use any other
kind of battery except as specified in this manual (Model
AD only). DO NOT connect this smoke alarm to any other
type of smoke alarm or auxiliar y device, except those list­ed in this manual.

•DO NOT remove or disconnect batter y or turn off AC
power to quiet unwanted alarms. This will remove your
protection. Open windows or fan the air around smoke
alarm to silence it.

•The Push-to-Test button accurately tests all smoke alarm
functions. DO NOT use any other test method. Test
smoke alarm weekly to ensure proper operation.

•This smoke alar m should be installed only by a licensed,
qualified electrician. Observe and follow all local and
national electrical and building codes for installation.

•This smoke alar m is designed to be used inside a single­family household. In multi-family buildings, each individual
living unit should have its own alarms. It is not a substitute
for a complete commercial alarm system. It should be used
only as supplemental protection in hotels, motels, dormito­ries, hospitals, nursing homes, or group homes.

•Install a smoke alar m in every room and on ever y level of
the home. Smoke may not reach the smoke alarm for
many reasons. For example, if a fire starts in a r emote

1

110-570H

WARNING: THIS SMOKE ALARM MAY SOUND A SHORT

BEEP WHEN POWER IS CONNECTED

.

S

MOKE ALARMS MUST NOT BE USED WITH DETECTOR

GUARDS UNLESS THE COMBINATION OF ALARM AND

GUARD HAS BEEN EVALUATED AND FOUND SUITABLE FOR

THAT PURPOSE

.

SMOKE ALARM

OWNERS MANUAL

READ AND SAVE FOR YOUR SAFETY

Model G

120V IONIZATION SMOKE ALARM

Model AD

120V AC IONIZATION SMOKE ALARM
WITH 9V DC BATTERY BACKUP

PLEASE READ AND SAVE

INSTALLER: Please leave this manual with the product.

The ionization type alarms are generally more ef fective at detecting
fast, flaming fires which consume combustible materials rapidly and
spread quickly. Sources of these fires may include flammable
liquids or paper burning in a waste container. The photoelectric
type alarms are generally more ef fective at detecting slow, smolder­ing fires which smolder for hours before bursting into flame.
Sources of these fires may include cigarettes burning in couches or
bedding. However, both types of alarms are designed to provide
adequate detection of both types of fires. If you desire the benefits
of both systems, you should install smoke alarms that combine in
one alarm both photoelectric and ionization sensing technologies.

S

T

A

T

E

O

F

C

A

L

I

F

O

R

N

I

A

S

T

A

T

E

F

I

R

E

M

A

R

S

H

A

L

L

I

S

T

I

N

G

S

E

R

V

I

C

E

110-570H English 11/8/06 11:05 AM Page 1

part of the home, on another level, in a chimney, wall,
roof, or on the other side of a closed door, smoke may
not reach the smoke alarm in time to aler t household
members. A smoke alarm will not promptly detect a fire
EXCEPT in the area or room in which it is installed.

•Inter connected smoke alarms installed in every r oom and
on every level of the household of fer maximum protection.
The National Fire Protection Agency (NFPA) recommends
interconnecting smoke alarms so that when one smoke
alarm senses smoke and sounds its alarm, all others will
sound as well. Do not interconnect smoke alarms from
one individual family living unit to another. Do not
connect this smoke alarm to any other type of alarm or
auxiliary device.

•Smoke alar ms may not alert ever y household member
every time. There may be limiting cir cumstances where a
household member may not hear the alarm (e.g., outdoor
or indoor noise, sound sleepers, drug or alcohol usage, the
hard of hearing, etc.). If you suspect that this smoke alarm
may not alert a household member, install and maintain
specialty smoke alarms. Current studies have shown
smoke alarms may not awaken all sleeping individuals,
and that it is the responsibility of individuals in the house­hold that are capable of assisting others to provide assis­tance to those who may not be awakened by the alarm
sound, or to those who may be incapable of safely evacu­ating the area unassisted.

•Smoke alar ms can only sound their alarms when they
detect smoke. Smoke alarms detect combustion par ticles
in the air. They do not sense heat, flame, or gas. This
smoke alarm is designed to give audible warning of a devel­oping fire. However, many fires are fast-burning, explosive,
or intentional. Others are caused by carelessness or safety
hazards. Smoke may not reach the smoke alarm QUICKLY
ENOUGH to ensure safe escape.

•Smoke alar ms have limitations. This smoke alarm is not
foolproof and is not warranted to protect lives or proper ty
from fire. Smoke alarms are not a substitute for insur­ance. Homeowners and renters should insure their lives
and property. In addition, it is possible for the smoke
alarm to fail at any time. For this reason, you must test
the smoke alarm weekly and replace ever y 10 years.

•Smoke alar ms must not be used with detector guards
unless the combination of alarm and guard has been eval­uated and found suitable for that purpose.

Proper Placement of Your Smoke Alarm

Code One Safety recommends complete coverage protection
achieved by installing a smoke alarm in ever y room of your home.

THIS EQUIPMENT SHOULD BE INSTALLED IN ACCORDANCE WITH
THE NATIONAL FIRE PROTECTION ASSOCIATION’S STANDARD 72
(National Fire Protection Association, Batterymar ch Park, Quincy, MA

02269).

The NFPA standard identifies the minimum requirement for locating
smoke alarms in family living units.

It states:

“2-2.1.1.1 Smoke alarms shall be installed outside of each sepa­rate sleeping area in the immediate vicinity of the bedrooms and on
each additional story of the family living unit including basements
and excluding crawl spaces and unfurnished attics. In new construc­tion a smoke alarm also shall be installed in each sleeping room.”

Further, section 2-2.2.1 states that:

“In new construction, where more than one smoke alarm is requir ed
by 2-2.1, they shall be so arranged that operation of any smoke
alarm shall cause the alarm in all smoke alarms within the dwelling
to sound.”

The NFPA, 1993 Edition, Appendix A, however, clearly points out
that:

“The required number of smoke alarms (as defined in the para­graphs above) may not provide reliable early warning protection for
those areas separated by a door from the areas protected by the
required smoke alarms. For this reason, it is recommended that the
householder consider the use of additional smoke alarms for those
areas for increased protection. The additional areas include: base­ment, bedrooms, dining room, furnace room, utility room, and hall­ways not protected by the required smoke alarms.”

Further, the California State Fire Marshal states that the minimum
number of required smoke alarms is not enough to give the earliest
warning under all conditions. The California State Fire Marshal
states that:

“Early warning fire detection is best achieved by the installation of
fire detection equipment in all rooms and areas of the household as
follows: A smoke alarm installed in each separate sleeping area (in
the vicinity, but outside the bedrooms), and heat or smoke alarms in
the living rooms, dining rooms, bedrooms, kitchens, hallways, attics,
furnace rooms, closets, utility and storage rooms, basements and
attached garages.”

It is clear that the earliest warning of a developing fire is best
achieved by the installation of smoke alarms in all rooms and areas
of the residence. Accordingly, Code One Safety recommends that
you install smoke alarms in ever y room of your residence (including
basements and attics) even though this is not required by the typical
code or standard.

In addition, we recommend that you interconnect all smoke alarms
capable of being interconnected.

Code One Safety recommends a minimum of two smoke alarms in
every home, no matter how small the home (including ef ficiency
apartments). Code One Safety also recommends maximum cover­age by installing smoke alarms in both required and recommended
locations as illustrated and described hereafter.

2

110-570H English 11/8/06 11:05 AM Page 2

Existing Homes:

The NFPA requires a smoke alarm on every level and outside
each sleeping area in existing construction. An existing
household with one level and one sleeping area is required to
have one smoke alarm.

New Construction Homes:

The NFPA requires AC-powered, interconnected smoke alarms
to be installed inside each bedroom, outside each bedroom
area, and on every level of the home. They also requir e a
minimum of two AC-powered, interconnected smoke alarms in
any new construction home.

Mobile Home Installation:

•For minimum protection, smoke alar ms should be
installed in compliance with H.U.D. Manufactured Home
Construction Safety Standards Title 24 CFR, Section

3280.208 and Section 3282.

•For additional protection, see single-stor y residence
smoke alarm requirements and recommendations for
existing homes and new construction.

NOTE: For mobile homes built before 1978, install smoke
alarms on inside walls between 4 and 12 inches from the ceil­ing (older mobile homes have little or no insulation in the ceil­ing). This is especially important if the ceiling is unusually hot
or cold.

Additional Alarm Placement Information

Install a smoke alarm as close to the center of the ceiling as
possible. If this is not practical, mount no closer than 4
inches from a wall or corner. Also, if local codes allow wall
mounting, install smoke alarms on walls between 4 and 12
inches from ceiling/wall intersections.

Install a smoke alarm in each room that is divided by a par tial
wall (either coming down from the ceiling at least 24 inches,
or coming up from the floor).

Install smoke alarms on peaked, cathedral, or gabled ceilings
3 feet from the highest point (measured horizontally).

3

BASEMENT

UTILITY

ROOM

KITCHEN

LIVING
ROOM

BEDROOM

HALL

BEDROOM

FINISHED ATTIC

DINNING ROOM

LIVING ROOM

KITCHEN

BEDROOM

BEDROOM

BEDROOM

SINGLE STORY RESIDENCE /
APARTMENT / MOBIL HOME

TWO STORY RESIDENCE

BASEMENT

UTILITY
ROOM

KITCHEN

LIVING
ROOM

BEDROOM

HALL

BEDROOM

FINISHED ATTIC

DINNING ROOM

LIVING ROOM

KITCHEN

BEDROOM

BEDROOM

BEDROOM

SINGLE STORY RESIDENCE /
APARTMENT / MOBIL HOME

TWO STORY RESIDENCE

KEY:

NFPA minimum REQUIRED smoke alarm locations
Code One Safety recommended additional smoke alarm locations
Denotes interconnection

CEILING

ACCEPTABLE HERE

NEVER HERE

3'-0"

PEAKED CEILING

110-570H English 11/8/06 11:05 AM Page 3

Install a smoke alarm in lived-in attics or attics which house
electrical equipment like furnaces, air conditioners, or heaters.

DO NOT Install Smoke Alarms:

•In ar eas where combustion particles are pr esent.
(Combustion particles are the by-products of something that
is burning.) Areas to avoid include poorly ventilated
kitchens, garages, near furnaces, or near hot water
heaters. Place smoke alarm as far from the source of com­bustion particles as possible to prevent nuisance alar ms.

•In damp or ver y humid areas such as bathrooms with
showers where normal humidity may rise above 93% rela­tive humidity. Areas above this humidity level can cause
false alarm.

•In direct air flow nor within 3 feet of air r eturns or heating
and cooling supply vents. Install at least 3 feet (0.9
meters) away from these areas. The air could blow
smoke away from the detector, interrupting its alarm.

•In rooms wher e temperatures may fall below 40°F (4°C) or
rise above 100°F (38°C).

•In extremely dusty, dir ty, or insect-infested areas. Loose
particles inter fere with smoke alarm operation.

How to Install the Model AD Smoke Alarm

This smoke alarm should be installed in accordance with the
National Fire Protection Association’s Standard 72 (National Fire
Protection Association, Batterymar ch Park, Quincy, MA 02269).

Install smoke alarm on a 4-inch octagon or single gang junc­tion box only.

1. From back of smoke alarm, remove mounting plate. (To

later engage tamper-resist feature, twist out and set
aside one of the pins molded into plate. Both pins are
exactly the same.)

2. Align recessed slots on plate with mounting holes of a

4-inch octagon or single gang junction box.

3. Gently pull household wires through center hole of plate.

4. Secure plate to junction box with mounting screws.

5. With a small wire connector, connect white wire from

connector plug to white household wire.

6. Connect black wire from connector plug to black house-

hold wire.

7. If interconnection is desired, connect yellow wire from

connector to interconnect wire between smoke alarms.
See section, “Interconnecting Smoke Alarms.”

NOTE:

If this will be a single-station smoke alarm, cover yellow
wire with electrical tape and tuck into junction box.

8. Connect new 9-volt battery to batter y connector inside

battery pocket. BE SURE BATTERY IS SECURELY CON­NECTED. Smoke alarm
may beep briefly when
battery is installed.

9. Close battery pocket door,

snapping it into place.
(For tamper-resist, use long­nosed pliers to remove thin
plastic from notch on
smoke alarm edge.)

10. Attach connector plug to

pins on back of smoke
alarm. Plug will only fit
one way and will snap into place.

11. Gently tug connector to be sure it is attached securely.

12. Position smoke alarm to mounting plate and turn clock-

wise to lock into place. (To engage tamper resist fea-

4

24"

STUB WALL

SOFFIT

DANGER

ELECTRICAL SHOCK HAZARD. TURN OFF POWER AT THE MAIN
FUSE BOX OR CIRCUIT BREAKER BY REMOVING THE FUSE OR
SWITCHING THE CIRCUIT BREAKER TO THE OFF POSITION.

WARNING

THIS SMOKE ALARM SHOULD BE INSTALLED ONLY BY A QUALIFIED
ELECTRICIAN. SMOKE ALARM WIRING TO BE USED SHALL BE IN
ACCORDANCE WITH THE PROVISIONS OF ARTICLE 210 AND 760 OF
THE NATIONAL ELECTRICAL CODE, ANSI/NFPA 70, AND ANY LOCAL
CODES THAT MAY APPLY. INTERCONNECT WIRE LOCATION SHALL BE
IN ACCORDANCE WITH NEC ARTICLE 300.3B.

!

!

REMOVE THIN PLASTIC FROM NOTCH

110-570H English 11/8/06 11:05 AM Page 4

ture, insert pin into notch on edge of smoke alar m after
alarm is properly positioned in base. See instruction #9
on the previous page.)

NOTE:

Smoke alarm will not
mount to plate if bat­tery is not installed.

13. Turn on power at

main fuse box or cir­cuit breaker.

14. Test smoke alarm.

See “Testing the
Smoke Alarm”.

Interconnecting Model AD Smoke Alarms

•This smoke alar m may be interconnected with as many as
17 other Models AD, ADC, and FX1218 smoke alarms.
DO NOT connect to any other type or model smoke alarm.

•Connect smoke alar ms to a single AC branch circuit. If
local codes do not permit, be sure the neutral wire is
common to both phases.

Red and Green Indicators (on Model AD)

This smoke alarm features red and green LED indicators that
can be seen through the Push-to-Test button. The LEDs indi­cate the following:

GREEN LED ON–AC power is present.

OFF–AC power is not present.

RED LED Blinks once a minute–indicating normal operation.

Blinks once a second-smoke alarm senses smoke
and simultaneously sounds an audible alarm.

(Interconnected system only):

OFF–another smoke alarm in the network has
sensed smoke and is signalling this alarm.

How to Install the Model G Smoke Alarm

This smoke alarm should be installed in accordance with the
National Fire Protection Association’s Standard 72 (National Fire
Protection Association, Batterymar ch Park, Quincy, MA 02269).

Install smoke alarm on a 4-inch octagon or single gang junc­tion box only.

1. From back of smoke alarm, unlock and remove mount-

ing plate by turning plate counter-clockwise.

2. Align plate with mounting holes of a 4-inch octagon or

single gang junction box.

3. Gently pull household wires through center hole of plate.

4. Secure plate to junction box.

5. With a small wire connector, connect white wire from

connector plug to white household wire.

6. Connect black wire from connector plug to black house-

hold wire.

7. If interconnection is desired, connect yellow wire from

connector to interconnect wire between smoke alarms.
See section, “Interconnecting Smoke Alarms.”

NOTE:

If this will be a single-station smoke alarm, cover yellow
wire with electrical tape and tuck into junction box.

8. Attach connector plug to pins on back of smoke alarm.

Plug will fit only one way.

9. Gently tug connector to be sure it is attached securely.

10. Position smoke alarm to mounting plate and turn clock-

wise to lock into place.

11. Turn on power at main fuse box or circuit breaker.

12. Test smoke alarm. See “Testing the Smoke Alarm.”

5

INSERT PIN HERE

WHITE WHITE WHITE

YELLOW YELLOW

BLACK BLACK BLACK

TO NEUTRAL

TO 120 VAC (HOT)

DANGER

ELECTRICAL SHOCK HAZARD. TURN OFF POWER AT THE MAIN
FUSE BOX OR CIRCUIT BREAKER BY REMOVING THE FUSE OR
SWITCHING THE CIRCUIT BREAKER TO THE OFF POSITION.

WARNING

THIS SMOKE ALARM SHOULD BE INSTALLED ONLY BY A QUALI­FIED ELECTRICIAN. SMOKE ALARM WIRING TO BE USED SHALL
BE IN ACCORDANCE WITH THE PROVISIONS OF ARTICLE 210 AND
760 OF THE NATIONAL ELECTRICAL CODE, ANSI/NFPA 70, AND
ANY LOCAL CODES THAT MAY APPLY. INTERCONNECT WIRE LOCA­TION SHALL BE IN ACCORDANCE WITH NEC ARTICLE 300.3B.

!

!

BLACK

BLACK

INTERCONNECT

WIRE
CONNECTOR

YELLOW

WHITE

110-570H English 11/8/06 11:05 AM Page 5

Interconnecting Model G Smoke Alarms

•Model G smoke alar m may be interconnected with as
many as 17 other Model G smoke alarms. DO NOT con­nect to any other type or model smoke alarm.

•Connect smoke alar ms to a single AC branch circuit. If
local codes do not permit, be sure the neutral wire is
common to both phases.

LED Indicator (on Model G)

This smoke alarm features an LED indicator that can be seen
through the Push-to-Test button. The LED indicates the following:

LED ON–indicating normal operation.

OFF–smoke alarm senses smoke and simulta­neously sounds an audible alarm.

(Interconnected system only):

ON–another smoke alarm in the network has
sensed smoke and is signaling this alarm.

Testing the Smoke Alarm

•Test each smoke alarm to be sure it is installed corr ectly
and operating properly.

•Test all smoke alarms in an interconnected system
after installation.

•The Push-to-Test button accurately tests all functions. DO
NOT use an open flame to test this smoke alarm. You
may ignite and damage the smoke alarm or your home.

• Test smoke alarms weekly and upon returning from vacation
or when no one has been in the household for several days.

•Stand at ar m’s length from the smoke alarm when test­ing. The alarm horn is loud to aler t you to an emergency
and can be harmful to hearing.

Test all smoke alarms weekly by doing the following:

1. Check Push-to-Test button. A constant green light indi-

cates the smoke alarm is receiving 120V AC power
(Model AD only).

2. Firmly depress the Push-to-Test button for at least five

(5) seconds. The smoke alarm will sound a loud beep
about three (3) times over a four-second period. The
alarm may sound for up to 10 seconds after releasing
the Push-to-Test button.

NOTE:

If smoke alarms are interconnected, all smoke alarms
should sound an alarm within three seconds after any test
button is pushed and the tested smoke alarm sounds.

3. If smoke alarm does not sound, turn of f power at main

fuse box or circuit breaker and check wiring. Retest
smoke alarm.

REPLACE OR RETURN THE ALARM IF THE PUSH-TO-TEST
FUNCTION DOES NOT OPERATE PROPERLY AFTER FOLLOW­ING THE PROCEDURES OUTLINED ABOVE (see REPAIR on
page 7).

Practice Fire Safety

If the smoke alarm sounds its alarm horn, and you have not
pushed the test button, it is warning of a dangerous situation.
Your immediate response is necessary. To prepare for such
occurrences, develop family escape plans, discuss them with
ALL household members, and practice them regularly.

•Expose ever yone to the sound of a smoke alarm and
explain what the sound means.

•Deter mine TWO exits from each room and an escape
route to the outside from each exit.

•Teach all household members to touch the door and use
an alternate exit if the door is hot. Instruct them not to
open the door if the door is hot.

•Teach household members to crawl along the floor to stay
below dangerous smoke, fumes, and gases.

•Deter mine a safe meeting place for all members outside
the building.

6

WHITE WHITE WHITE

YELLOW YELLOW

BLACK BLACK BLACK

TO NEUTRAL

TO 120 VAC (HOT)

DANGER IF ALARM HORN SOUNDS, AND SMOKE ALARM IS NOT

BEING TESTED, THE SMOKE ALARM IS SENSING SMOKE.
THE SOUND OF THE ALARM HORN REQUIRES YOUR
IMMEDIATE ATTENTION AND ACTION.

!

110-570H English 11/8/06 11:05 AM Page 6

What To Do In Case Of A Fire

1. Don’t panic; stay calm.

2. Leave the building as quickly as possible. Touch doors

to feel if they are hot before opening them. Use an
alternate exit if necessary. Crawl along the floor, and
DO NOT stop to collect anything.

3. Meet at a pre-arranged meeting place outside the building.

4. Call the fire department from outside the building.

5. Do not go back inside a burning building. Wait for the

fire department to ar rive.

These guidelines will assist you in the event of a fire.
However, to reduce the chance that fires will start, practice
fire safety rules and prevent hazardous situations.

Maintenance and Cleaning

In addition to weekly testing, the Model AD smoke alarm
requires yearly battery r eplacement and periodic cleaning to
remove dust, dirt, and debris.

Battery Replacement (Model AD only)

Always turn off power to smoke alar m before replacing bat­tery. Replace battery at least once a year or immediately
when the low battery signal sounds once a minute, even
though the smoke alarm is receiving AC power.

Use only the following batteries as replacements in the
Model AD smoke alarm:

Eveready 522 or 1222, or Duracell MN 1604

1. Turn off power to smoke alarm at main ser vice panel.

2. Turn smoke alarm counter-clockwise to detach from

mounting plate.

3. Gently pull down smoke alarm. Be careful not to sepa-

rate wire connections.

4. Pull out power plug from back of smoke alarm.

5. From back of smoke alarm, lift tab to open batter y

pocket door.

6. Remove battery from pocket. Disconnect and discar d

drained battery from batter y connector.

7. Connect a fresh 9-volt battery to connector. The bat-

tery will fit only one way. Be sure batter y connector is
securely attached to battery ter minals.

8. Place battery into batter y pocket.

9. Close battery pocket door. Push down until it snaps

into place.

10. Replace connector plug. Connector will snap into

place. Gently tug connector to be sure it is
attached properly.

11. Reattach smoke alarm to mounting plate by turning

smoke alarm clockwise until it snaps onto plate.

12. Turn on power and test smoke alarm using Push-to-

Test button.

Cleaning

Clean the smoke alarm at least once a month to remove
dust, dirt, or debris. Always turn of f power to smoke alarm
before cleaning.

•Using the soft br ush or wand attachment to a vacuum
cleaner, vacuum all sides and cover of smoke alarm. Be
sure all the vents are free of debris.

•If necessar y, turn off power and use a damp cloth to
clean smoke alarm cover.

Important

Do not attempt to remove the cover or clean inside the
smoke alarm. This will void your warranty.

Repair

Caution: do not attempt to repair this smoke alarm. Doing so
will void your warranty.

If smoke alarm is not operating properly, see “Troubleshooting”.
If necessary and if still under war ranty, return smoke alarm
to Code One Safety. Pack it in a well-padded carton, ship­ping prepaid, with a note describing the nature of the prob­lem and proof of date of purchase, to:

Code One Safety
Product Service Depar tment
28C Leigh Fisher Blvd.
El Paso, TX 79906 USA

If the smoke alarm is no longer under warranty, have a
licensed electrician replace the smoke alarm immediately
with a comparable Code One brand smoke alarm.

7

DANGER ELECTRIC SHOCK HAZARD. TURN OFF POWER AT MAIN

SERVICE PANEL BY REMOVING FUSE OR SWITCHING
APPROPRIATE CIRCUIT BREAKER TO OFF POSITION BEFORE
REPLACING BATTERY OR CLEANING SMOKE ALARM.

!

DANGER DO NOT USE ANY OTHER TYPE OF BATTERY, EXCEPT AS

SPECIFIED IN THIS MANUAL. DO NOT USE RECHARGE­ABLE BATTERIES.

!

110-570H English 11/8/06 11:05 AM Page 7

Troubleshooting

REPLACE OR RETURN THE ALARM IF THE PUSH-TO-TEST
FUNCTION DOES NOT OPERATE PROPERLY AFTER FOLLOW­ING THE PROCEDURES OUTLINED ABOVE (see REPAIR on
page 7).

Warranty

Code One Safety warrants to the original consumer purchaser
each new smoke alarm to be free from defects in material
and workmanship under normal use and ser vice for a period
of three (3) years from date of purchase. Code One Safety
agrees to repair or replace, at its option, any defective
smoke alarm, provided that it is returned with postage pre­paid and with proof of purchase date to Code One Safety.
This warranty does not cover damage resulting from accident,
misuse or abuse or lack of reasonable care of the product.
This warranty is in lieu of all other express warranties, obliga­tions or liabilities.

THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE ARE LIMITED TO A PERIOD OF
three (3) YEARS FROM PURCHASE DATE. Some states do
not allow limitations on how long an implied warranty lasts,
so the above limitations may not apply to you. IN NO CASE
SHALL CODE ONE SAFETY BE LIABLE FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR BREACH OF THIS OR
ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER,
EVEN IF THE LOSS OR DAMAGE IS CAUSED BY ITS NEGLIGENCE
OR FAULT. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation
or exclusion may not apply to you. This warranty gives you
specific legal rights, and you may also have other legal rights
which vary from state to state.

8

DANGER ALWAYS TURN OFF POWER AT MAIN FUSE BOX OR

CIRCUIT BREAKER BEFORE TAKING
TROUBLESHOOTING ACTION.

WARNING DO NOT DISCONNECT BATTERY OR AC POWER TO

QUIET AN UNWANTED ALARM. THIS WILL REMOVE
YOUR PROTECTION. FAN THE AIR OR OPEN A
WINDOW TO REMOVE SMOKE OR DUST.

!

!

PROBLEM SOLUTION

Smoke alarm does not sound
when tested.

1. Check that AC power is
turned on.

2. Turn of f power. Remove
smoke alarm from mounting
plate and:

a. check that connector plug

is securely attached.

b. check that battery is prop-

erly attached to connector
(Model AD only).

3. Clean smoke alarm.

Smoke alarm beeps about
once a minute (Model AD only)

Turn off power and replace
battery. See “Battery
Replacement” in the MAINTE­NANCE AND CLEANING section.

Smoke alarm sounds unwant­ed alarms when residents are
cooking, taking showers, etc.

1. Clean smoke alarm.

2. Hire an electrician to move
smoke alarm to a new
location. See SMOKE ALARM
PLACEMENT.

Interconnected smoke alarms
do not sound when system is
tested.

Press and hold test button for
at least three seconds after the
first unit sounds.

Code One Safety
28C Leigh Fisher Blvd.
El Paso, TX 79906 USA
©2006 Code One Safety 110-570H

110-570H English 11/8/06 11:05 AM Page 8
