Codelocks CL475 User Manual

INSTALLATION INSTRUCTIONS

Codelocks

0460/0465

0470/0475

A 1 x code front plate complete with threaded

cylinder (or europrofile cylinder)

B 1 x code front plate lever handle or knob
C 2 keys
D 1 x back plate
E 1 x back plate lever handle or knob
F 2 x neoprene seals
G 1 x cam plug for use with threaded

lockcase or europrofile lockcase

H 1 x gear ring for left hand hung doors
I 5 x fixing bolts (1 x spare)
J 1 x spindle set
K 1 x allen key
L 1 x tweezers
M 2 x spare tumblers (one red, one blue)

1 x code card
1 x template
1 x installation & operating instructions
1 x code change instructions

BOX CONTENTS

A D

B E

C

F

G

H

I

J

K

L

M

0460/0465 0470/0475

O460 – Narrow stile lock case complete with

threaded cylinder and cams.

0465 – Narrow stile lock case complete with
passage function, threaded cylinder and cams.

O470 – Narrow stile lock case complete with
euro profile cylinder and cams.

0475 – Narrow stile lock case complete with
passage function, euro profile cylinder and cams.

Note: Model number with a ‘K’ suffix indicates knob
handle. Model number with an ‘L’ suffix indicates lever
handle model.

Before installing please check
box contents.

B E
