Code CR2600 User Manual
USER MANUAL
NORTH AMERICA: ENGLISH
CR2600
MANUAL VERSION 05
RELEASE DATE: JULY 2014
Configuration Guidewww.codecorp.com YouTube.com/codecorporation
Statement of Agency Compliance
The Code Reader™ 2600 (CR2600) has been tested for compliance with FCC regulations and was found to be compliant
with all applicable FCC Rules and Regulations.
IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, this device must not be co-located or
operate in conjunction with any other antenna or transmitter.
CAUTION: Changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
The CR2600 has been tested for compliance to CE standards and guidelines and was found to conform to applicable CE
standards, specically the EMC requirements EN 55024, ESD EN 61000-4-2, Radiated RF Immunity EN 61000-4-3,
ENV 50204, EFT EN 61000-4-4, Conducted RF Immunity EN 61000-4-6, EN 55022, Class B Radiated Emissions, and
Class B Conducted Emissions.
The CR2600 has been tested and certied in compliance with the Technical Regulations Conformity Certication of
Specied Radio Equipment (ordinance of MPT N°.37. 1981), Article 2, Paragraph 1, Item 19.
Code voids product warranty if the hard case has been opened or tampered with in any way.
The CR2600 meets all safety and quality standards in accordance to EN 60950-1:2006/A11:2009/A1:2010.
CR2600 CodeXML® Modem FCC, Industry Canada and ICES Compliance
FCC:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT! Any changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate this equipment.
IMPORTANT! Tous les changements ou modications pas expressément approuvés par la partie responsable de la conformité ont pu
vider l’autorité de l’utilisateur pour actioner cet équipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the radiator and your body.
Industry Canada
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Important Note:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the radiator and your body.
Note Importante: (Pour l’utilisation de dispositifs mobiles)
Declaration d’exposition aus radiations:
Cet équipement est conforme aux limites d´exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet
équipment doit être installé et utilisé avec un mimimum de 20 cm de distance entre la source de rayonnement et votre corps.
C007964_05_CR2600_User_Manual
2
Code Reader™ 2600 User Manual
Copyright © 2014 Code Corporation.
All Rights Reserved.
The software described in this manual may only be used in accordance with the terms of its license agreement.
No part of this publication may be reproduced in any form or by any means without written permission from Code Corporation. This includes
electronic or mechanical means such as photocopying or recording in information storage and retrieval systems.
NO WARRANTY. This technical documentation is provided AS-IS. Further, the documentation does not represent a commitment on the part
of Code Corporation. Code Corporation does not warrant that it is accurate, complete or error free. Any use of the technical documentation
is at the risk of the user. Code Corporation reserves the right to make changes in specications and other information contained in this
document without prior notice, and the reader should in all cases consult Code Corporation to determine whether any such changes
have been made. Code Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or
consequential damages resulting from the furnishing, performance, or use of this material. Code Corporation does not assume any product
liability arising out of or in connection with the application or use of any product or application described herein.
NO LICENSE. No license is granted, either by implication, estoppel, or otherwise under any intellectual property rights of Code Corporation.
Any use of hardware, software and/or technology of Code Corporation is governed by its own agreement.
The following are trademarks or registered trademarks of Code Corporation:
CodeXML®, Maker, QuickMaker, CodeXML® Maker, CodeXML® Maker Pro, CodeXML® Router, CodeXML® Client SDK, CodeXML® Filter,
HyperPage, CodeTrack, GoCard, GoWeb, ShortCode, GoCode®, Code Router, QuickConnect Code, Rule Runner®, Cortex®, CortexRM,
CortexMobile, Code, Code Reader, CortexAG, CortexStudio, CortexTools, Afnity®, CortexDecoder, CortexJPOS, and CortexOPOS.
All other product names mentioned in this manual may be trademarks of their respective companies and are hereby acknowledged.
The software and/or products of Code Corporation include inventions that are patented or that are the subject of patents pending. U.S.
Patents: 6997387, 6942152, 7014113, 7070091, 7097099, 7353999, 7519239, 7621453, 8001550, 8011584.
The Code Reader software uses the Mozilla SpiderMonkey JavaScript engine, which is distributed under the terms of the Mozilla Public
License Version 1.1. The Code Reader software is based in part on the work of the Independent JPEG Group.
Code Corporation, 12393 S. Gateway Park Place, Ste. 600, Draper, Utah 84020
www.codecorp.com
C007964_05_CR2600_User_Manual
3
Table of Contents
1.0 - Included Items ........................................................................................... 5
2.0 - Set Up ....................................................................................................... 6
3.0 - Battery Installation and Removal .................................................................. 7
4.0 - Fuel Gauge Battery Status Indicator .............................................................. 7
5.0 - Charging the CR2600 ................................................................................. 7
6.0 - Powering On/Off the Reader ......................................................................... 8
7.0 - Scanning ................................................................................................... 8
8.0 - Establishing a Bluetooth Connection ............................................................. 9
9.0 - Transmitting Batch Data via Bluetooth Communication .................................10
10.0 - Transmitting Batch Data via USB Communication ......................................10
11.0 - Wired Communication via USB Downloader Mode ...................................... 11
12.0 - Reader Feedback .................................................................................... 11
13.0 - Reading Ranges ...................................................................................... 12
14.0 - Symbologies Defaulted On ....................................................................... 12
15.0 - Symbologies Defaulted Off ....................................................................... 12
16.0 - Reader ID and Firmware Version ............................................................... 13
17.0 - CR2600 Dimensions ............................................................................... 14
18.0 - Charging Station Dimensions ................................................................... 15
19.0 - CR2600 Maintenance ............................................................................. 15
20.0 - Warranty ................................................................................................ 16
C007964_05_CR2600_User_Manual
4
1.0 - Included if Ordered
USB 2.0 Cable
CR2600
(Model #: CR2611 or CR2612)
Mountable Palm
Charger
RS232 Cable
5VDC Power Supply
Charging Station Charging Station
with Embedded
CodeXML® Modem
CodeXML® M3 Modem
C007964_05_CR2600_User_Manual
Battery Cartridge
5
