PROFESSIONAL
SERIES
Owner’s Guide
For Model:
CA2LCD5
Flashlogic FLRS
RF Upgrade Kit
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
1CA2LCD5 / FLRS 4280855 Owners rev A.
Table of Contents
Using Your Remote Control .......................................................3
Remote Start Valet Mode ............................................................4
Additional 2 Way LCD Transmitter Functions ..........................5
2 Way LCD Transmitter Icon’s ...................................................7
Transmitter Programming ..........................................................8
Replacing Remote Control Batteries ........................................9
2 2017 Voxx Electronics Corporation. All rights reserved.
Using Your Remote Control
Door Lock
To lock the vehicle doors press and release the button.
Door Unlock
To unlock the vehicle doors press and release the button.
Two Stage Door Unlock (Optional)
If this feature is enabled on your system, pressing the button one time will unlock
only the driver’s door. Press again within three seconds to unlock the remaining
doors.
Activating the Trunk Release Feature (Optional)
If this feature is enabled on your system, pressing and holding the button for 3
seconds will open the vehicle’s trunk or hatch.
Using the Personal Protection Alarm (Panic)
Press and hold the button for 3 seconds to activate the personal protection alarm.
To stop the alarm, press and hold the button on the transmitter again for 3
seconds.
Remote Starting Your Vehicle
To activate the remote vehicle start function, press and release the button 2 times
within 2 seconds.
Remote Start Shutdown
Press and hold the button for 3 seconds to turn the vehicle off. Pressing the
vehicle’s brake will also shutdown the remote start.
3CA2LCD5 / FLRS 4280855 Owners rev A.
Entering the Vehicle while it is Running via Remote Vehicle Start
1. Unlock the vehicle’s doors.
2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!
3. Insert the key into the ignition switch and turn to the ON or RUN
position.
4. Press the brake pedal. The remote vehicle starter will disengage and
the vehicle will operate normally.
Preheating or Precooling the Vehicle’s interior
Before exiting the vehicle, set the temperature controls to the desired setting and
operation. After the system starts the vehicle, the heater or air conditioner will
activate and heat or cool the vehicle’s interior to your setting.
Remote Start Valet Mode
Enter / Exit Valet mode for systems using an Flashlogic FLRS kit.
1. Cycle ignition ON ve times [5x OFF/ON] rapidly. (complete this step
within 7 seconds)
2. Wait, LED 1 (on the FLRS kit) will turn solid RED for 2 seconds.
3. Turn ignition to OFF position.
4. Valet Mode Programming Procedure completed.
NOTE: In Valet Mode, the Remote starter is not functional. On units with Keyless
Entry, Lock and Unlock will remain functional. To exit valet mode: repeat steps 1 to 4.
4 2017 Voxx Electronics Corporation. All rights reserved.
Additional 2 Way LCD Transmitter Functions
Display Illumination
Press and hold the button for 1 second. The display will illuminate for 5 seconds.
Melody / Vibration Mode
To have the remote control vibrate, play a melody tone or both each time it receives a
response from the vehicle press and release then press and hold for 2
seconds.
Button Beeps
To toggle button beeps on or off press and release then press and hold for 2
seconds.
Battery Save Mode
While in POWER SAVE MODE the 2-way LCD transmitter will NOT look for any
incoming signals from the main unit until a button is pressed. The LCD screen will
display SAVE to indicate that power save mode is ON. To enter power save mode
press and hold for 5 seconds.
Button Lock
Press and release then press hold the for 2 seconds to toggle the button lock
on or off. When the button lock is active, the remote control will beep/vibrate 2 times
when a button is pressed indicating it is locked.
Illumination
Press and release 2 times then press and hold for 2 seconds to toggle
illumination on or off. When on, the display will illuminate when it receives or sends a
command.
2 Car Mode
To control a second security system enter 2 car mode by pressing then press
and together for 3 seconds. When the icon appears on the transmitter’s LCD
screen it will control the second security system. Use the same method to exit 2 car
mode and resume control of the original vehicle’s security system.
NOTE: A second security system must be installed and the LCD transmitter must be
learned to it before this feature will operate the additional system.
5CA2LCD5 / FLRS 4280855 Owners rev A.
Parking Meter Countdown
The parking meter countdown timer has 6 preset times, to access the preset times
and begin countdown press and release then press and hold for 2 seconds,
each additional press of will increase the countdown time.
Adjusting the Clock and Timer Settings
The clock, alarm clock and programmable countdown timer are accessed through the
Function Menu. Press and hold for 3 seconds to access the function menu, once
you have accessed the feature menu press and release to scroll through each
feature and follow the steps below to adjust the settings for each. Press and hold
for 2 seconds to exit the menu.
Clock Hour Press to increase or to decrease
Clock Minute Press to increase or to decrease
Alarm Clock Hour Press to increase or to decrease
Alarm Clock Minute Press to increase or to decrease
Alarm Clock ON / OFF Press to turn ON or to turn OFF
Countdown Timer Hour Press to increase or to decrease
Countdown Timer Minute Press to increase or to decrease
Countdown Timer ON / OFF Press to turn ON or to turn OFF
6 2017 Voxx Electronics Corporation. All rights reserved.
IGNITION ON/TRIGGER
2 Way LCD Transmitter Icon’s
NOTE:
Icons shown below are only be available when the host system connected
supports the available feature. Refer to the host system’s installation/user guide for
details of supported features.
LOCK
SYSTEM ARMED
TRANSMITTING
TRUNK TRIGGER
HOOD TRIGGER
SYSTEM TRIGGER
BATTERY INDICATOR
VIBRATE/SILENT MODE
2 CAR MODE
ALARM CLOCK
UNLOCK
VALET MODE
DOOR TRIGGER
FULL SHOCK TRIGGER
TIME COUNT DOWN
BATTERY SAVE MODE
MELODY MODE
TIME DISPLAY
ENGINE RUNNING
TIMER / TEMP.
START MODES
AUX 1 OUTPUT
AUX 3 OUTPUT
AUX 5 OUTPUT
AUX MODE
AUX 2 OUTPUT
AUX 4 OUTPUT
7CA2LCD5 / FLRS 4280855 Owners rev A.
Transmitter Programming
1. Turn the ignition ON.
2. Press and hold the valet/override button located on the antenna.
3. Within 10 seconds the LED’s will begin to ash.
4. Press 1 button of each transmitter you wish to program, the LED’s will
ash to conrm each transmitter.
5. Turn the ignition OFF
NOTE: This system has 1 button programming which programs all channels of the
system.
NOTE: The system will hold up to 4 transmitters in memory, programming a 5th
transmitter will erase the oldest transmitter in memory.
8 2017 Voxx Electronics Corporation. All rights reserved.
Replacing Remote Control Batteries
4 Button Remote Control - Model CAT4M
The battery inside each remote control should last approximately 1 year under normal
use. When the battery becomes weak you will notice the remote control range (the
distance from the vehicle the remote control will work) deteriorate and the small LED
on the remote control will dim. To replace the remote control batteries:
1. Remove 1 screw then disassemble the halves of the remote
control by unsnapping the back of the case.
2. Remove the old battery, observing the +/- symbols on the
batteries and replace with a new battery.
3. Reassemble the halves of the remote control and reinstall 1
screw.
4. Test operation of the remote control.
2 Way LCD Remote Control - Part # CATLCD
The AAA battery inside the 2-way LCD remote control should last approximately
6 months under normal use. When the battery becomes weak you will notice the
remote control range (the distance from the vehicle the remote control will work)
deteriorate and the BATTERY icon on the LCD remote control will show 1 bar or less.
1. Gently slide the battery cover off of the remote control.
2. Remove the old AAA battery, observing the +/- symbols on the
battery, and replace with a new AAA battery.
3. Gently slide the battery cover on to the back of the remote control.
4. Test operation of the remote control.
9CA2LCD5 / FLRS 4280855 Owners rev A.
10 2017 Voxx Electronics Corporation. All rights reserved.
11CA2LCD5 / FLRS 4280855 Owners rev A.
Voxx Electronics Corporation.
Customer Service 1-800-421-3209
WWW.CODE-ALARM.COM
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that
may cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
