Code CA1555 User Manual

PROFESSIONAL

SERIES

Owner’s Guide

For Model:

ca1555

* CASEC & CA2LCD5 *

Deluxe Vehicle Security and

Keyless Entry System

IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is

applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR

SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.

Table of Contents

Using Your Remote Control .................................................................... 3

Arming the Security System .............................................................. 3

Passive Arming Bypass .....................................................................3

Bypassing the Shock Sensor ............................................................ 3

Hidden Alarm Function ......................................................................3

Disarming the Security System ......................................................... 3

Two Stage Door Unlock (optional) .....................................................4

Activating Trunk Release (optional) ...................................................4

Activating AUX 1 (optional) ................................................................4

Entering AUX Mode and Activating Additional AUX Outputs ............. 4

Using the Progressive Car Finder Feature ........................................ 5

Using the Personal Protection Alarm .................................................5

Programmed Transmitter Notication ................................................5

Valet Mode ........................................................................................5

User Selectable Notication Chirps ................................................... 5

User Selectable LED ......................................................................... 6

Manually Overriding the Security System ......................................... 6

Carjack Mode .................................................................................... 6

Status LED, Light Flashes and Siren/Horn Indications ....................... 7

Additional 2-Way LCD Remote Control Functions ............................... 8

LCD Remote Control ICON’s ................................................................10

Remote Control Buttons & Functions ................................................. 11

Replacing Remote Control Batteries ................................................... 13

Programming Replacement Remote Controls .................................... 14

Warranty Information ............................................................................15

2 ca1555 Owners revA

Using Your Remote Control

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press the button. The

parking lights will ash 2 times, indicating the system is armed, has locked the doors (if equipped and connected) and activated the starter disable feature. The LED status indicator will blink steadily, once per second.

NOTE: The system is equipped with a feature called Silent Choice. If enabled, the

system requires a second press of the button to activate an audible arming

response from the vehicle.

Passive Arming Bypass

If passive arming is enabled on your system, while the system is disarmed, press

+ , the system will respond with 1 chirp and the LED will turn on. The security system will remain in this temporally bypassed state for as long as you wish. To exit

passive bypass, press the or button and the system will return to normal status.

Bypassing The Shock Sensor

To arm the system and ignore the shock sensor press button, then within 5

seconds press + , the system will respond with 1 long chirp.

NOTE: The system will only change the shock sensor setting for one arm cycle and

will be defaulted back to normal operation the next time the system is armed.

Hidden Alarm Function

Press the button rst, within 3 seconds press the button to activate the hidden

alarm function. The security system will arm with “Hidden Alarm Function” in which the siren / horn will be silenced if the system is triggered.

Disarming the Security System

To disarm the system press the button. The parking lights will ash 1 time,

indicating the system is disarmed and has unlocked the doors (if equipped and connected).

NOTE: The system is equipped with a feature called Silent Choice. If enabled, the

system requires a second press of the button to activate an audible disarming response from the vehicle. If your system is set up for 2 step unlock, a third press of unlock will activate the audible response.

*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more

than 2 seconds.

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the button one time will unlock

only the driver’s door. Press again within three seconds to unlock the remaining

doors.

Activating the Trunk Release Feature (Optional)

If this feature is enabled on your system, pressing and holding the button for 3

seconds will open the vehicle’s trunk or hatch.

Activating the AUX 1 Output (Optional)

If this feature is enabled on your system, pressing the and buttons

simultaneously will activate an optional feature. This feature can be programmed for a wide range of functions like power window or sunroof automation, please consult your installing dealer to determine the functionality of your system.

Entering AUX Mode and Activating the Additional AUX 2 - 5 Outputs (Optional)

To access the additional AUX outputs, AUX 2, AUX 3, AUX 4, and AUX 5, you must

rst enter the transmitters AUX Mode. This will “shift” the functions of the transmitter buttons from their standard operation to control of the AUX outputs.

AUX Mode - 4 button transmitter: Press and Hold and for 2

seconds, the transmitter LED will ash 1 time. AUX Mode will remain active for 15 seconds. AUX Mode will exit after 15 seconds of inactivity or by pressing and again for 2 seconds, the transmitter LED will ash 2 times to conrm exit.

AUX Mode - LCD 5 Button transmitter: Press and Hold for 2 seconds, the

transmitter LCD screen will display “AU”. AUX Mode will remain active for 15 seconds. AUX Mode will exit after 15 seconds of inactivity or by pressing again for 2 seconds.

Activating outputs while in AUX Mode:

AUX 2: Press and Hold for 3 seconds.

AUX 3: Press and Hold for 3 seconds.

AUX 4: Press and Hold for 3 seconds.

AUX 5: Press and Hold for 3 seconds.

4 ca1555 Owners revA

Using the Progressive Car Finder Feature

Press the button to locate your vehicle. The system will ash the parking lights

and sound 5 times at low volume, increasing in volume each time the button is

pressed.

Using the Personal Protection Alarm (Panic)

Press and hold the button for 3 seconds to activate the personal protection alarm.

During panic mode, the normal function of the transmitter buttons will be suspended. The transmitter’s and buttons can be used to lock and unlock the door (if the option is installed). To stop the alarm, press and hold the button on the transmitter again for 3 seconds. The system will automatically stop after 30 seconds.

Programmed Transmitter Notication

As a security precaution each time the vehicle’s ignition is turn on the status LED

light with ash the number of transmitters programmed into the system. This helps to identify unauthorized transmitters from accessing your vehicle. If you believe an unauthorized transmitter has been programmed to your system, contact your installing

dealer for assistance.

Valet Mode

When valet mode is activated the status LED will light solid, and all security functions will be disabled. To enter or exit valet mode simply follow the steps outlined below:

1. Turn the vehicle’s ignition ON.

2. Push and hold the programming/valet button, located on the antenna.

3. The LED will turn on solid when valet mode is active

4. Release the programming/valet button.

User Selectable Notication Chirps

System ARM/DISARM chirps can be toggled ON or OFF without entering the

programming feature banks.

1. Turn the ignition ON then OFF.

2. Press and release the valet/programming button 3 times. The system will respond with 1 chirp for ON or 2 chirps for OFF.

User Selectable LED

This feature will control whether the LED is ON or OFF when the system is Armed/

Locked and can be toggled ON or OFF without entering the programming feature banks.

1. Turn the ignition ON, OFF, ON, OFF.

2. Press and release the valet/programming button 3 times. The system will respond with 1 chirp for ON or 2 chirps for OFF.

Manually Overriding the Security System

Your system can be disarmed without the use of the transmitter. This is necessary,

since you will need the ability to operate your vehicle if the transmitter is lost or its

battery fails. To by-pass the alarm system;

1. Open the vehicle door. The alarm will sound.

2. Turn the ignition key to the ON position.

3. Within 10 seconds, press and release the valet push button switch.

The alarm system will stop sounding. You can now start and operate the vehicle

normally.

Carjack Mode (Anti-Hijack Mode)

This feature must be turned on in system programming, please consult your installing

dealer.

Triggering Carjack mode: While the ignition is ON and press and hold + for 2

seconds, the parking lights will ash 1 time and the system will act as follows;

1. 50 seconds after being triggered the siren will chirp for 15 seconds,

during this 15 seconds you will be alerted to push the valet button to turn off Carjack mode. If Carjack mode is not turned off at this time it

will advance to the next step.

2. Following the 15 second chirps (total time now 65 seconds) the siren

will go into full sound and the parking lights will start ashing.

3. 90 seconds after trigger in, addition to the siren and parking lights, the

system will activate the starter kill. THE SYSTEM WILL REMAIN IN THIS STATE UNTIL THE BATTERY IS DEPLETED.

OVERRIDE THE SYSTEM TO TURN OFF CARJACK MODE: Turn the ignition OFF

then On and press the valet button within 10 seconds.

6 ca1555 Owners revA
