Coda K-Series User Manual
K-Series Manual
K4
Type: Ultra compact 2-way full range system
Main Application: Top
Frequency Response: 80Hz–30kHz(-3dB)
Power Handling (AES): 250W
Program Power: 500W
Peak Power: 1000W
Sensitivity: 94dB
Max SPL peak: 124dB
Dispertion: 90° x 60°
Components:
Low frequency speaker:
2x5”/1.5”VCultralowdistortion
High frequency driver:
1.5”VCdriver
Crossover point: 1600Hz passive
Nominal impedance: 16Ω
Input connectors: 2xNeutrik™ NL4MP internal loop
Enclosure: 12/15mm Baltic birch plywood
Net weight: 8kg
Dimmensions: 160 x 480 x 184mm
TECHNICAL SPECIFICATIONS:
Type: Ultra compact 2-way full range system
Main Application: Top and stage monitor
Frequency Response: 80Hz – 30kHz (-3dB)
Power Handling (AES): 125W
Program Power: 250W
Peak Power: 500W
Sensitivity: 92dB
Max SPL peak: 118dB
Dispertion: 90° x 60°
Components:
Low frequency speaker:
5”/1.5”VCultralowdistortion
High frequency driver:
1”/1.5”VCdriver
Crossover point: 1600Hz passive
Nominal impedance: 16Ω
Input connectors: 2xNeutrik™ NL4MP internal loop
Enclosure: 12mm Baltic birch plywood
Net weight: 6kg
Dimmensions: 160 x 330 x 184mm
TECHNICAL SPECIFICATIONS:
K5
TheCodaAudioK4 is an ultra compact versatile, full range, 2-way
loudspeaker system that features a 5-inch ultra low distortion
low frequency driver and 1-inch
compression driver coupled to a rotatable 90° x 60°
elliptical waveguide. The K4 incorporates a
multi-design enclosure enabling it to be used
horizontal, vertical or
as a floor monitor.
The addition of flying
hardware as standard
together with the ability
to rotate the elliptical
waveguide allows
multipurpose applications.
The Coda Audio K5 is an ultra compact full range 2-way loudspeaker
system that features double 5-inch ultra low distortion cone
drivers and a 1-inch compression driver
coupled to a rotatable 90° x 60° elliptical
waveguide. The addition of M6 flying points as
a standard together with the ability to rotate
the elliptical waveguide allows multipurpose
applications.
Dimension drawing
160.0 mm
C
ontroller:
S
uitable Subwoofer:
2
Accessoires and Flying hardware drawings
U-bracket
vertical
AC24
:
330.0 mm
UC
PW12, PW12A
68620
Truss clamp
82.0 mm
:
150°
184.0 mm
120°
195/8
Stand fitting
135°
135°
Dimension drawing
160.0 mm
C
ontroller:
S
uitable Subwoofer:
CUC
A24
:
480.0 mm
PW12, PW12A
Accessoires and Flying hardware drawings
U-bracket
vertical
68620
Truss clamp
184.0 mm
82.0 mm
:
195/8
Stand fitting
K189 K189 Pro/K289K289Pro/
Type: Ultra compact 2-way full range system
Main Application: Top and stage monitor
Frequency Response: 60Hz – 30kHz (-3dB)
Power Handling (AES): 150W
Program Power: 300W
Peak Power: 600W
Sensitivity: 94.5dB
Max SPL peak: 122dB
Dispertion: 90° conical
Components:
Low frequency speaker:
8”
High frequency driver:
1”driver
Crossover point: 1900Hz
Nominal impedance: 8Ω (K189) / 16Ω (K189Pro)
Input connectors: 2xNeutrik™ NL4MP internal loop
Enclosure: 15mm plywood
Net weight: 11.2kg (K189) / 13kg (K189Pro)
Dimmensions: 250 x 480 x 285mm
TECHNICAL SPECIFICATIONS:
Type: Ultra compact 2-way full range system
Main Application: Top
Frequency Response: 55Hz – 30kHz (-3dB)
Power Handling (AES): 300W
Program Power: 600W
Peak Power: 1200W
Sensitivity: 97.5dB
Max SPL peak: 128dB
Dispertion: 90° conical (289)
Components:
Low frequency speaker:
2x8”
High frequency driver:
1”driver
Crossover point: 1900Hz
Nominal impedance: 4Ω (K289) / 16Ω (K289Pro)
Input connectors: 2xNeutrik™ NL4MP internal loop
Enclosure: 15mm plywood
Net weight: 17kg (K289) / 18kg (K289Pro)
Dimmensions: 250 x 700 x 300mm
TECHNICAL SPECIFICATIONS:
The CODA Audio K189 is a compact, full range, high output loudspeaker
system that offers both high fidelity and high efficiency for variety of
applications. The asymmetric profile of the
K189/K189Pro permits use as a Front of House
P.A. System or as a Stage Monitor.
The Coda Audio K289 contains a pair of low frequency 8-inch cone
drivers with 2-inch voice coils, and a 1-inch high frequency driver
mounted on a 90° conical
waveguide. All Pro enclosures include
14 M6 mounting suspension points and
an air cargo flying track.
AC24
:
480.0 mm
S
PW112, PW118, PW18A
68620
Truss clamp
Dimension drawing
250.0 mm
ontroller:
C
uitable Subwoofer:
S
Accessoires and Flying hardware drawings
U-bracket
vertical
Dimension drawing
135°
285 mm
:
105°
120°
161 mm
250.0 mm
C
ontroller:
S
uitable Subwoofer:
Accessoires and Flying hardware drawings
U-bracket
vertical
AC24S
:
700.0 mm
PW115, PW118, PW18A
68620
Truss clamp
300.0 mm
120.0 mm
:
155°
120°120°
155°
3
