7” WIDESCREEN TFT LCD
PORTABLE FLATSCREEN TELEVISION
TF-TV705
Instruction Manual
Please read this manual carefully before operation.
www.cobyusa.com Page 3
PRECAUTIONS
For Customer Use:
Enter below the serial number that is located on the
bottom of the unit. Retain this information for future
reference.
Model No. TF-TV705
Serial No.
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufcient magnitude to c onstitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presenc e of impor tant operation and servicing instructions in the literature accompanying
the appliance.
WARNING:
To prevent re or sh ock hazard, do not expo se this devic e to rain or mo isture. Dan gerous high voltage is present ins ide the
enclos ure. Do not op en the cabinet.
WARNING:
Handlin g the cords on this prod uct will exp ose you to lead, a chemical known to th e State of Cal ifornia to cause can cer, and
birth defects or other repro ductive ha rm. Wash hands afte r handli ng.
FCC Noti ce:
This equi pment has be en tested and found to com ply with th e limits for a C lass B digital device p ursuant wi th the FCC Rule s,
Part 15. Th ese limits are designed to provide r easonable protect ion against harmful in terference in a resi dential in stallati on.
This equi pment gene rates, uses, and can rad iate radio f requency e nergy, and if not installed a nd used in accordanc e with the
instru ctions may c ause harm ful inter ference to radio com munication.
CAUTION :
To prevent electric shoc k, match wide blade of plu g to wide slot of outlet and f ully inser t.
NOTE:
Before plugging the power cord into an AC outlet, make sure that all the con nection s have been made.
For recycling or disposal information about this product, please
contact your local authorities or the Electronics Industries Alliance:
www.eiae.org.
Page 2 Coby Electronics Corporation
IMPORTANT SAFETY INSTRUCTIONS
Read Instructions: All the safety and operating instructions should be read before the product
1.
is operated.
Retain Instructions: The safety and operating instructions should be retained for future refer-
2.
ence.
Heed Warnings: All warnings on the product and in the operating instructions should be
3.
adhered to.
Follow Instructions: All operating and usage instructions should be followed.
4.
Cleaning: Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners
5.
or aerosol cleaners. Use a damp cloth for cleaning.
Attachments: Use only attachments recommended by the manufacturer. Use of other attach-
6.
ments may be hazardous.
Water and Moisture: Do not use this product near water (e.g., near a bath tub, washbowl,
7.
kitchen sink, laundry tub, in wet basements, or near a swimming pool and the like).
Accessories: Do not place this product on an unstable cart, stand, tri-
8.
pod, bracket, or table. Use only with carts, stands, tripods, brackets,
or tables recommended by the manufacturer or sold with the product. Any mounting of the product should follow the manufacturer’s
instructions and should use a mounting accessor y recommended
by the manufacturer.
A product and cart combination should be moved with care. Quick
9.
stops, excessive force, and uneven surfaces may cause the product
and cart combination to overturn.
Ventilation: Slots and openings in the cabinet are provided for ventilation
10.
to ensure reliable operation of the product and to protect it from overheating. These openings
should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer instructions have been adhered to.
Power Sources: This product should be operated only from the type of power source indi-
11.
cated on the rating label. If you are not sure of the type of power supply to your home, consult
your product dealer or local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
Grounding or Polarization: This product may be equipped with a polarized alternating-current
12.
line plug that has one blade wider than the other. This plug will only t into the power outlet in
one direction. This is a safety feature. If you are unable to insert the plug fully into the outlet,
try reversing the direction of the plug. If the plug should still fail to t, contact an electrician to
replace the obsolete outlet. Do not defeat the safety purpose of the polarized plug.
Power-Cord Protection: Power supply cords should be routed so that they are not likely to
13.
be walked on or pinched by items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and at the point which they exit from the product.
Protective Attachment Plug: The product may be equipped with an attachment plug with
14.
overload protection. This is a safety feature. See the operating instructions for replacement
or directions to reset the protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same overload protection as the
original plug as specied by the manufacturer.
www.cobyusa.com Page 3
www.cobyusa.com Page 5
IMPORTANT SAFETY INSTRUCTIONS
Outdoor Antenna Grounding: If an outside antenna is connected to the product, be sure the
15.
antenna system is grounded so as to provide some protection against voltage surges and
built-up static charges. Ar ticle 810 of the National Electrical Code, ANS/NFPA 70 provides
information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding electrodes, and requirements for the
grounding electrode (see gure).
Lightning: For added protection for this product, unplug it from the wall outlet and disconnect
16.
the antenna or cable system during a lightning storm or when it is left unattended and unused
for long periods of time. This will prevent damage to the product due to lightning or power-line
surges.
Power Lines: An outside antenna system should not be located in the vicinity of overhead
17.
power lines or other electric light or power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system, extreme care should be taken to keep
from touching such power lines or circuits, as contact with them might be fatal.
Overloading: Do not overload wall outlets, extension cords, or integral convenience recep-
18.
tacles as this can result in a risk of re or electric shock.
Object and Liquid Entry: Never push objects of any kind into this product through openings
19.
as they may touch dangerous voltage points or shout-out parts that could result in a re or
electric shock. Never spill liquid of any kind on the product.
Servicing: Do not attempt to service this product yourself as opening or removing covers may
20.
expose you to dangerous voltage or other hazards. Refer all servicing to qualied service
personnel.
Damage Requiring Service: Unplug this product from the wall outlet and refer servicing to
21.
qualied service personnel under the following conditions: a) when the power-supply or plug
is damaged; b) if liquid has been spilled or if objects have fallen into the product; c) if the
product has been exposed to rain or water; d) if the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating
instructions as improper adjustment of other controls may result in damage and will often
require extensive work by a qualied technician to restore the product to its normal operation;
e) if the product has been dropped or damaged in any way; f) when the product exhibits a
distinct change in performance —this indicates a need for service.
Page 4 Coby Electronics Corporation
IMPORTANT SAFETY INSTRUCTIONS
Replacement Parts: When replacement parts are required, be sure that your service techni-
22.
cian has used replacement par ts specied by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in re, electric shock, or
other hazards.
Safety Check: Upon completion of any service or repairs to this product, ask the service tech-
23.
nician to per form safety checks to ensure that the product is in proper operating condition.
Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as recom-
24.
mended by the manufacturer.
Heat: The product should be situated away from heat sources such as radiators, heat regis-
25.
ters, stoves, or other products (including ampliers) that produce heat.
www.cobyusa.com Page 5
www.cobyusa.com Page 7
TABLE OF CONTENTS
PRECAUTIONS ................................................................................................................................2
IMPORTANT SAFETY INSTRUCTIONS .............................................................................................3
TABLE OF CONTENTS ......................................................................................................................6
FEATURES ........................................................................................................................................7
PACKAGE CONTENTS ....................................................................................................................8
LOCATION OF CONTROL S ............................................................................................................9
Left Panel View ................................................................................................................................9
Front Panel View ..............................................................................................................................9
Right Panel View ..............................................................................................................................9
Rear Panel View ..............................................................................................................................9
Remote Control ..............................................................................................................................10
GETTING STARTED ........................................................................................................................11
Powering your Device ....................................................................................................................11
AC Power Operation ..............................................................................................................11
Battery Operation...................................................................................................................11
Power Management .......................................................................................................................11
Using the Remote Control..............................................................................................................12
Cable Connections.........................................................................................................................13
Coaxial External Antenna Input (optional) .............................................................................13
Audio/Video (AV) Input (optional) ..........................................................................................13
TV FUNCTION ...............................................................................................................................14
Basic Operation .............................................................................................................................14
TV Setup Menu ..............................................................................................................................14
Menu Navigation ....................................................................................................................14
Menu Options .........................................................................................................................14
AV FUNCTION ..............................................................................................................................15
Basic Operation .............................................................................................................................15
AV Setup Menu ..............................................................................................................................15
Menu Navigation ....................................................................................................................15
Menu Options .........................................................................................................................15
TROUBLESHOOTING .....................................................................................................................16
SPECIFICATIONS ..........................................................................................................................17
Page 6 Coby Electronics Corporation
FEATURES
7” Widescreen TFT LCD Color Display
•
LED Backlight Technology provides a brighter display and increased battery life
•
High-Sensitivity NTSC TV with Digital Tuning
•
Integrated Telescopic Antenna
•
Coaxial Antenna Input for use with External Antenna Sources
•
AV Input for use with Video Games, VCRs, or other AV Sources
•
Headphone Jack for Private Listening
•
High-Output Stereo Speakers
•
Integrated Viewing Stand
•
Rechargeable Lithium-Ion Battery
•
Three-Way Power: AC/DC/Battery Operation
•
Full Function Remote Control
•
www.cobyusa.com Page 7
www.cobyusa.com Page 9
PACKAGE CONTENTS
5
2
3
4
Please make sure the following items are included with your LCD TV/monitor. If any items are
missing, contact your local dealer.
TF-TV705
1.
Remote Control
2.
AC Power Cord
3.
AV Cable
4.
Coaxial (RF) Antenna Adapter
5.
Page 8 Coby Electronics Corporation
1
2
3
5
6
15
16
4
13
7
9
11
8
10
12
14
17
18
LOCATION OF CONTROLS
Left Panel View
DC Power In
1.
Video In
2.
Audio In
3.
Headphone Out
4.
Front Panel View
Stereo Speakers
5.
TFT LCD Display
6.
AV/TV Mode
7.
Menu
8.
Volume Down
9.
Power Indicator
10.
Volume Up
11.
Channel Down
12.
Channel Up
13.
Remote Sensor
14.
Right Panel View
Coaxial (RF) Antenna In
15.
Power Switch (On/Off)
16.
www.cobyusa.com Page 9
Rear Panel View
Telescopic Antenna
17.
Kickstand
18.
www.cobyusa.com Page 11
LOCATION OF CONTROLS
Remote Control
TV/AV
1.
TV or AV Mode Select
Call
2.
View the current channel number
Recall
3.
Return to the previous channel
Menu
4.
Access the Setup Menu
Volume Up / Volume Down
5.
Adjust the volume level
Channel Up / Channel Down
6.
Change the channel up or down
Numeric Keypad
7.
Enter numeric input data.
Input
8.
Use with the Numeric Keypad to change
the channel directly.
Page 10 Coby Electronics Corporation
GETTING STARTED
To wall outlet
(AC 100-240V 50/60Hz)
To DC Power In
Powering your Device
AC Power Operation
Your device should be connected to an AC 100-240V wall outlet.
Using the supplied power adapter, plug one end of the adapter into the Power In jack of
•
your device and plug the other end into an AC 100-240V wall outlet.
Do not connect the power plug to a power outlet other than that which is indicated
here or on the label as this may result in the risk of re or electric shock.
Do not handle the power plug with wet hands. Doing so may cause electric shock.
Use only AC adapters of the type specied here. Failure to do so may cause a re
or damage the player.
Battery Operation
Your player can operate on a built-in 7.2V rechargeable battery.
To charge the battery, simply connect the AC adapter as directed above. The Power Indica-
•
tor will light red when the battery is being charged; it will light green when the battery is fully
charged.
The battery should be charged fully before it is used for the rst time.
Power Management
If the player will not be in use for a long period of time, set the Power Switch to the OFF position,
remove the battery, and unplug the player.
www.cobyusa.com Page 11
www.cobyusa.com Page 13
GETTING STARTED
2
1
4
3
Using the Remote Control
To load a battery in the remote:
Press in the direction of the arrow
1.
Slide the compartment out
2.
Place the battery in the compartment with the positive side ( + ) facing up
3.
Push the compartment in to close
4.
The battery used in this device may present a re or chemical hazard if mistreated.
Do not recharge, disassemble, incinerate, or heat the batteries.
Used batteries should be disposed of safely and not incinerated. Attention should
be shown to the environment aspects of battery disposal.
Keep batteries out of the reach of children.
To use the remote:
Point the remote at the remote sensor of the photo frame at a distance of no more than 15’
•
and at an angle no greater than 60 degrees.
Batteries will last for about one year under typical usage. Replace the batteries if
the remote is no longer working.
Do not spill water on the remote control.
Do not use the remote control for other equipment at the same time.
Remove the batteries if the remote control will not be in use for an extended period
of time.
Page 12 Coby Electronics Corporation
GETTING STARTED
External AV Source
(DVD, VCR, Camcorder)
External Antenna Source
(Cable Box, Antenna Line)
VIDEO IN (yellow)
RCA Composite
Video Out (Yellow)
Coaxial Antenna Adapter
Coaxial RF Out
RCA Stereo Audio Out
(Red & White)
AUDIO IN (black)
RF IN
Right PanelLeft Panel
Cable Connections
You can use an AV cable to connect an external device for display on the TF-TV705.
Do not connect the power until all connections have been made.
Coaxial External Antenna Input (optional)
Use a Coaxial (RF) Antenna Adapter to connect an external antenna source for use with the TFTV705 instead of the built-in telescopic antenna.
TV RF sources may include: Over-the-Air receiving antennas or cable lines. You can use a 75 ohm
coaxial cable to connect an outdoor antenna.
Attach an external antenna (RF, Cable) to the Coaxial (RF) Antenna Adapter.
1.
Plug the adapter into the Coaxial (RF) Antenna In jack of the unit.
2.
Set the unit to TV mode.
3.
Audio/ Video (AV) Input (optional)
Use a Audio/ Video (AV) cable to connect an external AV source for use with the TF-TV705.
External AV sources may include: DVD players, VCRs, camcorders, or game consoles.
Plug the AV cable’s black 3.5mm jack into the Audio In jack of the TF-TV705.
1.
Plug the AV cable’s yellow 3.5mm jack into the Video In jack of the TF-TV705.
2.
Connect the AV cable’s red and white RCA jacks to the audio output of the external device.
3.
Connect the AV cable’s yellow RCA jack to the video output of the external device.
4.
Set the unit to AV mode.
5.
www.cobyusa.com Page 13
www.cobyusa.com Page 15
TV FUNCTION
Basic Operation
Prepare the antenna (optional) and power connections (see the Getting Started section for
1.
details)
To turn the TV on, set the Power Switch to the “On” position.
2.
To set the unit to TV mode, press AV/TV. You should see the antenna signal on screen.
3.
To change the channel, press CH+/CH-.
4.
To change the channel directly, press INPUT on the remote, then use the numeric keypad
5.
to enter a channel number.
To view the current channel number on screen, press CALL. To return to a previously
6.
viewed channel, press RECALL.
To adjust the volume level, press VOL+/VOL-.
7.
TV Setup Menu
Menu Navigation
To navigate the TV menu:
Press MENU. The Setup menu will
•
appear on screen.
To select an option, press CH+/CH-.
•
To adjust a selected option, press
•
VOL+/VOL-.
To exit the Setup menu, press
•
MENU.
Menu Options
The TV setup menu contains the following options: ANTENNA, AUTO, FINE, SKIP, BRIGHTNESS, CONTRAST, COLOR, RESET.
Item Description
Antenna Set the Antenna system type: HRC, IRC, Air, Cable.
Auto Select to search and store all available broadcast channels.
Fine Adjust to ne-tune reception of a channel
Skip Set to “On” skip an unwanted channel; set to “Off” to keep the channel
Brightness Adjust the brightness level of the display screen.
Contrast Adjust the contrast level of the display screen.
Color Adjust the color level of the display screen.
Reset Restore all options to their factory-default settings
Page 14 Coby Electronics Corporation
AV FUNCTION
Basic Operation
Prepare the AV Input and power connections (see the Getting Started section for details).
1.
To turn the TV on, set the Power Switch to the “On” position
2.
To set the unit to AV mode, press AV/TV. You should see the AV Input signal on screen
3.
To adjust the volume level, press VOL+/VOL-
4.
AV Setup Menu
Menu Navigation
To navigate the AV setup menu:
Press MENU. The AV Setup menu will appear on screen.
•
To select an option, press CH+/CH-.
•
To adjust a selected option, press VOL+/VOL-.
•
To exit the Setup menu, press MENU.
•
Menu Options
The TV setup menu contains the following options: BRIGHTNESS, CONTRAST, COLOR, RESET.
Item Description
Brightness Adjust the brightness level of the display screen.
Contrast Adjust the contrast level of the display screen.
Color Adjust the color level of the display screen.
Reset Restore all options to their factory-default settings
I
www.cobyusa.com Page 15
www.cobyusa.com Page 17
TROUBLESHOOTING
If you have a problem with this TV, please read the troubleshooting guide below and check our
website at www.cobyusa.com for Frequently Asked Questions (FAQs) and rmware updates. If
these resources do not resolve the problem, please contact Technical Support.
COBY Electronics Technical Support
56- 65 Rust Street
Maspeth, NY 11378
Hours: Monday to Friday, 8:30 AM–11:00 PM EST
Email: techsupport@cobyusa.com
Phone: 800-681-2629 or 718-416-3197
Web: www.cobyusa.com
There is no power to the device.
•
•
There is no picture.
•
•
•
Saturday to Sunday, 9:00 AM–11:00 PM EST
Ensure that the Power Switch is physically set to the ON position.
Ensure that the AC adapter cord is securely connected to the TV and the proper wall outlet.
Ensure that the T V set has been powered on and is set to the correct mode (TV or AV).
Ensure that the connections between the player and the TV are secure and correct.
Check if the connection cables are damaged.
The picture is noisy or distorted.
Ensure that the video source is compatible with your TV (NTSC or PAL).
•
If an antenna is in use, try repositioning it for better reception.
•
Ensure that the AV cable is securely connected.
•
There is no sound or distorted sound.
Ensure that the T V and/or AV device have been turned on and properly set up.
•
Ensure that the T V and/or AV connections are secure and correct.
•
If an antenna is in use, try repositioning it for better reception.
•
The remote control doesn’t work.
Ensure that there are no obstacles between the remote and the player.
•
Point the remote at the remote sensor on the main unit.
•
Ensure that the batteries in the remote retain a charge and have been installed correctly.
•
Try replacing the remote’s batteries.
•
The unit has malfunctioned.
Unplug the TV and let it rest for 30 minutes, then reconnect the power. The restore function
•
should reset the TV.
Page 16 Coby Electronics Corporation
SPECIFICATIONS
Display Type 7” Widescreen TFT LCD with LED Backlight
Display Resolution 480 x 234
TV System NTSC
TV Tuning system Full Over-The-Air Channels
VHF-L: 55.25MHZ ~ 127.25 MHZ
VHF-H: 133.25 MHZ ~ 361.25 MHZ
UHF: 367.25 ~ 801.25 MHZ
Power Supply AC: 100-240V 50/60Hz
Power Consumption Working: 15W (max)
Input Component Video
Output 3.5mm Headphone
Operating Temperature 50ºF - 104ºF
Unit Dimensions 6.50” x 5.20” x 2.56” (WHD)
Weight 0.91 lbs
DC: 9V, 1.5A
Stereo Audio
Coaxial Antenna (RF)
Specications and manual are subject to change without prior notice.
www.cobyusa.com Page 17
www.cobyusa.com Page 19
NOTES
Page 18 Coby Electronics Corporation
NOTES
www.cobyusa.com Page 19
COBY Electronics Corp.
56- 65 Rust Street
Maspeth, NY 11378
ww w.cobyusa.com
ww w.ecoby.com
Loading...
