COBY electronic TFDVD7752 User Manual
TFDVD7752
PORTABLE DVD / CD / MP3 PLAYER
7” Twin Screen Portable LCD DVD Player
Instruction Manual
Please read this manual carefully before operation.
2
PRECAUTIONS
CAUTION
RISK O F ELECTRIC S HOCK
DO NOT OPE N
CAUTION : TO R EDUCE THE RISK OF FIRE AND ELECTRIC SHOC K, D O NOT REMOVE TH E COV ER (OR BACK )
OF THE UNIT. REFER SERVICING ONLY TO QUALIFIED
SERVICE PERSON NEL.
For Customer Use:
Enter below the serial number that is located on the
bottom of the unit. Retain this information for future
referenc e.
Model No. TFDVD7752
Serial No.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to aler t
the user to the presence of uninsulated “dangerous volt age” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electr ic shock.
The exclamation point within an equilateral triangle is intended to aler t the user to the presence of important operation and servicing instructions in the literature accompanyin
g the
appliance.
WARNING:
To prevent fire or shock hazard, do not e xpose this device to r ain or moisture. Dangerous high volt age is present inside th e
enclosure. Do not op en the cabinet.
Handling the c ords on this p roduct will expos e you to lead, a chemical kn own to the State of California to cause c ancer, and
birth defects or other reproductive harm. Wash han ds after han dling.
CAUTIO N:
This Digit al Video Dis c player employs a la ser system. To prevent direc t exposure to the lase r beam, do not t ry to o
enclosure or defeat the safet y interlo cks. When open and the interlocks are defeated, visible laser radiation is present.
To prevent electric shock, matc h wide blade of plu g to wide slot of outlet and fully in sert.
Use of controls, adjustments, or perfo rmance of procedures other than those sp ecified h erein may result in hazardous radiation
exposure. DO NOT S TARE INTO THE B EAM.
NOTICE:
This prod uct incorporates copyright protection technology that is p rotected by U.S. pate nts an
rights. Use of this copyright protec tion technology must be authorized by Macrovision, and is intended for home and other
limited viewing us es only unless otherwise authorized by Macrovision. Revers e engineering or disas sembly is prohibite d.
FCC Notice:
d other inte llectual property
pen the
FCC Statement:this device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and(2) This device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for Class B digital devic es, pursuant to Par t 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment
does cause harmful inter ference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to tr y
to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.- Increase the separation between the equipment and
receiver.- Connect the equipment into an outlet on a circuit different from that to which the receiver i
s
connected.- Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with Class B limits in Subpart B of Par t 15 of the FCC
rules.
3
PRECAUTIONS
Do not make any changes or modifications to the equipment unless other wise specifi ed in
the manual. If such changes or modifications should be made, you coul d be requi red to stop
operation of the equipment.
For recycling or disposal information about this product, please
contact your local authorities or the Electronics Industries Alliance:
www.eiae.org.
4
IMPORTANT SAFETY INSTRUCTIONS
Read Instructions: All the safety and operating instructions should be read before the product 1.
is operated.
Retain Instructions: The safety and operating instructions should be retained for future refer-2.
ence.
Heed Warnings: All warnings on the product and in the operating instructions should be 3.
adhered to.
Follow Instructions: All operating and usage instructions should be followed.4.
Cleaning: Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners 5.
or aerosol cleaners. Use a damp cloth for cleaning.
Attachments: Use only attachments recommended by the manufacturer. Use of other attach-6.
ments may be hazardous.
Water and Moisture: Do not use this product near water (e.g., near a bath tub, washbowl, 7.
kitchen sink, laundry tub, in wet basements, or near a swimming pool and the like).
Accessories: Do not place this product on an unstable cart, stand, 8. tri-
pod, bracket, or table. Use only with carts, stands, tripods, brackets,
or tables recommended by the manufacturer or sold with the product. Any mounting of the product should follow the manufacturer’s
instructions and should use a mounting accessor y recommended
by the manufacturer.
A product and cart combination should be moved with care. Quick 9.
stops, excessive force, and uneven surfaces may cause the product
and cart combination to overturn.
Ventilation: Slots and openings in the cabinet are provided for ventila-10. tion to
ensure reliable operation of the product and to protect it from overheating. These openings
should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer instructions have been adhered to.
Power Sources: This product should be operated only from the type of power source indi-11.
cated on the rating label. If you are not sure of the type of power supply to your home, consult
your product dealer or local power company. For products intended to operate from batter y
power or other sources, refer to the operating instructions.
Grounding or Polarization: This product may be equipped with a polarized alternating-current 12.
line plug that has one blade wider than the other. This plug will only t into the power outlet in
one direction. This is a safety feature. If you are unable to insert the plug fully into the outlet,
try reversing the direction of the plug. If the plug should still fail to t, contact an electrician to
replace the obsolete outlet. Do not defeat the safety purpose of the polarized plug.
Power-Cord Protection: Power supply cords should be routed so that they are not likely to 13.
be walked on or pinched by items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and at the point which they exit from the product.
Protective Attachment Plug: The product may be equipped with an attachment plug with 14.
overload protection. This is a safety feature. See the operating instructions for replacement
or directions to reset the protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same overload protection as the
original plug as specied by the manufacturer.
5
IMPORTANT SAFETY INSTRUCTIONS
Outdoor Antenna Grounding: If an outside antenna is connected to the product, be sure the 15.
antenna system is grounded so as to provide some protection against voltage surges and
built-up static charges. Article 810 of the National Electrical Code, ANS/NFPA 70 provides
information with regard to proper grounding of the mast and suppor ting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding electrodes, and requirements for the
grounding electrode (see gure).
Lightning: For added protection for this product, unplug it from the wall outlet and disconnect 16.
the antenna or cable system during a lightning storm or when it is left unattended and unused
for long periods of time. This will prevent damage to the product due to lightning or power-line
surges.
Power Lines: An outside antenna system should not be located in the vicinity of overhead 17.
power lines or other electric light or power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system, extreme care should be taken to keep
from touching such power lines or circuits, as contact with them might be fatal.
Overloading: Do not overload wall outlets, extension cords, or integral convenience recep-18.
tacles as this can result in a risk of re or electric shock.
Object and Liquid Entry: Never push objects of any kind into this product through openings 19.
as they may touch dangerous voltage points or shout- out parts that could result in a re or
electric shock. Never spill liquid of any kind on the product.
Servicing: Do not attempt to service this product yourself as opening or removing covers may 20.
expose you to dangerous voltage or other hazards. Refer all servicing to qualied service
personnel.
Damage Requiring Service: Unplug this product from the wall outlet and refer ser vicing to 21.
qualied service personnel under the following conditions: a) when the power-supply or plug
is damaged; b) if liquid has been spilled or if objects have fallen into the product; c) if the
product has been exposed to rain or water; d) if the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating
instructions as improper adjustment of other controls may result in damage and will often
require extensive work by a qualied technician to restore the product to its normal operation;
e) if the product has been dropped or damaged in any way; f) when the product exhibits a
distinct change in performance—this indicates a need for service.
6
IMPORTANT SAFETY INSTRUCTIONS
Replacement Parts: When replacement parts are required, be sure that your service techni-22.
cian has used replacement par ts specied by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in re, electric shock, or
other hazards.
Safety Check: Upon completion of any service or repairs to this product, ask the service tech-23.
nician to perform safety checks to ensure that the product is in proper operating condition.
Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as recom-24.
mended by the manufacturer.
Heat: The product should be situated away from heat sources such as radiators, heat regis-25.
ters, stoves, or other products (including ampliers) that produce heat.
7
TABLE OF CONTENTS
PRECAUTIONS ...............................................................................................................................2
IMPORTANT SAFETY INSTRUCTIONS ........................................................................................4
TABLE OF CONTENTS ...................................................................................................................7
PACKAGE CONTENTS ...................................................................................................................9
ABOUT OPTICAL DISCS ..............................................................................................................10
Disc Requirements.................................................................................................................10
Disc Care and Maintenance ..................................................................................................10
Handling a Disc ..............................................................................................................10
Cleaning a Disc ..............................................................................................................10
LOCATION OF CONTROLS .......................................................................................................... 11
Front View ..............................................................................................................................11
Back View ..............................................................................................................................12
Left View ................................................................................................................................12
Right View ..............................................................................................................................12
Remote Control ......................................................................................................................13
Battery Installation .................................................................................................................14
Power Supply .........................................................................................................................14
Headphone Connection ......................................................................................................... 14
CONNECTIONS ............................................................................................................................15
Power, Audio and Video Output Connections .......................................................................15
Connecting to a wall outlet ............................................................................................15
Outputting AV signal from the main unit to the monitor by the DC car cord .................15
Using the car plug ..........................................................................................................16
Outputting AV signal from the main unit to the monitor ................................................16
Audio and Video Connectios ( external device) ....................................................................16
Connecting to an Amplier Equipped with a Dolby Pro Logic Surround .............................. 17
Rechargeable Battery Pack ................................................................................................... 17
BASIC OPER ATIONS ....................................................................................................................18
Basic Playback .......................................................................................................................18
Play/Pause/Stop ............................................................................................................18
Previous /Next (Skip) .....................................................................................................18
Forward/Reverse (Search) ............................................................................................18
Slow/Step .......................................................................................................................18
Menu Navigation ....................................................................................................................19
Numeric Keypad ....................................................................................................................19
Disc Error Messages .............................................................................................................19
Power Management ...............................................................................................................19
PLAYER FUNCTIONS ...................................................................................................................20
Menu/Title ..............................................................................................................................20
Setup ......................................................................................................................................20
Display ...................................................................................................................................20
CD/DVD .........................................................................................................................20
8
TABLE OF CONTENTS
JPEG ..............................................................................................................................20
Repeat Mode..........................................................................................................................21
Repeat A-B Mode ..................................................................................................................21
Multi-Angle/Subtitle/Audio .....................................................................................................21
Zoom ......................................................................................................................................21
Clear .......................................................................................................................................21
Search ....................................................................................................................................21
DVD Mode......................................................................................................................21
CD Mode ........................................................................................................................21
LCD Mode ..............................................................................................................................22
Program Function ..................................................................................................................22
DVD Program Mode ......................................................................................................22
CD Program Mode .........................................................................................................23
SETUP ...........................................................................................................................................24
Language Setup .....................................................................................................................24
Screen Setup .........................................................................................................................24
Audio Setup ............................................................................................................................25
Custom Setup ........................................................................................................................25
SPECIFICATIONS .........................................................................................................................26
HEADREST MOUNTING BAG PLACEMENT ..............................................................................27
TROUBLESHOOTING ...................................................................................................................28
9
PACKAGE CONTENTS
Please make sure the following items are included in the package. If any items are missing, please
contact your local dealer.
Car Adaptor with AV
cable
Audio & Video Cable
L
R
Earphones
Headrest Mounting Bags
Loading...
