COBY electronic DP-768 User Manual

DP-768
7” Widescreen TFT LCD Digital Photo Frame
with Video and Music Playback
INSTRUCTION MANUAL
Please read this manual carefully before operation
The lightning ash with arrowhead symbol within an equilateral tri­angle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufcient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and servicing instructions in the literature acc ompanying the appliance.
For Custom er Use:
Enter below the serial number that is located on the bot tom of the unit. Retain this info rmation for future reference.
Model N o. DP-768
Serial N o.
For recycling or disposal information about this product, please contact your local authorities or the Electronics In­dustries Alliance: www.eiae.org.
Page 2 Coby Electronics Corporation
WARNING:
To prevent re or shock hazard, do not expose this device to rain or moisture. Dangerous high voltage is present inside the enclosure. Do not open the cabinet.
CAUTION:
To prevent electric shock, match wide blade of plug to wide slot of outlet and fully insert.
CAUTION:
Changes or modic ations not expressly approved in this manual could void your authority to operate this equipment.
Protec t your hearing:
Hearing experts advise against the constant use of personal stereos played at high volume. Constant exposure to high volumes can lead to hear ing loss. If you should experience ringing in the ears or hearing loss, discontinue use and seek medical advice.
NOTICE:
The LCD panel used in this player contains millions of thin lm transistors that have been manufactured using a high-technology process to deliver a crisp, clear, and detailed picture. Occasionally, a few of these transistors may become stuck or non-active; please note that this is a normal result of the manufacturing proc ess and does not affect the performance of the player.

Important Safety Instructions

Read these instructions.
1.
Keep these instruc tions.
2.
Heed all warnings.
3.
Follow all instructions.
4.
Do not use this apparatus near water.
5.
Clean only with dry cloth.
6.
Do not block any ventilation openings. Install in accordanc e with the manufacturer’s
7. instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
8. apparatus (including ampliers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
9. has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
10. receptacles, and the point where they exit from the apparatus.
Only use at tachments/accessories specied by the manufacturer.
11.
Use only with the car t, stand, tripod, bracket, or table specied by the
12. manufacturer, or sold with the apparatus. When a cart is used, use cau­tion when moving the cart/apparatus combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused for long periods of time.
13.
Refer all servicing to qualied service personnel. Servicing is required when the ap-
14. paratus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Caution
• Never push objects of any kind into this product, through openings or other wise; this may result in objects touching dangerous voltage points or short-out parts that could result in a personal or proper ty damage or injur y, including re or electric shock. Never spill liquid of any kind on the product.
• Ventilation: Any electrically powered consumer electronic product generates heat while in use, thereby requiring proper ventilation. To ensure reliable operation of the product and to protect it from overheating, do not operate the product on a bed, sofa, rug, or other similar soft surface, and never block any ventilation slots or openings provided for the unit. This product should not be operated in any enclosed area such as a cabinet, bookcase or rack unless proper ventilation is provided for the unit.
Page 4 Coby Electronics Corporation
Important Safety Instructions
• Water is a natural conductor of electricity. To avoid the possibility of shock or severe injury, do not use this product in or near any sources of water (e.g., a bath tub, washbowl, kitchen sink, laundry tub, in wet basements, a swimming pool and the like).
• Power Sources: This product should be operated only from the type of power source indicated on the rating label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For produc ts intended to operate from battery power or other sources, refer to the operating instructions.
• Lightning can cause power surges, which may damage or destroy your product. For added protection, unplug it from the wall outlet and disconnect the antenna or cable system during a lightning storm or when it is left unattended and unused for long periods of time.
• Overloading: Always operate any electrical device in accordance with applicable electrical codes. Never overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of personal or property damage or injury, including re or electric shock.
• Servicing: Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards, including the risk of injury or damage to persons or propert y. Your warranty will also be voided. Refer all servicing to qualied service per sonnel.
• Damage Requiring Service: Unplug this produc t from the wall outlet and refer servicing to qualied servic e personnel if: a) the power-supply or plug is damaged in any way; b) liquid has been spilled or if objects have fallen or been introduced into the product; c) the product has been exposed to rain, water or other sources of moisture; d) the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as improper adjustment of other controls may result in damage and/or require extensive work by a qualied service tech­nician to restore the product to its normal operation; e) the product has been dropped or damaged in any way; f) the product exhibits a distinc t change in performance indic ative of a need for service.
• Replacement Parts: When replacement parts are required, be sure that your ser vice tech­nician has used replacement par ts specied by the manufacturer or have the same char­acteristics as the original part. Unauthorized substitutions may result in injury to proper ty or persons including the risk of re, electric shock, or other hazards, and your warranty will be voided.
• Safety Check: Upon completion of any ser vice or repairs to this product, ask the ser vice technician to per form appropriate safety checks to ensure that the product is in proper operating condition.
• Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

Table of Contents

PRECAUTIONS .....................................................................................2
IMPORTANT SAFETY INSTRUCTIONS ...................................................4
TABLE OF CONTENTS ...........................................................................6
PACKAGE CONTENTS .........................................................................8
FEATURES .............................................................................................9
LOCATION OF CONTROLS ................................................................10
Main Unit ...........................................................................................................10
Remote Control ................................................................................................. 12
Installing a Battery in the Remote Control ................................................13
Using the Remote Control ........................................................................ 14
GETTING STARTED ............................................................................. 15
Installing a Memory Card ..................................................................................15
Connecting Power to your Frame .....................................................................16
Turning Your Photo Frame On/Off ....................................................................16
PLAYING YOUR FILES ........................................................................ 17
File Browser Menu ............................................................................................ 17
Using the File Browser Inter face ..............................................................18
File Type Icons .......................................................................................... 18
Extended Settings..................................................................................... 19
Card Selection Menu ................................................................................ 20
Photo Viewer ..................................................................................................... 21
Photo Viewer Controls ..............................................................................21
Photo Slideshow .......................................................................................22
Audio/Video Player ...........................................................................................23
Audio/Video Player Controls ....................................................................23
SETUP MENU ......................................................................................25
Language Options ............................................................................................. 25
Photo Options ...................................................................................................26
Reset Options ...................................................................................................27
Page 6 Coby Electronics Corporation
Table of Contents
OPTIONAL CONNECTIONS ..............................................................28
Headphones ...................................................................................................... 28
Audio Out ..........................................................................................................28
Composite Video ............................................................................................... 29
CHANGING THE FACEPLATE ............................................................30
FIRMWARE UPGRADES ......................................................................32
TROUBLESHOOTING ..........................................................................33
SPECIFICATIONS ...............................................................................35

Package Contents

Please make sure that the items shown below are included in the package. Should an item be missing, please contact the local retailer from which you purchased this product.
COBY DP-768
1.
Remote Control
2.
Two Wooden Frames (Maple and Black)
3.
AC Adapter
4.
Manual
5.
Page 8 Coby Electronics Corporation

Features

7” Widescreen TFT LCD Color Display
Displays JPEG Image Files
Plays MP3 and WMA Audio Files
Plays AVI, MPG, and XviD Video Files
AV Output for use with Home Theater Systems
SD, MMC, MS, xD, and CF Card Slots
Full-Size USB Port for use with Flash Memory Drives
Integrated Stereo Speakers
Two Interchangeable Frames
Wall Mountable Design with Detachable Stand

Main Unit

1
2
3
6
4
5
7
9
11
13
8
10
12
Front View
Remote Sensor
1.
7” TFT LCD (16:9)
2.
Rear View
Frame Clip
3.
Mounting Hole
4.
Speaker
5.
Detachable Stand
6.
Top View
Menu/Setup
7.
Press once for Menu; Press and hold for Setup
Enter/Slideshow
8.
Press once for Enter; Press and hold for Slideshow
Down
9.

Location of Controls

Up
10.
Left /Volume Down
11.
Press once for Left; Press and hold for Volume Down
Right/Volume Up
12.
Press once for Right; Press and hold for Volume Up
Volume Level Dial
13.
Page 10 Coby Electronics Corporation
Location of Controls
18
17
14
16
15
22
21
19
20
Left View
Compact Flash (CF)
14.
Memory Stick (MS)
15.
xD-Picture (xD)
16.
Secure Digital (SD) /
17. Multi Media Card (MMC)
USB Full-Size
18. (for use with USB ash drives)
Right View
Video Out
19.
Headphone / Audio Out
20.
Power Switch (On / Off)
21.
Power In Jack
22.

Remote Control

2
1
4
6
3
5
8
10
11
9
12
13
14
15
16
17
7
Menu
1.
Aspect Ratio
2.
Play / Pause
3.
Zoom
4.
Up (Navigation)
5.
Left (Navigation)
6.
Down (Navigation)
7.
Right (Navigation)
8.
Enter
9.
Stop
10.
Previous / Reverse
11.
Next / Forward
12.
Volume Down
13.
Volume Up
14.
Angle
15.
Setup
16.
Slideshow
17.
Location of Controls
Page 12 Coby Electronics Corporation
Location of Controls

Installing a Batter y in the Remote Control

The remote control requires one “CR2025” battery. To load a battery in the remote:
Slide the compartment out in
1. the direction of the arrow.
Place the battery in the com-
2. partment with the positive side (+) facing up.
Push the compartment in to close.
3.
Batteries will last for about one year under typical usage. Replace
the batteries if the remote is no longer working.
Remove the battery if the remote control will not be in use for an
Used batteries should be disposed of safely and not incinerated.
Keep batteries out of the reach of children.
extended period of time.
The battery used in this device may present a re or chemical
hazard if mistreated. Do not recharge, disassemble, incinerate, or heat the batteries.
Attention should be shown to the environment aspects of battery disposal.
Location of Controls

Using the Remote Control

Point the remote at the remote sensor of the photo frame at a distance of no
more than 15’ and at an angle no greater than 60 degrees.
Do not spill water on the remote control.
Do not use the remote control for other equipment at the same
time.
Page 14 Coby Electronics Corporation

Getting Started

To start playing photos, music, and videos on your digital photo frame, you will need to:
Install a memory card with compatible photo, music, and/or video les.
1.
Connect your photo frame to a power source.
2.
Turn on the photo frame.
3.

Installing a Memory Card

Your photo frame suppor ts the following types of memory cards:
Secure Digital cards (SD)
MultiMedia Card (MMC)
Compact Flash cards (CF)
xD-Picture card (xD)
Memory Stick (MS)
Simply insert the memory card of your choice into its corresponding card slot lo­cated on the left panel of the photo frame. Take care to orient the card in the proper direction.
Additionally, a full-size USB port is provided for use with USB ash memory drives.
MS and SD cards cannot be installed for use at the same time.
Getting Started

Connecting Power to your Frame

Your Photo Frame should be connected to an AC 100-240V wall outlet.
Using the supplied power adapter,
plug one end of the adapter into your photo frame’s Power In Jack and plug the other end into an AC 100-240V wall outlet.
Do not connect the power plug to a power outlet other than that
which is indicated here or on the label as this may result in the risk of re or electric shock.
Do not handle the power plug with wet hands. Doing so may cause
Use only the AC adapter supplied with the photo frame. Failure to

Turning Your Photo Frame On/Off

electric shock.
do so may cause a re or damage the player.
To turn your photo frame on, set the Power Switch to the “On” position.
To turn your photo frame of f, set the Power Switch to the “Off ” position.
If no memory cards have been loaded, the photo frame will auto-
matically display a demo slideshow after 10 seconds. To stop the demo slideshow, press any button or load a card.
Page 16 Coby Electronics Corporation

Playing Your Files

File Browser Menu

The File Browser allows you to view and play photos, music, and videos from any memory cards loaded into your photo frame.
Load a card into its corresponding slot and turn on the player. The photo frame will display the File Browser menu shown below.
You can also access the File Browser menu at any time by pressing .
To play a le, use the navigation keys to select a le and press to start
playback.
Selected File
1.
Number of Selected File /
2. Total Number of Files
Current Card Icon
3.
Name of Selected File
4.
File Type Icon
5.
Extended Information of
6. Selected File (if available)
Extended Settings
7.
Thumbnail Preview
8.
Playing Your Files

Using the File Browser Interface

Use the Navigation keys to make a selection:
To move the selection up, press .
To scroll up quickly, press and hold .
To move the selection down, press .
To scroll down quickly, press and hold .
To move the selection lef t, press .
To scroll left quickly, press and hold .
To move the selection right, press .
To scroll right quickly, press and hold .
Press to conrm the highlighted selection.
To return to the previous screen/folder, press .
To change the selected memory card, press until the Card Selection
menu appears.

File Type Icons

Icon Description
Photo File
Audio (Music) File
Video File
Folder
Previous Folder (Up)
Page 18 Coby Electronics Corporation
Playing Your Files

Extended Settings

Filter
Choose which types of les will be displayed (Audio, Photo, or Video).
If a there is no checkmark next to the type, those les will not be displayed
in the list.
Flat Mode
Turn Flat Mode on or of f. When Flat Mode is on, all les loaded on the memory card will be played.
Additionally, there are 2 Flat Mode options that you can set.
Repeat: Of f, Single, Folder, All
Mode: Normal, Shufe, Intro (for Audio only).
When Flat Mode is set to off, only audio les will be played.
Program
Use the Program List to customize the order in which les will play.
Edit Mode must be set to “On” for all functions to be available.
Use the Navigation Keys to select Edit Mode in the Extended Settings.
1.
Select les from the list and press to mark them with a check. To remove
2. the check, press again.
Select and conrm “Add to Program”. This will add the marked les to the
3. Program List
To view the Program List, select and conrm “Program View”.
4.
Playing Your Files
To play the Program List:
Make sure that Edit Mode is set to “Off ”.
Select a le in the Program List and press to start playback. The les in
the Program List will be played in sequence automatically.
To add more les to the Program List:
When the frame is in Program View, select and conrm “Browser View”.
Repeat Steps 1 to 4 to add les to the Program List.
To remove les from the Program List:
Make sure that Edit Mode is set to “Off ” and that the frame is in “Program
View”.
Select les from the Program List and press to mark them with a check.
Select “Clear Program” to remove the marked les.

Card Selection Menu

If multiple memory cards have been loaded, use the Card Selection menu to view les on a different card.
From the Play Menu screen, press until the
Card Selection menu appears.
Press or to select a card and then press
to conrm. The photo frame will load the contents of the card and display the Play Menu screen.
MS and SD cards cannot be installed for use at the same time.
Page 20 Coby Electronics Corporation
Playing Your Files

Photo Viewer

To start viewing your photos, select a photo le from the File Browser menu and press . The Photo Viewer will launch and display your photo in full-screen mode.
The photo frame will display compatible photo les, only. Baseline
JPEG les of up to 8MB and 32 million pixels are supported.

Photo Viewer Controls

Remote
Key
or
Frame
Button
Hold ENT ER/ SLIDES HOW
ENTER /
SLIDES HOW
MENU
--
--
Description
View the next photo.
View the previous photo.
Toggle the photo slideshow on or off.
Pause the photo slideshow.
Stop and return to the File Browser menu.
Change the magnication level of the displayed photo.
Each successive press of will change the magni­cation level as shown below:
Rotate the displayed photo.
Each successive press of will rotate the photo 90 degrees in a clockwise direction (90, 180, 270, No Rota­tion).
Playing Your Files
Remote
Key

Photo Slideshow

The slideshow function is enabled automatically when viewing your photos. When the slideshow function is enabled, the next photograph in the list will be displayed automatically after a predetermined length of time.
To toggle the slideshow function off or on, press .
To manually view the next photo, press .
To manually view the previous photo, press .
To change the length between transitions, change the option in the Setup
menu. Please refer to the Setup section of this manual for more information.
Frame
Button
Change the aspect ratio of the display.
--
Photo Viewing options may be set in the Setup menu. Please refer
to the “Setup” section of this manual for more information.
Photo Slideshow options may be set in the Setup menu. Please
refer to the “Setup” section of this manual for more information.
Each successive press of will toggle the display between a 4:3 (standard) or 16:9 (widescreen) aspect ratio.
Description
Page 22 Coby Electronics Corporation
Playing Your Files

Audio/ Video Player

To start playing music or video, select an audio or video le from the File Browser menu and press .
The photo frame will play compatible audio and video les, only.
MP3 and WMA audio les and AVI (XviD), MPG, and MPEG video les are supported.

Audio/ Video Player Controls

Remote
Key
Frame
Button
-- Play the next le.
-- Play the previous le.
Change the rate of forward playback (fast forward).
Each successive press will change the rate as follows:
Press to resume normal playback.
Change the rate of reverse playback (rewind).
Each successive press will change the rate as follows:
Press to resume normal playback.
ENTER /
SLIDES HOW
MENU
Volume
Level Dial
Play or pause the le.
Stop playback.
Increase the volume level.
Description
Playing Your Files
Remote
Key
Frame
Button
Volume
Level Dial
Repeat and Shufe playback options may be set in the Flat Mode
settings. Please refer to the “Playing Your Files > Extended Set­tings > Flat Mode” section of this manual for more information.
Decrease the volume level.
Description
Page 24 Coby Electronics Corporation

Setup Menu

To adjust the settings and options of your digital photo frame, press . The Setup Menu be displayed on screen.
Use the navigation keys to highlight and display option / sub-menu.
To conrm a selection, press .
To return to a previous menu level, press .
To exit the Setup Menu, press .
Please choose your desired settings as shown in the screens
below. The options marked ‘ ” are the default settings.

Language Options

OSD Language: Sets the language of the on-screen display.
Subtitle: Sets the language of the video subtitle. The video le must have
subtitle support for this option to work.
Setup Menu

Photo Options

View Mode: The Auto Fit setting will scale photographs to best t the display.
JPEG Interval: Sets the inter val between slideshow transitions.
Transition: Sets the slideshow transition type.
When the Transition option is set to “User”, the photo slideshow
function will not automatically transition to the next photo. Press
or to manually transition to the previous or next photo,
respectively.
Page 26 Coby Electronics Corporation

Reset Options

Select and conrm “Yes” to restore the default settings of the photo frame.
Setup Menu

Optional Connections

Your digital photo frame comes equipped with stereo audio and video output jacks.
Disconnect power from the photo frame and all additional
components prior to making these connections.

Headphones

Connect the Headphone / Audio Out jack to a pair of headphones or earphones for private listening. Audio output to the speakers will be disconnected automatically when a pair of headphones are in use.

Audio Out

Connect the Headphone / Audio Out jack to a pair of speakers, a stereo TV, or an amplier for audio output only.
An audio connection cable terminating in a 3.5mm plug is re-
quired to make this connection.
Page 28 Coby Electronics Corporation
Optional Connections

Composite Video

Connect the Video Out jack to a TV or monitor with composite video input capabil­ity for video output. Combine this connection with the Audio Out connection for Audio and Video output to a T V with AV Input jacks or a home theater system.
A composite video connection cable terminating in a 3.5mm plug
is required to make this connection.
Please refer to the instruction manual of your TV for more guidance.

Changing the Faceplate

Your digital photo frame comes equipped with interchangeable faceplates to match your home decor.
To detach a faceplate from your photo frame:
Rotate the clips on the rear of the frame in the direction indicated by the
1. arrows in the diagram.
The main unit may now be separated from the faceplate.
2.
Page 30 Coby Electronics Corporation
Changing the Faceplate
To attach a faceplate to your photo frame:
Place the front of the main unit into the rear of the faceplate.
1.
Rotate the clips on the frame in the direction indicated by the arrows in the
2. diagram so that the frame is secured to the main unit.

Firmware Upgrades

From time to time, COBY may release rmware updates to improve the perfor­mance of the DP-768 or to add additional features. Please check the COBY web ­site periodically at www.cobyusa.com to see if new rmware has been released for your photo frame.
Page 32 Coby Electronics Corporation

Troubleshooting

If you have a problem with this unit, please read the troubleshooting guide below and check our website at www.cobyusa.com for Frequently Asked Questions (FAQs) and rmware updates. If these resources do not resolve the problem, please contact Technical Support.
COBY Electronics Technical Suppor t
56- 65 Rust Street Maspeth, NY 11378
Email: techsuppor t@cobyusa.com
Web: www.cobyusa.com
Phone: 800-727-3592 (8:00 AM–11:00 PM EST, seven days a week)
The player does not turn on.
I cannot select a memory card.
The player will not play my music le.
The player will not play my video le.
800-681-2629 (8:00 AM– 5:30 PM EST, Monday to Friday) 718-416-3197 (8:00 AM–5:30 PM EST, Monday to Friday)
Make sure the unit has been powered on manually (i.e., the Power Switch has been physically set to the ON position).
Ensure that the power cord has been properly connected to the power outlet.
Ensure that a memory card or USB ash drive has been properly installed.
Ensure that the memory card or USB ash drive is not defective.
Ensure that the le is in a compatible format (MP3 or WMA).
The le may be copy-protected. This player cannot play copy-protected les.
Ensure that the video le will play on your computer using Windows Media Player 10. If the le works on the computer, use the same computer to con­vert the video to a compatible format.
Troubleshooting
The sound quality of the music is poor.
Try playing the le on your computer. If the sound quality is still poor, try
downloading the le again or re-encoding the le yourself.
Ensure that the bit rate of the le is not too low. The higher the bit rate of the
le, the better it will sound. The minimum recommended bitrate is 128kbps for MP3s and 96kbps for WMAs.
The picture is noisy or distorted when connected to a TV.
Reset the color system of the T V set.
Ensure that the photo frame is connected using an RCA composite video
cable.
There is no sound.
Ensure that the volume has been set to a reasonable level.
The remote control does not work.
Make sure the unit has been powered on manually (i.e., the Power Switch has
been physically set to the ON position).
Remove any obstacles between the remote control and the frame.
Point the remote control towards the remote sensor on the frame.
Ensure that the battery has been installed correctly in the remote control.
Replace the battery.
The photo frame has malfunctioned.
Turn the photo frame off and let it rest for 30 minutes. After that, turn on the
photo frame -- the restore function should reset the photo frame.
Try updating the player’s rmware. Please refer to the Firmware Upgrade
section of this manual for detailed instructions.
Page 34 Coby Electronics Corporation
Specications
Display Type 7” Full-Color TFT LCD
Display Resolution 480 x 23 4
Memory CF Card Slot
SD/MMC Card Slot
xD Card Slot
MS Card Slot
USB Flash Drive
Audio Format Support MP3 (32 - 384kbps, CBR/ VBR)
WMA
Video Format Support AVI (XviD)
MPG
MPEG
Photo Format Support JPEG (8MB maximum)
Audio Output 3.5mm Stereo / Headphone Out
Integrated Stereo Speakers
Video Output Composite Video
Power Supply DC 12V, 1A
100-240V AC Adapter
1 x CR2025 Battery (Remote)
Specications and manual are subject to change without prior notice.
768ZR
COBY Electronics Corp.
56- 65 Rust Street Maspeth, NY 11378
ww w.cobyusa.com ww w.ecoby.com
Loading...
