5.6” Color TFT LCD Digital Photo Frame
with Video and Music Playback
DP-562
INSTRUCTION MANUAL
Please read this manual carefully before operation
PRECAUTIONS
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufcient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operation and servicing
instructions in the literature acc ompanying the appliance.
For Custom er Use:
Enter below the serial number that is located on the bot tom of
the unit. Retain this info rmation for future reference.
Model N o. DP-5 62
Serial N o.
For recycling or disposal information about this product, please contact your local authorities or the Electronics Industries Alliance: www.eiae.org.
2
PRECAUTIONS
WARNING:
To prevent re or sh ock haz ard, do not expose t his device to rain o r moistu re. Dangerous high voltage is
present i nside th e enclo sure. Do n ot open th e cabine t.
CAUTION :
To prevent electric shock, match wide blade of plu g to wide sl ot of outl et and fully inser t.
Protec t your hearin g:
Hearing exper ts advise again st the co nstant u se of personal ste reos pl ayed at high volume. Constant
exposur e to high vol umes ca n lead to he aring l oss. If you should ex perie nce rin ging in th e ears or h earing
loss, discontinue use an d seek medical ad vice.
3
IMPORTANT SAFETY INSTRUCTIONS
Read Instructions: All the safety and operating instructions should be read
1.
before the product is operated.
Retain Instructions: The safety and operating instructions should be retained
2.
for future reference.
Heed Warnings: All warnings on the product and in the operating instructions
3.
should be adhered to.
Follow Instructions: All operating and usage instructions should be followed.
4.
Cleaning: Unplug this product from the wall outlet before cleaning. Do not use
5.
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Attachments: Use only attachments recommended by the manufacturer. Use
6.
of other attachments may be hazardous.
Water and Moisture: Do not use this product near water (e.g., near a bath tub,
7.
washbowl, kitchen sink, laundry tub, in wet basements, or near a swimming
pool and the like).
Accessories: Do not place this product on an unstable cart, stand, tripod,
8.
bracket, or table. Use only with carts, stands, tripods, brackets, or tables
recommended by the manufacturer or sold with the product. Any mounting
of the product should follow the manufacturer’s instructions and should use a
mounting accessory recommended by the manufacturer.
A product and car t combination should be moved with care.
9.
Quick stops, excessive force, and uneven surfaces may
cause the product and cart combination to overturn.
Ventilation: Slots and openings in the cabinet are provided
10.
for ventilation to ensure reliable operation of the product
and to protect it from overheating. These openings should
never be blocked by placing the product on a bed, sofa, rug,
or other similar surface. This product should not be placed in
a built-in installation such as a bookcase or rack unless proper ventilation is
provided or the manufacturer instructions have been adhered to.
Power Sources: This product should be operated only from the type of power
11.
source indicated on the rating label. If you are not sure of the type of power
supply to your home, consult your product dealer or local power company. For
products intended to operate from battery power or other sources, refer to the
operating instructions.
4
IMPORTANT SAFETY INSTRUCTIONS
Grounding or Polarization: This product may be equipped with a polarized
12.
alternating-current line plug that has one blade wider than the other. This plug
will only t into the power outlet in one direction. This is a safety feature. If you
are unable to inser t the plug fully into the outlet, try reversing the direction of
the plug. If the plug should still fail to t, contact an electrician to replace the
obsolete outlet. Do not defeat the safety purpose of the polarized plug.
Power-Cord Protection: Power supply cords should be routed so that they are
13.
not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and at
the point which they exit from the product.
Protective Attachment Plug: The product may be equipped with an attach-
14.
ment plug with overload protection. This is a safety feature. See the operating
instructions for replacement or directions to reset the protective device. If
replacement of the plug is required, be sure the service technician has used
a replacement plug that has the same overload protection as the original plug
as specied by the manufacturer.
Outdoor Antenna Grounding: If an outside antenna is connected to the prod-
15.
uct, be sure the antenna system is grounded so as to provide some protection
against voltage surges and built-up static charges. Article 810 of the National
Electrical Code, ANS/NFPA 70 provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire
to an antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements
for the grounding electrode (see gure).
5
IMPORTANT SAFETY INSTRUCTIONS
Lightning: For added protection for this product, unplug it from the wall outlet
16.
and disconnect the antenna or cable system during a lightning storm or when
it is left unattended and unused for long periods of time. This will prevent
damage to the product due to lightning or power-line surges.
Power Lines: An outside antenna system should not be located in the vicinity
17.
of overhead power lines or other electric light or power circuits, or where it
can fall into such power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching such power lines
or circuits, as contact with them might be fatal.
Overloading: Do not overload wall outlets, extension cords, or integral conve-
18.
nience receptacles as this can result in a risk of re or electric shock.
Object and Liquid Entry: Never push objects of any kind into this product
19.
through openings as they may touch dangerous voltage points or shout-out
parts that could result in a re or electric shock. Never spill liquid of any kind
on the product.
Servicing: Do not attempt to service this product yourself as opening or re-
20.
moving covers may expose you to dangerous voltage or other hazards. Refer
all servicing to qualied ser vice personnel.
Damage Requiring Service: Unplug this product from the wall outlet and re-
21.
fer servicing to qualied service personnel under the following conditions: a)
when the power-supply or plug is damaged; b) if liquid has been spilled or if
objects have fallen into the product; c) if the product has been exposed to rain
or water; d) if the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating instructions as improper adjustment of other controls may result in damage and
will often require extensive work by a qualied technician to restore the product to its normal operation; e) if the product has been dropped or damaged in
any way; f) when the product exhibits a distinct change in performance—this
indicates a need for ser vice.
Replacement Parts: When replacement par ts are required, be sure that your
22.
service technician has used replacement parts specied by the manufacturer
or have the same characteristics as the original par t. Unauthorized substitutions may result in re, electric shock, or other hazards.
Safety Check: Upon completion of any ser vice or repairs to this product, ask
23.
the ser vice technician to perform safety checks to ensure that the product is
in proper operating condition.
6
IMPORTANT SAFETY INSTRUCTIONS
Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling
24.
only as recommended by the manufacturer.
Heat: The product should be situated away from heat sources such as ra-
25.
diators, heat registers, stoves, or other products (including ampliers) that
produce heat.
7
TABLE OF CONTENTS
PRECAUTIONS .....................................................................................2
IMPORTANT SAFETY INSTRUCTIONS ...................................................4
TABLE OF CONTENTS ...........................................................................8
PACKAGE CONTENTS .......................................................................10
FEATURES ...........................................................................................
11
LOCATION OF CONTROLS ................................................................ 12
Top View ............................................................................................................12
Left View ........................................................................................................... 12
Front View .........................................................................................................12
Right View .........................................................................................................12
Remote Control .................................................................................................13
GETTING STARTED ............................................................................. 14
Using the Remote Control................................................................................. 14
Installing a Memory Card ..................................................................................15
Powering your Digital Picture Frame ................................................................15
Turning Your Photo Frame On/Off ....................................................................16
Menu Interface Navigation ................................................................................16
Select Card Screen ...........................................................................................17
Select Mode Screen..........................................................................................18
Overview of Icons ............................................................................................. 19
PHOTO MODE ....................................................................................20
Photo List ..........................................................................................................20
Photo View ........................................................................................................21
Zoom .........................................................................................................21
Rotate ........................................................................................................ 21
Screensize (Screen Ratio) ........................................................................ 21
Slideshow ..........................................................................................................22
MUSIC MODE ....................................................................................23
Music List ..........................................................................................................23
Music Controls ..................................................................................................24
8
TABLE OF CONTENTS
VIDEO MODE .....................................................................................25
Video List .......................................................................................................... 25
Video Controls ..................................................................................................26
FILE MODE .........................................................................................27
File List ..............................................................................................................27
SETUP MENU ......................................................................................28
Photo Options ...................................................................................................28
Music Options ...................................................................................................29
Video Options....................................................................................................2 9
System Options ................................................................................................. 29
Copy Options ....................................................................................................29
Delete Options ..................................................................................................30
CABLE CONNECTION .......................................................................31
Composite Video ............................................................................................... 31
Headphones ...................................................................................................... 32
Audio- Only Output ............................................................................................32
COMPUTER CONNECTION (USB) .....................................................33
USB Driver Installation (Required for Windows 98 SE Only) ........................... 33
Connecting to a Computer ................................................................................33
Transferring Files ..............................................................................................34
Microsoft Windows ....................................................................................3 4
Macintosh OS X ........................................................................................34
Disconnecting from a Computer .......................................................................34
Microsoft Windows ....................................................................................3 5
Macintosh OS X ........................................................................................35
FACEPLATES .......................................................................................36
FIRMWARE UPGRADES ......................................................................37
TROUBLESHOOTING ..........................................................................38
SPECIFICATIONS ...............................................................................41
9
2
6
3
4
1
8
7
5
ZOOM
ENTER
SETUP
VOL- VOL+
ANGLE
DIGITAL PHOTO FRAME
MENU
DP562
MUTE
PACKAGE CONTENTS
Please make sure that the items shown below are included in the package. Should
an item be missing, please contact the local retailer from which you purchased this
product.
10
COBY DP-562
1.
USB Cable
2.
Audio/Video (AV) Cable
3.
Remote Control
4.
5.
6.
7.
8.
Stereo Headphones
AC Adapter
Installation CD
Manual
FEATURES
5.6” TFT LCD Color Screen
•
LED backlight technology provides a brighter display
•
Displays JPEG and BMP Photo Files
•
Plays MP3 and WMA Music Files
•
Plays Most MP4 and AVI Video Files from Digital Cameras
•
Photo Slideshow with Music
•
AV Output for use with Home Theater Systems
•
SD, MMC, xD, and CF Card Slots
•
Full-Size USB port for use with USB Flash Drives
•
USB Port for Fast File Transfers
•
Integrated Stereo Speakers
•
Interchangeable Faceplate
•
Detachable Stand
•
Full Function Remote Control
•
Wall Mountable
•
11
12
4
2
6
ENTER/SLIDE
MENU
3
5
1
8
10
11
9
12
13
14
15
18
19
20
16
17
7
Top View
Menu/Setup
1.
Press once for Menu;
Press and hold for
Setup
Enter/Slideshow
2.
Press once for Enter;
Press and hold for
Slideshow
Down
3.
Up
4.
Left /Volume Down
5.
Press once for Left;
Press and hold for
Volume Down
LOCATION OF CONTROLS
6.
7.
Left View
8.
9.
10.
11.
12.
Right /Volume Up
Press once for Right;
Press and hold for
Volume Up
Backlight Level Dial
MS Slot (MS)
Compact Flash (CF)
xD-Picture (xD)
Secure Digital (SD) /
Multi Media Card
(MMC)
USB Full-Size
(for use with USB
ash drives)
USB-mini
13.
(for PC connection)
Front View
5.6” TFT LCD
14.
Remote Sensor
15.
Right View
Headphone /
17.
Video Out
16.
Audio Out
Power Switch
18.
(On / Off )
Power In Jack
19.
Detachable Kickstand
20.
Remote Control
2
1
4
6
3
5
8
10
11
9
12
13
14
15
16
17
7
Menu
1.
Mute
2.
Play / Pause
3.
Zoom
4.
Up (Navigation)
5.
Left (Navigation)
6.
Down (Navigation)
7.
Right (Navigation)
8.
Enter
9.
Stop
10.
Previous / Reverse
11.
Next / Forward
12.
Volume Down
13.
Volume Up
14.
Angle
15.
Setup
16.
Slideshow
17.
13
GETTING STARTED
2
1
4
3
Using the Remote Control
To load a battery in the remote:
Press in the direction of the arrow
1.
Slide the compartment out
2.
Place the battery in the compartment with the positive side ( + ) facing up
3.
Push the compartment in to close
4.
To use the remote:
Point the remote at the remote sensor of the photo frame at a distance of no
•
more than 15’ and at an angle no greater than 60 degrees.
Batteries will last for about one year under typical usage. Replace the batter-
•
ies if the remote is no longer working.
Do not spill water on the remote control.
•
Do not use the remote control for other equipment at the same time.
•
Remove the batteries if the remote control will not be in use for an extended
•
period of time.
14
The battery used in this device may present a re or chemical
hazard if mistreated. Do not recharge, disassemble, incinerate, or
heat the batter ies.
Used batteries should be disposed of safely and not incinerated.
Attention should be shown to the environment aspects of battery
disposal.
Keep batteries out of the reach of children.
GETTING STARTED
Installing a Memory Card
Your picture frame supports the following types of memory cards:
Compact Flash cards (CF)
•
Secure Digital cards (SD)
•
MultiMedia Card (MMC)
•
xD-Picture card (xD)
•
Simply insert the memory card of your choice into its corresponding card slot located on the left panel of the photo frame. Take care to orient the card in the proper
direction.
Getting photos and les onto your picture frame for viewing couldn’t be easier!
Powering your Digital Picture Frame
Your Picture Frame should be connected to
an AC 100-240V wall outlet.
Using the supplied power adapter,
•
plug one end of the adapter into
your photo frame’s Power In Jack
and plug the other end into an AC
100-240V wall outlet.
Do not connect the power plug to a power outlet other than that
which is indicated here or on the label as this may result in the risk
of re or electric shock.
Do not handle the power plug with wet hands. Doing so may cause
electric shock.
Use only AC adapters of the type specied here. Failure to do so
may cause a re or damage the player.
15
GETTING STARTED
Turning Your Photo Frame On/Off
To turn your photo frame on, set the Power Switch to the “On” position.
•
To turn your photo frame of f, set the Power Switch to the “Off ” position.
•
Menu Interface Navigation
To select the different menu options and les of your digital photo frame:
Use the Navigation keys to make a selection.
•
To move the selection up, press
•
To scroll up quickly, press and hold
To move the selection down, press
•
To scroll down quickly, press and hold
To move the selection lef t, press
•
To scroll left quickly, press and hold
To move the selection right, press
•
To scroll right quickly, press and hold
Press ENTER to conrm the highlighted selection.
•
To return to the previous screen, press MENU.
•
To advance to the next page, press
•
To return to a previous page, press
•
16
GETTING STARTED
Selected Inserted No CardNo Card
SELECT CARD SCREEN
Select Card Screen
Upon turning on the power, your photo frame will display the “Select Card“ screen
shown below.
Use the navigation keys to select an available card slot and then press EN -
•
TER to conrm.
Inser ted: A card icon that is in-color indicates that a memory card has
been inserted (installed) in the corresponding slot.
No Card: A card icon that is grayed-out indicates that a memory card
has not been installed in the corresponding slot and is not
available for use.
Selected: A highlighted frame indicates that the card slot is selected. Only
card slots with an installed memory card may be selected.
17
GETTING STARTED
Select Mode Screen
Upon selecting a card, your photo frame will display the “Select Mode“ screen
shown below.
Use the navigation keys to select a player mode and then press ENTER to
•
conrm.
File Mode: Manage and play les from an installed memory card.
Music Mode: Play music les from an installed memory card.
Photo Mode: View photo les from an installed memory card.
Video Mode: Play video from an installed memory card.
18
GETTING STARTED
Overview of Icons
Upon entering a player mode, icons will appear in the lower-left corner of the display screen.
Icon Description
Enter/conrm the selected item
Press ENTER
Return to the previous item/screen
Press MENU
Select the item/le to the right
Press
Select the item/le to the left
Press
Select the previous item/le
Press
Select the next item/le
Press
Indicates that a function is currently unavailable
Start photo slideshow
Press
Start background music during slideshow
Press ENTER during slideshow
Start playback of music or video (in Music or Video modes)
Press ENTER in Music or Video list.
Pause playback
Press during playback
Stop playback
Press during playback
19
PHOTO MODE
To display your photos, select Photo Mode from the “Select Mode” screen and
press ENTER.
Photo List
Upon entering Photo Mode, your photo frame will scan the memory card for available photos and display the “Photo List“ screen shown below. The Photo List displays thumbnail images of all available photos.
To display a photo (full screen), use the navigation keys to select a thumbnail
•
and press ENTER to conrm.
20
Selected thumbnail le (highlighted)
1.
Current Page Number / Total Number of Pages
2.
Filename of selected thumbnail
3.
Resolution (size) of selected thumbnail
4.
The Photo List will display supported Photo les, only.
Your photo frame can display baseline JPEG les of up to 32
million pixels and 14MB in size, as well as BMP les up to 1024 x
1024 and 14MB in size.
PHOTO MODE
Photo View
Upon entering a thumbnail in the “Photo List”, your photo frame will display the
photo in full-screen Photo View mode.
To view the previous photo, press
•
To view the next photo, press
•
Zoom
To increase the level of magnication, press ZOOM.
Each successive press of ZOOM will change the level of magnication as
•
shown below
To pan around the magnied picture, use the navigation keys.
•
Rotate
To rotate the picture, press ANGLE.
Each successive press of ROTATE will change the angle of rotation as shown
•
below
Screensize (Screen Ratio)
To toggle the screensize between 4:3 (standard) and 16:9 (widescreen), repeatedly
press the LEFT button on the photo frame.
21
PHOTO MODE
Slideshow
To display your photographs as a slideshow, press at any time.
To play background music during the slideshow, press the ENTER key
•
To adjust the volume level, press VOL- or VOL+
•
To mute the audio, press MUTE. To restore the audio, press MUTE again.
•
Pressing the ENTER key on the main unit while background music is
•
playing will also mute the audio.
If the photo frame is turned off during the slideshow, the slideshow
will resume the next time the photo frame is turned on.
22
MUSIC MODE
To play your digital audio les, select Music Mode from the “Select Mode” screen
and press ENTER.
Music List
Upon entering Music Mode, your photo frame will scan the memory card for available audio les and display the “Music List“ screen shown below. The Music List
displays the lenames of all available audio les.
Use the navigation keys to select an audio le and press ENTER to star t
•
playback.
“Playback” icon indicates the le that is being played
1.
Selected le (highlight bar)
2.
Current Page Number / Total Number of Pages
3.
Track length
4.
Filename
5.
The Music List will display suppor ted audio les, only.
Your photo frame can play digital MP3 and WMA audio les.
23
MUSIC MODE
Music Controls
Use the navigation keys to select an audio le and press ENTER to start playback.
During playback:
To pause playback, press . To resume playback, press again
•
To play the next le, press
•
To play the previous le, press
•
To fast-forward through the current le, press and hold
•
To reverse through the current le, press and hold
•
To stop playback, press
•
To adjust the volume level, press VOL- or VOL+
•
To mute the audio, press MUTE. To restore the audio, press MUTE again.
•
24
VIDEO MODE
To play your digital video les, select Video Mode from the “Select Mode” screen
and press ENTER.
Video List
Upon entering Video Mode, your photo frame will scan the memory card for available audio les and display the “ Video List“ screen shown below. The Video List
displays the lenames of all available video les.
Use the navigation keys to select a video le and press ENTER to start play-
•
back.
Filename
1.
Selected le (highlight bar)
2.
Current Page Number / Total Number of Pages
3.
File size
4.
The Video List will display suppor ted Video les, only.
Your photo frame can play digital AVI and MP4 video les from
most digital cameras.
25
VIDEO MODE
Video Controls
Use the navigation keys to select a video le and press ENTER to start playback.
During playback:
To pause playback, press . To resume playback, press again
•
To play the next le, press
•
To play the previous le, press
•
To stop playback, press
•
To adjust the volume level, press VOL- or VOL+
•
To mute the audio, press MUTE. To restore the audio, press MUTE again.
•
Reverse and fast-forward play is not available in video mode.
26
FILE MODE
FILE LIST SCREEN
To browse and play all your digital les, select File Mode from the “Select Mode”
screen and press ENTER.
File List
Upon entering File Mode, your photo frame will scan the memory card for all available les and display the “File List“ screen shown below.
Use the navigation keys to select a le and press ENTER to start playback.
•
To return to the File List during playback, press MENU. If MENU is pressed
•
during slideshow playback, the photo frame will return to the Photo List screen
instead.
Filetype icon
1.
Selected le (highlight bar)
2.
File size / Date taken (photo)
3.
Preview screen:
4.
Thumbnail (Photo) or Name & Artist (MP3/WMA, if available)
Please refer to the Photo Mode, Music Mode, and Video Mode
sections of this manual for playback controls.
27
SETUP MENU
To adjust the settings and options of your digital photo frame, press SETUP. The
Setup Menu will be displayed on screen.
Use the navigation keys to highlight and display option / sub-menus
•
To conrm a selection, press ENTER
•
To return to a previous menu level. press
•
To exit the Setup Menu, press SETUP
•
The Setup Menu is not available during video playback.
The Copy File and Delete File options are only available from
within another mode (i.e., File/Photo/Music/Video mode).
Please choose your desired settings as shown in the screens
below. The options marked ‘ ” are default settings.
Photo Options
28
SETUP MENU
Music Options
Video Options
System Options
Copy Options
Use the Copy option from within a selected mode to copy les from one location
to another.
Highlight the source le in the File/Photo/Music/ Video List
1.
Press SETUP to enter the Setup Menu and select a Copy option (One, All)
2.
Select a target location
3.
Conrm Yes or No
4.
29
SETUP MENU
Delete Options
Use the Delete option from within a selected mode to delete les.
Highlight the target le in the File/Photo/Music/Video List
1.
Press SETUP to enter the Setup Menu and select a Delete option (One, All)
2.
Conrm Yes or No
3.
30
CABLE CONNECTION
To use your DP-562 to output audio and video to an external home theater system,
use the connections diagrammed below.
Composite Video
31
CABLE CONNECTION
Headphones
Audio-Only Output
To output audio only, use the AV connection but do not connect the Video cables.
32
COMPUTER CONNECTION (USB)
USB Port
(computer)
USB Port (mini)
Connect the DP-562 to a computer with the USB cable provided to:
Transfer les to and from your photo frame’s installed memory cards
•
Perform basic le management functions.
•
USB Driver Installation (Required for Windows 98 SE Only)
It is not necessary to install the USB driver if your computer is running Microsof t
Windows ME/2000/XP or newer, or Macintosh OS X. Computers running these operating systems will recognize your photo frame automatically when connected.
If your computer is running Windows 98 SE:
Insert the Installation CD into your computer’s CD or DVD drive. Make sure to
1.
place the mini-CD in the center, recessed well of the drive tray.
Navigate to MY COMPUTER and double-click on the CD/DVD drive icon
2.
(usually “D:”).
Double-click on the folder “Win98 USB Drivers” and then on the folder “eng-
3.
lish”.
Double-click on the SETUP icon (SETUP.EXE) to start the USB driver instal-
4.
lation program.
Follow the on-screen instructions to complete the installation and then restart
5.
your computer.
Mini- CDs should only be used in normal tray-loading CD/DVD
drives. Mini-CDs may be used in slot-loading drives with the
proper adapter; please contact your computer or drive manufac turer for more information.
Connecting to a Computer
Connect the photo frame to your computer with the supplied USB cable. Upon
connection:
Your computer will automatically
•
recognize any memory cards installed in your photo frame. An icon representing your installed memory cards
will appear as “Removable Disks” when you open “My Computer”.
33
COMPUTER CONNECTION (USB)
It may take Windows several minutes to recognize and set up the device the rst
•
time it is connected depending on your hardware conguration.
Transferring Files
The USB 2.0 High-Speed connection makes it easy to transfer music, video, or
photo les (or any other data) quickly between the photo frame and your computer.
Simply use the photo frame as you would a oppy disk using basic operating system commands.
If you need further assistance with transferring les, please refer to your operating
system’s instruction manual or on-screen help.
Do not disconnect or otherwise interrupt the photo frame during
transmission - this could damage or corrupt the photo frame’s
rmware or your les.
Microsoft Windows
Double-click the “My Computer” icon on your desktop and then double-click
1.
the Removable Disk icon that corresponds with the photo frame’s installed
memory card.
Drag your media les (or other les) to the Removable Disk.
2.
You may choose to use folders/subfolders to organize your media and data.
•
Macintosh OS X
Open a Finder window. Locate the les you would like to transfer from your
1.
computer. Select the les/folders with the mouse and press APPLE-C (copy)
on the keyboard.
Click on the Removable Disk icon located on the left side of the nder window.
2.
The computer will display all les and folders currently stored in the memory
card.
Press APPLE-V (paste) on the keyboard to transfer the les you selected in
3.
Step 1 to the memory card.
Disconnecting from a Computer
Disconnect your photo frame as instructed below to prevent data loss or le/rmware corruption.
34
COMPUTER CONNECTION (USB)
Microsoft Windows
Double-click the green arrow in the taskbar located on the lower-right side of
1.
the computer screen (Safely Remove Hardware).
Safely Remove Hardware:
2.
Select “USB Mass Storage Device” from the list that appears and then click
on “Stop”.
Stop a Hardware Device: Select “USB Mass Storage Device” from the list
that appears and then click on “OK”.
Select “USB Mass Storage Device” from the list that appears and then click
on “OK”.
When the “Safe to Remove Hardware” window appears, click the OK button
3.
and disconnect the USB cable from the photo frame and your computer.
Macintosh OS X
On the left side of the Finder window, identify the appropriate Removable
1.
Disk icon.
Click on the “Eject” arrow on the right of the Removable Disk icon.
2.
Disconnect the USB cable from the photo frame and your computer.
3.
35
FACEPLATES
Your digital photo frame comes equipped with interchangeable face plates.
To attach a faceplate to your photo frame:
Afx “B” to the main unit
1.
Press and push “A” into the main unit with the Coby logo facing down
2.
The two par ts are now attached
3.
To detach a faceplate from your photo frame:
Press and pull “A”
1.
While it is opened, detach the main unit by releasing it from “B”
2.
The faceplate has been detached
3.
36
FIRMWARE UPGRADES
From time to time, COBY may release rmware updates to improve the performance of the DP-562 or to add additional features. Please check the COBY web site periodically at www.cobyusa.com to see if new rmware has been released for
your photo frame.
Download the latest rmware for your photo frame from www.cobyusa.com.
1.
Save this le to the computer.
Connect your photo frame to the computer. Double-click the Removable Icon
2.
that corresponds to your photo frame, and then double-click the FIRMWARE
folder to open it.
Double-click the downloaded rmware le (you may need a le compression
3.
utility installed on your computer). In the window that appears, select the le
that ends with “.BIN” and copy it to your photo frame’s FIRMWARE folder.
Disconnect your photo frame from the computer and turn it off.
4.
Turn the photo frame back on. The photo frame should update its rmware
5.
automatically.
Do not disconnect your photo frame from the computer or otherwise interrupt the rmware upgrade—doing so could damage your
photo frame and render it inoperable.
37
TROUBLESHOOTING
If you have a problem with this unit, please read the troubleshooting guide below
and check our website at www.cobyusa.com for Frequently Asked Questions
(FAQs) and rmware updates. If these resources do not resolve the problem,
please contact Technical Support.
COBY Electronics Technical Suppor t
56- 65 Rust St.
Maspeth, NY 11378
Hours: Monday to Friday, 8:30 AM–11:00 PM EST
Email: techsupport@cobyusa.com
Phone: 800-681-2629 or 718-416-3197
Web: www.cobyusa.com
The player does not turn on.
•
•
The sound quality of the music is poor.
•
•
Saturday to Sunday, 9:00 AM–11:00 PM EST
Make sure the unit has been powered on manually (i.e., the Power Switch has
been physically set to the ON position).
Ensure that the power cord has been properly connected to the power outlet.
Try playing the le on your computer. If the sound quality is still poor, try downloading the le again or re-encoding the le yourself.
Ensure that the bit rate of the le is not too low. The higher the bit rate of the
le, the better it will sound. The minimum recommended bitrate is 128kbps for
MP3s and 96kbps for WMAs.
I cannot transfer les to the photo frame.
Ensure that your computer is running a supported operating system.
•
If you are running Microsoft Windows 98 SE, ensure that the USB driver has
•
been properly installed.
Ensure that the supplied USB cable is securely attached to the player and the
•
PC, or try using another USB cable.
38
TROUBLESHOOTING
If you have connected the player through a USB hub, try connecting the player
•
directly to your computer.
Ensure that the player’s memory capacity is not full.
•
I cannot select a memory card.
Ensure that a memory card has been installed.
•
Ensure that the memory card is properly installed.
•
Ensure that the memory card is not defective.
•
I cannot copy les to a target location.
Ensure that the target card has enough memory to contain the le.
•
The player will not play my music le.
Ensure that the le is in a compatible format (MP3 or WMA).
•
The le may be copy-protected. This player cannot play copy-protected les.
•
The player will not play my video le.
Ensure that the video le will play on your computer using Windows Media
•
Player 10. If the le works on the computer, use the same computer to convert
the video to a compatible format.
The picture is noisy or distorted.
Reset the color system of the T V set.
•
Ensure that the photo frame is connected using the RCA AV cable.
•
There is no sound.
Ensure that the volume has been set to a reasonable level.
•
The remote control does not work.
Make sure the unit has been powered on manually (i.e., the Power Switch has
•
been physically set to the ON position).
Remove any obstacles between the remote control and the frame.
•
Point the remote control towards the remote sensor on the frame.
•
39
TROUBLESHOOTING
Ensure that the battery has been installed correctly in the remote control.
•
Replace the battery.
•
The photo frame has malfunctioned.
Turn the photo frame off and let it rest for 30 minutes. After that, turn on the
•
photo frame -- the restore function should reset the photo frame.
Try updating the player’s rmware. Please refer to the Firmware Upgrade sec-
•
tion of this manual for detailed instructions.
40
SPECIFICATIONS
Display Type 5.6” Full- Color TFT LCD
Display Resolution 320 x 23 4
Memory CF Card Slot
Audio Format Support MP3 (32 - 320kbps, CBR /VBR)
Video Format Support AVI
Photo Format Support JPEG (14MB)
PC Interface USB 2.0 High-Speed (device)
Plug and Play Support Windows 98SE/2000/ME/XP or newer
Audio Output 3.5mm Stereo / Headphone
Video Output Composite Video
Power Supply DC 12V, 1A
SD/MMC Card Slot
xD Card Slot
WMA
MP4
MJPEG (640 x 480)
BMP (14MB)
Mac OS X
Integrated Stereo Speakers
100-240V AC Adapter
Specications and manual are subject to change without prior notice.
41
NOTES
42
NOTES
43
COBY Electronics Corp.
56- 65 Rust Street
Maspeth, NY 11378
ww w.cobyusa.com
ww w.ecoby.com
Loading...
