Foreword
Thank You
Congratulations on your purchase of the Coby CSMP
English
Digital Speaker System for iPod® with Dual Alarm Clock/
FM Radio. This system is designed for use with iPod and
is compatible with most iPod models including the rdgeneration iPod Nano, the iPod Touch, and others.
Please read all operational and safety instructions thoroughly before using this system, and follow all instructions
carefully.
Getting Started
To get started, connect the power cord to the power
socket on the rear panel and a wall outlet(AC V/
Hz Hz), then press [STANDBY] to switch on the unit.
Features
LCD display screen
Universal dock for iPod
Full function remote control
Two-channel audio input
Digital PLL FM Radio Tuner
Clock with dual alarm timers
Page 4 Coby Ele ctronics Corpo ration
Foreword
Package Contents
Please make sure that the items shown below are included
in the package. Should an item be missing, please contact
the local retailer from which you purchased this product.
CSMP (main unit)
Instruction manual
Remote control with x CR battery
Dock adapters for iPod*
* Dock ad apter cartridges are includ ed for you r conveni ence and a re sub ject to ch ange. Ap ple inc ludes do ck adapt ers with t heir rec ent iPo d models.
English
www.cobyusa .com Page 5
www.cobyusa .com Page 7
Unit Overview
Front panel
English
Left Speaker1.
LCD Screen2.
Right Speaker3.
Back panel
Left Channel Audio Input1.
Right Channel Audio Input2.
Power Socket3.
FM Antenna 4.
Page 6 Coby Ele ctronics Corpo ration
Unit Overview
Top panel
Previous/Alarm Clock 1/Channel-1.
Next/Alarm Clock 2/Channel+2.
Standby3.
Sleep4.
Mode5.
Snooze6.
Play/Pause7.
Volume-8.
Volume+9.
Standby Indicator10.
iPod Docking Station Cover11.
iPod Docking Connector12.
English
For information on button functions, please refer
to Remote Control section.
www.cobyusa .com Page 7
www.cobyusa .com Page 9
Unit Overview
Remote control
English
Key Description
1 STA ND BY/S NO OZ E Press to switch on unit. When unit is
turned on, pr ess to put in STANDBY mode.
For more info rmation on Clock Functions, see Clo ck Settings sec tion.
Page 8 Coby Ele ctronics Corpo ration
Unit Overview
Key Description
2 MODE Switch between IPOD, TUNER (radio)
and AUX-IN modes.
Note: IPOD mode is not available
when no iPod is doc ked in device.
3 FAST FORWARD/
SEARCH
4 FAST REWIND/
SEARCH
5, 7,
Direction Keypad In IPOD mode, navigate iPod menu.
18,
21
6 PLAYLIST + In IPOD mode, skip to next playlist.
8 PLAYLIST – In IPOD mode, skip to previous
9 MENU/MEMORY In IPOD mode, press to display iPod
In IPOD mode, press and hold for f ast
forward playback.
In TUNER mode, pres s to tune radio to
next available frequency.
In IPOD mode, press and hold for f ast
rewind playback.
In TUNER mode, pres s to tune radio to
previous available frequency.
playlist.
menu.
In TUNER mode, pres s to store preset
radio stations.
English
www.cobyusa .com Page 9
www.cobyusa .com Page 11
Unit Overview
Key Description
10 MUTE Press to mute sound in IPOD, TUNER or
English
11 SLEEP/TIME In STANDBY mode, press to display
12 EQ Press to select equalizer mode (FLAT,
13 NEXT/ALARM 2/
CH+
AUX mode.
In STANDBY mode, press and hold to
restore de fault settings and reset all
clock functions.
CLOCK TIME.
When unit is tur ned on, press
repeatedly to display CLOCK TIME,
ALARM TIME 1 – 2, ALARM TYPE 1 – 2,
SNOOZE TIME.
For more information on Clo ck Functions, see Clo ck Settings section.
JAZZ, CLA SSICAL, POP, ROCK) for audio
pla y.
In STANDBY mode, press to view
ALARM 2 TIME.
In IPOD mode, press to skip to the
next track.
In TUNER mode, pres s to skip to the
next pre set radio frequenc y.
Page 10 Coby Ele ctronics Corpo ration
Unit Overview
Key Description
14 PL AY/P AUS E/
STEREO
15 PREVIOIUS/
ALARM 1/CH --
16 STOP Stops playback in IPOD mode.
17 ALBUM+ In IPOD mode, skips playback to next
19 ENTER Press to conrm IPOD menu selection
20 ALBUM – In IPOD mode, skips playback to
22 REPEAT/SCAN In IPOD mode, press to switch play-
23 VOLUME+/- - Increase/decrease volume in IPOD,
In IPOD mode, press to play or pause
audio.
In TUNER mode, pres s to switch between
Stereo and Mono FM ra dio reception.
In STANDBY mode, press to view
ALARM 1 TIME.
In IPOD mode, press to skip to the
previous tr ack.
In TUNER mode, pres s to skip to the
previous preset radio f requency.
track.
or device set tings.
previous tr ack.
back repeat settings.
In TUNER mode, pres s to auto scan all radio freque ncies. Press again to s top scan.
TUNER and AUX modes.
English
www.cobyusa .com Page 11
www.cobyusa .com Page 13
Setting the Clock
Setting Mode
To access the clock’s SETTING Mode, place the device in
English
STANDBY mode and then hold down [SLEEP/TIME].
Press [SLEEP/TIME] to toggle between menu items
(CLOCK, ALARM, ALARM, SNOOZE, etc) and sections
(HOUR/MINUTE, ALARM TYPE, etc).
Press [PREVIOUS/ALARM /CH] or [NEXT/ ALARM /
CH+] to adjust value or switch options. Press [SLEEP/
TIME] to conrm.
Press [SLEEP/TIME] again to proceed to the next item
in the SETTING menu.
To set the CLOCK TIME
Press [SLEEP/TIME] to access CLOCK TIME Setting Mode.
Select CLOCK TIME using instructions provided below.
To set the ALARM
This device includes a dual alarm clock which allows up to
preset alarm times. Press [SLEEP/TIME] to access Alarm
Setting Mode. Select ALARM TIME and ALARM TYPE using
instructions provided above. For more information on
ALARM TYPE, see below.
Page 12 Coby Ele ctronics Corpo ration
Setting the Clock
Wake to iPod Alarm
Select ALARM TYPE: IPOD. Insert iPod in docking station
and set device to STANDBY mode. iPod playback will begin
at ALARM TIME. If no iPod is inserted in the device docking
station, the unit will buzz at ALARM TIME. If the unit is
switched on and iPod is playing at ALARM TIME, playback
will stop and the alarm will buzz. The unit will return to its
previous mode after the alarm is stopped.
Wake to Radio Alarm
Select ALARM TYPE: RADIO. Set device to STANDBY mode.
Radio playback will begin on most recent frequency at
ALARM TIME. If the unit is switched on and radio is playing
at ALARM TIME, radio play will stop and the alarm will
buzz. The unit will return to its previous mode after the
alarm is stopped.
Wake to Buzzer Alarm
Select ALARM TYPE: BUZZER. Make sure that the device
is switched on; buzzer will not sound if unit is in STANDBY
mode. Buzzer will sound at ALARM TIME. The alarm lasts
for one minute and becomes gradually louder if it is not
turned o.
Wake to AUX Alarm
Select ALARM TYPE: AUX. Set device to STANDBY mode.
Unit will wake up to AUX mode at ALARM TIME. If the unit
is switched on at ALARM TIME, the alarm will buzz. The
unit will return to its previous mode after the alarm is
stopped.
www.cobyusa .com Page 13
English
www.cobyusa .com Page 15
Setting the Clock
To stop the ALARM
Press ALARM or ALARM to shut o and reset the alarm.
English
To use the SNOOZE function
To delay the alarm for a short period of time ( –
minutes), press SNOOZE. The snooze function is available
up to times per alarm, after which the alarm will shut o.
For additional information on setting the SNOOZE time,
please see Setting Mode instructions above.
To set AUTO OFF time
The AUTO OFF function will turn o the device automatically after a set period of time ( – minutes). To set
AUTO OFF time, switch the device on. Press and hold
[SLEEP/TIME] to enter the AUTO OFF setting mode. Press
[SLEEP/TIME] repeatedly to select AUTO OFF time. To
disable the AUTO OFF function, select ‘’.
To display clock and alarm clock settings:
In STANDBY mode, press [SLEEP/TIME] to display the
CLOCK TIME. Press [ALARM] and [ALARM] to display
corresponding ALARM TIME.
In ON mode, Press [SLEEP/TIME] repeatedly to
display the CLOCK TIME, ALARM TIMES ( & ), ALARM
TYPES ( & ) and SNOOZE TIME.
Page 14 Coby Ele ctronics Corpo ration
Radio Mode
Using the Radio
To listen to the radio, press [MODE] and select TUNER
mode.
Autoscan
Press [REPEAT/SCAN] to perform a full scan of all available
frequencies from . to MHz. Press [STOP] to halt the
scan.
Seek
Press and hold [SEARCH+] to search for next available
radio frequency. Press and hold [SEARCH --] to scan for
previous available frequency.
Tuning
Press [SEARCH+]/[SEARCH –] to increase/decrease frequency by . MHz.
Programming Station Memory
Your device will store up to preset radio frequencies.
To set a frequency, press [MENU/MEMORY] to enter
programming mode. (Screen will display ‘MEM’.) Select the
desired frequency by pressing CH+/CH –. To conrm your
selection, press [MENU/MEMORY].
Listening to the radio
Press [CH+]/[CH-] to skip to the next preset channel
or return to the previous preset channel.
www.cobyusa .com Page 15
English
www.cobyusa .com Page 17
Radio Mode
Press [STEREO] to change the FM mode reception
settings.
For information on using [EQ], [MUTE] and [VOL+/-]
English
in TUNER mode, please refer to the Remote Control
cha pter.
If the system is in programming mode, you must
conrm your selection and exit by pressing
[MENU/MEMORY] before using scan func tions.
Page 16 Coby Ele ctronics Corpo ration
iPod Mode
Connect your iPod to the dock on the device’s top panel
for high-quality audio playback.
iPod Adapters
To ensure proper connection,
an array of iPod adapters is included with this device. Before
connecting, please select the
correct iPod adapter for your
iPod model.
To install a new adapter, press it into the docking station
until it is rmly in place.
Check that the iPod adapter is the correct size and
type for your iPod model before connecting.
To avoid damaging hardware, turn o the unit be-
fore connecting or disconnecting iPod.
When switched on, the unit will recharge the bat-
tery of any iPod in the dock.
This device does not include a video decoder; if
you select a video le from your iPod menu, the
playback will be sound only.
www.cobyusa .com Page 17
English
www.cobyusa .com Page 19
iPod Mode
Playback Operation
After connecting your iPod to
English
the dock, turn on the device.
Press [MODE] to select IPOD
mode.
The [MENU] and Direction Keys cor-
respond to the functions of your iPod:
Press [MENU] to display the iPod menu; use the
direction key [UP] or [DOWN] to select an item.
Press [RIGHT] to enter an item submenu.
Press [LEFT] or [MENU] to return to the previous
menu.
During playback, press [PLAY/PASUE] to pause; press
again to resume playback.
Press [STOP] to stop playback.
Press [PLAYLIST-]/[PLAYLIST+] to skip to the previous/
next playlist.
Press [ALBUM-]/[ALBUM+] or [NEXT]/[NEXT to skip to
the previous/next track in the playlist.
Press and hold [FAST FORWARD] for fast forward play-
back; for fast rewind, press and hold [FAST REWIND].
Press [REPEAT] repeatedly to change playback repeat
mode.
For more information on using [EQ], [MUTE] and
[VOL+/-] in IPOD mode, please refer to the Unit
Overview section.
Page 18 Coby Ele ctronics Corpo ration
AUX IN Mode
External Equipment Connections
You can enjoy high-quality audio playback from a CD
player, DVD player or other external apparatus through
this unit’s speakers.
To connect an external device:
For your safety, disconnect the power cord before
connecting external equipment.
Use a pair of audio cables to connect the audio
output on your external equipment to the auxiliary
audio input on the unit’s back panel. Connect the
white cable/plug to the left channel auxiliary audio
input, and the red cable/plug to the right.
After the connections have been made, power
on the unit. Press [MODE] to select AUX-IN mode.
Select playback on the external device to play audio
through this unit’s speaker system.
For information on using [EQ], [MUTE] and [VOL+/-]
in AUX-IN mode, please refer to the Remote Control
cha pter.
www.cobyusa .com Page 19
English
www.cobyusa .com Page 21
Troubleshooting
If you have a problem with this device, please read the
troubleshooting guide below and check our website at
www.cobyusa.com for Frequently Asked Questions (FAQs)
English
and rmware updates. If these resources do not resolve
the problem, please contact Technical Support.
Address
Coby Electronics Technical Suppor t
56- 65 Rust Street
Maspeth, NY 11378
Email
techsupport@cobyusa.com
Web
www.cobyusa.com
Phone
800 -727-3592: Mon –Fri, 8:00AM–11:00PM EST
Saturdays, 9:00AM– 5:30PM EST
718-416-3197: Mon– Fri, 8:0 0AM –5:30PM EST
If you experience problems with the speaker
system, please take the following steps:
Check that the power cord connections to the system
and wall outlet are secure.
Check that the system has been turned on.
Check that the volume has been turned up.
Check that the correct audio mode is selected.
Check that a compatible iPod and correct connection
adapter have been inserted in the dock.
Check that the correct radio frequency is selected.
Page 20 Coby Ele ctronics Corpo ration
Troubleshooting
If you experience problems while attempting to
use the remote control, check that the batteries are
inserted and fully charged.
Please refer to the table below for common troubleshooting techniques.
Problem Cause Solution
No audio/ no
display
Display
functioning,
but no audio
Power is not connected
Connect power and
recheck s ystem
Unit is not turned on Turn unit on and
recheck s ystem
Faulty plug pack
power supply
Incorrec t audio mode
selected
Volume turned dow n
on unit
iPod not connec ted
properly
Faulty equipment
Contact manufacturer
for a replacement plug
Select correct audio
mode
Adjust volume using
+/– controls on unit
Remove iPod from dock
and reconnec t
Contact manufacturer
(speaker, iPod, dock
connection)
English
www.cobyusa .com Page 21
www.cobyusa .com Page 23
Troubleshooting
Problem Cause Solution
Poor FM re-
English
ception, static
or crackling
iPhone shows
error message when
connecte d to
dock
Interference from
other devices; poor
reception quality
iPhone not operating
in airplane mode
iPhone may cause
interference when
operated outside of
airplane mode
Reposition FM antenna,
or relocate s ystem to
another position
Select airplane mode
before connecting
iPhone to the doc k
Select airplane mode
before connecting
iPhone to the doc k
Page 22 Coby Ele ctronics Corpo ration
Specications
Power Supply AC 100 -240V ~ 50/60Hz
Output Power 3W x 2 (RMS)
Auxiliary Input RCA stereo
Tuner System FM
Compatible with
Speci cati ons and manual are s ubjec t to chang e withou t notice.
English
www.cobyusa .com Page 23
www.cobyusa .com Page 25
Safety Notices
English
The light ning ash with ar rowhead symbo l within an equilateral
triang le is intended to al ert the user to th e presence of uninsulated “dangerou s voltage” withi n the product’s enclosu re that may
be of suf cient magnitu de to constitute a risk of el ectric shock .
The exclamation p oint within an equ ilateral trian gle is intended to
alert t he user to the pres ence of import ant operation and serv icing instr uctions in the l iterature acc ompanying the app liance.
For Customer Use:
Enter below the serial number that is located on the rear
of the unit. Retain this information for future referenc e.
Model No. CSMP160
Serial No.
WARNING: To prevent r e or shock hazard , do not expose this device to r ain or moisture.
Danger ous high voltage i s present inside t he enclosure. D o not open the cabi net.
CAUTION: To prevent ele ctric shock, m atch wide blade of p lug to wide slot of outlet and
fully insert.
Protec t your heari ng: Hearing experts advise against the constant use of personal stereos
played at high volume. Constant exposure to high volumes can lead to hearing loss. If you
should experience ringing in the ears or hearing loss, discontinue use and seek medical advice.
For recyc ling or disposal inform ation about this p roduct, pleas e contact
your loc al authoritie s or the Electron ics Industri es Alliance: www.eiae.org.
Page 24 Coby Ele ctronics Corpo ration
Safety Notices
FCC Statement:
This devi ce complies wi th Part 15 of the FCC Rul es. Operation i s subject to the fo llowing two c onditions:
(1) This devi ce may not cause harmful in terference, and
(2) This devi ce must accept any interferenc e received, inc luding interference t hat
may cause undesired oper ation.
Note: Th is equipment has be en tested and foun d to comply with the limit s for Class
B digita l devices, pursuant to Par t 15 of the FCC rules. These lim its are designed to
provide reasonable protectio n against harmf ul interferen ce in a residential installatio n.
This equipment generate s, uses and can rad iate radio frequ ency energy and, i f not
installed and us ed in accordanc e with the instr uctions, may cause harm ful interfere nce
to radio c ommunicatio ns. However, there is no guarant ee that interfe rence will not
occur in a parti cular installa tion. If this equipment do es cause harmf ul interferen ce to
radio or televisi on reception, w hich can be deter mined by turning the equi pment off
and on, the user is encourag ed to try to correct the i nterferenc e by one or more of the
follow ing measures:
Reorie nt or reloc ate the rece iving ante nna.•
Increa se the sepa ration be tween the e quipment a nd receive r.•
Connec t the equip ment into an o utlet on a ci rcuit di erent fro m that to whic h the receiv er is •
connected.
Consult t he dealer or a n experi enced radi o/TV tec hnician fo r help•
Use of shie lded cable is re quired to comply with Class B limit s in Subpart B of Par t 15
of the FCC r ules.
Do not make a ny changes or modi cations to the equipment unles s otherwise sp ecied
in the manual. If suc h changes or modi cations sho uld be made, you cou ld be required
to stop operatio n of the equipment.
English
www.cobyusa .com Page 25
www.cobyusa .com Page 27
Safety Notices
Important Safety Instructions
Read Instru ctions: All the safety and operat ing instru ction s should be 1.
read before the pr oduct i s opera ted.
English
Retain I nstru ction s: The safety and operating ins truc tions s hould b e 2.
retain ed for future refe rence.
Heed Warnings: All warn ings on the product and in the operating 3.
instructio ns shoul d be adher ed to.
Follow Inst ruct ions: All operating and usag e in struc tions should b e 4.
followed.
Cleani ng: Unplug this pr oduct from th e wall outlet b efore cleaning. 5.
Do not use liquid cleaner s or aerosol cleaners. Use a damp clot h
for cleaning.
Attac hments: Use only attachments re comme nded by the ma nufac -6.
turer. Use of ot her attachments may be h azard ous.
Water and M oistur e: Do not us e this pr oduct n ear water (e.g., near a 7.
bath t ub, washbowl, kitc hen sink, laundr y tu b, in wet basements, or
near a swi mming po ol and th e like).
Ventilation: Slots and op enings in the c abinet are prov ided fo r venti -8.
lation to ensure reliable oper ation of the produc t and to protect it from
overhea ting. These opening s should never be bloc ked by placing the
produc t on a bed, sof a, rug, or ot her similar surf ace. This p roduc t
should not be placed in a built-in inst allati on such as a bookcase
or rack unless proper ventilat ion is provided or the manufactur er
instructio ns have been adhere d to.
Power So urces: This pr oduct should be operated only fro m the t ype 9.
of power s ource indi cated on the rating lab el. I f you are not sure of
the type of power supply to your home, cons ult your produc t dealer or
local p ower co mpany. For pro ducts intended to operate from batter y
power or ot her sou rces, r efer to the operat ing inst ruct ions.
Power-C ord Protectio n: Power suppl y cor ds should be routed so 10.
that they are not likely to be walked on or pinched by items placed
upon or against them, p aying par ticul ar attention to c ords at plugs,
conveni ence receptacle s, and at t he point which they exit from the
product.
Lightning: For adde d protec tion for this p roduc t, unplu g i t from the 11.
wall outlet and disc onnec t the antenna or cable system during a lightning sto rm or w hen it is lef t unattended and unused for long period s
of time. This will prevent dam age to the produc t d ue t o li ghtnin g or
power-line surg es.
Page 26 Coby Ele ctronics Corpo ration
Loading...
