INSTRUCTION MANUAL
Please read this manual carefully before operation
INSTRUCTION MANUAL
Please read this manual carefully before operation.
PMP4320
4.3” Widscreen TFT Portable Media Player with
Video Recording and SD Card Slot
2
PRECAUTIONS
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufcient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operation and servicing
instructions in the literature accompanying the appliance.
For recycling or disposal information about this product,
please contact your local authorities or the Electronics Industries Alliance: www.eiae.org.
For Customer Use:
Enter below the serial number that is located on the bottom of the unit.
Retain this information for future reference.
Model No. PMP4320
Serial No.
3
PRECAUTIONS
WARNING:
To prevent re or shock hazard, do not expose this device to rain or moisture. Dangerous high voltage is
present inside the enclosure. Do not open the cabinet.
CAUTION:
To prevent electric shock, match wide blade of plug to wide slot of outlet and fully insert.
WARNING:
Handling the cords on this product will expose you to lead, a chemical known to the State of California to
cause cancer, and birth defects or other reproductive harm. Wash hands after handling.
Protect your hearing:
Hearing experts advise against the constant use of personal stereos played at high volume. Constant
exposure to high volumes can lead to hearing loss. If you should experience ringing in the ears or hearing
loss, discontinue use and seek medical advice.
4
IMPORTANT SAFETY INSTRUCTIONS
Read Instructions: All the safety and operating instructions should be read before the
product is operated.
Retain Instructions: The safety and operating instructions should be retained for future
reference.
Heed Warnings: All warnings on the product and in the operating instructions should
be adhered to.
Follow Instructions: All operating and usage instructions should be followed.
Cleaning: Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Attachments: Use only attachments recommended by the manufacturer. Use of other
attachments may be hazardous.
Water and Moisture: Do not use this product near water (e.g., near a bath tub, washbowl,
kitchen sink, laundry tub, in wet basements, or near a swimming pool and the like).
Accessories: Do not place this product on an unstable cart, stand, tripod,
bracket, or table. Use only with carts, stands, tripods, brackets, or
tables recommended by the manufacturer or sold with the product.
Any mounting of the product should follow the manufacturer’s instructions and should use a mounting accessory recommended by
the manufacturer.
A product and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the product
and cart combination to overturn.
Ventilation: Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. These openings should
never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This
product should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer instructions have been adhered to.
Power Sources: This product should be operated only from the type of power source
indicated on the rating label. If you are not sure of the type of power supply to your home,
consult your product dealer or local power company. For products intended to operate
from battery power or other sources, refer to the operating instructions.
Grounding or Polarization: This product may be equipped with a polarized alternatingcurrent line plug that has one blade wider than the other. This plug will only t into the
power outlet in one direction. This is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the direction of the plug. If the plug should still fail to t,
contact an electrician to replace the obsolete outlet. Do not defeat the safety purpose
of the polarized plug.
Power-Cord Protection: Power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles, and at the point which they exit
from the product.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
5
Protective Attachment Plug: The product may be equipped with an attachment plug with
overload protection. This is a safety feature. See the operating instructions for replacement or directions to reset the protective device. If replacement of the plug is required,
be sure the service technician has used a replacement plug that has the same overload
protection as the original plug as specied by the manufacturer.
Outdoor Antenna Grounding: If an outside antenna is connected to the product, be sure
the antenna system is grounded so as to provide some protection against voltage surges
and built-up static charges. Article 810 of the National Electrical Code, ANS/NFPA
70 provides information with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode (see gure).
Lightning: For added protection for this product, unplug it from the wall outlet and disconnect the antenna or cable system during a lightning storm or when it is left unattended
and unused for long periods of time. This will prevent damage to the product due to
lightning or power-line surges.
Power Lines: An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme care should
be taken to keep from touching such power lines or circuits, as contact with them might
be fatal.
Overloading: Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of re or electric shock.
Object and Liquid Entry: Never push objects of any kind into this product through openings as they may touch dangerous voltage points or shout-out parts that could result in
a re or electric shock. Never spill liquid of any kind on the product.
14.
15.
16.
17.
18.
19.
IMPORTANT SAFETY INSTRUCTIONS
6
Servicing: Do not attempt to service this product yourself as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to qualied
service personnel.
Damage Requiring Service: Unplug this product from the wall outlet and refer servicing
to qualied service personnel under the following conditions: a) when the power-supply
or plug is damaged; b) if liquid has been spilled or if objects have fallen into the product;
c) if the product has been exposed to rain or water; d) if the product does not operate
normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as improper adjustment of other controls may result
in damage and will often require extensive work by a qualied technician to restore the
product to its normal operation; e) if the product has been dropped or damaged in any
way; f) when the product exhibits a distinct change in performance—this indicates a
need for service.
Replacement Parts: When replacement parts are required, be sure that your service
technician has used replacement parts specied by the manufacturer or have the same
characteristics as the original part. Unauthorized substitutions may result in re, electric
shock, or other hazards.
Safety Check: Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to ensure that the product is in proper operating
condition.
Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
Heat: The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including ampliers) that produce heat.
20.
21.
22.
23.
24.
25.
IMPORTANT SAFETY INSTRUCTIONS
7
PRECAUTIONS .....................................................................................2
IMPORTANT SAFETY INSTRUCTIONS ...................................................4
TABLE OF CONTENTS ...........................................................................7
PACKAGE CONTENTS .......................................................................10
GETTING STARTED ............................................................................. 12
PMP4320 at a Glance .......................................................................................12
Front View .................................................................................................12
Top View....................................................................................................12
Bottom View .............................................................................................. 12
Left View ...................................................................................................12
Right View ................................................................................................. 12
Connections ......................................................................................................13
Connecting Headphones .........................................................................13
Connecting to a Television (AV Out) ........................................................13
Connecting to an AV Device (AV In) ........................................................ 13
Connecting Power ..................................................................................... 14
AC Adapter ........................................................................................14
Connecting to a Computer ........................................................................ 15
USB Driver Installation .....................................................................15
Transferring Files to your PMP4320 .........................................................16
Disconnecting from a Computer ...............................................................17
Microsoft Windows ....................................................................................17
Macintosh OS X ........................................................................................ 17
Using the PMP4320 Controls ...........................................................................18
Power On/Off ............................................................................................18
Hold Function ............................................................................................ 18
Reset Function .......................................................................................... 18
Adjusting the Volume ................................................................................ 18
Navigating the Menu ................................................................................. 18
PMP4320 Display ..............................................................................................19
Main Menu ................................................................................................19
File Browser Screen..................................................................................20
File Browser Controls .......................................................................21
File Browser Context Options ...........................................................21
TABLE OF CONTENTS
8
VIDEO MODE .....................................................................................23
Getting Video on Your Computer ......................................................................23
Playing Video ....................................................................................................23
Video File Browser Context Options ........................................................23
Video Playback Controls........................................................................... 24
MUSIC MODE ....................................................................................25
Getting Music on Your Computer ......................................................................25
Playing Music ....................................................................................................25
Music File Browser Context Options ........................................................25
Music Playback Controls ..........................................................................26
Repeat A-B Mode .....................................................................................27
PHOTO MODE ....................................................................................28
Getting Photos on Your Computer ....................................................................28
Viewing Photos .................................................................................................28
Photo File Browser Context Options ........................................................28
Photo Viewing Controls ............................................................................28
EBOOK MODE ...................................................................................30
Reading EBooks ...............................................................................................30
Ebook File Browser Context Options........................................................30
Ebook Reader Controls ............................................................................30
RECORD MODE .................................................................................31
Recording Audio and Video to your PMP4320 ................................................. 31
Record Mode Options ............................................................................... 31
Record Controls ........................................................................................32
EXPLORER MODE ...............................................................................33
Managing and Viewing Files on your PMP4320 ...............................................33
RESUME MODE ..................................................................................34
RADIO MODE ....................................................................................35
Listening to FM Radio Broadcasts ....................................................................35
Radio Screen Display ...............................................................................35
Radio Mode Context Options ...................................................................35
Radio Mode Controls ................................................................................36
TABLE OF CONTENTS
9
SETUP MODE ......................................................................................37
Display Options .................................................................................................37
System Options .................................................................................................37
Power Options ...................................................................................................37
PlayMode Options .............................................................................................38
RESTORE & FIRMWARE UPGRADES ...................................................39
Restoring Your PMP (Format) ...........................................................................39
Upgrading Your PMP Firmware ........................................................................40
ABOUT DIGITAL MUSIC FILES ........................................................... 41
TROUBLESHOOTING ..........................................................................42
SPECIFICATIONS ...............................................................................44
TABLE OF CONTENTS
10
Please make sure that the items shown below are included in the package. Should an item be
missing, please contact the local retailer from which you purchased this product.
COBY PMP4320
USB Cable
Audio/Video (AV) Cable
Professional Stereo Earphones
AC Adapter
Installation CD
Manual
1.
2.
3.
4.
5.
6.
7.
4
6
2
3
5
1
7
PACKAGE CONTENTS
11
20GB Hard Disk Stores up to 10,000 Songs or 80 Hours of Video
Brilliant 4.3” Widescreen TFT LCD True-Color Display
SD/MMC Card Slot for Additional Data Transfer and Storage
Plays Music, Video, Photos, and Text
ID3 and LRC Support for Song and Synchronized Lyric Information Display
Records Audio or Video from External AV Devices (No PC Required)
Integrated FM Radio and Recorder
Integrated Microphone for Digital Voice Recording
USB 2.0 for Ultra-Fast File Transfers (up to 40x faster than USB 1.0)
Rechargeable Lithium Polymer Battery
Upgradable Firmware
FEATURES
12
GETTING STARTED
PMP4320 at a Glance
Front View
4.3” Widescreen TFT LCD Display
Power/Charge Indicator
Menu
Navigation Joystick
Up / Volume +
Down / Volume -
Left
Right
Press Joystick
Option
Repeat A-B
Top View
Stereo Speakers
Microphone
Bottom View
Hold/LCD/AV Out Switch
Left View
Headphone Jack
USB 2.0 Port
AV Out Jack
AV In Jack
DC 5V Power Jack
Right View
Power
SD/MMC Card Slot
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
2
4
3
5
6
10
11
12
13
14
1
16
15
9
7
8
13
Connections
Connecting Headphones
Connect headphones/earphones to the Headphone Out jack for
private listening.
Lower the volume level before connecting headphones, then
gradually increase the volume for comfortable listening.
Hearing experts advise against the constant use of personal stereos played at high volume.
Constant high-volume use can lead to hearing loss. If you experience ringing in your
ears or hearing loss, discontinue use immediately and seek medical advice.
Connecting to a Television (AV Out)
Connect a television to the AV Out jack to play
video or photos on your home theater system.
Make the connections as shown in the
diagram.
Set the Hold/LCD/AV Out switch to the
“AV Out” position.
Set your television to the correct AV
mode. You will see the PMP4320 video
signal displayed on your TV screen.
Connecting to an AV Device (AV In)
Connect an external AV device (e.g., camcorder, DVD player, video game console) to the AV
In jack to use your PMP4320 as a recording
device.
Make the connections as shown in the
diagram.
Set the Hold/LCD/AV Out switch to the
“LCD” position.
Set your television to the correct AV mode.
You will see the PMP4320 video signal
displayed on your TV screen.
Be sure to set the “Setup > System > TV Standard” setting of your
PMP4320 to match the video signal (NTSC or PAL).
1.
2.
3.
1.
2.
3.
GETTING STARTED
To AV Out Jack
TV with Composite Video &
RCA Stereo Input
VIDEO
R
L
AV Cable
Yellow Red White
To AV In Jack
External Device with AV Output
(Camcorder, DVD Player, etc.)
VIDEO
R
L
AV Cable
Yellow Red White
14
Connecting Power
This device operates on an integrated rechargeable battery. The battery should be charged
fully before using your player for the rst time.
AC Adapter
This adapter should be used with 100-240V 60/60Hz AC wall outlets.
Plug the supplied AC adapter into an AC 100-240V electrical wall
outlet.
Connect the other end of the adapter to your device’s DC 5V Power
jack. The Power/Charge indicator on your device will light orange
When charging has been completed, the Power/Charge indicator
on your device will light green.
The battery should be charged fully (minimum 4 hours) before its initial use
to ensure optimum lifetime performance.
The battery used in this device may present a re or chemical
burn hazard if mistreated. Do not disassemble, incinerate, or heat the battery.
Do not connect the power plug to a power outlet other than that which is in-
dicated here or on the label as this may result in the risk of re or electric
shock.
Do not handle the power plug with wet hands. Doing so may cause electric
shock.
Use only AC adapters of the type specied here. Failure to do so may case a
re or damage the player.
GETTING STARTED
To DC 5V
Jack
15
Connecting to a Computer
If you are using Windows 98 SE, you must install the USB driver contained on the supplied
Installation CD. Please see the USB Driver Installation section for more information.
Connect the PMP4320 to a computer to transfer media (music, video, photos, etc.) to and from
your PMP4320. To connect to a computer:
Turn the player off.
Connect the player to your computer using the supplied USB cable. It may take Windows
several minutes to recognize and set up the device the rst time it is connected depending on your hardware conguration
If your computer is running Windows 98 SE, NT, 2000, ME, or XP, your player will be
detected as a “Removable Disk” when you open “My Computer”.
For more information and support regarding le transfers and manage-
ment, please refer to the documentation that came with your computer or
operating system.
USB Driver Installation
It is not necessary to install the USB driver if your computer is running Microsoft Windows
ME/2000/XP or newer, or Macintosh OS X. Computers running these operating systems will
recognize your player automatically when connected.
If your computer is running Windows 98 SE:
Insert the Installation CD into your computer’s CD or DVD drive. Make sure to place the
mini-CD in the center, recessed well of the drive tray.
Navigate to MY COMPUTER and double-click on the CD/DVD drive icon (usually “D:”).
Double-click on the folder “Win98 USB Drivers” and then on the folder “english”.
Double-click on the SETUP icon (SETUP.EXE) to start the USB driver installation program.
1.
2.
1.
2.
3.
4.
GETTING STARTED
USB Port
USB Port
(mini)
PMP4320
(Left View)
Computer
16
Follow the on-screen instructions to complete the installation and then restart your computer.
Mini-CDs should only be used in normal tray-loading CD/DVD drives. MiniCDs may be used in slot-loading drives with the proper adapter; please contact your computer or drive manufacturer for more information.
Transferring Files to your PMP4320
The USB 2.0 High-Speed connection makes it easy to transfer music, video, photo, and text
les (or any other data) quickly between the PMP and your computer. Simply use the PMP as
you would a oppy disk using basic operating system commands.
If you need further assistance with transferring les, please refer to your operating system’s instruction manual or on-screen help, or the documentation that was included with your computer.
Do not disconnect or otherwise interrupt the PMP during transmission - this
could damage or corrupt the PMP’s rmware or your les. If the PMP is
accidentally disconnected and is not working properly, reset your PMP (see
the Powering Your PMP section for details).
5.
GETTING STARTED
17
GETTING STARTED
Disconnecting from a Computer
Please follow the steps below to prevent data loss or corruption when disconnecting from a
computer.
Microsoft Windows
Double-click the green arrow in the taskbar located
on the lower-right side of the computer screen
(Safely Remove Hardware).
Safely Remove Hardware:
Select “USB Mass Storage Device” from
the list that appears and then click on
“Stop”.
Stop a Hardware Device: Select “USB
Mass Storage Device” from the list that
appears and then click on “OK”.
Select “USB Mass Storage Device” from
the list that appears and then click on
“OK”.
When the “Safe to Remove Hardware”
window appears, click the OK button and
disconnect the USB cable from the player
and your computer.
Macintosh OS X
On the left side of the Finder window, identify
the appropriate Removable Disk icon.
Click on the “Eject” arrow on the right of the Removable Disk icon.
Disconnect the USB cable from the player and
your computer.
1.
2.
3.
1.
2.
3.
18
Using the PMP4320 Controls
Power On/Off
To turn your player on, press
To turn your player off, press and hold
Hold Function
The Hold/LCD/AV Out switch (located on the bottom of your player) locks/unlocks the key
controls of your player to prevent them from being pressed accidentally.
To lock the key controls, slide the switch left to the HOLD position.
To unlock the key controls, slide the switch right to the LCD or AV OUT position.
Reset Function
If your player freezes or otherwise behaves abnormally, press and hold to turn off and
reset your player.
Adjusting the Volume
When your player is in Video or Music playback mode, press or to adjust the volume
level up or down, respectively.
Navigating the Menu
Use the Navigation Joystick to move the selection cursor. Press the joystick to enter (conrm)
a selection.
To access the Main Menu Desktop, press and hold .
To cancel or to return to the previous screen, press .
To access a context (option) menu, press .
To move the selection left, press .
To move the selection right, press .
To move the selection up, press
To move the selection down, press
To enter (conrm) a selection, press .
GETTING STARTED
19
PMP4320 Display
Main Menu
The Main Menu gives you access to the different function modes of your PMP.
To select a mode, press or to highlight the mode with the Selection Cursor and then
press .
To return to the Main Menu Desktop, press and hold .
27
1
2
3
4
9
8
7
6
5
Video
Watch your digital video les
(AVI, MPEG-1, -2, and -4, and XviD).
Music
Play your digital music files (MP3, WMA).
Record through the microphone.
View your digital picture les (JPG).
E-Book
Read your electronic text les (TXT)
Record
Record audio, video, or voice.
1.
2.
3.
4.
5.
Explorer
View and organize your media library.
Resume
Resume playback of the last le played.
FM Radio
Listen to FM Radio broadcasts.
Setup
Change the internal settings of your PMP.
6.
7.
8.
9.
GETTING STARTED
20
File Browser Screen
The File Browser Screen allows you to view your collection of media.
The File Browser screen will display the type of media that corresponds with the Browser mode, only. Music les will not be displayed
in Video mode.
C:/Video/
57
Ice.avi
independ-day1.asf
matrix-smiths.wmv
mpeg4aac_03.mp4
AAA.DVX
BBB.avi
CCC.asf
DDD.wmv
EEE.mp4
Video
5
6
1
2
3
4
Browser Mode
Indicates the types of les displayed by
the le browser. “Video” indicates that only
supported video types are displayed.
List of Files
Selected File
1.
2.
3.
Information View
Press or as indicated to view or hide
le information details.
Volume Level
Battery Level
4.
5.
6.
GETTING STARTED
21
File Browser Controls
Use the following controls in File Browser mode.
Key Function
Press
Move the selection up
Press
Move the selection down
Press or
Show or hide le information details
Press
Return to the previous folder/screen
Hold
Return to the Main Menu Desktop
Press
Enter the selection
Press
Display the context menu
File Browser Context Options
Press to view the following context options.
Item Function
Desktop Return to the Main Menu Desktop
New
Create a new folder. A text input screen will appear:
Use the navigation joystick to input the name of the new folder. Press
to save the new folder when you are done.
GETTING STARTED
22
Item Function
Copy
Prepare to copy the selected le.
After selecting a le to copy, navigate to the target folder.
Press to access the context menu and select PASTE to
complete the copy function.
Move
Prepare to move the selected le
After selecting a le to move, navigate to the target folder.
Press to access the context menu and select PASTE to
complete the move function.
Paste
Complete copying or moving a le (only available during copy or move
operations -- see “Copy” and “Move” above).
Delete Delete the selected le
Rename
Rename the selected le. A text input screen will appear:
Use the navigation joystick to input the name of the new folder. Press
to save the new folder when you are done.
Information Display le information details
GETTING STARTED
23
Getting Video on Your Computer
There are a number of ways to get digital video onto your computer:
Internet: There are many free digital videos available for download from the internet.
Common le types that your player supports are: AVI, XviD, and MPEG-4.
Take care to respect copyright laws and to download videos from legal sources.
RSS Feeds: Many free and popular media management programs (e.g., Winamp) include free video RSS feeds.
Convert Your Own: There are many software utilities available that will convert preexisting videos to a format compatible with your PMP4320 (e.g., VirtualDub).
Create Your Own: Your PMP4320 can record video in MP4 format (please see the Re-
cord Mode section for more information).
Once you have obtained video on your computer, you can transfer it to your PMP4320 for portable viewing (please see the Transferring Files to Your PMP4320 section for more details).
Playing Video
To play videos on your player:
Select and conrm VIDEO from the Main Menu Desktop.
Select and conrm a supported video le from the File Browser to start playback.
Video File Browser Context Options
Press to view the following context options.
Item Function
Desktop Return to the Main Menu Desktop
New Create a new folder
Copy Prepare to copy the selected le
Move Prepare to move the selected le
Paste
Complete copying or moving a le (only available during copy or move
operations)
Delete Delete the selected le
Rename Rename the selected le
Information Display le information details
1.
2.
VIDEO MODE
24
Video Playback Controls
Use the following controls during video playback.
Key Function
Press Pause playback. Press again to resume playback.
Press
Play previous track
Press
Play next track
Hold
Reverse through the current track
Hold
Fast forward through the current track
Press or
Adjust the volume level up or down
Press
Return to the File Browser
Hold
Return to the Main Menu Desktop
Press
Display option bar
The Option bar items are:
Item Function
Play next track
Play previous track
Change Repeat Mode: Repeat Folder Once, Repeat Folder All
Change Aspect Ratio: 4:3, 16:9, Full Screen, Half Screen
VIDEO MODE
25
Getting Music on Your Computer
There are a number of ways to get digital music onto your computer:
Internet: There are many websites that make music available for free, legal download.
There are also sites such as eMusic.com from which you can purchase legal MP3 music unencumbered by DRM.
Take care to respect copyright laws and to download music from legal sources.
RSS Feeds: Many free and popular media management programs (e.g., Winamp) include free music and audio RSS feeds (commonly referred to as “podcasts”).
Convert Your Own: There are many audio extraction and conversion utilities available
that allow you to convert your CD library to MP3 format for personal use.
Create Your Own: Your PMP4320 can record audio in MP3 format (please see the Re-
cord Mode section for more information).
Once you have obtained music on your computer, you can transfer it to your PMP4320 for portable listening (please see the Transferring Files to Your PMP4320 section for more details).
Playing Music
To play music on your player:
Select and conrm MUSIC from the Main Menu Desktop.
Select and conrm a supported music le from the File Browser to start playback.
Music File Browser Context Options
Press to view the following context options.
Item Function
Desktop Return to the Main Menu Desktop
New Create a new folder
Copy Prepare to copy the selected le
Move Prepare to move the selected le
Paste
Complete copying or moving a le (only available during copy or move
operations)
Delete Delete the selected le
Rename Rename the selected le
Information Display le information details
1.
2.
MUSIC MODE
26
Music Playback Controls
Use the following controls during music playback.
Key Function
Press Pause playback. Press again to resume playback.
Press
Play previous track
Press
Play next track
Hold
Reverse through the current track
Hold
Fast forward through the current track
Press or
Adjust the volume level up or down
Press
Return to the File Browser
Hold
Return to the Main Menu Desktop
Press
Display option bar
The Option bar items are:
Item Function
Play next track
Play previous track
Change Repeat Mode: Repeat Folder Once, Repeat Folder All
Toggle ID3 (song data) or LRC (lyric) information display
Repeat A-B mode.
Access equalizer settings
MUSIC MODE
27
Repeat A-B Mode
Repeat A-B mode allows you can dene a segment of an audio track to be played repeatedly
in a loop.
During music playback, press to set the start point “A” of the loop.
Press again to set the end point “B” of the loop. The track segment will now play repeatedly in a loop from point “A” to point “B”.
Press again to resume normal playback.
MUSIC MODE
28
PHOTO MODE
Getting Photos on Your Computer
Connect a digital camera to your computer to transfer photos to your computer.
From your computer, you can transfer the les to your PMP4320 for portable viewing (please
see the Transferring Files to Your PMP4320 section for more details).
If your digital camera uses an SD or MMC memory card for storage, you can use the integrated SD/MMC card slot on the PMP4320 to transfer or view the photos directly.
Viewing Photos
To view photos on your player:
Select and conrm PHOTO from the Main Menu Desktop.
Select and conrm a supported photo le from the File Browser to start viewing.
Photo File Browser Context Options
Press to view the following context options.
Item Function
Desktop Return to the Main Menu Desktop
Music Resume Return to music playback screen
Information Display le information details
Photo Viewing Controls
Use the following controls during photo viewing.
Key Function
Press Start slideshow. Press again to exit slideshow mode.
Press
View previous photo
Press
View next photo
Press
Rotate photo counterclockwise
Press
Rotate photo clockwise
Press
Return to the File Browser
Hold
Return to the Main Menu Desktop
Press
Display option bar
1.
2.
29
The Option bar items are:
Item Function
Set image as Main Menu Desktop background. To restore the original
background, restore the player’s default settings in the Setup menu.
+
Zoom in on photograph. Use the navigation joystick to pan around a
magnied photo.
-
Zoom out.
4
Display 4 photos simultaneously on the screen.
12
Display 12 photos simultaneously on the screen.
Return to music playback screen
PHOTO MODE
30
Reading EBooks
To read E-Book text les on your player:
Select and conrm EBOOK from the Main Menu Desktop.
Select and conrm a text le from the File Browser to start reading.
Ebook File Browser Context Options
Press to view the following context options.
Item Function
Desktop Return to the Main Menu Desktop
New Create a new folder
Copy Prepare to copy the selected le
Move Prepare to move the selected le
Paste
Complete copying or moving a le (only available during copy or move
operations)
Delete Delete the selected le
Rename Rename the selected le
Information Display le information details
Ebook Reader Controls
Use the following controls during text reading.
Key Function
Press
Read previous le
Press
Read next le
Press
Go to previous page
Press
Go to next page
Press
Return to the File Browser
Hold
Return to the Main Menu Desktop
1.
2.
EBOOK MODE
31
RECORD MODE
Recording Audio and Video to your PMP4320
Your PMP4320 can record audio in MP3 format as well as video in MP4 format.
To make a recording:
Connect an external AV source to the AV In jack.
Select and conrm RECORD from the Main Menu Desktop.
Set the options on the Record Mode screen.
Select and conrm PREVIEW to view or listen to the external source without recording.
Select and conrm START to begin recording.
Record Mode Options
Item Function
Recording
Select the recording source.
Audio: Record audio from the AV In jack in MP3 format
Voice: Record voice from the microphone in MP3 format
Video: Record video (with sound) from the AV In jack in MP4 format
Quality
Select the quality of the recording. Higher quality recordings will take
up more memory.
Auto Stop Automatic Stop timer
Start Start recording
Preview Preview external audio or video signal
Time Adjust time
1.
2.
3.
4.
5.
57
Record
Recording
Quality
Start
Preview
Time:
2006-01-01 00:00
Voice
Mid
32
Record Controls
Use the following controls during recording.
Key Function
Press Pause recording. Press again to resume recording.
Press
Stop and save recording.
RECORD MODE
33
EXPLORER MODE
Managing and Viewing Files on your PMP4320
Explorer mode works like the Music, Video, and Photo File browser modes except that it will
display ALL types of les.
To access Explorer mode, select and conrm EXPLORER from the Main Menu Desktop.
The root folder allows you to access the PMP4320 memory (C:) or the optional SD card
(A:) if one is installed.
When you select and conrm a le, the PMP4320 will play the le if it is supported.
For information on how to use the Explorer File Browser, please refer to the Getting Started
section of this manual.
34
RESUME MODE
Resume mode allows you to quickly return to the last video played. Video playback will resume
from the timepoint at which you stopped the video.
To access Resume mode, select and conrm RESUME from the Main Menu Desktop.
35
RADIO MODE
Listening to FM Radio Broadcasts
To listen to the radio:
Select and conrm RADIO from the Main Menu Desktop.
Earphones (or headphones) must be connected to the PMP’s Headphone
jack for Radio operation for use as an antenna.
Radio Screen Display
Tuning Mode (Preset or Scan)
Frequency Pointer
Frequency Bar
Current Frequency
Current Preset Station
Available Preset Stations
Radio Mode Context Options
Press to view the following option
bar items.
Item Function
Toggle between Preset or Scan (manual) tuning modes. (The scan
mode icon looks like an eye.)
Auto Search function scans and automatically stores all available FM
broadcasts to Preset stations.
Record the current FM broadcast in MP3 format. Press to stop
and save the recording.
Toggle between headphone audio output and speaker output.
or
Delete or Save Preset Station
Return to Main Menu Desktop while playing current station in the
background.
1.
1.
2.
3.
4.
5.
6.
6
5
1
4
2
3
36
Radio Mode Controls
Use the following controls in Radio mode.
Key Function
Press Pause playback. Press again to resume playback.
Press
Previous preset station or frequency
Press
Next preset station or frequency
Hold
In Scan mode, seek the next available lower frequency
Hold
In Scan mode, seek the next available higher frequency
Press or
Adjust the volume level up or down
Press
Return to the Main Menu Desktop
Press
Display option bar
RADIO MODE
37
SETUP MODE
Enter Setup mode to adjust your player’s internal options.
Display Options
Item Function
Brightness Adjust the brightness of the display
Font Color Change the system font color
Focus Color Change the selected item font color
Bar Color Change the selection bar color
Scheme Themes Select a preset color theme.
System Options
Item Function
Language Change the on-screen menu language
TV Standard Change the video signal standard (NTSC or PAL)
System Info View system information (memory capacity, rmware, etc.)
Factory Setting Restore all options to their factory-default settings
Power Options
Item Function
Backlight
Adjust the duration of time the display backlight will remain on for after
the last key press. This is a power-saving feature.
A setting of “ON” will keep the backlight on always.
Power Off
Adjust the duration of time the player will remain on for when it is idle.
This is a power-saving feature.
38
CABLE CONNECTION
PlayMode Options
Item Function
Slide show
Adjust the duration of time a photo is displayed in photo slideshow
mode.
Music Playmode Random, Repeat all, Repeat one
FM Sensitivity Low, Mid, High.
39
RESTORE & FIRMWARE UPGRADES
From time to time, COBY may release rmware updates to improve the performance of the
PMP4320 or to add additional features. Please check the COBY website periodically at www.
cobyusa.com to see if new rmware has been released for your PMP. If you are experiencing abnormal behavior with your PMP, you may choose to restore (format) your PMP before
updating its rmware.
Restoring Your PMP (Format)
Connect the PMP4320 to a computer using the supplied USB cable.
On the computer, locate the Removable Disk icon that corresponds to the PMP4320.
Right-click on the Removable Disk icon and select Format.
A dialog box will appear on-screen. Change the settings to format the PMP as a FAT16
drive, and then click the START button to begin the formatting process.
When the formatting process is complete, disconnect the USB cable from the PMP.
Press and hold to turn the PMP off, and then turn it back on.
Formatting your PMP will erase all of your data from it (including musics,
recordings, movies, photos). Make sure to copy and back up the data on
your PMP that you do not want to lose prior to formatting.
1.
2.
3.
4.
5.
6.
40
Upgrading Your PMP Firmware
Download the latest rmware for your PMP from
www.cobyusa.com. Save this le to
the computer.
Connect your PMP to the computer. Double-click the Removable Icon that corresponds
to your PMP, and then double-click the FIRMWARE folder to open it.
Double-click the downloaded rmware le (you may need a le compression utility in
-
stalled on your computer). In the window that appears, select the le named “UPDATE.
BST” and copy it to your PMP’s root folder (for example, E:\).
Disconnect your PMP from the computer.
Press and hold to turn the PMP off, and then turn it back on. The PMP will update its
rmware automatically.
Do not disconnect your PMP from the computer or otherwise interrupt the
rmware upgrade —doing so could damage your PMP and render it inoperable.
1.
2.
3.
4.
5.
RESTORE & FIRMWARE UPGRADES
41
For more information about digital MP3 and WMA les, please visit our website at
www.cobyusa.com.
ABOUT DIGITAL MUSIC FILES
42
If you have a problem with this player, please read the troubleshooting guide below and
check our website at www.cobyusa.com for Frequently Asked Questions (FAQs) and
rmware updates. If these resources do not resolve the problem, please contact Technical
Support.
The player does not turn on.
The battery level may be too low. Try charging the player or operate the player on AC
power.
Ensure that the Lock switch is disengaged.
Try resetting your player (press and hold the Power key).
The player does not turn charge when connected to a computer (USB
charge).
Try resetting your player (press and hold the Power key).
There is no sound during playback.
Check the volume level.
Ensure that the headphones are attached securely to the player.
The sound quality of the music is poor.
Try playing the le on your computer. If the sound quality is still poor, try downloading the
le again or re-encoding the le yourself.
Ensure that the bit rate of the le is not too low. The higher the bit rate of the le, the better it will sound. The minimum recommended bitrate is 128kbps for MP3s and 96kbps
for WMAs.
Ensure that the headphones are attached securely to the player.
COBY Electronics Technical Support
56-65 Rust St.
Maspeth, NY 11378
Hours: Monday to Friday, 8:30 AM–11:00 PM EST
Saturday to Sunday, 9:00 AM–11:00 PM EST
Email: techsupport@cobyusa.com
Phone: 800-681-2629 or 718-416-3197
Web:
www.cobyusa.com
TROUBLESHOOTING
43
The buttons do not work.
Ensure that the battery is charged or that the player is operating on AC power.
Ensure that the Lock switch is disengaged.
The player will not play my music/video le.
Ensure that the le is in a compatible format.
The le may be copy-protected. This player cannot play copy-protected les.
The LCD characters are corrupted.
Ensure that the correct language has been selected.
The player will not play my video le.
Ensure that the video le will play on your computer using Windows Media Player 10. If
the le works on the computer, use the same computer to convert the video to a compatible format.
I cannot transfer les to the player.
Ensure that your computer is running a supported operating system.
If you are running Microsoft Windows 98 SE, ensure that the USB driver has been properly installed.
Ensure that the supplied USB cable is securely attached to the player and the PC, or try
using another USB cable.
If you have connected the player through a USB hub, try connecting the player directly
to your computer.
Ensure that the player’s memory capacity is not full.
The player has malfunctioned.
Try resetting your player (press and hold the Power key).
Try updating the player’s rmware. Please refer to the Restore & Firmware Upgrades
section of this manual for detailed instructions.
TROUBLESHOOTING
44
Display Type 4.3” TFT LCD
Display Resolution 480 x 272
Memory 20GB Hard Disk
SD/MMC Card Slot for Expanded Memory Capacity
Audio Format Support MP3, WMA
Video Format Support MPEG-4 (ASF, AVI, MP4)
XviD (AVI, MP4)
WMV9 (WMV, ASF)
Photo Format Support JPEG (max 3264 x 2448)
GIF
BMP
FM Frequency Range 87.5 - 108.0MHz
Song Info Support ID3, LRC
PC Interface USB 2.0 High-Speed
Plug and Play Support Windows 98SE/2000/ME/XP or newer
Mac OS X
Audio Output 3.5mm Stereo (Headphone)
Integrated Stereo Speakers
Video Output Composite Video
Audio Input 3.5mm Stereo
Integrated Microphone
Video Input Composite Video
Power Supply DC 5V:
Rechargeable Lithium-ion Battery
100-240V AC Adapter
Specications and manual are subject to change without prior notice.
SPECIFICATIONS
COBY Electronics Corp.
56-65 Rust Street
Maspeth, NY 11378
www.cobyusa.com
www.ecoby.com
Loading...
