For series
MID7015-4G
EN
Coby® Kyros™ Internet Tablet
Instruction Manual ............................................. Page 2
Please read carefully before use
Page 2 Table Of Contents
English
Table of Contents Â
Thank You .....................................................4
Package Contents ........................................................4
Features..........................................................................5
GeTTinG To know The MiD7015 ..................6
Unit at a Glance ...........................................................6
About the Touchscreen ...............................................9
Protective Film ........................................................9
Using Your Finger Tip ..............................................9
Touchscreen Actions..............................................9
About the Orientation Sensor ...................................11
Charging the Tablet ...................................................11
Inserting a Memory Card ..........................................12
About the Protective Case ........................................13
GeTTinG STarTeD .........................................14
Turning the Tablet On and Off .................................14
Turning the Screen On and Off (Standby) ........14
Unlocking the Screen ..........................................15
Home Screen at a Glance ........................................16
Adding Widgets and Icons .................................17
Changing Home Screens ....................................18
Removing Widgets and Icons.............................19
About Menus ...............................................................19
About Notications .....................................................21
ConneCTinG To The inTerneT ..................22
Requirements ............................................................. 22
Connect to a Wi-Fi Network ......................................23
Connect to a Wi-Fi Network Manually ....................25
Forget a Wi-Fi Network ...............................................27
abouT appliCaTionS ..................................28
To Launch an Application .........................................28
Preinstalled Applications ...........................................28
Installing Additional Applications ............................ 30
About the AppsLib Store .................................... 30
Removing Applications ..............................................31
browSinG The web .....................................33
opTional ConneCTionS ..........................36
Connecting to a Computer ......................................36
Connecting to a TV ....................................................37
Connecting Headphones ........................................38
Using the USB Full-Size Adapter .................................39
Connecting a Keyboard .....................................39
Connecting a Storage Device ...........................39
Page 3 Table Of Contents
English
SeTTinG The SYSTeM opTionS ................... 40
Wireless & Networks ................................................... 40
Sound & Display ..........................................................41
Location & Security ....................................................42
Applications ............................................................... 44
Privacy ......................................................................... 45
SD Card & Device Storage ....................................... 46
Search ..........................................................................47
Language & Keyboard ..............................................47
Date & Time .................................................................47
About Device ............................................................. 48
SpeCifiCaTionS ...........................................49
SupporT ........................................................50
SafeTY noTiCeS ...........................................51
Page 4 Thank You
English
Thank You Â
Congratulations on your purchase of a Coby® Kyros™
Internet Tablet. This guide is provided to help you get
started quickly with your player; please read it carefully
and save it for future reference.
For detailed instructions, up-to-date information, and helpful
tips, please visit the Coby website at www.cobyusa.com.
This manual is available for download from the
Coby website as a PDF le.
To view PDF documents, download and install
the free Adobe Acrobat reader from the Adobe
website at www.adobe.com.
package Contents
Please make sure that the items shown below are
included in the package. Should an item be missing,
please contact the local retailer from which you purchased this product.
Coby® Kyros™
Internet Tablet
Protective case
Stylus
USB cable
This package may contain plastic bags or other
materials that pose a hazard to children. Be
sure to safely dispose of all packing materials
after opening.
USB full-size (Type A)
adapter
Professional stereo
earphones
Power adapter
Page 5 Thank You
English
features
Browse the web, watch videos on YouTube, check
e-mail, and more on a generous 7.0” LCD screen
* Requires optional HDMI cable (Type A-to-Type C). 1080p
HD video playback requires a video le encoded at 1080p.
Streaming video quality will be affected by the source, and
the quality and condition of your network connection.
Intuitive touchscreen controls powered by Android
OS
Connect to the Internet wirelessly with high-speed
networking support (Wi-Fi 802.11 b/g)
Plays popular video, music, and photo formats
Connect and enjoy 1080p HD video on your HDTV
via HDMI *
View pages in portrait or landscape with automatic
orientation detection
Download and read thousands of books with the
included Aldiko E-book reader application **
Expandable memory with optional microSDHC card
Rechargeable lithium-polymer battery
** Reading books in the ePub format requires the included
Aldiko E-book reader application.
Page 6 Getting To Know The Mid7015
English
1 2 3
5 4
Getting to know the MiD7015 Â
unit at a Glance
Name Description
1 Stylus
2 Home key Press to return to the home screen.
3 Menu key Press to view the option menu.
4 Back key Press to return to the previous screen.
5 Touchscreen
LCD
Slide the stylus out to use it. Store
the stylus here when it is not in use.
Press and hold to view a list of
recently used applications; touch an
application in the list to launch it.
Note: When you press the Menu key
from within an application, you will
see the options for that application.
To view the Android system options,
press the Menu key from the home
screen.
If the keyboard is on the screen, press
to close the keyboard.
Display and control screen.
Touch controls are displayed on the
screen. Press (or press and hold) icons
with your nger to control the player.
Page 7 Getting To Know The Mid7015
English
Name Description
6
6 Reset key Press to reset the tablet if it freezes or
otherwise behaves abnormally. (Use
a paperclip or other small object to
gently press this key.)
Page 8 Getting To Know The Mid7015
English
Name Description
7
11
10
12
9
8
7 Power key Press to turn the unit on, or to turn
8 Power jack
(DC input)
9 microSDHC
card slot
10 Headphone
jack
the screen on and o.
Press and hold to access the Power
O menu
Charge and power the MID7015 with
the included power adapter.
Load external microSDHC memory
cards here.
Audio output connection for headphones.
Note: Speaker output is automatically disabled when headphones are
connected to the player.
11 HDMI jack
(mini Type C)
12 USB 2.0 Hi-
speed port
Connect to a TV or other display.
Connect to a computer to transfer
data (e.g., music, videos, photos, les)
Page 9 Getting To Know The Mid7015
English
about the Touchscreen
Your tablet comes equipped with an easy-to-use touchscreen which allows access to the tablet’s functions. Use
your nger tip (or a stylus) to touch the area of the screen
where a control icon is displayed. If you touch and hold
the screen, it will register as a continuous button press.
To av oid damaging the screen, do not touch it
with excessive force or with any object other
than your nger or a stylus. For best response,
make sure your hands are clean before using
the touchscreen controls.
Protective Film
A thin lm has been applied to the touchscreen to protect
it during shipping. The protective lm should be removed
before use. To remove it, simply take a corner of the lm
and peel it away from the screen
Using the Stylus
A stylus is included for your convenience and is the
preferred method for interacting with the tablet. You can
use the tip of the stylus to make precise selections on the
touchscreen.
The stylus is stored in the top left corner of the tablet.
Return the stylus to its storage compartment when it is
not in use.
Using Your Finger Tip
The touchscreen is designed for
precision and responds best when
touched with the smallest point
possible.
Use the tip of your ngernail to
touch the screen. The hard, curved
edge of the ngernail makes contact
with the touchscreen at a small
point, allowing for much greater
precision than if you were to use the
at pad of your nger.
Touchscreen Actions
You can control the functions of the tablet by using the
touchscreen. To control the tablet with the touchscreen,
use your ngertip or stylus to manipulate icons, buttons,
menu items, the onscreen keyboard, and other items
displayed on the screen.
Page 10 Getting To Know The Mid7015
English
You can perform the following actions on the touchscreen
using your ngertip or stylus.
Touch: To activate an on-screen item (e.g.,
application icons, buttons, menu
items, and the letter/symbols of the
on-screen keyboard), simply touch
them with your ngertip or stylus.
Touch and
Hold:
Some on-screen items have an
alternate action if you touch and hold
it (e.g., opening an alternate menu, or
to activate the drag function). To touch
and hold an item, touch the item and
do not lift your ngertip/stylus until the
action occurs.
Drag: Drag an on-screen item to change its
position (e.g., an application icon on
the home screen).
To drag an item, touch and hold it for
a moment, then without lifting your
ngertip/stylus, move your ngertip/
stylus on the screen until the item
reaches its target destination.
Swipe: Swipe up/down on the screen to scroll
through a list. On some screens,
you may be able to swipe left/right to
change the view.
To swipe, touch the screen and then
quickly move your ngertip/stylus
across the screen without lifting your
ngertip/stylus. Do not pause on the
screen with your ngertip/stylus at
the initial point of contact or you may
accidentally drag an item instead.
Double-tap: Quickly tap the screen twice on a
webpage or other application screen to
zoom (the application must support the
double-tap/zoom function). Within the
browser, double-tapping a webpage
section will cause the browser to zoom
and t that section to the width of the
screen.
Page 11 Getting To Know The Mid7015
English
about the orientation Sensor
The tablet contains a sensor that will automatically
change the orientation of most screens as you rotate the
tablet. The sensor works best when the tablet is rotated
perpendicular to the ground (i.e., when the tablet is held
upright and not at on its back).
The orientation sensor can be turned on an off in the
Sound & display settings menu.
Charging the Tablet
The tablet comes with a built-in rechargeable lithiumpolymer battery.
Before using the tablet, the battery should be charged
fully. The Status Indicator will light green when the battery is charged fully.
To charge the battery:
Plug one end of the included power adapter into an 1.
AC 100-240V outlet.
Plug the other end of the included power adapter into 2.
the Power jack on the tablet.
Disconnect the power adapter when the tablet is fully 3.
charged.
The battery used in this device may present a re
or chemical burn if mistreated. Do not disassemble,
incinerate, or heat the device. Do not leave the de-
vice in a place subject to direct sunlight, or in a car
with its windows closed. Do not connect the device
to a power source other than that which is indicated
here or on the label as this may result in the risk of
re or electric shock.
Page 12 Getting To Know The Mid7015
English
inserting a Memory Card
The tablet accepts microSDHC memory cards. Insert a
memory card into the microSDHC card slot to:
Increase the memory capacity of your tablet
To release and remove a memory card:
UNMOUNT the memory card.1.
From the home screen, press the a. Menu key, and
then touch Settings to show the settings menu.
Play media les stored on the memory card (e.g.,
music, video, or photo les).
To insert a memory card:
Align the memory card with the card slot. The metal 1.
contacts of the memory card should face the back of
the tablet and away from the LCD screen.
Slide the card into the spring-loaded slot. Push the 2.
card in until it clicks into place.
Do not attempt to insert objects other than a
microSD or microSDHC memory card into the
card slot. A compatible memory card should t
easily into the card slot; if you encounter resis-
tance, check the alignment of the card. Do not
attempt to force the card in.
Avoid touching the gold contacts of the memory
card.
Touch b. SD card & device storage to show the
SD card & device storage settings.
Touch c. Unmount SD card to prepare the memory
card for safe removal.
Push the card further into the slot until you hear a 2.
click. The card will spring out of the slot.
Grasp the card by its edge to remove it.3.
To avoid damage and data corruption, do not
remove a memory card while data is being writ-
ten to or read from the card. For example, do not
remove a card while playing a music le stored
on the card.
Page 13 Getting To Know The Mid7015
English
about the protective Case
The tablet comes preinstalled in a protective case.
To remove the tablet from the case:
There are 5 tabs around the edge of the tablet that
secure it within the case.
Identify the smallest tab located by the top-right 1.
corner. This tab is circled in the illustration below.
To release the tablet, use your thumb to gently push 2.
the tab away to the right so that it unhooks from the
edge of the tablet.
Lift and slide the tablet away from the case.3.
Page 14 Getting Started
English
Getting Started Â
Turning the Tablet on and off
To turn the tablet on:
Press and hold the Power key until the LCD screen
turns on. Wait until the Home screen appears; the
tablet is now ready for use.
To turn the tablet off:
Press and hold the 1. Power key until the Device Op-
tions menu appears.
Touch 2. Power off on the screen. A conrmation message will appear.
Touch 3. OK to turn off the tablet.
Turning the Screen On and Off (Standby)
When the tablet is on, you can turn off the screen to
conserve battery power. Simply press the Power key
once to turn the screen off. Press the Power key again to
turn the screen back on.
To conserve battery power, the screen can be
set to turn off automatically when the tablet is
not in use (between 15 seconds and 30 minutes). This Screen timeout option can be found
in the Sound and display settings menu.
Page 15 Getting Started
English
Unlocking the Screen
When the screen turns off, you will have to unlock the
screen when you turn it back on.
To unlock the screen, drag the lock icon across the
screen towards the speaker icon.
If a password has been set, enter the password to nish
unlocking the screen. The Screen Unlock password can
be set in the Location and security settings menu.
Page 16 Getting Started
English
home Screen at a Glance
2
3
4
5
1
The home screen is the starting point for all of the
features of your tablet.
Name Description
1 Notication
bar
Shows notication icons such as new
messages and alarms; drag the bar
down to the bottom of the screen to
open the full Notications panel. The
right side of the bar also shows status
information such as the time, battery
level, and network signal strength.
Note: You can press the Menu key
and then touch Notications to
open the full Notications panel from
the Home screen.
2 Volume con-
trols
3 Widgets Widgets are small applications that
4 Launcher Tab Open the Launcher to view a list of all
Touch “–“ to decrease the volume
level. Touch “+” to increase the volume level.
you can use directly from the home
screen.
applications installed on the tablet.
Touch the Launcher tab to open the
Launcher.
Note: You can swipe left and right to
view additional screens.
Page 17 Getting Started
English
Name Description
5 Icons Touch an icon to open an application
or folder
Adding Widgets and Icons
For quick access to your information and applications,
you can add widgets, as well as shortcuts to applications
or folders to the Home screen.
Touch and hold an empty spot on the home screen. The Add
to Home screen menu will appear.
Page 18 Getting Started
English
To add a shortcut, touch Shortcuts, then choose an
application, bookmark, music playlist, or setting.
To add a widget, touch Widgets; then choose a
widget from the menu.
To add a folder, touch Folders.
You can use folders to keep your Home screen
tidy. Drag icons onto a folder to place them in the
folder.
To view the contents of a folder, touch the folder to
open it. You can then touch an icon to launch it.
To rename a folder, touch the folder to open it,
then touch and hold the top title bar. A Rename
folder box will appear; enter the new Folder
name and then touch OK.
Changing Home Screens
If there is not enough room on the current Home screen
to add a widget/icon, you can place them on another
Home screen.
A total of three Home screens are available.
To change the Home screen, swipe left or right
across the screen.
Page 19 Getting Started
English
Removing Widgets and Icons
To remove unwanted widgets and icons from your Home
screen:
Touch and hold the widget/icon. The Launcher tab 1.
will change to show a trash can.
Without removing your ngertip/stylus from the 2.
screen, drag the icon to the trash can.
about Menus
There are two types of menus used by the tablet.
Option menus. 1.
Option menus contain items related to the current screen or
application. To view an option menu, press the Menu key.
Not all screens or applications have an option
menu; if a menu does not exist, nothing will
happen if you press the Menu key.
Page 20 Getting Started
English
Context menus.2.
Context menus contain items related to a specic item on
the screen. To view a context menu, touch and hold an
item on the screen.
Touch & hold All pictures.
A context menu will appear.
Not all items have a context menu; if a menu
does not exist, nothing will happen if you touch
and hold the item.
Page 21 Getting Started
English
About Notications
The icons that appear in the Notication bar at the top
of the screen alerts you when new messages arrive or
alarms or other application events occur.
To respond to a notication:1.
Touch a notication in the list; the Notications panel will
close and the application associated with the notication
will launch.
View and respond to the notications by opening the full
Notications panel.
Drag the Notication bar down to the bottom of
the screen to open the Notications panel from any
screen, or;
On the Home screen, press the Menu key and then
touch Notications to open the Notications panel.
To clear all notications:2.
Touch the Clear button at the top right of the Notications
panel; the panel will close and all notications will be
cleared.
To close the Notications panel:3.
Drag the handle at the bottom of the Notications
panel to the top of the screen, or;
Press the Back key.
Page 22 Connecting To The Internet
English
Connecting to the internet Â
This tablet can utilize Wi-Fi data networks to connect to the Internet. Wireless Wi-Fi technology can provide Internet access
at distances of over 300 feet; however, this distance can be affected by y our surrounding environment and Wi-Fi router.
requirements
In order to connect to the Internet, you will need the
following:
A wireless router or access point with a broad-1.
band Internet connection
The wireless router must support Wi-Fi 802.11b/ g connections. If the router supports 802.11n, make sure that it has
been congured to accept 802.11b/g connections as well.
A minimum connection speed of 64 Kbps is
recommended. Faster speeds will enable a
better Internet experience.
The wireless router network settings2.
You will need to know the name of your network (SSID),
as well as the password or other credentials if your
network is secured. These settings can usually be found
on the administration webpage of your wireless router.
Please refer to your wireless router’s documentation for
help, or ask your network administrator for details.
You may encounter open Wi-Fi networks, or
“hotspots.” These networks are usually congured so that you can simply connect to them
without needing to know its settings; the tablet
will obtain all the information it needs from the
router automatically.
Page 23 Connecting To The Internet
English
Connect to a wi-fi network
The Notication bar displays icons that indicate your
tablet’s Wi-Fi status.
Notication that an open Wi-Fi network is in
range.
Connected to a Wi-Fi network (waves
indicate connection strength).
Make sure that the Wi-Fi option box is checked: e.
Touch Wi-Fi.
[no icon]
1. Turn on the Wi-Fi radio if it is not already on. To
turn on Wi-Fi:
There are no Wi-Fi networks in range, or the
Wi-Fi radio is off.
Go to the Home screen: a.
Press the Home key.
Open the Settings menu: b.
Press the Menu key, then touch Settings.
Open the Wireless & networks menu: c.
Touch Wireless & networks.
Open the Wi-Fi settings menu: d.
Touch Wi-Fi settings.
When Wi-Fi is on, the tablet will look for and display a list
of available Wi-Fi networks.
If a network that you have connected to previ-
ously is found, the tablet will connect to it.
If you don’t see your network in the list, you
can force the tablet to re-scan. To scan for
networks, press the Menu key, and then touch
Scan.
Page 24 Connecting To The Internet
English
2. Select an available Wi-Fi network to connect to:
In the same Wi-Fi settings menu above, touch a network
in the list.
If the network is open, the tablet will prompt you to
conrm connection to the network. Touch Connect
to conrm.
If the network is secured (as indicated by a Lock
icon), the tablet will prompt you to enter a password
or other credentials. Touch the Wireless password
box to show the on-screen keyboard and then use it
to enter the password. Touch Connect to conrm.
When you have successfully connected to a Wi-Fi
network, the Notications bar at the top of the screen will
show a Wi-Fi signal indicator.
If the network is secured, you will need to con-
tact the network’s administrator to .
If you don’t see your network in the list, you
can force the tablet to re-scan. To scan for
networks, press the Menu key, and then touch
Scan.
Page 25 Connecting To The Internet
English
Connect to a wi-fi network Manually
Connect to a Wi-Fi network manually if you want to add
a Wi-Fi network when it is not in range, or to connect to
a router that has been set to obscure the network name
(SSID).
1. Open the Wi-Fi settings menu. To do so:
Go to the Home screen: a.
Press the Home key.
Open the Settings menu: b.
Press the Menu key, then touch Settings.
Open the Wireless & networks menu: c.
Touch Wireless & networks.
Open the Wi-Fi settings menu: d.
Touch Wi-Fi settings.
2. Turn on the Wi-Fi radio if it is not already on.
Make sure that the Wi-Fi option box is checked:
Touch Wi-Fi.
3. Open the “Add Wi-Fi network” screen.
Touch Add Wi-Fi network located at the bot-
tom of the screen (after the list of discovered
networks).
Page 26 Connecting To The Internet
English
4. Enter the network information manually. If you
do not know this information, contact the administrator/owner of the network.
Network SSID: Enter the name of the network.
Security: If the network is secured, touch the
security menu box to select the type of security
used.
Wireless password: If security has been
chosen, enter the required security credentials.
(Check the Show password box to reveal the
password as you type.)
Touch Save to nish adding the Wi-Fi network.
The tablet will now connect to this network automatically
with the saved credentials when it comes into range.
Page 27 Connecting To The Internet
English
forget a wi-fi network
Remove a saved Wi-Fi network from the tablet if you no
longer use it or if you don’t want the tablet to connect to it
automatically.
Open the 1. Wi-Fi settings menu.
Turn on the Wi-Fi radio if it is not already on.2.
Touch and hold the name of the network.3.
Touch 4. Forget network.
Page 28 About Applications
English
about applications Â
Applications allow your tablet to perform many different
functions.
To launch an application
Touch the application icon on the home screen or in the
Launcher.
Launcher screen:
The screen shown above is for illustrative pur-
poses only. Coby reserves the right to modify
and improve the nal list of applications avail-
able on the tablet.
preinstalled applications
Some applications have been installed on your tablet for
your convenience. These applications include:
View the current time, or set an alarm.
Download and read thousands of ebooks. Supports the ePub standard.
Browse the web.
Page 29 About Applications
English
Perform simple mathematical operations.
View detailed usage statistics, as well as
adjust options that are not available in
the Settings menu.
Optimize the accuracy of the touchscreen.
Check your e-mail.
View photos and play videos.
Play music.
Access the Settings menu to adjust the
tablet’s options.
Launch the mobile YouTube™ browser
page to watch internet videos.
Browse for, download, and install applications from the AppsLib store.
Page 30 About Applications
English
installing additional applications
You can also download an install additional applications from AppsLib, the web browser, or other sources.
Downloading and installing new applications to your tablet
can extend its functionality in many ways.
The tablet must be set to allow installation of applications
from non-Market sources. The Unknown sources option
can be set in the Application settings menu.
Support for third-party applications is provided b y
their respective applications developers. Coby is
not responsible for the behavior of these applications; please review the description and terms of
use provided by third-party developers carefully
before installing applications on your tablet.
About the AppsLib Store
You can download and install applications from the included AppsLib
store. To open the AppsLib store:
Touch the 1. Launcher icon.
Touch the 2. AppsLib icon.
When installing an application, it will tell you what functions of the phone it needs to control and if it needs
access to your data. Make sure you review these access
requirements carefully before completing the installation.
Be especially cautious with applications that
request access to many functions or to a signicant amount of your data. You are responsible for the results of applications installed on
your tablet.
Page 31 About Applications
English
You can learn more about AppsLib, and browse applications by visiting their website at www.appslib.com.
Some developers allow you to download and
install applications directly from their website.
Touch
3. Applications, and then touch Manage ap-
plications to show a list of all applications installed
on the tablet.
Support for third-party applications is provided b y
the respective application developer. Coby is not
responsible for the behavior of these applications;
please review the description and terms of use
provided by third-party developers carefully be-
fore installing applications on your tablet.
removing applications
Uninstall unwanted applications to remove them from the
tablet.
From the Home screen, 1. press the Menu key.
Touch 2. Settings to open the Settings menu.
Page 32 About Applications
English
Touch the name of the application you want to 4.
uninstall; the Application Info screen will open.
Touch 5. Uninstall. The tablet will prompt you to
conrm.
Touch 6. OK to uninstall the application.
Page 33 Browsing The Web
English
browsing the web Â
1
2
The Browser application lets you visit webpages and nd information on the web. Keep up with the news, your friends, or
enjoy video from YouTube ™, the world’s most popular video-sharing community.
To use Browser, the tablet must be
connected to the Internet. Read the
section “Connecting to the Internet” to
learn how to connect to the Internet.
To open Browser, touch the Browser
icon on the Home screen or in the
Launcher.
Name Description
1 Address bar Displays the address (URL) of the
2 Bookmark
icon
current page. Touch the bar to enter a
new address or to search the web.
Touch the Bookmark icon to add or
view bookmarks, to view your most
visited sites, or to view your browser
history.
Page 34 Browsing The Web
English
Some common Browser actions are described below.
To go to a webpage.
1. Touch the Address
bar at the top of
the Browser screen.
The keyboard will
open automatically.
(If the Address bar
is not visible, drag
the page down to
return to the top of
the Browser screen.)
2. Use the keyboard
to enter the address (URL) of the
webpage (e.g.,
m.youtube.com.
3. Touch Go to open
the webpage.
To bookmark a webpage.
Bookmark your favorite webpages in order to visit
them quickly without entering a URL.
1. Go to the webpage
that you want to
bookmark
2. Touch the
Bookmark icon to
the right of the Address bar.
3. Touch the Add tile.
Page 35 Browsing The Web
English
4. If desired, you can
modify the name
of the bookmark
or its location (URL
address). Otherwise,
touch OK to nish
adding the bookmark.
To open a new browser window.
1. Press the Menu key
to show the Browser
options.
2. Touch New Win-
dow to open a new
browser window.
To switch between browser windows.
To go to a bookmarked webpage.
1. Touch the Bookmark icon to the
right of the Address
bar.
1. Press the Menu key
to show the Browser
options.
2. Touch Windows to
show a list of open
browser windows.
2. Touch a bookmark
tile to open it.
3. Touch the name of a
window to switch to
it, or touch the “x” to
close the window.
Page 36 Optional Connections
English
optional Connections Â
Connecting to a Computer
Connect the tablet to a computer to transfer les.
Connect your tablet to the computer.1.
With the included USB cable:
Plug the small end of the cable into the USB 2.0 Hi-
speed connector of the tablet.
Plug the large end of the cable into an available USB
2.0 Hi-speed port on the computer.
When your tablet is connected, a USB icon will
2.
appear in the Notication bar.
Drag the Notication bar down to open the notications
panel.
Page 37 Optional Connections
English
Mount the storage drive.3.
Touch USB connected (Internal) to mount the tablet’s
built-in storage, then touch Mount when prompted to
conrm. When mounted, you can copy les to/from
your computer to it.
If a memory card is installed, touch USB connected
(External) to mount the card, then touch Mount when
prompted to conrm. When mounted, you can copy
les to/from the computer to it.
Your tablet will be recognized by the computer as a
Removable Storage drive. Drag and drop les between
your tablet and the computer. To learn more about copy-
ing les, please refer to the documentation included with
your computer or operating system.
To prevent damage or corruption of the les on
your tablet or memory card, be sure to follow your
computer’s instructions for connecting and dis-
connecting USB devices.
Connecting to a TV
Connect to a TV to enjoy your tablet from the comfort of
your living room. An HDMI cable (Type A-to-Type C) is
required to connect the tablet to a TV.
Before connecting the tablet to the TV, you will have to
adjust a few display settings on the tablet.
Make sure that the tablet is set to output over HDMI
For optimal visual performance, make sure that the
video output resolution of your tablet matches the
capabilities of the TV.
To adjust the display settings:
From the home screen, press the 1. Menu key, and
then touch Settings to show the settings menu.
Touch 2. Sound & display to show the Sound & display
settings.
Touch 3. Output Select, and then touch HDMI to enable video output from the tablet’s HDMI connector.
Page 38 Optional Connections
English
Touch 4. HDMI Setting, and then touch a resolution
option that matches the display capabilities of the TV:
Choose a. 1920 x 1080p 60Hz if your TV is capable
of displaying 1080p video.
Choose b. 1280 x 720p 60Hz if your TV is capable
of displaying 720p or 1080i video.
Connecting headphones
Connect a pair of headphones (or earphones) to the
tablet to enjoy media in private.
Lower the volume level of the tablet before connecting
headphones, and then slowly raise the volume to a
comfortable listening level.
To connect the tablet to the TV:
Plug the small end of the HDMI cable into the mini 1.
HDMI connector of the tablet
Plug the large end of the HDMI cable into the HDMI 2.
port on the TV.
Turn on the TV, and set its display mode to the HDMI 3.
port that the tablet is connected to.
The tablet’s display will be output to the TV screen.
If you need help setting the display mode of the
TV, please refer to the documentation provided
by the TV manufacturer.
The headphones must have a 3.5 mm (1/8 in) plug.
When headphones are connected, speaker output
will be disabled automatically.
Hearing experts advise against the constant
use of personal stereos played at high volume.
Constant exposure to high volumes can lead to
hearing loss. If you should experience ringing
in the ears or hearing loss, discontinue use and
seek medical advice.
Page 39 Optional Connections
English
using the uSb full-Size adapter
The USB full-size adapter can be used to connect and
use USB devices with the tablet. The adapter converts
the mini USB port on the tablet into a USB On-the-Go
(OTG) connector.
Connecting a Keyboard
For times when you want to type for an extended period
of time, you may want to connect a full-size keyboard to
the tablet.
Use the included USB full-size (Type A) adapter to connect a keyboard to the tablet.
You may also use this connection to add a
mouse to the tablet.
The adapter supports one connection at a time.
To use a keyboard and mouse simultaneously,
you will need to add an external USB hub.
Connecting a Storage Device
Use the included USB full-size (Type A) adapter to
connect a storage device to the tablet (e.g., a USB ash
memory drive).
This connection supports a maximum storage
size of 8 GB. For additional storage capacity, a
microSD card can be added to the tablet.
Page 40 Setting The System Options
English
Setting the System options Â
Open the system settings menu to adjust how the tablet
looks and functions.
Many applications will have their own settings;
refer to the documentation provided by the ap-
plication developer to learn more.
To open the Settings menu:
From the Home screen, press the 1. Menu key.
Touch 2. Settings to open the Settings menu.
The settings are grouped by category. Touch a category
to open and adjust its settings.
wireless & networks
Setting Description
Airplane mode Check to disable all wireless radios.
Wi-Fi Check to turn on the wireless net-
working radio (Wi-Fi 802.11b/g).
Wi-Fi settings Touch to scan for and view a list of
available Wi-Fi networks.
Wi-Fi Check to turn on the wireless net-
working radio (Wi-Fi 802.11b/g).
Network
notication
Add Wi-
network
Check to receive an alert in the
Notications bar when an open Wi-Fi
network becomes available.
Touch to congure a Wi-Fi network
that is out of range, or that is set to
obscure its SSID network name.
Page 41 Setting The System Options
English
Sound & Display
Setting Description
Sound settings
Silent mode Check to disable all sounds except
for alarms and media (e.g., video or
music that is playing). Alarms and
media must be silenced within their
respective applications.
Ringer volume Drag a slider to set the volume level
for system and application notications.
(Leave the Use incoming call
volume for notications option
checked; this tablet does not support
phone calling functions.)
Media volume Drag a slider to set the volume
level for media playback (e.g., video
or music). You can also adjust the
volume level during media playback
by using the controls provided in the
Notications bar.
Notication ringtone
Select the ringtone that sounds
when you receive a notication.
A sample of the ringtone will play
when you touch it.
Setting Description
Audible selection Check to play a sound when making
a screen selection.
SD card notications
Display settings
Orientation Check to have the tablet automati-
Animation Adjust the level of animated transi-
Output Select Select the video output mode of the
Check to play a sound when you
receive a memory card notication
(microSD, microSDHC).
cally detect and rotate the screen to
match its orientation.
tions between screens. Lowering the
animation level may increase system
and battery performance.
tablet.
None: turn o the HDMI connector.•
HDMI: turn on the HDMI connector. •
Video will not be output to the
tablet’s screen when HDMI output
is on.
Page 42 Setting The System Options
English
Setting Description
HDMI Setting Select the video output resolution
UI Resolution
Setting
Brightness Drag a slider to adjust the bright-
Screen Timeout Set how long before the screen turns
over HDMI.
1920 x 1080p 60Hz: For use with •
TVs that support 1080p.
1280 x 720p 60Hz: For use with TVs •
that support 720p or 1080i.
This option is reserved for future use.
Adjusting this option has no function
at this time.
ness level of the screen. Setting the
brightness to the lowest comfortable
level will maximize battery life.
Use a lower setting when viewing in
dim environments; use a higher setting in bright environments.
o after the last touch of the screen/
button. To maximize battery life,
use the shortest timeout that is still
convenient.
location & Security
Setting Description
My Location
Use wireless networks
Screen unlock pattern
Set unlock pattern Create a pattern that must be drawn
Require pattern Uncheck to stop requiring an unlock
Check to use information from Wi-Fi
and mobile networks to determine
your approximate location.
Your location information is anonymous and is used to personalize and
improve your experience with many
applications.
on the screen in order to unlock the
device.
This screen unlock pattern can
protect your device and data from
unauthorized use.
pattern to unlock the device.
You will be required to draw your
current unlock pattern in order to
uncheck this option.
Page 43 Setting The System Options
English
Setting Description
Use visible pattern Check to draw lines between points
in the unlock pattern.
Passwords
Visible passwords Check to briey display each charac-
ter as you enter a password. This can
help you verify that the password is
being entered correctly.
Credential storage
Use secure credentials
Check to give applications access
to your device’s encrypted store of
secure certicates and related passwords and other credentials. Secure
certicates must conform with the
PKCS #12 standard.
Credential storage is used to establish certain kinds of secure Wi-Fi connections. Your network administrator
should be able to assist with installing and conguring any credentials
necessary to connect to your organization’s secure network.
If you have not set a password for
credential storage, this setting is
dimmed.
Setting Description
Install from SD card Touch to install a secure certicate
from your device’s memory card.
Set password Set or change the password for your
secure credential storage.
The length of your password must be
a minimum of 8 characters.
Clear storage Delete all secure certicates and
related passwords and other credentials. In addition, the secure credential storage password will be erased.
You will be prompted to conrm that
you want to do this.
If no credentials exist, this setting is
dimmed.
Page 44 Setting The System Options
English
applications
Setting Description
Unknown sources Check to permit installation of ap-
plications obtained from locations
other than Android Market (e.g.,
alternate app markets, web sites,
email, etc).
The included AppsLib market is considered an alternate app market. This
setting must be checked in order to
install applications from AppsLib.
Note: To protect your device and
personal data, download applications only from trusted sources!
Setting Description
Manage applications
Running services Display a list of all running services.
Display a list of all the applications
and other software installed on your
device. Touch an item in the list to
view detailed information about the
app, to uninstall the app, or to force
it to stop if it is currently running.
By default, only downloaded apps
are shown sorted in alphabetical
order.
Press Menu and touch Filter to
change the list to display all apps,
running apps only, or downloaded
apps only.
Press Menu and touch Sort by size
to display apps in order by size.
Touch a service in the list to stop it,
or to change its settings.
A service is an application (or part of
an application) that runs in the background in order to provide services
to other applications -- even when
their main application is not running.
Page 45 Setting The System Options
English
Setting Description
Development Check USB debugging to allow
debugging tools on a computer to
communication with the device via a
USB connection.
Check Stay awake to prevent the
screen from dimming and locking
when the device is connected to
power or to a USB device that provides power.
Check Allow mock locations to
permit a development tool on a
computer to override the device’s
location information.
privacy
Setting Description
Personal data
Factory data reset Erase all of your personal data from
internal device storage, including information about e-mail accounts, any
other accounts, system and application settings, and any downloaded
applications.
Resetting the device does not erase
any system software updates you’ve
downloaded or any les on your
memory card, such as music or photos. Downloaded books will not be
erased, but you will have to restore
them using the included Aldiko app
when prompted.
If you reset the device in this way,
you will be prompted to reenter the
same kind of information as when
you rst started Android.
Page 46 Setting The System Options
English
SD Card & Device Storage
Setting Description
SD card
Total space Displays the total capacity of any
memory card installed in your device.
If no card is installed, this setting is
dimmed.
Available space Displays the amount of capacity free
on any card installed in your device.
If no card is installed, this setting is
dimmed.
Unmount SD card Unmount a memory card from the
device in order to safely remove it
while the device is on or to format a
card.
This setting is dimmed if no card is
installed, or if it has already been unmounted, or if it has been mounted
on your computer.
Format SD card Prepare a memory card for use with
the device. Formatting a card will
permanently erase everything on
the card. The memory card must be
unmounted before you can format it.
Setting Description
Nand memory (Internal memory)
Total space Displays the total storage capacity
of your device. Your device’s internal
memory is used to store the operating system, its components, applications (including those you have
downloaded), and data associated
with your applications.
Available space Displays the amount of capacity free
on your device.
Unmount Nand
memory
Mount Nand
memory
Format Nand
memory
Unmount the device’s internal
memory.
Mount the device’s internal memory
if it has been unmounted.
Permanently erase everything stored
in internal memory. The internal
memory must be unmounted before
you can format it.
Page 47 Setting The System Options
English
Search
Setting Description
Web search
Google search settings
Quick Search box
Searchable items The quick search box can be found
Clear search shortcuts
Congure your Google web search
options.
on the device’s home screen.
Check an item to have it included in
device searches. Uncheck an item to
exclude it from device searches.
Erase the search results history that
appears below the Quick Search Box.
language & keyboard
Setting Description
Select locale Select the language to use for the
text on the device.
Text settings
Android keyboard Congure the on-screen keyboard
options.
Setting Description
User dictionary Add, remove, or edit words from
the dictionary. The device uses the
dictionary to help increase the speed
and accuracy of your typing as you
use the Android keyboard.
Date & Time
Setting Description
Set date Set the date of the device’s internal
clock.
Select time zone Set the time zone of the device’s
internal clock.
Set time Set the time of the device’s internal
clock.
Use 24-hour format Check to display the time using the
24-hour format (e.g., 13:00 instead of
1:00 PM).
Select date format Select how you want the device to
display dates.
Page 48 Setting The System Options
English
about Device
Setting Description
Battery use See which applications and system
components you have been using
since the device was last connected
to a power source. This list is sorted
by the amount of power used.
Touch an item in the list to see more
information or to access a settings
screen.
Nothing will be displayed if the device is connected to a power source.
Legal information Display legal information about the
software included with your device.
Model number Displays the model number of your
device.
Firmware version Displays the rmware version num-
ber of the operating system installed
on your device. You may need this
information when talking with customer support.
Setting Description
Kernel version Displays the kernel version number
of the operating system installed on
your device. You may need this information when talking with customer
support.
Build number Displays the build version number
of the operating system installed on
your device. You may need this information when talking with customer
support.
Page 49 Specications
English
Specications Â
Please visit www.cobyusa.com for the latest product information. Design, specications, and manual are subject to
change without notice.
Processor ARM1176™ (720 MHz)
RAM 256 MB DDR2
Storage 4 GB ash built-in
microSDHC card slot (max. 16GB
supported)
Display 7.0” touchscreen
TFT LCD (800 x 480)
Wi-Fi Networking IEEE 802.11 b/g
Video Output Mini HDMI, type C
(1080p and 720p supported)
Audio Output 3.5 mm headphone
PC Interface USB 2.0 Hi-speed*
Additional
Features
Operating System Android™ 2.1
Power Rechargeable Li-poly battery
* This port also supports USB 2.0 OTG connections via
the included USB full-size (type A) adapter. USB 2.0
OTG supports the connection of low power USB devices such as
mice or keyboards, as well as storage devices up to 8 GB in size.
Built-in microphone
Built-in speaker
Power Adapter (DC 5V, 2A)
Page 50 Support
English
Support Â
If you have a problem with this device, please check our website at www.cobyusa.com for Frequently Asked Questions
(FA Q) and product updates. If these resources do not resolve the problem, please contact Technical Support.
Coby electronics Technical Support
Email techsupport@cobyusa.com
Web www.cobyusa.com
Phone 877-302-2629
Monday to Friday, 9:00AM–9:00PM EST
Page 51 Safety Notices
English
Safety notices Â
The lightning ash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufcient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operation and servicing instructions in the
literature accompanying the appliance.
For recycling or disposal information about this
product, please contact your local authorities or
the Electronics Industries Alliance: www.eiae.org.
For Customer Use:
Enter below the serial number that is located on the rear of the
unit. Retain this information for future reference.
Model No.
Serial No.
WARNING: To prevent re or shock hazard, do not expose this
device to rain or moisture. Dangerous high voltage is present inside
the enclosure. Do not open the cabinet.
Protect your hearing: Hearing experts advise against the con-
stant use of personal stereos played at high volume. Constant exposure
to high volumes can lead to hearing loss. If you should experience
ringing in the ears or hearing loss, discontinue use and seek medical
advice.
Note: If the product suddenly has no response or powers off, an elec-
trostatic discharge may be the cause. In this circumstance, please
follow the procedures below for recovery:
Reset the player (use a paper clip to gently press the Reset button •
on the bottom of the player).
Turn on the unit again•
Page 52 Safety Notices
English
fCC Statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.•
Consult the dealer or an experienced radio/TV technician for help•
Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15 of the FCC rules.
Do not make any changes or modications to the equipment unless otherwise specied in the manual. If such changes or modications should
be made, you could be required to stop operation of the equipment.
Page 53 Safety Notices
English
important Safety instructions
Read Instructions: All the safety and operating instruc-1.
tions should be read before the product is operated.
Retain Instructions: The safety and operating instruc-2.
tions should be retained for future reference.
Heed Warnings: All warnings on the product and in 3.
the operating instructions should be adhered to.
Follow Instructions: All operating and usage instruc-4.
tions should be followed.
Cleaning: Unplug this product from the wall outlet be-5.
fore cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
Attachments: Use only attachments recommended by 6.
the manufacturer. Use of other attachments may be
hazardous.
Water and Moisture: Do not use this product near 7.
water (e.g., near a bath tub, washbowl, kitchen sink,
laundry tub, in wet basements, or near a swimming
pool and the like).
Ventilation: Slots and openings in the cabinet are 8.
provided for ventilation to ensure reliable operation of
the product and to protect it from overheating. These
openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventila-
tion is provided or the manufacturer instructions have
been adhered to.
Power Sources: This product should be operated only
9.
from the type of power source indicated on the rating
label. If you are not sure of the type of power supply to
your home, consult your product dealer or local power
company. For products intended to operate from battery power or other sources, refer to the operating
instructions.
Overloading: Do not overload wall outlets, extension 10.
cords, or integral convenience receptacles as this can
result in a risk of re or electric shock.
Object and Liquid Entry: Never push objects of any 11.
kind into this product through openings as they may
touch dangerous voltage points or shout-out parts that
could result in a re or electric shock. Never spill liquid
of any kind on the product.
Servicing: Do not attempt to service this product your-12.
self as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servic-
ing to qualied service personnel.
Damage Requiring Service: Unplug this product from 13.
the wall outlet and refer servicing to qualied service
personnel under the following conditions: a) when the
power-supply or plug is damaged; b) if liquid has been
spilled or if objects have fallen into the product; c) if
the product has been exposed to rain or water; d) if
English
the product does not operate normally by following the
operating instructions. Adjust only those controls that
are covered by the operating instructions as improper
adjustment of other controls may result in damage and
will often require extensive work by a qualied technician to restore the product to its normal operation; e)
if the product has been dropped or damaged in any
way; f) when the product exhibits a distinct change in
performance—this indicates a need for service.
Replacement Parts: When replacement parts are re-14.
quired, be sure that your service technician has used
replacement parts specied by the manufacturer or
have the same characteristics as the original part.
Unauthorized substitutions may result in re, electric
shock, or other hazards.
Safety Check: Upon completion of any service or 15.
repairs to this product, ask the service technician to
perform safety checks to ensure that the product is in
proper operating condition.
Heat: The product should be situated away from heat 16.
sources such as radiators, heat registers, stoves, or
other products (including ampliers) that produce
heat.
legal and Trademark notices
Coby and Kyros are trademarks of Coby Electronics Corporation.
Android is a trademark of Google Inc. Use of this trademark is subject
to Google Permissions.
Portions of the artwork used for this package are modications based
on work created and shared by Google and used according to terms
described in the Creative Commons 3.0 Attribution License.
HDMI, the HDMI Logo and High-Denition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
microSDHC is a registered trademark of the SD Card Association.
USB is a registered trademark of USB Implementers Forum, Inc.
YouTube™ is a trademark of Google, Inc.
All other trademarks and logos are property of their respective owners
unless indicated otherwise.
Page 54 Safety Notices
Coby electronics Corp.
1991 Marcus Ave, Suite 301
Lake Success, NY 11042
www.cobyusa.com
www.ecoby.com
Coby is a registered trademark of Coby Electronics Corporation.
Printed in China.
MID7015-4G
IB v1.6a_20101124-3
Loading...
