For series
MID7015-4G
EN
Coby® Kyros™ Internet Tablet
Quick Start Guide ................................................ Page 2
Please read carefully before use
Page 2 Table Of Contents
English
Table of Contents Â
Thank You .....................................................................................................................................4
Package Contents .........................................................................................................................................................4
Features...........................................................................................................................................................................5
GeTTinG To know The MiD7015 ..................................................................................................6
Unit at a Glance ............................................................................................................................................................6
About the Touchscreen ................................................................................................................................................9
Protective Film ...................................................................................................................................................9
Using the Stylus ..................................................................................................................................................9
Touchscreen Actions ........................................................................................................................................9
About the Orientation Sensor .................................................................................................................................... 11
Charging the Tablet .................................................................................................................................................... 11
Inserting a Memory Card ...........................................................................................................................................12
GeTTinG STarTeD .........................................................................................................................13
Turning the Tablet On and Off ..................................................................................................................................13
Turning the Screen On and Off (Standby) ...................................................................................................14
Unlocking the Screen .....................................................................................................................................14
Home Screen at a Glance .........................................................................................................................................15
About Applications .....................................................................................................................................................17
Preinstalled Applications ...............................................................................................................................17
About Menus ................................................................................................................................................................18
About Notications ......................................................................................................................................................20
Page 3 Table Of Contents
English
ConneCTinG To The inTerneT ..................................................................................................21
Requirements ...............................................................................................................................................................21
Connect to a Wi-Fi Network .......................................................................................................................................22
BrowSinG The weB .....................................................................................................................24
ManaGinG appliCaTionS ........................................................................................................27
opTional ConneCTionS ..........................................................................................................30
Connecting to a Computer .......................................................................................................................................30
Connecting to a TV ..................................................................................................................................................... 31
Connecting Headphones ..........................................................................................................................................32
SeTTinG The SYSTeM opTionS ....................................................................................................33
SpeCifiCaTionS ...........................................................................................................................34
SupporT ........................................................................................................................................35
SafeTY noTiCeS ...........................................................................................................................36
Page 4 Thank You
English
Thank You Â
Congratulations on your purchase of a Coby® Kyros™
Internet Tablet. This guide is provided to help you get
started quickly with your player; please read it carefully
and save it for future reference.
For detailed instructions, up-to-date information, and helpful
tips, please visit the Coby website at www.cobyusa.com.
The manual is available for download from the
Coby website as a PDF le.
To view PDF documents, download and install
the free Adobe Acrobat reader from the Adobe
website at www.adobe.com.
package Contents
Please make sure that the items shown below are
included in the package. Should an item be missing,
please contact the local retailer from which you purchased this product.
Coby® Kyros™
Internet Tablet
Protective case
Stylus
This package may contain plastic bags or other
materials that pose a hazard to children. Be
sure to safely dispose of all packing materials
after opening.
USB cable
Professional stereo
earphones
Power adapter
Page 5 Thank You
English
features
Browse the web, watch videos on YouTube, check
e-mail, and more on a generous 7.0” LCD screen
* Requires optional HDMI cable (Type A-to-Type C). 1080p
HD video playback requires a video le encoded at 1080p.
Streaming video quality will be affected by the source, and
the quality and condition of your network connection.
Intuitive touchscreen controls powered by Android
OS
Connect to the Internet wirelessly with high-speed
networking support (Wi-Fi 802.11 b/g)
Plays popular video, music, and photo formats
Connect and enjoy 1080p HD video on your HDTV
via HDMI *
View pages in portrait or landscape with automatic
orientation detection
Download and read thousands of books with the
included Aldiko E-book reader application **
Expandable memory with optional microSD card
Rechargeable lithium-polymer battery
** Reading books in the ePub format requires the included
Aldiko E-book reader application.
Page 6 Getting To Know The Mid7015
English
1 2 3
5 4
Getting to know the MiD7015 Â
unit at a Glance
Name Description
1 Stylus
2 Home key Press to return to the home screen.
3 Menu key Press to view the option menu.
4 Back key Press to return to the previous screen.
5 Touchscreen
LCD
Use the tip of the stylus to make precise selections on the touchscreen.
Press and hold to view a list of
recently used applications; touch an
application in the list to launch it.
Note: When you press the Menu key
from within an application, you will
see the options for that application.
To view the Android system options,
press the Menu key from the home
screen.
If the keyboard is on the screen, press
to close the keyboard.
Display and control screen.
Touch controls are displayed on the
screen. Press (or press and hold) icons
with your nger to control the player.
Page 7 Getting To Know The Mid7015
English
Name Description
6
6 Reset key Press to reset the tablet if it freezes or
otherwise behaves abnormally. (Use
a paperclip or other small object to
gently press this key.)
Page 8 Getting To Know The Mid7015
English
7 USB 2.0 Hi-
7
11
10
12
9
8
8 HDMI jack
9 Headphone
Name Description
Connect to a computer to transfer
speed port
(mini Type C)
jack
data (e.g., music, videos, photos, les)
Connect to a TV or other display.
Audio output connection for headphones.
Note: Speaker output is automatically disabled when headphones are
connected to the player.
10 microSD card
11 Power jack
12 Power key Press to turn the unit on, or to turn
slot
(DC input)
Load external microSD memory cards
here.
Charge and power the MID7015 with
the included power adapter.
the screen on and o.
Press and hold to access the Power
O menu
Page 9 Getting To Know The Mid7015
English
about the Touchscreen
Your tablet comes equipped with an easy-to-use touchscreen which allows access to the tablet’s functions. Use
your nger tip (or a stylus) to touch the area of the screen
where a control icon is displayed. If you touch and hold
the screen, it will register as a continuous button press.
To av oid damaging the screen, do not touch it
with excessive force or with any object other
than your nger or a stylus. For best response,
make sure your hands are clean before using
the touchscreen controls.
Protective Film
A thin lm has been applied to the touchscreen to protect
it during shipping. The protective lm should be removed
before use. To remove it, simply take a corner of the lm
and peel it away from the screen
Using the Stylus
A stylus is included for your convenience. You can use
the tip of the stylus to make precise selections on the
touchscreen.
The stylus is stored in the top left corner of the tablet.
Return the stylus to its storage compartment when it
is not in use.
Touchscreen Actions
You can control the functions of the tablet by using
the touchscreen in combination with the three touch
keys located on the bezel. To control the tablet with the
touchscreen, use your ngertip or stylus to manipulate
icons, buttons, menu items, the onscreen keyboard, and
other items displayed on the screen.
You can perform the following actions on the touchscreen
using your ngertip or stylus.
Touch: To activate an on-screen item (e.g.,
application icons, buttons, menu
items, and the letter/symbols of the
on-screen keyboard), simply touch
them with your ngertip or stylus.
Page 10 Getting To Know The Mid7015
English
Touch and
Hold:
Some on-screen items have an
alternate action if you touch and hold
it (e.g., opening an alternate menu, or
to activate the drag function). To touch
and hold an item, touch the item and
do not lift your ngertip/stylus until the
action occurs.
Drag: Drag an on-screen item to change its
position (e.g., an application icon on
the home screen).
To drag an item, touch and hold it for
a moment, then without lifting your
ngertip/stylus, move your ngertip/
stylus on the screen until the item
reaches its target destination.
Swipe: Swipe up/down on the screen to scroll
through a list. On some screens,
you may be able to swipe left/right to
change the view.
To swipe, touch the screen and then
quickly move your ngertip/stylus
across the screen without lifting your
ngertip/stylus. Do not pause on the
screen with your ngertip/stylus at
the intial point of contact or you may
accidentally drag an item instead.
Double-tap: Quickly tap the screen twice on a
webpage or other application screen to
zoom (the application must support the
double-tap/zoom function). Within the
browser, double-tapping a webpage
section will cause the browser to zoom
and t that section to the width of the
screen.
Page 11 Getting To Know The Mid7015
English
about the orientation Sensor
The tablet contains a sensor that will automatically
change the orientation of most screens as you rotate the
tablet. The sensor works best when the tablet is rotated
perpendicular to the ground (i.e., when the tablet is held
upright and not at on its back).
The orientation sensor can be turned on an off in the
Sound & display settings menu.
Charging the Tablet
The tablet comes with a built-in rechargeable lithiumpolymer battery.
Before using the tablet, the battery should be charged
fully. The Status Indicator will light green when the battery is charged fully.
To charge the battery:
Plug one end of the included power adapter into an 1.
AC 100-240V outlet.
Plug the other end of the included power adapter into 2.
the Power jack on the tablet.
Disconnect the power adapter when the tablet is fully 3.
charged.
The battery used in this device may present a re
or chemical burn if mistreated. Do not disassemble,
incinerate, or heat the device. Do not leave the de-
vice in a place subject to direct sunlight, or in a car
with its windows closed. Do not connect the device
to a power source other than that which is indicated
here or on the label as this may result in the risk of
re or electric shock.
Page 12 Getting To Know The Mid7015
English
inserting a Memory Card
The tablet accepts microSD memory cards. Insert a
memory card into the microSD card slot to:
Increase the memory capacity of your tablet
To release and remove a memory card:
UNMOUNT the memory card.1.
From the home screen, press the a. Menu key, and
then touch Settings to show the settings menu.
Play media les stored on the memory card (e.g.,
music, video, or photo les).
To insert a memory card:
Align the memory card with the card slot. The metal 1.
contacts of the memory card should face up towards
the LCD screen.
Slide the card into the spring-loaded slot. Push the 2.
card in until it clicks into place.
Do not attempt to insert objects other than a
microSD memory card into the card slot. A com-
patible memory card should t easily into the
card slot; if you encounter resistance, check the
alignment of the card. Do not attempt to force
the card in.
Avoid touching the gold contacts of the memory
card.
Touch b. SD card & device storage to show the
SD card & device storage settings.
Touch c. Unmount SD card to prepare the memory
card for safe removal.
Push the card further into the slot until you hear a 2.
click. The card will spring out of the slot.
Grasp the card by its edge to remove it.3.
To avoid damage and data corruption, do not
remove a memory card while data is being being
written to or read from the card. For example, do
not remove a card while playing a music le
stored on the card.
Page 13 Getting Started
English
Getting Started Â
Turning the Tablet on and off
To turn the tablet on:
Press and hold the Power key until the LCD screen
turns on. Wait until the Home screen appears; the
tablet is now ready for use.
To turn the tablet off:
Press and hold the 1. Power key until the Device Options menu appears.
Touch 2. Power off on the screen. A conrmation message will appear.
Touch 3. OK to turn off the tablet.
Page 14 Getting Started
English
Turning the Screen On and Off (Standby)
When the tablet is on, you can turn off the screen to
conserve battery power. Simply press the Power key
once to turn the screen off. Press the Power key again to
turn the screen back on.
To conserve battery power, the screen can be
set to turn off automatically when the tablet is
not in use (between 15 seconds and 30 minutes). This Screen timeout option can be found
in the Sound and display settings menu.
Unlocking the Screen
When the screen turns off, you will have to unlock the
screen when you turn it back on.
To unlock the screen, drag the lock icon across the
screen towards the speaker icon.
Page 15 Getting Started
English
If a password has been set, enter the password to nish
2
3
4
5
1
unlocking the screen. The Screen Unlock password can
be set in the Location and security settings menu.
home Screen at a Glance
The home screen is the starting point for all of the
features of your tablet.
Page 16 Getting Started
English
1 Notication
Name Description
Shows notication icons such as new
bar
messages and alarms; drag the bar
down to the bottom of the screen to
open the full Notications panel. The
right side of the bar also shows status
information such as the time, battery
level, and network signal strength.
Note: You can press the Menu key
and then touch Notications to
open the full Notications panel from
the Home screen.
Name Description
4 Launcher Tab Open the Launcher to view a list of all
applications installed on the tablet.
Touch the Launcher tab to open the
Launcher.
Note: You can swipe left and right to
view additional screens.
5 Icons Touch an icon to open an application
or folder
2 Volume con-
trols
3 Widgets Widgets are small applications that
Touch “–“ to decrease the volume
level. Touch “+” to increase the volume level.
you can use directly from the home
screen. To add widgets to the home
screen, touch and hold an empty
spot on the home screen; the Add
to Home screen menu will appear.
Touch Widgets; then choose a widget
from the menu.
Page 17 Getting Started
English
about applications
To open an application, touch the application icon on the
home screen or in the Launcher.
Preinstalled Applications
Some applications have been installed on your tablet for
your convenience. These applications include:
Launcher screen:
The screen shown above is for illusrative pur-
poses only. Coby reserves the right to modify
and improve the nal list of applications avail-
able on the tablet.
Browse the web.
Check your e-mail.
Alarm Clock View the current time, or set an alarm.
View photos and play videos.
Play music.
Launch the mobile YouTube™ browser
page to watch internet videos.
Page 18 Getting Started
English
Download and read thousands of ebooks. Supports the ePub standard.
about Menus
There are two types of menus used by the tablet.
Browse for, download, and install applications from the AppsLib store.
You can also download an install additional applications
from AppsLib, the web browser, or other sources.
The tablet must be set to allow installation of applcations
from non-Market sources. The Unknown sources option
can be set in the Application settings menu.
Support for third-party applications is provided b y
their respective applications developers. Coby is
not responsible for the behavior of these applications; please review the description and terms of
use provided by third-party developers carefully
before installing applications on your tablet.
Option menus. 1.
Option menus contain items related to the
current screen or application. To view an option
menu, press the Menu key.
Not all screens or applications have an option
menu; if a menu does not exist, nothing will
happen if you press the Menu key.
Page 19 Getting Started
English
Context menus.2.
Context menus contain items related to a specic item on
the screen. To view a context menu, touch and hold an
item on the screen.
A context menu will appear.
Touch & hold All pictures.
Not all items have a context menu; if a menu
does not exist, nothing will happen if you touch
and hold the item.
Page 20 Getting Started
English
About Notications
The icons that appear in the Notication bar at the top
of the screen alerts you when new messages arrive or
alarms or other application events occur.
To respond to a notication:1.
Touch a notication in the list; the Notications panel will
close and the application associated with the notication
will launch.
View and respond to the notications by opening the full
Notications panel.
Drag the Notication bar down to the bottom of
the screen to open the Notications panel from any
screen, or;
On the Home screen, press the Menu key and then
touch Notications to open the Notications panel.
To clear all notications:2.
Touch the Clear button at the top right of the Notications
panel; the panel will close and all notications will be
cleared.
To close the Notications panel:3.
Drag the handle at the bottom of the Notications
panel to the top of the screen, or;
Press the Back key.
Page 21 Connecting To The Internet
English
Connecting to the internet Â
This tablet can utilize Wi-Fi data networks to connect to the Internet. Wireless Wi-Fi technology can provide Internet access
at distances of over 300 feet; however, this distance can be affected by y our surrounding environment and Wi-Fi router.
requirements
In order to connect to the Internet, you will need the
following:
A wireless router or access point with a broad-1.
band Internet connection
The wireless router must support Wi-Fi 802.11b/ g connections. If the router supports 802.11n, make sure that it has
been congured to accept 802.11b/g connections as well.
A minimum connection speed of 64 Kbps is
recommended. Faster speeds will enable a
better Internet experience.
The wireless router network settings2.
You will need to know the name of your network (SSID),
as well as the password or other credentials if your
network is secured. These settings can usually be found
on the administration webpage of your wireless router.
Please refer to your wireless router’s documentation for
help, or ask your network administrator for details.
You may encounter open Wi-Fi networks, or
“hotspots.” These networks are usually congured so that you can simply connect to them
without needing to know its settings; the tablet
will obtain all the information it needs from the
router automatically.
Page 22 Connecting To The Internet
English
Connect to a wi-fi network
The Notication bar displays icons that indicate your
tablet’s Wi-Fi status.
Notication that an open Wi-Fi network is in
range.
Connected to a Wi-Fi network (waves
indicate connection strength).
Make sure that the Wi-Fi option box is checked: e.
Touch Wi-Fi.
[no icon]
1. Turn on the Wi-Fi radio if it is not already on. To
turn on Wi-Fi:
There are no Wi-Fi networks in range, or the
Wi-Fi radio is off.
Go to the Home screen: a.
Press the Home key.
Open the Settings menu: b.
Press the Menu key, then touch Settings.
Open the Wireless & networks menu: c.
Touch Wireless & networks.
Open the Wi-Fi settings menu: d.
Touch Wi-Fi settings.
When Wi-Fi is on, the tablet will look for and display a list
of available Wi-Fi networks.
If a network that you have connected to previ-
ously is found, the tablet will connect to it.
If you don’t see your network in the list, you
can force the tablet to re-scan. To scan for
networks, press the Menu key, and then touch
Scan.
Page 23 Connecting To The Internet
English
2. Select an available Wi-Fi network to connect to:
In the same Wi-Fi settings menu above, touch a network
in the list.
If the network is open, the tablet will prompt you to
conm connection to the network. Touch Connect to
conrm.
If the network is secured (as indicated by a Lock
icon), the tablet will prompt you to enter a password
or other credentials. Touch the Wireless password
box to show the on-screen keyboard and then use it
to enter the password. Touch Connect to conrm.
When you have successfully connected to a Wi-Fi
network, the Notications bar at the top of the screen will
show a Wi-Fi signal indicator.
To learn about how to add a Wi-Fi network
when it is not in range or when the router is
set to obscure the network name (SSID); or to
congure advanced Wi-Fi options, please refer
to the manual.
Page 24 Browsing The Web
English
Browsing the web Â
1
2
The Browser application lets you visit webpages and nd information on the web. Keep up with the news, your friends, or
enjoy video from YouTube ™, the world’s most popular video-sharing community.
To use Browser, the tablet must be
connected to the Internet. Read the
section “Connecting to the Internet” to
learn how to connect to the Internet.
To open Browser, touch the Browser
icon on the Home screen or in the
Launcher.
Name Description
1 Address bar Displays the address (URL) of the
2 Bookmark
icon
current page. Touch the bar to enter a
new address or to search the web.
Touch the Bookmark icon to add or
view bookmarks, to view your most
visited sites, or to view your browser
history.
Page 25 Browsing The Web
English
Some common Browser actions are described below.
To go to a webpage.
To bookmark a webpage.
Bookmark your favorite webpages in order to visit
them quickly without entering a URL.
1. Touch the Address
bar at the top of
the Browser screen.
The keyboard will
open automatically.
(If the Address bar
is not visible, drag
the page down to
return to the top of
the Browser screen.)
2. Use the keyboard
to enter the address (URL) of the
webpage (e.g.,
m.youtube.com.
3. Touch Go to open
the webpage.
1. Go to the webpage
that you want to
bookmark
2. Touch the
Bookmark icon to
the right of the Address bar.
3. Touch the Add tile.
Page 26 Browsing The Web
English
4. If desired, you can
modify the name
of the bookmark
or its location (URL
address). Otherwise,
touch OK to nish
adding the bookmark.
To open a new browser window.
1. Press the Menu key
to show the Browser
options.
2. Touch New Win-
dow to open a new
browser window.
To switch between browser windows.
To go to a bookmarked webpage.
1. Touch the Bookmark icon to the
right of the Address
bar.
1. Press the Menu key
to show the Browser
options.
2. Touch Windows to
show a list of open
browser windows.
2. Touch a bookmark
tile to open it.
3. Touch the name of a
window to switch to
it, or touch the “x” to
close the window.
Page 27 Managing Applications
English
Managing applications Â
Downloading and installing new applications to your tablet can extend its functionality in many wa ys.
You can download and install applications from the
included AppsLib store. To open the AppsLib store:
Touch the
1. Launcher icon.
Touch the 2. AppsLib icon.
When installing an application, it will tell you what functions of the phone it needs to control and if it needs
access to your data. Make sure you review these access
requirements carefully before completing the installation.
Be especially cautious with applications that
request access to many functions or to a signicant amount of your data. You are responsible for the results of applications installed on
your tablet.
Page 28 Managing Applications
English
You can learn more about AppsLib, and browse applications by visiting their website at www.appslib.com.
Some developers allow you to download and
install applications directly from their website.
Support for third-party applications is provided b y
the respective application developer. Coby is not
responsible for the behavior of these applications;
please review the description and terms of use
provided by third-party developers carefully be-
fore installing applications on your tablet.
To uninstall an application:
From the Home screen, 1. press the Menu key.
Touch 2. Settings to open the Settings menu.
Touch 3. Applications, and then touch Manage ap-
plications to show a list of all applications installed
on the tablet.
Page 29 Managing Applications
English
Touch the name of the application you want to 4.
uninstall; the Application Info screen will open.
Touch 5. Uninstall. The tablet will prompt you to
conrm.
Touch 6. OK to uninstall the application.
Page 30 Optional Connections
English
optional Connections Â
Connecting to a Computer
Connect the tablet to a computer to transfer les.
Connect your tablet to the computer.1.
With the included USB cable:
Plug the small end of the cable into the USB 2.0 Hi-
speed connector of the tablet.
Plug the large end of the cable into an available USB
2.0 Hi-speed port on the computer.
When your tablet is connected, a USB icon will
2.
appear in the Notication bar.
Drag the Notication bar down to open the notications
panel.
Page 31 Optional Connections
English
Mount the storage drive.3.
Touch USB connected (Internal) to mount the tablet’s
built-in storage, then touch Mount when prompted to
conrm. When mounted, you can copy les to/from
your computer to it.
If a memory card is installed, touch USB connected
(External) to mount the card, then touch Mount when
prompted to conrm. When mounted, you can copy
les to/from the computer to it.
Your tablet will be recognized by the computer as a
Removable Storage drive. Drag and drop les between
your tablet and the computer. To learn more about copy-
ing les, please refer to the documentation included with
your computer or operating system.
Connecting to a TV
Connect to a TV to enjoy your tablet from the comfort of
your living room. An HDMI cable (Type A-to-Type C) is
required to connect the tablet to a TV.
Before connecting the tablet to the TV, you will have to
adjust a few display settings on the tablet.
Make sure that the tablet is set to output over HDMI
For optimal visual performance, make sure that the
video output resolution of your tablet matches the
capabilities of the TV.
To adjust the display settings:
From the home screen, press the 1. Menu key, and
then touch Settings to show the settings menu.
Touch 2. Sound & display to show the Sound & display
settings.
Touch 3. Output Select, and then touch HDMI to enable video output from the tablet’s HDMI connector.
Page 32 Optional Connections
English
Touch 4. HDMI Setting, and then touch a resolution
option that matches the display capabilities of the TV:
Choose a. 1920 x 1080p 60Hz if your TV is capable
of displaying 1080p video.
Choose b. 1280 x 720p 60Hz if your TV is capable
of displaying 720p or 1080i video.
Connecting headphones
Connect a pair of headphones (or earphones) to the
tablet to enjoy media in private.
Lower the volume level of the tablet before connecting
headphones, and then slowly raise the volume to a
comfortable listening level.
To connect the tablet to the TV:
Plug the small end of the HDMI cable into the mini 1.
HDMI connector of the tablet
Plug the large end of the HDMI cable into the HDMI 2.
port on the TV.
Turn on the TV, and set its display mode to the HDMI 3.
port that the tablet is connected to.
The tablet’s display will be output to the TV screen.
If you need help setting the display mode of the
TV, please refer to the documentation provided
by the TV manufacturer.
The headphones must have a 3.5 mm (1/8 in) plug.
When headphones are connected, speaker output
will be disabled automatically.
Hearing experts advise against the constant
use of personal stereos played at high volume.
Constant exposure to high volumes can lead to
hearing loss. If you should experience ringing
in the ears or hearing loss, discontinue use and
seek medical advice.
Page 33 Setting The System Options
English
Setting the System options Â
Open the system settings menu to adjust how the tablet
looks and functions.
Many applications will have their own settings;
refer to the documentation provided by the ap-
plication developer to learn more.
To open the Settings menu:
From the Home screen, press the 1. Menu key.
Touch 2. Settings to open the Settings menu.
The settings are grouped by category. Touch a category
to open and adjust its settings.
Please refer to the manual for a description of
the items in the Settings menu.
Page 34 Specications
English
Specications Â
Please visit www.cobyusa.com for the latest product information. Design, specications, and manual are subject to
change without notice.
Processor ARM1176™ (800 MHz)
RAM 256 MB DDR2
Storage 4 GB ash built-in
microSD card slot (max. 16GB supported)
Display 7.0” touchscreen
TFT LCD (800 x 480)
Wi-Fi Networking IEEE 802.11 b/g
Video Output Mini HDMI, type C
(1080p and 720p supported)
Audio Output 3.5 mm headphone
PC Interface USB 2.0 Hi-speed
Additional
Features
Operating System Android™ 2.1
Power Rechargeable Li-poly battery
Built-in microphone
Built-in speaker
Power Adapter (DC 5V, 2A)
Page 35 Support
English
Support Â
If you have a problem with this device, please check our website at www.cobyusa.com for Frequently Asked Questions
(FA Q) and product updates. If these resources do not resolve the problem, please contact Technical Support.
Coby electronics Technical Support
Email techsupport@cobyusa.com
Web www.cobyusa.com
Phone 877-302-2629
Monday to Friday, 9:00AM–9:00PM EST
Page 36 Safety Notices
English
Safety notices Â
The lightning ash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufcient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operation and servicing instructions in the
literature accompanying the appliance.
For recycling or disposal information about this
product, please contact your local authorities or
the Electronics Industries Alliance: www.eiae.org.
For Customer Use:
Enter below the serial number that is located on the rear of the
unit. Retain this information for future reference.
Model No.
Serial No.
WARNING: To prevent re or shock hazard, do not expose this
device to rain or moisture. Dangerous high voltage is present inside
the enclosure. Do not open the cabinet.
Protect your hearing: Hearing experts advise against the con-
stant use of personal stereos played at high volume. Constant exposure
to high volumes can lead to hearing loss. If you should experience
ringing in the ears or hearing loss, discontinue use and seek medical
advice.
Note: If the product suddenly has no response or powers off, an elec-
trostatic discharge may be the cause. In this circumstance, please
follow the procedures below for recovery:
Reset the player (use a paper clip to gently press the Reset button •
on the bottom of the player).
Turn on the unit again•
Page 37 Safety Notices
English
fCC Statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.•
Consult the dealer or an experienced radio/TV technician for help•
Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15 of the FCC rules.
Do not make any changes or modications to the equipment unless otherwise specied in the manual. If such changes or modications should
be made, you could be required to stop operation of the equipment.
Page 38 Safety Notices
English
important Safety instructions
Read Instructions: All the safety and operating instruc-1.
tions should be read before the product is operated.
Retain Instructions: The safety and operating instruc-2.
tions should be retained for future reference.
Heed Warnings: All warnings on the product and in 3.
the operating instructions should be adhered to.
Follow Instructions: All operating and usage instruc-4.
tions should be followed.
Cleaning: Unplug this product from the wall outlet be-5.
fore cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
Attachments: Use only attachments recommended by 6.
the manufacturer. Use of other attachments may be
hazardous.
Water and Moisture: Do not use this product near 7.
water (e.g., near a bath tub, washbowl, kitchen sink,
laundry tub, in wet basements, or near a swimming
pool and the like).
Ventilation: Slots and openings in the cabinet are 8.
provided for ventilation to ensure reliable operation of
the product and to protect it from overheating. These
openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventila-
tion is provided or the manufacturer instructions have
been adhered to.
Power Sources: This product should be operated only
9.
from the type of power source indicated on the rating
label. If you are not sure of the type of power supply to
your home, consult your product dealer or local power
company. For products intended to operate from battery power or other sources, refer to the operating
instructions.
Overloading: Do not overload wall outlets, extension 10.
cords, or integral convenience receptacles as this can
result in a risk of re or electric shock.
Object and Liquid Entry: Never push objects of any 11.
kind into this product through openings as they may
touch dangerous voltage points or shout-out parts that
could result in a re or electric shock. Never spill liquid
of any kind on the product.
Servicing: Do not attempt to service this product your-12.
self as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servic-
ing to qualied service personnel.
Damage Requiring Service: Unplug this product from 13.
the wall outlet and refer servicing to qualied service
personnel under the following conditions: a) when the
power-supply or plug is damaged; b) if liquid has been
spilled or if objects have fallen into the product; c) if
the product has been exposed to rain or water; d) if
Page 39 Safety Notices
English
the product does not operate normally by following the
operating instructions. Adjust only those controls that
are covered by the operating instructions as improper
adjustment of other controls may result in damage and
will often require extensive work by a qualied technician to restore the product to its normal operation; e)
if the product has been dropped or damaged in any
way; f) when the product exhibits a distinct change in
performance—this indicates a need for service.
Replacement Parts: When replacement parts are re-14.
quired, be sure that your service technician has used
replacement parts specied by the manufacturer or
have the same characteristics as the original part.
Unauthorized substitutions may result in re, electric
shock, or other hazards.
Safety Check: Upon completion of any service or 15.
repairs to this product, ask the service technician to
perform safety checks to ensure that the product is in
proper operating condition.
Heat: The product should be situated away from heat 16.
sources such as radiators, heat registers, stoves, or
other products (including ampliers) that produce
heat.
legal and Trademark notices
Coby and Kyros are trademarks of Coby Electronics Corporation.
Android is a trademark of Google Inc. Use of this trademark is subject
to Google Permissions.
Portions of the artwork used for this package are modications based
on work created and shared by Google and used according to terms
described in the Creative Commons 3.0 Attribution License.
HDMI, the HDMI Logo and High-Denition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
microSD is a registered trademark of the SD Card Association.
USB is a registered trademark of USB Implementers Forum, Inc.
YouTube™ is a trademark of Google, Inc.
All other trademarks and logos are property of their respective owners
unless indicated otherwise.
Coby electronics Corp.
1991 Marcus Ave, Suite 301
Lake Success, NY 11042
www.cobyusa.com
www.ecoby.com
Coby is a registered trademark of Coby Electronics Corporation.
Printed in China.
MID7015-4G
ESG v1.01
Loading...
