Page 1
DP-758
7” Widescreen Color TFT LCD Digital Photo Frame
INSTRUCTION MANUAL
Please read this manual carefully before operation
Page 2
Precautions
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufcient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operation and servicing
instructions in the literature acc ompanying the appliance.
For Custom er Use:
Enter below the serial number that is located on the bot tom of
the unit. Retain this info rmation for future reference.
Model N o. DP-758
Serial N o.
For recycling or disposal information about this product,
please contact your local authorities or the Electronics Industries Alliance: www.eiae.org.
Page 2 Coby Electronics Corporation
Page 3
Precautions
WARNING:
To prevent re or shock hazard, do not expose this device to rain or moisture. Dangerous high
voltage is present inside the enclosure. Do not open the cabinet.
CAUTION:
To prevent electric shock, match wide blade of plug to wide slot of outlet and fully insert.
Page 4
Important Safety Instructions
Read Instructions: A ll the safet y and operating instructions should be read before the
1.
product is operated.
Retain Instructions: The safety and operating instr uctions should be retained for future
2.
reference.
Heed Warnings: All warnings on the product and in the operating instructions should
3.
be adhered to.
Follow Instructions: All operating and usage instructions should be followed.
4.
Cleaning: Unplug this product from the wall outlet before cleaning. Do not use liquid
5.
cleaner s or aerosol cleaners. Use a damp cloth for cleaning.
Attachments: Use only attachments recommended by the manufacturer. Use of other
6.
attachments may be hazardous.
Water and Moisture: Do not use this product near water (e.g., near a bath tub, washbowl,
7.
kitchen sink, laundry tub, in wet basements, or near a swimming pool and the like).
Accessories: Do not place this product on an unstable car t, stand, tripod, bracket, or
8.
table. Use only with carts, stands, tripods, brackets, or tables recommended by the
manufacturer or sold with the product. Any mounting of the product should follow the
manufacturer’s instructions and should use a mounting accessory recommended by
the manufacturer.
A product and car t combination should be moved with care. Quick stops,
9.
excessive force, and uneven sur faces may cause the product and cart
combination to over turn.
Ventilation: Slots and openings in the cabinet are provided for ventilation
10.
to ensure reliable operation of the product and to protect it from over heating. These openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar sur face. This product should not be placed in a built-in installation
such as a bookcase or rack unless proper ventilation is provided or the manufacturer
instructions have been adhered to.
Power Sourc es: This product should be operated only from the type of power source
11.
indicated on the rating label. If you are not sure of the type of power supply to your home,
consult your product dealer or local power company. For products intended to operate
from battery power or other sources, refer to the operating instructions.
Grounding or Polar ization: This product may be equipped with a polarized alternating-
12.
current line plug that has one blade wider than the other. This plug will only t into the
power outlet in one direction. This is a safet y feature. If you are unable to inser t the plug
fully into the outlet, tr y reversing the direction of the plug. If the plug should still fail to t,
contact an electrician to replace the obsolete outlet. Do not defeat the safety purpose
of the polarized plug.
Power-Cord Protection: Power supply cords should be routed so that they are not likely
13.
to be walked on or pinched by items placed upon or against them, paying particular
attention to cords at plugs, convenienc e receptacles, and at the point which they exit
from the product.
Page 4 Coby Electronics Corporation
Page 5
Important Safety Instructions
Protective Attachment Plug: The product may be equipped with an attachment plug with
14.
overload protection. This is a safety feature. See the operating instructions for replacement or directions to reset the protective device. If replacement of the plug is required,
be sure the ser vice technician has used a replacement plug that has the same overload
protection as the original plug as specied by the manufacturer.
Outdoor Antenna Grounding: If an outside antenna is connected to the product, be sure
15.
the antenna system is grounded so as to provide some protection against voltage surges
and built-up static charges. Article 810 of the National Electrical Code, ANS/NFPA
70 provides information with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna- discharge unit, size of grounding
conductors, location of antenna- discharge unit, connec tion to grounding electrodes,
and requirements for the grounding electrode (see gure).
Lightning: For added protection for this product, unplug it from the wall outlet and discon-
16.
nect the antenna or cable system dur ing a lightning storm or when it is left unattended
and unused for long periods of time. This will prevent damage to the product due to
lightning or power-line surges.
Power Lines: An outside antenna system should not be located in the vicinit y of over-
17.
head power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme care should
be taken to keep from touching such power lines or circuits, as contact with them might
be fatal.
Overloading: Do not overload wall outlets, extension cords, or integral convenience
18.
receptacles as this can result in a risk of re or electric shock.
Page 6
Important Safety Instructions
Object and Liquid Entry: Never push objects of any kind into this product through open-
19.
ings as they may touch dangerous voltage points or shout-out par ts that could result in
a re or elec tric shock. Never spill liquid of any kind on the product.
Servicing: Do not attempt to service this product yourself as opening or removing covers
20.
may expose you to dangerous voltage or other hazards. Refer all servicing to qualied
service personnel.
Damage Requiring Service: Unplug this produc t from the wall outlet and refer servicing
21.
to qualied ser vice personnel under the following conditions: a) when the power-supply
or plug is damaged; b) if liquid has been spilled or if objects have fallen into the product;
c) if the product has been exposed to rain or water; d) if the product does not operate
normally by following the operating instructions. Adjust only those controls that are covered by the operating instr uctions as improper adjustment of other c ontrols may result
in damage and will of ten require ex tensive work by a qualied technician to restore the
product to its normal operation; e) if the product has been dropped or damaged in any
way; f) when the product exhibits a distinct change in performance—this indicates a
need for service.
Replacement Par ts: When replacement par ts are required, be sure that your ser vice
22.
technician has used replacement par ts specied by the manufacturer or have the same
characteristics as the original part. Unauthor ized substitutions may result in re, electric
shock, or other haz ards.
Safety Check: Upon completion of any ser vice or repairs to this product, ask the ser vice
23.
technician to perform safet y checks to ensure that the product is in proper operating
condition.
Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as
24.
recommended by the manufacturer.
Heat: The product should be situated away from heat sources such as radiators, heat
25.
register s, stoves, or other products (including ampliers) that produce heat.
Page 6 Coby Electronics Corporation
Page 7
Table of Contents
PRECAUTIONS .....................................................................................2
IMPORTANT SAFETY INSTRUCTIONS ...................................................4
TABLE OF CONTENTS ...........................................................................7
PACKAGE CONTENTS & FEATURES ..................................................... 9
Package Contents ............................................................................................... 9
Features ..............................................................................................................9
LOCATION OF CONTROLS ................................................................10
Top View ............................................................................................................10
Left View ........................................................................................................... 10
Front View .........................................................................................................10
Right View .........................................................................................................10
GETTING STARTED ............................................................................. 11
Installing a Memory Card .................................................................................. 11
Powering your Digital Picture Frame ................................................................11
Item List Screen ................................................................................................ 12
Select Card Screen ........................................................................................... 13
Photo Slideshow ...............................................................................................13
To View Next / Previous Photo .........................................................................13
PHOTO MODE .................................................................................... 13
To Rotate the Photo / Change the screen ratio ................................................14
Calendar with Time Screen ..............................................................................15
CLOCK MODE ................................................................................... 15
SETUP MODE ...................................................................................... 16
Setup Screen ....................................................................................................16
To adjust the Picture/Clock/LCD settings & Reset ........................................... 16
SETUP MODE ...................................................................................... 17
INTERCHANGEABLE FACEPLATES ..................................................... 18
Page 8
Table of Contents
FIRMWARE UPGRADES ...................................................................... 19
TROUBLESHOOTING ..........................................................................20
SPECIFICATIONS ...............................................................................22
NOTES ................................................................................................23
Page 8 Coby Electronics Corporation
Page 9
Package Contents & Features
Package Contents
Please make sure that the items shown below are included in the package. Should
an item be missing, please contact the local retailer from which you purchased this
product.
Features
7” Widescreen TFT LCD Color
•
Screen
Displays JPEG Photo Files
•
MS and SD/MMC Card Slots
•
USB Port for Fast File Transfers
•
Interchangeable Faceplate
•
Detachable Stand
•
Wall Mountable
•
Page 10
Top View
1.
Menu
Press for exit
2.
Enter/Slideshow
Press for Enter
Press for Slideshow
Down
3.
Up
4.
Left
5.
Press for Left during
selecting
Press for rotating
(In Photo Mode)
Location of Controls
Right
6.
Press for Right during
selecting
Press for Full screen /
Original screen
(In Photo Mode)
Left View
Memor y Stick (MS)
7.
Secure Digital (SD) /
8.
Multi Media Card (M MC)
USB Port (connect to a
9.
computer)
Front View
10.
Right View
11.
12.
13.
7” TFT LCD
Power Switch (On / Off)
Power In Jack
Detachable Kickstand
Page 10 Coby Electronics Corporation
Page 11
Getting Started
Installing a Memory Card
Your photo frame suppor ts the following types of memory cards:
Compact Flash cards (CF)
•
Secure Digital cards (SD)
•
MultiMedia Card (MMC)
•
Simply insert the memory card of your choice into its corresponding card slot located on the left panel of the photo frame. Take care to orient the card in the proper
direction.
Getting photos and les onto your picture frame for viewing couldn’t be easier!
Powering your Digital Picture Frame
Your Photo Frame should be connected to
an AC 100-240V wall outlet.
Using the supplied power adapter,
•
plug one end of the adapter into
your photo frame’s Power In Jack
and plug the other end into an AC
100-240V wall outlet.
Do not connect the power plug to a power outlet other than that
which is indicated here or on the label as this may result in the risk
of re or electric shock.
Do not handle the power plug with wet hands. Doing so may cause
Use only the AC adapter supplied with the photo frame. Failure to
electric shock.
do so may cause a re or damage the player.
Page 12
Getting Started
Item List Screen
Upon turning on the power, your photo frame will display the “ITEM LIST” screen
show below.
Page 12 Coby Electronics Corporation
Page 13
Photo Mode
Select Card Screen
Insert MS or SD/MMC card to the corresponding slot.
•
Select PHOTO in Item List screen and press ENTER, the
•
“Select Card” screen appears on LCD shown below.
Selecting: A card icon that is in-color with highlighted frame indicates that
Inser ted: A card icon that is in-color indicates that the card has been
inserted.
No Card: A card icon that is grayed-out indicates that the card has not
been installed for use.
Photo Slideshow
Press or to select the desired inser ted card.
•
Press ENTER to start playing Photo slideshow.
•
To View Next / Previous Photo
In slideshow mode, press ENTER for “SINGLE SHOW”.
•
Press to view the next photo.
•
Press to view the previous photo.
•
the card is being selected.
Page 14
Photo Mode
To Rotate the Photo / Change the screen ratio
Press to rotate the photo to angles shown below:
Rotation 90° → Rotation 180° → Rotation 270° → Original
•
Press to toggle the screen ratio between Full Screen and Original.
•
To adjust the photo slideshow speed to Fast / Middle / Slow, please
turn to Setup section.
Page 14 Coby Electronics Corporation
Page 15
Clock Mode
Calendar with Time Screen
Insert MS or SD/MMC card to the corresponding slot.
•
Select CLOCK on Item List screen and press ENTER, the “Calendar with
•
Time” screen appears on LCD shown below.
Press / to select a year number, repeatedly press this button will
•
increase / decrease the number of years.
Press / to select a month number, repeatedly press this button will
•
decrease / increase the number of months.
To adjust the time and day, please turn to Setup section.
•
NOTE: This Digital Photo Frame has no ash memor y, so date and time re-
quire adjusting manually after turning on the player.
Page 16
Setup Mode
Setup Screen
Insert MS or SD/MMC card to the corresponding slot.
•
Select SETUP on Item List screen and press ENTER, the SETUP screen
•
appears on LCD shown below.
To adjust the Picture/Clock/LCD settings & Reset
Press / to select Picture/Clock /LCD/System in Setup List.
•
Press ENTER to select the sub-settings.
•
Picture:
Use to select the desired item.
•
Press MENU to go back to Setup List.
Clock:
Press / to move cursor between time and date, and press /
•
to adjust the time and date which will be displayed on Clock screen before
turning off the player.
Press ENTER to conrm the Selection.
•
Page 16 Coby Electronics Corporation
Page 17
Setup Mode
LCD:
Press / to select different items.
•
Press / to adjust the values and press ENTER to conrm.
•
System Reset
Press / to select Ok/Cancel and press ENTER to conrm.
•
Page 18
Interchangeable Faceplates
To afx a faceplate to your photo frame:
Attach the faceplate to the main unit and rotate
1.
the clips in the direction of the arrows at a +/-90°
angle.
Now it has been afxed to the surface of the
2.
photo frame.
To detach the faceplate from your photo frame.
Rotate the clips in the direction of the arrows at a +/-90° angle.
1.
Simply remove the main unit from the faceplate, the faceplate has been
2.
detached.
Page 18 Coby Electronics Corporation
Page 19
Firmware Upgrades
From time to time, COBY may release rmware updates to improve the performance of the DP-758 or to add additional features. Please check the COBY web site periodically at www.cobyusa.com to see if new rmware has been released for
your photo frame.
Page 20
Troubleshooting
If you have a problem with this unit, please read the troubleshooting guide below
and check our website at www.cobyusa.com for Frequently Asked Questions
(FAQs) and rmware updates. If these resources do not resolve the problem,
please contact Technical Support.
COBY Electronics Technical Suppor t
56- 65 Rust Street
Maspeth, NY 11378
Email: techsupport@cobyusa.com
Web: www.cobyusa.com
Phone: 800-727-3592 (8:00 AM –11:00 PM EST, seven days a week)
The player does not turn on.
•
•
I cannot select a memory card.
•
•
•
The picture is noisy or distorted.
•
•
Page 20 Coby Electronics Corporation
800-681-2629 (8:00 AM– 5:30 PM EST, Monday to Friday)
718-416-3197 (8:00 AM–5:30 PM EST, Monday to Friday)
Make sure the unit has been powered on manually (i.e., the Power Switch has
been physically set to the ON position).
Ensure that the power cord has been properly connected to the power outlet.
Ensure that a memory card has been installed.
Ensure that the memory card is properly installed.
Ensure that the memory card is not defective.
Reset the color system of the T V set.
Ensure that the photo frame is connected using the RCA AV cable.
Page 21
Troubleshooting
The photo frame has malfunctioned.
Turn the photo frame off and let it rest for 30 minutes. After that, turn on the
•
photo frame -- the restore function should reset the photo frame.
Try updating the player’s rmware. Please refer to the Firmware Upgrade
•
section of this manual for detailed instructions.
Page 22
Specications
Display Type 7” Full-Color TFT LCD
Display Resolution 480 x 3 (RGB) x 234
Memory MS Card Slot
SD/MMC Card Slot
Photo Format Support JPEG (8MB)
USB Port USB 2.0 High-Speed
Power Supply DC 12V, 1A
Specications and manual are subject to change without prior notice.
100-240V AC Adapter
Page 22 Coby Electronics Corporation
Page 23
Notes
Page 24
COBY Electronics Corp.
56- 65 Rust Street
Maspeth, NY 11378
ww w.cobyusa.com
ww w.ecoby.com
Loading...
