INSTRUCTION MANUAL
Please read this manual carefully before operation.
CX-CD397
Micro CD/MP3 Player Stereo System with
AM/FM Tuner, SD Card Slot, and USB Port
Page 2 Coby Electronics Corporation
www.cobyusa.com Page 3
PRECAUTIONS
The lightning ash with arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of sufcient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operation and servicing instructions in the literature accompanying the appliance.
WARNING:
To prevent re or shock hazard, do not expose this device to rain or moisture. Dangerous high
voltage is present inside the enclosure. Do not open the cabinet.
CAUTION:
To prevent electric shock, match wide blade of plug to wide slot of outlet and fully insert.
WARNING:
Handling the cords on this product will expose you to lead, a chemical known to the State
of California to cause cancer, and birth defects or other reproductive harm. Wash hands
after handling.
PROTECT YOUR HEARING:
Hearing experts advise against the constant use of personal stereos played at high
volume. Constant exposure to high volumes can lead to hearing loss. If you should
experience ringing in the ears or hearing loss, discontinue use and seek medical advice.
For Customer Use:
Enter below the serial number that is located on the unit. Retain this information for
future reference.
Model No. CX-CD397
Serial No.
www.cobyusa.com Page 3
ON PROTECTION AGAINST LASER ENERGY EXPOSURE
As the laser beam used in this compact disc player is harmful to the eyes, do not attempt
to disassemble the casing.
Stop operation immediately if any liquid or solid object should fall into the cabinet.
Do not put anything in the safety slot. If you do, the laser diode will be ON when the CD
door is still open.
If the unit is not to be used for a long period of time, make sure that all power sources
are disconnected from the unit. Remove all batteries from the battery compartment, and
unplug the AC-DC adapter from the wall outlet. Make it a practice to remove the AC-DC
adapter by grasping the main body and not by pulling the cord.
This unit employs a laser. The use of controls or adjustment or performance of procedures other than those specied here may result in exposure to hazardous radiation.
ON PLACEMENT
Do not use the unit in places which are extremely hot, cold, dusty, or humid.
Place the unit on a at and even surface.
Do not restrict the air ow of the unit by placing it in a place with poor ventilation, by
covering it with a cloth, or by placing it on a carpet.
ON CONDENSATION
When left in a heated room where it is warm and damp, water droplets or condensation
may form inside the unit.
When there is condensation inside the unit, the unit may not function normally.
Let the unit stand 1 to 2 hours before turning the power on, or gradually heat the room up
and dry the unit before use.
Should any trouble occur, remove the power source and refer servicing to qualied personnel.
For recycling or disposal information about this product, please contact your local
authorities or the Electronics Industries Alliance: www.eiae.org.
PRECAUTIONS
Page 4 Coby Electronics Corporation
www.cobyusa.com Page 5
IMPORTANT SAFETY INSTRUCTIONS
Read Instructions: All the safety and operating instructions should
be read before the product is operated.
Retain Instructions: The safety and operating instructions should be
retained for future reference.
Heed Warnings: All warnings on the product and in the operating
instructions should be adhered to.
Follow Instructions: All operating and usage instructions should be
followed.
Cleaning: Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
Attachments: Use only attachments recommended by the manufacturer. Use of other attachments may be hazardous.
Water and Moisture: Do not use this product near water (e.g., near
a bath tub, washbowl, kitchen sink, laundry tub, in wet basements, or
near a swimming pool and the like).
Accessories: Do not place this product on an
unstable cart, stand, tripod, bracket, or table.
Use only with carts, stands, tripods, brackets,
or tables recommended by the manufacturer
or sold with the product. Any mounting of
the product should follow the manufacturer’s
instructions and should use a mounting accessory recommended by the manufacturer.
A product and cart combination should be
moved with care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to overturn.
Ventilation: Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the product and to protect it
from overheating. These openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer instructions have been adhered to.
Power Sources: This product should be operated only from the type
of power source indicated on the rating label. If you are not sure of
the type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
www.cobyusa.com Page 5
Grounding or Polarization: This product may be equipped with a
polarized alternating-current line plug that has one blade wider than
the other. This plug will only t into the power outlet in one direction.
This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the direction of the plug. If the plug should still
fail to t, contact an electrician to replace the obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
Power-Cord Protection: Power supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and at the point which they exit from the
product.
Protective Attachment Plug: The product may be equipped with an
attachment plug with overload protection. This is a safety feature. See
the operating instructions for replacement or directions to reset the
protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same
overload protection as the original plug as specied by the manufacturer.
Outdoor Antenna Grounding: If an outside antenna is connected to
the product, be sure the antenna system is grounded so as to provide
some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANS/NFPA 70 provides
information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge
unit, size of grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the ground-
ing electrode (see gure).
12.
13.
14.
15.
IMPORTANT SAFETY INSTRUCTIONS
Page 6 Coby Electronics Corporation
www.cobyusa.com Page 7
Lightning: For added protection for this product, unplug it from the
wall outlet and disconnect the antenna or cable system during a lightning storm or when it is left unattended and unused for long periods
of time. This will prevent damage to the product due to lightning or
power-line surges.
Power Lines: An outside antenna system should not be located in
the vicinity of overhead power lines or other electric light or power
circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken
to keep from touching such power lines or circuits, as contact with
them might be fatal.
Overloading: Do not overload wall outlets, extension cords, or in-
tegral convenience receptacles as this can result in a risk of re or
electric shock.
Object and Liquid Entry: Never push objects of any kind into this
product through openings as they may touch dangerous voltage
points or shout-out parts that could result in a re or electric shock.
Never spill liquid of any kind on the product.
Servicing: Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualied service personnel.
Damage Requiring Service: Unplug this product from the wall outlet
and refer servicing to qualied service personnel under the following conditions: a) when the power-supply or plug is damaged; b) if
liquid has been spilled or if objects have fallen into the product; c) if
the product has been exposed to rain or water; d) if the product does
not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as
improper adjustment of other controls may result in damage and will
often require extensive work by a qualied technician to restore the
product to its normal operation; e) if the product has been dropped or
damaged in any way; f) when the product exhibits a distinct change in
performance—this indicates a need for service.
Replacement Parts: When replacement parts are required, be sure
that your service technician has used replacement parts specied by
the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in re, electric shock, or other
hazards.
Safety Check: Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to ensure that
the product is in proper operating condition.
16.
17.
18.
19.
20.
21.
22.
23.
IMPORTANT SAFETY INSTRUCTIONS
www.cobyusa.com Page 7
Wall or Ceiling Mounting: The product should be mounted to a wall
or ceiling only as recommended by the manufacturer.
Heat: The product should be situated away from heat sources such
as radiators, heat registers, stoves, or other products (including ampli-
ers) that produce heat.
24.
25.
IMPORTANT SAFETY INSTRUCTIONS
Page 8 Coby Electronics Corporation
www.cobyusa.com Page 9
This equipment has been tested and found to comply with the limits for
a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio technician for help.
COMPLIANCE WITH FCC REGULATIONS
www.cobyusa.com Page 9
CD CARE & MAINTENANCE
Handling CDs
Hold a CD by its edges. Avoid touching the recorded side of the disc. To
remove a CD from its storage case, press down on the center retention
mechanism of the case and lift the disc out.
Cleaning CDs
Use a dry, soft cloth to wipe off any ngerprints and dusts from the playing surface of the disc. Wipe in a straight line radially from the center
to the outside edge of the disc. Small dust particles and light stains will
not affect playback quality.
Never use chemicals such as record sprays, anti-static sprays, benzene, or thinners to clean your CDs.
To reduce the risk of scratches, always put CDs back in their case
after use.
Do not subject CDs to prolonged exposure to direct sunlight, high
humidity, or high temperatures.
Do not place stickers or labels on either side of the CD.
Cleaning the CD Player Lens
A dirty lens can cause CD playback to skip. If the lens is very dirty, the
CD may not work at all. Unplug the power supply, open the CD door,
and clean the lens as follows:
For Dust or Dry Particles - use a camera lens brush/blower to blow
on the lens a few times. Then, wipe the lens gently with the brush,
and blow on the lens once more.
For Fingerprints - use a dry cotton swab to wipe the lens in a straight
line radially from the center to the outside edge.
Page 10 Coby Electronics Corporation
www.cobyusa.com Page 11
TABLE OF CONTENTS
PRECAUTIONS ...................................................................................... 2
IMPORTANT SAFETY INSTRUCTIONS ................................................... 4
COMPLIANCE WITH FCC REGULATIONS ........................................... 8
CD CARE & MAINTENANCE ................................................................ 9
Handling CDs ......................................................................................... 9
Cleaning CDs ......................................................................................... 9
Cleaning the CD Player Lens ................................................................ 9
TABLE OF CONTENTS ......................................................................... 10
PACKAGE CONTENTS ........................................................................ 12
FEATURES ............................................................................................ 13
GETTING STARTED .............................................................................. 14
CX-CD397 at a Glance ........................................................................ 14
Top View..................................................................................... 15
Bottom View ............................................................................... 15
LCD Digital Display .................................................................... 15
Remote Control .......................................................................... 16
Mounting the CX-CD397 ..................................................................... 17
Connections ......................................................................................... 18
Speakers .................................................................................... 18
Power ......................................................................................... 18
Headphones ............................................................................... 18
Remote Control .................................................................................... 19
CD MODE ........................................................................................... 20
Basic Operation ................................................................................... 20
CD Functions ....................................................................................... 20
Play/Pause/Stop ........................................................................ 20
Previous/Next (Skip) ..................................................................20
Reverse/Forward (Scan) ...............................................................
20
UDISK MODE ...................................................................................... 21
Basic Operation ................................................................................... 21
SD/MMC MODE ................................................................................. 22
Basic Operation ................................................................................... 22
www.cobyusa.com Page 11
RADIO MODE ..................................................................................... 23
Basic Operation ................................................................................... 23
MENU MODE ...................................................................................... 24
Menu Mode Options ............................................................................ 24
Clock .......................................................................................... 24
Timer .......................................................................................... 24
EQ (Equalizer) ............................................................................25
Bass ........................................................................................... 25
ID3 .............................................................................................. 25
Additional Options (Remote Control) .................................................. 26
Sleep ......................................................................................... 26
Repeat and Random Play .......................................................... 26
Program Play ............................................................................. 27
TROUBLESHOOTING .......................................................................... 28
SPECIFICATIONS ................................................................................ 31
TABLE OF CONTENTS
Page 12 Coby Electronics Corporation
www.cobyusa.com Page 13
PACKAGE CONTENTS
Please make sure the following items are included in the package. If
any items are missing, contact your local dealer.
CX-CD397 Main Unit
Stereo Speakers (x 2)
Remote Control
Instruction Manual
www.cobyusa.com Page 13
FEATURES
Top-Loading CD Player
Plays Regular CDs and CDs with MP3 Files
CD, CD-R, CD-RW Compatible
SD/MMC Card Slot for MP3/WMA Playback
(SD/MMC Card Not Included)
USB Port for MP3/WMA Playback from MP3 Player
Multi-Function Backlit LCD Display
Analog AM/FM Stereo Tuner (Rotary Tuning, Digital Readout)
Dynamic Bass Boost System (DBBS)
Full-Range Speaker System
110/220V Dual Voltage
Page 14 Coby Electronics Corporation
www.cobyusa.com Page 15
GETTING STARTED
CX-CD397 at a Glance
1
14
15
16
17
2
3
4
5
6
7
8
9
13
12
11
10
18
19
20 21 22
23
www.cobyusa.com Page 15
Top View
Open (CD Compartment)
Volume Down
Volume Up
Skip Down
Skip Up
AM/FM Tuning Dial
Power (On/Off)
Power/Standby Indicator
LCD Display
Play/Pause (Enter)
Stop
Folder/Tuner Band
Function
Headphone Jack
Remote Sensor
USB Port
SD/MMC Card Slot
Bottom View
FM Antenna Lead
110/220V Voltage Selector
Switch
AC Power Cord
Right Speaker Output Jacks
Left Speaker Output Jacks
Wall Mounts
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
LCD Digital Display
GETTING STARTED
Page 16 Coby Electronics Corporation
www.cobyusa.com Page 17
Remote Control
Function
Cycle through the player
modes.
Power/Standby
Turn the system On/Off.
/ Enter
Play/Pause Music /
Enter a menu selection.
Skip Down
Skip to the previous track /
Reverse through the current
track.
Skip Up
Skip to the next track /
Fast Forward through the
current track.
Stop
Stop CD playback.
Band/Folder
Toggle between AM/FM
radio bands /
Cycle through folders during
MP3 playback.
Sleep
Set the Sleep Timer.
Menu
Cycle through the Menu
options.
Program
Program a sequence of
tracks for playback.
Random
Change Random playback
mode.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Repeat
Change Repeat playback
mode.
Volume Down
Adjust the volume level down.
Volume Up
Adjust the volume level up.
Timer
Toggle the Timer On/Off.
Battery Compartment Cover
12.
13.
14.
15.
16.
GETTING STARTED
3
6
9
12
15
1
4
7
10
13
16
2
5
8
11
14
www.cobyusa.com Page 17
Mounting the CX-CD397
To mount your CX-CD397 to either a wall or the pedestal base:
Using 4 screws, afx the mounting plate to either a wall or to the
pedestal base.
Align the 4 mounting slots on the bottom of the main unit to hang
on the hooks of the mounting plate.
1.
2.
GETTING STARTED
Hooks
Screws
Mounting Plate
Mounting
Hooks
Page 18 Coby Electronics Corporation
www.cobyusa.com Page 19
Connections
Speakers
Always connect the speakers before connecting the power supply.
Connect the black wire of the left speaker to the black terminal
marked “L-” on the rear of the main unit.
Connect the red wire of the left speaker to the red terminal marked
“L+” on the rear of the main unit.
Connect the black wire of the right speaker to the black terminal
marked “R-” on the rear of the main unit.
Connect the red wire of the right speaker to the red terminal marked
“R+” on the rear of the main unit.
Power
This unit runs on AC 110V or 220V power.
Make sure that the voltage selector on the bottom of the unit is
set to the proper voltage. If you are unsure which voltage setting
to use, please contact the local retailer from which you purchased
this product.
Plug the power cord into an AC wall socket.
To turn the player on, set the POWER switch to the “On” position.
The voltage selection for North America is 110V.
Headphones
Always lower the volume level prior to connecting headphones to the unit.
Failure to do so may result in damage to your hearing or to the
headphones.
Connect your headphones to the Headphone jack. Audio will not
be output to the speakers when headphones are connected to
the unit.
1.
2.
3.
1.
2.
GETTING STARTED
www.cobyusa.com Page 19
Remote Control
Refer to the diagram. Remove the
battery compartment cover located
on the rear of the remote control.
Insert 2 x “AA” batteries, making
sure to match their polarities (+/–)
to the markings on the inside of the
compartment. Replace the cover.
To use the remote, point it at the remote sensor of the player. Operate
the remote within 15 feet of the
sensor and at an angle of +/- 60
degrees.
Batteries in the remote will last for approximately 6 months under
normal use. Replace the batteries if the remote control does not
work. Do not mix old with new batteries, or different types of batteries.
Remove the batteries from the remote if it will not be used for a long
period of time.
The battery used in this device may present a re or
chemical burn if mistreated. Do not recharge, disassemble, incinerate, or heat the battery (~212ºF).
Keep batteries away from children.
GETTING STARTED
Page 20 Coby Electronics Corporation
www.cobyusa.com Page 21
CD MODE
CD Mode allows you to play regular audio CDs, or CDs that contain
digital MP3 or WMA music les.
If the CD contains MP3 or WMA les, playback control
will be the same as in UDISK mode. See the UDISK
Mode section for more information.
DRM-encrypted WMA les are not supported.
Basic Operation
Press FUNCTION to select CD mode.
To open the CD Door, press . Insert a CD with its label
facing up. Close the CD Door (it will click into place).
Press to start CD playback.
CD Functions
Play/Pause/Stop
Press to start playback.
Press during playback to pause. Press again to resume
playback.
Press during playback to stop the disc.
Previous/Next (Skip)
Press to skip to the previous track.
Press to skip to the next track.
Reverse/Forward (Scan)
Press and hold to scan through the current track in a reverse
direction.
Press and hold to scan through the current track in a forward
direction.
1.
2.
3.
www.cobyusa.com Page 21
UDISK MODE
UDISK mode allows you to play digital MP3 and WMA music les from
USB ash drives.
Use only USB-MSC devices or ash disk drives. USB-
MTP devices are not supported.
DRM-encrypted WMA les are not supported.
Basic Operation
Press FUNCTION to select UDISK mode.
Connect a USB disk drive containing MP3/WMA les to the USB
port on the front of the unit. Playback will start automatically.
Press to pause playback or press to stop playback completely. Press again to resume playback.
Press or to select the previous or next track, respectively.
If the USB drive contains folders, press BAND/FOLDER to cycle
through the folders.
Playback will stop automatically when all tracks on the USB drive
have been played.
If the ID3 Display feature has been turned on in the Menu Options (and
the MP3 le being played contains ID3 information), then the le name,
song title, and artist name will be displayed on the LCD.
Page 22 Coby Electronics Corporation
www.cobyusa.com Page 23
SD/MMC MODE
SD/MMC mode allows you to play digital MP3 and WMA music les
from SD or MMC ash cards.
DRM-encrypted WMA les are not supported.
Basic Operation
Press FUNCTION to select UDISK mode.
Insert a SD or MMC card containing MP3/WMA les into the SD/
MMC card slot on the front of the unit. Playback will start automatically.
Press to pause playback or press to stop playback completely. Press again to resume playback.
Press or to select the next or previous track, respectively.
If the SD/MMC card contains folders, press BAND/FOLDER to cycle
through the folders.
Playback will stop automatically when all tracks on the SD/MMC
card have been played.
If the ID3 Display feature has been turned on in the Menu Options (and
the MP3 le being played contains ID3 information), then the le name,
song title, and artist name will be displayed on the LCD.
www.cobyusa.com Page 23
Listen to AM or FM radio broadcasts.
Basic Operation
Press FUNCTION to select RADIO mode.
Press BAND/FOLDER to select the AM or FM band.
AM: Listen to AM broadcasts.
FM: Listen to FM broadcasts.
Turn the AM/FM Tuning Dial to select a broadcast station.
When the tuner is locked in to a stereo broadcast, the LCD screen
will display “STEREO” Tuning.
For the best FM radio reception, position the FM Radio Antenna
located on the rear of the unit away from the speaker and power
cables.
The AM antenna is built directly into the unit. If AM reception is
weak, you may need to rotate or move the unit to obtain a better
signal.
RADIO MODE
Page 24 Coby Electronics Corporation
www.cobyusa.com Page 25
MENU MODE
Set the unit’s internal options. Press MENU on the remote control to
cycle through the Menu options: Clock, Timer, EQ, Bass, and ID3.
All of the instructions in this section refer to the keys
on the remote control.
Menu Mode Options
Clock
Set the internal clock time.
Press MENU until the LCD screen displays “CLOCK” and then
press .
Press to change between the “hours” and the “minutes” eld
(the selected eld will blink).
Press or to adjust the hours/minutes down or up,
respectively.
When you have nished, press MENU to return to the Menu mode.
Timer
Set the Timer to have the unit turn on/off automatically at a set time.
To toggle the Timer feature on/off, press TIMER on the remote (the
LCD will display “TIMER” when the Timer is on).
Make sure the internal clock has been properly set before using the Timer feature.
Make sure the unit has been turned off before setting the Timer.
Press MENU until the LCD screen displays “TIMER” and then
press .
When the LCD screen displays “ON TMR”, press . Set the
time that you want the unit to turn on (see the CLOCK section for
information on how to make adjustments to the time). Press
when you have nished.
1.
2.
3.
1.
2.
3.
www.cobyusa.com Page 25
When the LCD screen displays “OFF TMR”, press . Set the
time that you want the unit to turn off (see the CLOCK section for
information on how to make adjustments to the time). Press
when you have nished.
To have the unit turn on in CD or Radio mode, place
the unit in that mode accordingly prior to turning off the
unit in Step 1.
The Timer function does not work with the UDISK and
SD/MMC modes.
Make sure that the Timer feature has been turned on
(the LCD screen will display “TIMER”).
EQ (Equalizer)
Set the EQ options to change the equalizer presets.
Press MENU until the LCD screen displays “EQ”; then press .
Press to cycle through the equalizer preset options: Flat,
Rock, Jazz, Classic, and Pop.
Bass
Set the Bass option to turn the bass boost feature on or off.
Press MENU until the LCD screen displays “BASS” and then
press .
Press to toggle the bass on (BBS ON) or off (BBS OFF).
ID3
Set the ID3 option to turn the ID3 information display feature on or
off. When ID3 is turned on (and the MP3 le being played contains
ID3 information), then the le name, song title, and artist name will be
displayed on the LCD screen.
Press MENU until the LCD screen displays “ID3”; then press .
Press to toggle the ID3 display on (ID3 ON) or off (ID3 OFF).
4.
1.
2.
1.
2.
1.
2.
MENU MODE
Page 26 Coby Electronics Corporation
www.cobyusa.com Page 27
Additional Options (Remote Control)
These options can be set directly from the remote control. They are not
part of the Menu options.
Sleep
This setting will turn the unit off automatically after a set amount of
time.
Press SLEEP repeatedly to set the amount of time before the unit
turns off. The minimum length is 10 minutes; the maximum is 90
minutes.
Press SLEEP again to display the remaining amount of time for
2 seconds.
Press SLEEP again to change the amount of “Sleep” time.
To cancel the Sleep function, press SLEEP until the LCD no
longer displays “SLEEP”.
Repeat and Random Play
This setting changes the order in which the unit will play tracks.
Press REPEAT to cycle through the Repeat Play options: Repeat,
Repeat Folder, and Repeat All.
Repeat: Repeat the current track
Repeat Folder: Repeat all tracks in the current folder
Repeat All: Repeat all tracks
Press RANDOM to toggle Random Play on or off. When this is set to
“On”, the unit will play tracks in a random order.
Random Play will not work when the unit is in Program
Play mode.
1.
2.
3.
4.
MENU MODE
www.cobyusa.com Page 27
Program Play
Program a sequence of up to 20 tracks to be played.
Press to make sure playback is stopped.
Press to enter Program Mode. The LCD screen will
display [MEMORY], [00], and [P 01].
While [00] is blinking, press or to select a track number,
and then press to store it in memory. The LCD screen
now displays [P 02]. (In UDISK or SD/MMC modes, you can
press BAND/FOLDER rst to select a folder rst.)
Repeat the previous step until you have selected up to 20 tracks.
Press to start Program Play.
Pressing or during Program Play will display
the programmed track number. Press to clear the
program list. The program list will also be lost if you
open the CD Door or if the unit is unplugged.
1.
2.
3.
4.
MENU MODE
Page 28 Coby Electronics Corporation
www.cobyusa.com Page 29
TROUBLESHOOTING
If you have a problem with this device, please read the troubleshooting
guide below and check our website at www.cobyusa.com for Frequently
Asked Questions (FAQs) and rmware updates. If these resources do
not resolve the problem, please contact Technical Support.
COBY Electronics Technical Support
Address: 56-65 Rust St.
Maspeth, NY 11378
Hours: 8:30 AM–11:00 PM EST, seven days a week
Phone: 800-681-2629 or 718-416-3197
Email: techsupport@cobyusa.com
Web: www.cobyusa.com
There is no power to the device.
Ensure that the power cord is securely connected to the unit and the
proper wall outlet.
Ensure that the voltage selector has been set properly (110V or 220V).
There is no sound.
Ensure that the speaker connections are secure and correct.
Try adjusting the volume.
Ensure that the player is in the proper mode (CD, UDISK, SD/MMC,
Radio).
Ensure that headphones are not connected to the unit.
The sound is distorted.
The unit may be positioned too closely to a large appliance (e.g, a
TV or refrigerator). If possible, turn the appliance off or move the unit
to another location.
Ensure that the radio is in broadcast reception range.
Decrease the volume level.
www.cobyusa.com Page 29
The remote control doesn’t work.
Ensure that there are no obstacles between the remote and the
player.
Point the remote at the remote sensor on the main unit.
Strong light (e.g. direct sunlight, uorescent lights, strobe lights) may
interfere with the remote signal.
Ensure that the batteries in the remote retain a charge and have
been installed correctly.
Try replacing the remote’s batteries.
The device does not play.
Moisture may have condensed inside the player. Remove the disc
and leave the player on for 1-2 hours and then try again.
The USB disk or SD/MMC card does not play.
Use only USB-MSC devices or ash disk drives. USB-MTP devices
are not supported.
Ensure that the USB disk or SD/MMC card has been loaded with
compatible MP3 or WMA les.
Ensure that the capacity of the SD/MMC card does not exceed 2GB.
High-capacity SD cards (HCSD) are not supported by this player.
DRM-encrypted WMA les are not supported.
The CD will not play.
Ensure that the CD has been loaded with its label facing up.
Ensure that the CD is not damaged, scratched, or dirty.
Ensure that the CD is an audio CD, or that it contains compatible
MP3 or WMA les.
DRM-encrypted WMA les are not supported.
TROUBLESHOOTING
Page 30 Coby Electronics Corporation
www.cobyusa.com Page 31
TROUBLESHOOTING
Playback is “skipping”.
Ensure that the CD is not damaged, scratched, or dirty.
Ensure that the unit has been installed in a stable location to avoid
vibration and shock.
The player will only play one track, repeatedly.
Ensure that REPEAT mode is off (press REPEAT to cancel).
The Function mode is not working.
Ensure that the CD Compartment Lid is closed.
www.cobyusa.com Page 31
SPECIFICATIONS
Power Supply AC 110/220V (Dual Voltage)
Power Consumption 25W
Tuning System AM: 530 - 1700kHz
FM: 88 - 108MHz
Audio Output Stereo Speakers (x2)
Peak Power 20W (10W x 2)
Speaker Dimensions 4.3” x 8.4” x 3.6” (WHD)
Unit Dimensions 11.8” x 2.6” x 7.0” (WHD)
Specications and manual are subject to change without notice.
COBY Electronics Corp.
56-65 Rust Street
Maspeth, NY 11378
www.cobyusa.com
www.ecoby.com
Loading...
