For more information or to
order any of our products,
please visit our website:
www.cobra.com
CB Radios
microTALK
®
Radios
Radar/Laser Detectors
Safety Alert
®
Traffic Warning Systems
Accessories
GPS (Global Positioning System)
HighGear
®
Accessories
CobraMarine
™
VHF Radios
Power Inverters
The Cobra Electronics Corporation
™
line of quality products includes:
Nothing comes close to a Cobra
®
English
VHF MARINE RADIO
MR HH100 VP EU
Printed in the Philippines Part No. 480-116-P
Owner’s Manual
Nothing comes close to a Cobra
®
English
100VP-BR 6/23/04 3:06 PM Page 38
A1
English
Our Thanks to You and
Customer Assistance
Introduction
Thank you for purchasing a CobraMarine™VHF radio.
Properly used, this product will give you many years
of reliable service.
How Your CobraMarine
™
VHF Radio Works
This radio is a battery powered portable transceiver for use afloat. It gives you
2-way vessel-to-vessel and vessel-to-shore station communications, primarily
for safety and secondarily for navigation and operational purposes. With it, you
can call for help, get information from other boaters, talk to lock or bridge tenders
and make radiotelephone calls to anywhere in the world through a marine operator.
Customer Assistance
Should you encounter any problems with this product, or not understand
its many features, please refer to this owner’s manual. If you require further
assistance after reading this manual, please contact your local dealer.
NOTE
Your equipment will be black. White images are shown in this manual for
illustration purposes only.
This equipment is intended for use in:
For Warranty, Product Service and
Accessory Information
Please contact your local dealer or distributor.
See the enclosed leaflet that provides contact
information for the CobraMarine
™
international
distributors.
Customer Assistance
©
2004 Cobr
a Electronics Europe Limited
Dungar House
Nor
thumber
land A
venue
Dun Laoghaire
County Dub
lin, Ireland
www.cobra.com
❑
a
AT
❑
a
BE
❑ CY
❑
a
CZ
❑ DE
❑
a
DK
❑
a
EE
❑
a
ES
❑
a
FI
❑
a
FR
❑
a
GB
❑
a
GR
❑
a
HU
❑
a
IE
❑
a
IS
❑
a
IT
❑
a
LT
❑
a
LV
❑
a
LI
❑
a
LU
❑
a
MT
❑
a
NL
❑
a
NO
❑
a
PL
❑
a
PT
❑
a
SE
❑
a
CH
❑ SI
❑
a
SK
❑ TR
100VP-BR 6/23/04 3:06 PM Page A1
A3
English
Backlit LCD Screen
and Product Features
Introduction
Dual Power
Selectable to 500 mW or 2 watts output
power for near or distant calling.
International/Canada/U.S.A. Channels
Allows operation on any of the three
different channel maps established
for these areas.
Splashproof
Water resistant — meets
JIS4 Standards.
Channel Scan
Lets you scan through all channels
to find conversations in progress.
Button Lock
Prevents accidental changes to your
settings when you set this feature.
Instant Channel 16
Instant access to priority Channel 16.
Product Features
•
Channel
Numbers
Simplex
Operation
Icon
U-I-C Active
Channel Map
Icons
Button
Lock Icon
Receive or Transmit
Signal Strength Icons
Keystroke
Tones Icon
Scan Icon
Power Saver
Icon
Battery Power
Icon
High/Low
Power Icons
Transmit
Icon
Busy
Icon
Backlit LCD (Liquid Crystal Display) Screen
•
Power Saver
Uses battery saver circuitry to
extend the life of your batteries.
Keystroke Tones
Can be turned On or Off.
Waterproof Pouch
Makes the unit completely waterproof
(one pouch per radio included).
Four AAA Rechargeable
NiMH Batteries Included
Provides extended operating time
compared to alkaline batteries with
no memory effect (one set of batteries
per radio included).
Wall Mount Charger Included
Lets you charge the batteries right
in the radio (one charger per radio
included). In addition, a UK-compatible
connector is included.
Belt
Clip
Battery
Compartment
Battery
Door
Latch
A2
English
Controls and Indicators
Introduction
Microphone/
Speaker
Backlit
LCD
Screen
On-Off Power/
Volume Knob
Antenna
Instant
Channel
16 Button
Channel
Up Button
Channel
Down Button
High/Low Power –
Lock Button
Mode
Button
UIC Button
External Speaker/
Microphone Jack
Talk
Button
Backlight/
Monitor
Button
Charge
Jack
Wrist Strap
Connector
100VP-BR 6/23/04 3:06 PM Page A2
Introduction
Table of Contents
Nothing comes close to a Cobra
®
1
Introduction
Our Thanks to You . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Customer Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A2
Backlit LCD Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Recommendations for Marine Communication . . . . . . . . . . . . . . . . . . 4
VHF Marine Radio Protocols
Licensing Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
VHF Marine Radio Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Voice Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Radiotelephone Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Emergency Messages and Distress Procedure . . . . . . . . . . . . . . . . . . . 8
VHF Marine Channel Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation
Included in this Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wrist Strap, Belt Clip, Spkr/Mic Jack and Waterproof Pouch . . . . . . . 23
Batteries and Charger Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Operating Your Radio
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Standby/Receive and Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Advanced Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
CE Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
100VP-BR 6/23/04 3:06 PM Page 1
Introduction
Important Safety Information
Introduction
Important Safety Information
2
English
Nothing comes close to a Cobra
®
3
CAUTIONS
Your radio is only splashproof when the batteries are properly installed.
AVOID using or storing the radio at temperatures below -20˚C or above 60˚C.
KEEP your radio at least 1 m away from your vessel’s magnetic navigation compass.
DO NOT attempt to service any internal parts yourself. Have any necessary
service performed by a qualified technician.
This radio is supplied with four NiMH (Nickel-Metal Hydride)
rechargeable batteries.
■
Use only the CobraMarine™charger to recharge
NiMH batteries in the radio.
■
Do not short circuit the batteries.
■
When replacing the batteries, dispose of the old batteries
properly. NiMH batteries may explode if disposed of in a fire.
■
The charger is to be used for charging purposes only.
It is not to be used during normal operation.
Changes or modifications to your radio MAY VOID its compliance with
government rules and make it illegal to use.
Important Safety Information
•
Before assembling and using your CobraMarine™VHF radio,
please read these general precautions and warnings.
Warning and Caution Statements
To make the most of this radio, it must be assembled and used properly.
Please read the assembly and operating instructions carefully before assembling
and using it. Special attention must be paid to the
WARNING and CAUTION
statements in this manual.
WARNING
Statements identify conditions that could result in personal injury or loss of life.
CAUTION
Statements identify conditions that could cause damage to the radio
or other equipment.
General Precautions
The following WARNINGS and CAUTIONS will make you aware of RF exposure
hazards and how to assure you operate the radio within the recommended RF
exposure limits established for it.
WARNINGS
Your radio generates electromagnetic RF (radio frequency) energy when it is
transmitting. To ensure that you and those around you are not exposed to
excessive amounts of that energy:
ALWAYS hold the radio at least 5 cm away from you when you are transmitting.
NEVER allow the antenna to touch any part of your body when transmitting.
KEEP the radio at least as far from bystanders as from yourself.
DO NOT transmit more than 50% of the time the radio is in use.
ALWAYS use only Cobra Electronics Corporation™authorized accessories
(batteries, belt clips, chargers, etc.)
DO NOT operate the radio in an explosive atmosphere, near blasting sites,
or in any area where signs are posted prohibiting radio transmissions.
DO NOT allow children or anyone unfamiliar with proper procedures
to operate the radio without supervision.
100VP-BR 6/23/04 3:06 PM Page 2
Recommendations for
Marine Communication Licensing Information
4
English
Nothing comes close to a Cobra
®
5
Recommendations for Marine Communication
•
The frequencies your radio uses are set aside to enhance safety afloat and for vessel
navigation and operational messages over a range suitable for nearshore voyages.
If the 2 watt maximum output of your radio isn’t sufficient for the distances you
travel from the coast, consider purchasing a CobraMarine
™
hand held radio with
up to 5 watts of output power or installing a CobraMarine
™
fixed mount radio with
up to 25 watts of output power. (Visit www.cobra.com or your local dealer for
model availability.)
If you will be going far offshore, you should consider adding even more powerful
radio equipment such as HF single side band or satellite radio for your vessel.
The coastguard does not endorse mobile phones as substitutes for
marine radios. They generally cannot communicate with rescue vessels and,
if you make a distress call on a mobile phone, only the party you call will
be able to hear you. Additionally, mobile phones may have limited coverage
over water and can be hard to locate. If you don’t know where you are, the
coastguard will have difficulty finding you if you’re using a mobile phone.
However, mobile phones can have a place on board where mobile coverage
is available — to allow social conversations and keep the marine frequencies
uncluttered and available for their intended uses.
Licensing Information
•
The radio operates on all currently allocated marine channels and is switchable for
use according to international, Canadian or U.S.A. regulations. It features instant
access to emergency Channel 16 by pressing one key.
CobraMarine
™
VHF radios comply with the U.S. FCC (Federal Communications
Commission) requirements that regulate the Maritime Radio Service.
Station License
The UK requires a ships radio license and a marine radio operator’s certificate before
transmitting equipment can be used aboard a vessel. Other European countries have
specific requirements of their own.
For detailed information and applications, contact the Radio Licensing Centre run
by Royal Mail in the UK. In other countries contact the relevant national postal or
telecommunications authority.
Canadian or U.S.A. Station License
If your vessel will be entering the sovereign waters of Canada or the U.S.A., you
should contact Industry of Canada, Radio Regulatory Branch or the U.S. Federal
Communications Commission for licensing and operating information.
Radio Call Sign
A radio call sign is included as part of the ships radio license in the UK.
Other countries may have different practices; contact your local regulatory
authority for information.
User Responsibility and Operating Locations
All users are responsible for observing domestic and foreign government regulations
and are subject to severe penalties for violations. The VHF frequencies on your radio
are reserved for marine use and require a special license to operate from land,
including when your boat is on its trailer.
VHF Marine Radio ProtocolsIntroduction
100VP-BR 6/23/04 3:06 PM Page 4
VHF Marine Radio
Procedures Voice Calling
6
English
Nothing comes close to a Cobra
®
7
VHF Marine Radio Procedures
•
Maintain Your Watch
Whenever your boat is underway, the radio must be turned On and
be tuned to Channel 16 except when being used for messages.
Power
Try 1⁄2 watt first if the station being called is within a few kilometres. If there
is no answer, switch to a higher power. This will conserve your battery
and minimize interference to other users.
Calling Coast Stations
Call a coast station on its assigned channel. You may use Channel 16
when you do not know the assigned channel.
Calling Other Vessels
Call other vessels on Channel 16. You may also call on ship-to-ship channels
when you know that the vessel is listening on a ship-to-ship channel.
Limits on Calling
You must not call the same station for more than 30 seconds at a time.
If you do not get a reply, wait at least 2 minutes before calling again.
After three calling periods, wait at least 15 minutes before calling again.
Change Channels
After contacting another station on a calling channel, change immediately
to a channel which is available for the type of message you want to send.
Station Identification
Identify your station by your call sign, ship name or other official number
at both the beginning and end of each message.
Prohibited Communications
You MUST NOT transmit:
■
False distress or emergency messages.
■
Messages containing obscene, indecent or profane words or meaning.
■
General calls, signals or messages (messages not addressed to
a particular station) on Channel 16, except in an emergency or
if you are testing your radio.
■
When you are on land.
Voice Calling
•
To call another vessel or a shore installation such as a lock or bridge tender:
■
Make sure your radio is On.
■
Select Channel 16 and listen to make sure it is not being used.
■
When the channel is quiet, press the Talk button and call the ship you wish
to contact. (Hold the radio at least 5 cm from your face and speak directly
into it in a normal tone of voice — clearly and distinctly.) Say “[name
of station being called] THIS IS [your vessel’s name or call sign]”.
■
Once contact is made on the calling channel, you must switch to a proper
working channel. See the channel listing on pages 12 – 21.
The vessel Corsair calling the vessel Vagabond:
Corsair:
“Vagabond, this is Corsair.”
Vagabond: “Corsair, this is Vagabond. Reply 72 (or any proper working channel).”
Corsair: “72.” or “Roger.”
■
After communications are completed, each vessel must sign off with its
call sign or vessel name and switch to Channel 16.
NOTE
For the best sound quality at the station you’re calling, hold the radio
at least 5 cm from your mouth and slightly off to one side. Speak in
a normal tone of voice.
VHF Marine Radio Protocols VHF Marine Radio Protocols
For Example
100VP-BR 6/23/04 3:06 PM Page 6
MAYDAY
PAN PAN
SECURITE
Radiotelephone Calls
Emergency Messages
and Distress Procedure
8
English
Nothing comes close to a Cobra
®
9
Radiotelephone Calls
•
Boaters may make and receive radiotelephone calls to and from any number on the
telephone network by using the services of public coast stations. Calls can be made
— for a fee — between your VHF radio and telephones on land, sea and in the air.
See pages 12 – 21 for the public correspondence (marine operator) channels.
If you plan to use these services, consider registering with the operator of the
public coast station that you plan to work through. Those services can provide
you with detailed information and procedures to follow.
CAUTION
You may disclose privileged information during a radiotelephone call.
Keep in mind that your transmission is NOT private, as it is on a regular
telephone. Both sides of the conversation are being broadcast and can be
heard by anyone who has a radio and tunes to the channel you are using.
Emergency Messages and Distress Procedure
•
The ability to summon assistance in an emergency is the primary reason
to have a VHF marine radio. The marine environment can be unforgiving,
and what may initially be a minor problem can rapidly develop into a
situation beyond your control.
The coastguard monitors Channel 16, responds to all distress calls
and coordinates all search and rescue efforts. Depending on the availability
of other capable vessels or commercial assistance operators in your vicinity,
coastguard or coastguard auxiliary craft may be dispatched.
In any event, do communicate with the coastguard as soon as you experience
difficulties and before your situation becomes an emergency. Use the emergency
message procedures only after your situation has become grave or you are faced
with a sudden danger threatening life or property and requiring immediate help.
If you are merely out of fuel, do not send an emergency message. Drop your
anchor and call a friend or marina to bring the fuel you need or give you a tow.
Marine Emergency Signals
The three spoken international emergency signals are:
The distress signal
MAYDAY is used to indicate that a station is threatened
by grave and imminent danger and requests immediate assistance.
The urgency signal
PAN PAN is used when the safety of the vessel or person
is in jeopardy. (This signal is properly pronounced pahn-pahn.)
The safety signal
SECURITE is used for messages about the safety of navigation or
important weather warnings. (This signal is properly pronounced see-cure-it-tay.)
When using an international emergency signal, the appropriate
signal is to be spoken three times prior to the message.
If You Hear a Distress Call
You must give any message beginning with one of these signals priority
over any other messages. ALL stations MUST remain silent on Channel 16
for the duration of the emergency unless the message relates directly to
the emergency.
If you hear a distress message from a vessel, stand by your radio. If it is
not answered,
YOU should answer. If the distressed vessel is not nearby,
wait a short time for others who may be closer to acknowledge. Even if
you cannot render direct assistance, you may be in a position to relay
the message.
VHF Marine Radio Protocols VHF Marine Radio Protocols
100VP-BR 6/23/04 3:06 PM Page 8
For Example
Emergency Messages
and Distress Procedure
Emergency Messages
and Distress Procedure
10
English
Nothing comes close to a Cobra
®
11
Marine Distress Procedure
Speak slowly — clearly — calmly.
1. Make sure your radio is On.
2. Select VHF Channel 16.
3. Press Talk button and say:
“MAYDAY — MAYDAY — MAYDAY”
(or “PAN PAN — PAN PAN — PAN PAN”
or “SECURITE — SECURITE — SECURITE”)
4. Say:
“THIS IS [your vessel name or call sign].”
5. Say:
“MAYDAY” (or “PAN PAN” or “SECURITE”)
[your vessel name or call sign].
6. Tell where you are:
(Your position or what navigational aids or landmarks are near.)
7. State the nature of your distress.
8. State the kind of assistance needed.
9. Give number of persons aboard and conditions of any injured.
10. Estimate present seaworthiness of your vessel.
11. Briefly describe your vessel (length, type, colour, hull).
12. Say:
“I WILL BE LISTENING ON CHANNEL 16.”
13. End message by saying:
“THIS IS [your vessel name or call sign] OVER.”
14. Release Talk button and listen. Someone should answer.
If not, repeat the call, beginning at item 3 above.
For medical problems such as crew hit by sailboat boom or heart
trouble, make a PAN PAN call as above with the word medico added.
“PAN PAN MEDICO — PAN PAN MEDICO — PAN PAN MEDICO”
The coastguard will try to link you to a doctor who can give
expert advice and evaluate the need for evacuation.
Keep the radio nearby. Even after your message has been received, the coastguard can
find you more quickly if you can transmit a signal for a rescue boat to home in on.
“Mayday — Mayday — Mayday”
“This is Corsair — Corsair — Corsair”
“Mayday Corsair”
“Point Lynas bears 220 degrees magnetic — distance 8 kilometres”
“Struck submerged object and flooding — need pump and tow”
“Four adults, three children aboard — no one injured”
“Estimate we will remain afloat one-half hour”
“Corsair is an 8 metre sloop with blue hull and tan deck house”
“I will be listening on Channel 16”
“This is Corsair”
“Over”
It is a good idea to write out a script of the message form and post it where you
and others on your vessel can see it when an emergency message needs to be sent.
VHF Marine Radio Protocols VHF Marine Radio Protocols
100VP-BR 6/23/04 3:06 PM Page 10
VHF Marine
Channel Assignments
VHF Marine
Channel Assignments
12
English
Nothing comes close to a Cobra
®
13
VHF Marine Channel Assignments
•
Three sets of VHF channels have been established for marine use internationally,
in the U.S.A. and in Canada. Most of the channels are the same for all three maps,
but there are definite differences (see table on the following pages). Your radio has
all three maps built into it and will operate correctly in whichever area you choose.
When shipped from the factory, your radio will be set to the International Channel
Map. (See page 28 for instructions on how to change the Channel Map.)
The following is a brief outline of the channel assignments in the International
Channel Map.
Distress, Safety and Calling
Channel 16
Getting the attention of another station (calling) or in emergencies
(distress and safety).
Intership Safety
Channel 6
Ship-to-ship safety messages and for search and rescue messages to
coastguard ships and aircraft.
On-Board Communication
Channel 15
Used for communication between parts of large ships.
Non-Commercial
Channels 68, 72
Working channels for small vessels. Messages must be about needs of the
vessel, such as fishing reports, berthing and rendezvous. Use Channel 72 only
for ship-to-ship messages.
Commercial
Channels 8, 9, 10, 11, 17, 67, 88, 88A
Working channels for working ships only. Messages must be about business or
needs of the ship. Use Channels 8, 67, 88 and 88A only for ship-to-ship messages.
Public Correspondence (marine operator)
Channels 1, 2, 3, 4, 5, 7, 23, 24, 25, 26, 27, 28, 60,
61, 62, 63, 64, 65, 66, 78, 82, 84, 85, 86, 87, 88
For calls to marine operators at public coast stations. You can make and receive
telephone calls through these stations.
Port Operations
Channels 4, 5, 7, 12, 14, 18, 19, 20, 21, 22, 61, 62, 63,
64, 65, 66, 69, 71, 73, 74, 77, 79, 80, 81, 82, 83
Used for directing the movement of ships in or near ports, locks or waterways.
Messages must be about operational handling, movement and safety of ships.
Navigational
Channels 13, 67
Channels are available to all vessels. Messages must be about navigation,
including passing or meeting other vessels. These are also the main working
channels for most locks and drawbridges. You must keep your messages
short and power output at no more than 1 watt.
Digital Selective Calling
Channel 70
This channel is set aside for distress, safety and general calling using
only digital selective calling techniques. Voice communication is prohibited;
your radio cannot transmit voice messages on this channel.
NOTE
The U.S.A. and Canada impose restrictions on the use of many channels
within their territorial waters. These are noted in the channel assignment
chart. If operating your vessel in the U.S.A. or Canadian waters, consult the
national communication authority or a knowledgeable local radio operator
for further guidance.
VHF Marine Radio Protocols VHF Marine Radio Protocols
100VP-BR 6/23/04 3:06 PM Page 12
VHF Marine
Channel Assignments
VHF Marine Radio Protocols
VHF Marine
Channel Assignments
14
English
Nothing comes close to a Cobra
®
15
VHF Marine Radio Protocols
Channel Use
01 Public Correspondence (marine operator)
01A Port Operations and Commercial; VTS in selected areas
02 Public Correspondence (marine operator)
03 Public Correspondence (marine operator)
03A Government Only
04 Public Correspondence (marine operator); Port Operations; Ship Movement
04A West Coast (coastguard only); East Coast (commercial fishing)
05 Public Correspondence (marine operator); Port Operations; Ship Movement
05A Port Operations; VTS in selected areas
06 Intership Safety
07 Public Correspondence (marine operator); Port Operations; Ship Movement
07A Commercial
08 Commercial (intership only)
09 Boater Calling Channel; Non-Commercial (recreational)
10 Commercial
11 Commercial; VTS in selected areas
12 Port Operations; VTS in selected areas
13 Intership Navigation Safety (bridge-to-bridge); in U.S. waters,
large vessels maintain a listening watch on this channel
14 Port Operations; VTS in selected areas
15 Environmental (receive only); used by class C EPIRB’s.
15 International (on-board communication); Canada (EPIRB buoys only)
16 International Distress, Safety and Calling
17 State Controlled (U.S.A. only)
Channel Channel Map Frequency Power
Number Int’l Canada USA Transmit Receive Limits
01
••
156.050 160.650
01A
•
156.050 156.050
02 •• 156.100 160.700
03 •• 156.150 160.750
03A • 156.150 156.150
04 • 156.200 160.800
04A • 156.200 156.200
05 • 156.250 160.850
05A ••156.250 156.250
06 • • • 156.300 156.300
07 • 156.350 160.950
07A ••156.350 156.350
08 •••156.400 156.400
09 • • • 156.450 156.450
10 •••156.500 156.500
11 •••156.550 156.550
12 • • • 156.600 156.600
13
•••
156.650 156.650 1 Watt CAN and USA
14 •••156.700 156.700
15 • Rx Only 156.750
15 •• 156.750 156.750 1 Watt INT and CAN
16 • • • 156.800 156.800
17 •••156.850 156.850 1 Watt CAN
100VP-BR 6/23/04 3:06 PM Page 14
VHF Marine
Channel Assignments
VHF Marine
Channel Assignments
16
English
Nothing comes close to a Cobra
®
17
VHF Marine Radio Protocols VHF Marine Radio Protocols
Channel Use
18 Port Operations; Ship Movement
18A Commercial
19 Port Operations; Ship Movement
19A Commercial
20 International (port operations, ship movement); Canada (coastguard only)
20A Port Operations
21 Port Operations; Ship Movement
21A U.S. (government only); Canada (coastguard only)
22 Port Operations; Ship Movement
22A U.S. and Canadian coastguard Liaison and Maritime Safety Information
Broadcasts that are announced on Channel 16
23 Public Correspondence (marine operator)
23A Government Only
24 Public Correspondence (marine operator)
25 Public Correspondence (marine operator)
26 Public Correspondence (marine operator)
27 Public Correspondence (marine operator)
28 Public Correspondence (marine operator)
60 Public Correspondence (marine operator)
61 Public Correspondence (marine operator); Port Operation; Ship Movement
61A U.S. (government only); Canada (coastguard only);
West Coast (coastguard only); East Coast (commercial fishing)
62 Public Correspondence (marine operator); Port Operations; Ship Movement
62A West Coast (coastguard only); East Coast (commercial fishing)
Channel Channel Map Frequency Power
Number Int’l Canada USA Transmit Receive Limits
18
•
156.900 161.500
18A
••
156.900 156.900
19
•
156.950 161.550
19A
••
156.950 156.950
20
•••
157.000 161.600 1 Watt CAN
20A
•
157.000 157.000
21
• •
157.050 161.650
21A
••
157.050 157.050
22
•
157.100 161.700
22A
• •
157.100 157.100
23
••
157.150 161.750
23A
•
157.150 157.150
24
•••
157.200 161.800
25
•••
157.250 161.850
26
•••
157.300 161.900
27
• • •
157.350 161.950
28
•••
157.400 162.000
60
••
156.025 160.625
61
•
156.075 160.675
61A
••
156.075 156.075
62
•
156.125 160.725
62A
•
156.125 156.125
100VP-BR 6/23/04 3:06 PM Page 16
VHF Marine
Channel Assignments
VHF Marine
Channel Assignments
18
English
Nothing comes close to a Cobra
®
19
VHF Marine Radio Protocols VHF Marine Radio Protocols
Channel Channel Map Frequency Power
Number Int’l Canada USA Transmit Receive Limits
63
•
156.175 160.775
63A
•
156.175 156.175
64
• •
156.225 160.825
64A
••
156.225 156.225
65
•
156.275 160.875
65A
••
156.275 156.275
66
•
156.325 160.925
66A
••
156.325 156.325 1 Watt CAN
67
•••
156.375 156.375 1 Watt USA
68
•••
156.425 156.425
69
•••
156.475 156.475
70
•••
RX only 156.525
71
•••
156.575 156.575
72
•••
156.625 156.625
73
•••
156.675 156.675
74
•••
156.725 156.725
77
• • •
156.875 156.875 1 Watt CAN
78
•
156.925 161.525
78A
• •
156.925 156.925
Channel Use
63 Public Correspondence (marine operator); Port Operations; Ship Movement
63A Port Operations and Commercial; VTS in selected areas
64 Public Correspondence (marine operator); Port Operations; Ship Movement
64A U.S. (government only); Canada (Commercial Fishing)
65 Public Correspondence (marine operator); Port Operations; Ship Movement
65A Port Operations
66 Public Correspondence (marine operator); Port Operations; Ship Movement
66A Port Operations
67 U.S. (commercial); used for bridge-to-bridge communications in lower
Mississippi River (intership only); Canada (commercial fishing), S&R
68 Non-Commercial (recreational)
69 International (intership, port operations, ship movement);
U.S. (non-commercial, recreational); Canada (commercial fishing only)
70 Digital Selective Calling (voice communications not allowed)
71 International (port operations, ship movement);
U.S. and Canada (non-commercial, recreational)
72 Non-Commercial (intership only)
73 International (intership, port operations, ship movement);
U.S. (port operations); Canada (commercial fishing only)
74 International (Intership, Port Operations, Ship Movement);
U.S. (port operations); Canada (commercial fishing only)
77 Port Operations (intership only); restricted to communications
with pilots for movement and docking of ships
78 Public Correspondence (marine operator)
78A Non-Commercial (recreational)
100VP-BR 6/23/04 3:06 PM Page 18
VHF Marine
Channel Assignments
VHF Marine
Channel Assignments
20
English
Nothing comes close to a Cobra
®
21
VHF Marine Radio Protocols VHF Marine Radio Protocols
Channel Channel Map Frequency Power
Number Int’l Canada USA Transmit Receive Limits
79
•
156.975 161.575
79A
••
156.975 156.975
80
•
157.025 161.625
80A
••
157.025 157.025
81
•
157.075 161.675
81A
••
157.075 157.075
82
•
157.125 161.725
82A
••
157.125 157.125
83
••
157.175 161.775
83A
••
157.175 157.175
84
•••
157.225 161.825
84A
•
157.225 157.225
85
•••
157.275 161.875
85A
•
157.275 157.275
86
•••
157.325 161.925
86A
•
157.325 157.325
87
• •
157.375 161.975
87
•
157.375 157.375
87A
•
157.375 157.375
88
••
157.425 162.025
88
•
157.425 157.425
88A
•
157.425 157.425
NOTE
Many of the plain numbered channels, such as 01, 02 and 03, transmit and
receive on different frequencies. This is termed duplex operation. The rest of
the plain numbered channels and all of the A channels, such as 01A, 03A
and 04A, transmit and receive on a single frequency, which is termed simplex
operation. Your radio automatically adjusts to these conditions. When in simplex
operation, the A icon will appear on the LCD (see illustration on page A2).
Channel Use
79 Port Operations; Ship Movement
79A Commercial (also non-commercial only in Great Lakes)
80 Port Operations; Ship Movement
80A Commercial (also non-commercial only in Great Lakes)
81 Port Operations; Ship Movement
81A U.S. (government only; environmental protection operations)
82 Public Correspondence (marine operator); Port Operation; Ship Movement
82A U.S. (government only); Canada (coastguard only)
83 Canada (coastguard only)
83A U.S. (government only); Canada (coastguard only)
84 Public Correspondence (marine operator)
84A Public Correspondence (marine operator)
85 Public Correspondence (marine operator)
85A Public Correspondence (marine operator)
86 Public Correspondence (marine operator)
86A Public Correspondence (marine operator)
87 Public Correspondence (marine operator)
87 Public Correspondence (marine operator)
87A Public Correspondence (marine operator)
88 Public Correspondence (ship to coast); in U.S. only within
121 kilometres of Canadian Border
88 Commercial Intership only
88A Commercial Intership only
NOTE
All the listed channels are pre-programmed at the factory according to
international regulations, those of Industry Canada (Canada) and those
of the FCC (U.S.A.). They cannot be altered by the user nor can modes
of operation be changed between simplex and duplex.
100VP-BR 6/23/04 3:06 PM Page 20
Included in this Package
Wrist Strap, Belt Clip, Spkr/Mic
Jack and Waterproof Pouch
22
English
Nothing comes close to a Cobra
®
23
Included in this Package
•
You should find all of the following items in the
package with your CobraMarine
™
VHF radio:
Wrist Strap, Belt Clip, Speaker/Microphone Jack
and Waterproof Pouch
•
The radio is shipped with a Wrist Strap, Belt Clip and Waterproof Pouch
in the package. The Speaker/Microphone Jack can be used with additional
accessories. Contact your local CobraMarine
™
dealer for optional accessories.
Wrist Strap
Your radio comes with the Wrist Strap already attached.
It can be easily removed if you choose not to use it.
Belt Clip
Use the Belt Clip to carry your radio around with you.
Simply squeeze the clip and place it where you prefer.
Radio
Waterproof Pouch
Operating Instruction Manual
Belt Clip Wrist Strap
Wall Mount Charger with UKCompatible Connector*
For connection to AC wall outlet.
Rechargeable NiMH Batteries
InstallationInstallation
Belt Clip
Wrist Strap
*The charger is to be used for charging purposes only.
It is not to be used during normal operation.
100VP-BR 6/23/04 3:06 PM Page 22
Wrist Strap, Belt Clip, Spkr/Mic
Jack and Waterproof Pouch
Installation Installation
Batteries and Charger Jack
24
English
Nothing comes close to a Cobra
®
25
External Speaker/Microphone Jack
Your radio can be fitted with an optional External Speaker/Microphone
(not included), freeing your hands for other tasks. Contact your local
CobraMarine
™
dealer for optional accessories.
To attach the external speaker/microphone:
1.
Open the speaker/microphone tab on top
of the radio.
2. Insert the plug into the speaker/microphone jack.
Waterproof Pouch
Use the included Waterproof Pouch to not only keep your radio dry,
but also dust and dirt free.
To enclose the radio in the waterproof pouch:
1.
With the CobraMarine™logo facing up,
slip radio, face up, into opening under
Velcro
®
flap at the bottom of the
waterproof pouch.
2. Turn pouch and radio over so that the
CobraMarine
™
logo is facing down.
3. Roll bottom of pouch (between Velcro
®
pieces) towards upper piece of Velcro®.
4. Secure bottom piece of Velcro®to
upper piece of Velcro
®
.
Batteries and Charger Jack
•
Your radio includes four rechargeable NiMH (Nickel-Metal Hydride) Batteries
(part No. FA-BP) and a wall mount charger (part No. MRC 100) in the
package. Your wall charger is capable of recharging one radio with batteries
installed in the battery compartment. A UK compatible connector (part No.
MRCA 100) is included if required for use with the wall charger.
You should fully charge the included rechargeable NiMH batteries before
using your radio for the first time.
CAUTION
The charger is to be used for charging purposes only.
It is not to be used during normal operation.
Installing the Batteries
To install or replace batteries:
1.
Remove belt clip by releasing belt clip latch
and sliding clip down.
2. Pull down on the battery door latch to remove
the battery compartment cover.
3. Insert the rechargeable NiMH batteries
(part No. FA-BP) according to polarity markings.
4. Replace battery compartment cover and belt clip.
NOTE
Your radio can also be operated with four
standard AAA alkaline batteries. Always use
high quality alkaline batteries. Position batteries
according to polarity markings.
NOTE
Contact your local CobraMarine™dealer for
optional accessories.
WARNING
Only the rechargeable NiMH batteries
(part No. FA-BP) can be recharged.
Remove Belt Clip
Remo
ve Battery Cover
Insert Four Batteries
Speaker/Micr
ophone Tab
Waterproof Pouch
100VP-BR 6/23/04 3:06 PM Page 24
Batteries and Charger Getting Started
26
English
Nothing comes close to a Cobra
®
27
Charging the Batteries
To recharge the rechargeable NiMH battery pack in the radio:
1.
Insert NiMH batteries (part No. FA-BP) in the
battery compartment. (See page 25 for
installing batteries.)
2. Open the charge tab on the side of the unit.
3. Insert the plug into the charge jack.
4. Plug the power supply into an electrical outlet,
using the supplied UK compatible connector if needed.
A full charge will take approximately 15 hours.
You can leave the unit in trickle charge indefinitely.
NOTE
Your radio can also be operated with four
standard AAA alkaline batteries.
WARNING
Only the rechargeable NiMH batteries (part No. FA-BP)
can be recharged.
Maintaining the Battery Charge
As you use your radio, the battery power icon will
show the battery power remaining. When the icon
shows only one or no segment, it is time to change
the batteries.
It is a good idea to keep a set of fresh, high quality
alkaline batteries with your radio. Should the rechargeable
batteries become discharged and no electrical power
source be available, you can insert the alkaline batteries
and continue to use your radio until you can return to
using the rechargeable ones.
Getting Started
•
Refer to the foldout on the front cover of this manual to identify the various
controls and indicators on your radio.
Throughout this manual you will be instructed to press or to press and hold
buttons on the radio. Press means a momentary press, then release; press and
hold means to hold the button down.
Whenever you press any button except the
Talk button on your radio, a brief
tone (beep) will sound to confirm the button press. With all button presses,
the appropriate icon will appear on the LCD and the backlight will turn
On.
The backlight will stay On for five seconds after the button is released.
At times you will hear two other sounds. Two beeps will sound to confirm
your setting changes and three beeps will sound to notify you of an error.
Power On-Off
The On-Off Power/Volume knob on the top of the radio is held in the Off
position by a click stop.
To turn your radio On:
1.
Turn the On-Off Power/Volume knob clockwise
until you hear and feel a click.
When the radio is powered
On, a brief tone will sound,
the display backlight will turn On and the display will
show all icons for two seconds. All buttons will be
inoperative during these two seconds.
After two seconds, the radio will return to the settings in
effect when it was last powered
Off, the LCD will show
the appropriate icons and all controls will be operative.
The radio will then be in
Standby mode.
When first turned
On or after memory loss,
the following defaults will be set:
■
Channel 1A
■
Transmit power high
■
Frequency channel map set to international
■
Battery indicator set
To turn your radio Off:
1.
Turn the On-Off Power/Volume knob all the way
anticlockwise until you hear and feel a click.
Operating Your Radio
On-Off Power/Volume Knob
On-Off Power/Volume Knob
Charge Tab
Fully Charged
Installation
100VP-BR 6/23/04 3:06 PM Page 26
Channels
Your radio will receive and transmit VHF signals on
the Channel indicated on the LCD. You can change
the Channel at any time using the Channel Up and
Channel Down buttons.
To change channels:
1.
Press the Channel Up or Channel Down button.
If you are on Channel 88, pressing the
Channel Up
button will advance to Channel 1. If you are on
Channel 1, pressing the Channel Down button
will advance to Channel 88.
You can hold the
Channel Up or Channel Down
button for fast advance.
The beep sound will occur only at the first press
of the button and not during fast advance.
If the new channel selected is restricted to low power,
the radio will automatically switch to Low Power mode
and the Low Power icon will appear on the LCD.
If the radio is in the
Key Lock mode, the channel will
not change and the three-beep error signal will sound.
Transmit Power Output
Your radio can Transmit selectively at 1⁄2 or 2 watts
of power. Cobra Electronics Corporation
™
suggests
you maintain the low power setting for short-range
communications, to conserve battery life and to avoid
overpowering nearby stations with your signal. Use the
high power setting for long-range communications or
when you do not receive a response to a signal sent
at
1
⁄2 watt.
To toggle between the High
and Low Power modes:
1.
Press the High/Low Power – Lock button.
The LCD will show which mode is in effect.
Getting Started Getting Started
28
English
Nothing comes close to a Cobra
®
29
Volume
The On-Off Power/Volume knob also controls the speaker
Volume. The Volume adjustment applies only to what you
hear from the speaker and does not affect the Volume of
your outgoing messages, which is controlled by the
circuitry of your radio.
To increase the volume:
1.
Turn the On-Off Power/Volume knob clockwise.
To decrease the volume:
1.
Turn the On-Off Power/Volume knob anticlockwise.
Power Saver
Your radio has a unique circuit designed to extend battery
life. If there are no transmissions within ten seconds, the
radio will automatically switch to
Power Save mode and
the Save icon will flash in the LCD. This will not affect the
radio’s ability to receive incoming transmissions.
International/Canada/U.S.A. Channel Maps
Three sets of VHF Channel Maps have been established
for marine use internationally, in Canada and in the U.S.A.
Most of the channels are the same for all three maps,
but there are definite differences (see information on
pages 12 – 21). Your radio has all three maps built
into it and will operate correctly in whichever area
you choose.
To set your radio for the area
in which you will be using it:
1.
From Standby mode, press and hold the UIC button.
The U, I, or C icon will blink on the LCD.
Repeat step 1 to shift to the next channel map(s).
Operating Your Radio Operating Your Radio
Low Power Mode
High Power Mode
High/Low Power – Lock Button
Channel Up or Down Buttons
Currentl
y On Channel 88
P
ower Saver Icon
UIC Button
On-Off Power/Volume Knob
Active Channel
Map Icon
100VP-BR 6/23/04 3:07 PM Page 28
Getting Started Standby/Receive and Transmit
30
English
Nothing comes close to a Cobra
®
31
Backlight
The LCD will be illuminated by the Backlight whenever the
Backlight/Monitor button is pressed. It will remain On for
ten seconds. If a button on the front panel is pressed while
the
Backlight is On, it will remain On for ten seconds after
that button is pressed.
Key Lock
To prevent accidental changes to your settings, you can Lock:
■
Channel 16 Button
■
Channel Up Button
■
Channel Down Button
■
High/Low Power Feature
■
Mode Button
■
UIC Button
To lock or unlock the buttons:
1.
Press and hold the High/Low Power-Lock button
for three seconds. The Lock icon will appear
or disappear in the LCD.
When key lock is
On, pressing any of the listed buttons
on the front of the radio will result in a three-beep error
message. Both the
Backlight/Monitor button and the Talk
button are active — you can receive or transmit a message
with key lock On, but you cannot change the channel.
Standby/Receive and Transmit
•
Standby and Receive
Standby mode is the usual mode for the radio whenever it is turned On. From this
mode, you can change your settings using the buttons on the front of the radio
and switch to
Transmit mode using the Talk button. Signals will be Received
on the selected channel(s) and alerts broadcast by the coastguard will activate
the corresponding routines in your radio.
NOTE
Coastguard alerts are broadcast on Channel 16.
While in
Standby mode, you will receive any messages sent on the
channel to which you are tuned.
Transmit
Transmit mode gives you the ability to interact with
safety services, other vessels and shore stations. When
you use this capability, be sure to follow the procedures
and to observe the courtesies that govern its use so
everyone benefits. (See pages 12 – 21 to help you
select the proper channels.)
To transmit a message:
1.
Check to see that your radio is set to a proper
channel for the type of message you plan to send.
2. Toggle to the low power setting.
3. With the microphone about 5 cm from your
mouth, press and hold the Talk button and
speak into the microphone. The Transmit
icon will appear on the LCD.
4. Release the Talk button when you have finished
speaking. Your radio can only operate in either the
Transmit or the Receive mode at any given time.
You will not hear the response to your message
unless the
Talk button is released.
When the last segment disappears from the
Battery
Power icon, the battery outline of the icon will start to
blink to indicate very little power is left. The radio will
still transmit until the battery voltage drops below the
minimum required to operate the radio.
Operating Your Radio Operating Your Radio
Backlight/Monitor Button
Key Lock Icon
High/Low Power-Lock Button
Locked Buttons
Check Channel Number
5 cm from Mouth
T
alk Button
Low Power Mode
T
ransmit Icon
100VP-BR 6/23/04 3:07 PM Page 30
Advanced Operation Advanced Operation
32
English
Nothing comes close to a Cobra
®
33
Advanced Operation
•
Channel 16
This function gives you quick access to the calling
Channel 16 from any operational mode.
To switch to Channel 16:
1.
Press the Channel 16 button to change to Channel 16.
To exit the
Channel 16 mode and return to whatever status
existed before entering this mode, press the Channel 16
button a second time.
While in the
Channel 16 mode, you can also press the
Channel Up and Channel Down buttons to change channels.
If the radio is in the
Key Lock mode, the channel will not
change and the three-beep error signal will sound.
Channel Scan
During Channel Scan, the radio will rapidly switch from channel to channel.
Whenever any activity is detected, the radio will stop the scan for ten seconds
to allow you to listen briefly on that channel. It will then continue to scan
unless you switch out of the
Scan mode.
To enter channel scan:
1.
Press the Mode button until the Scan icon
flashes on the display.
2. Press the Channel Up or Channel Down
button to begin scanning channels.
The radio will immediately begin to scan the entire
channel map selected in the active channel map.
The Scan icon will show on the LCD.
NOTE
The radio’s operation will be suspended indefinitely
until the Channel Up or Channel Down button is
pressed while the Scan icon is flashing.
To exit channel scan:
1.
From Scan mode, press the Talk button. This will return
the radio to Standby mode on the last scanned channel.
During channel scan (while receiving an incoming
transmission), you can choose from the following:
a.
Press the Talk button to remain on that channel and end
scanning. This will return the radio to Standby mode.
b. Press the Channel Up or Channel Down button
to resume scanning channels.
If you do not press any buttons within ten seconds,
your radio will automatically resume scanning channels.
During channel scan (while not receiving a transmission),
you can choose from the following:
a.
Press the Talk button to communicate on the last
memory location scanned and return to Standby mode.
b. Press the Channel Up or Channel Down button to
change scan direction.
Keystroke Tones
With Keystroke Tones turned On, your radio will sound beeps each time
you press a button or change a setting.
To turn keystroke tones On or Off:
When you turn your radio On for the first time,
keystroke tones will be On.
1. Press the Mode button until the Keystroke Tones
icon flashes on the display. The current On or Off
setting is displayed.
2. Press the Channel Up or Channel Down button to
turn keystroke tones On or Off.
3. When your desired Keystroke Tone mode setting
is displayed, choose one of the following:
a. Press the Mode button to enter the new
setting and proceed to other functions.
b. Press the Talk button to enter the new
setting and return to Standby mode.
The setting you select will be saved when you turn
your radio
Off and On again. When keystroke tones
are On, the Keystroke Tone icon will be displayed.
Operating Your Radio Operating Your Radio
Mode Button
Channel Up or Down Buttons
Scan Icon
Channel 16 Button
Channel 16
a
Talk or Channel Up/Down
b
Mode Button
Channel Up or Down Buttons
K
e
ystr
oke
T
ones Icon
100VP-BR 6/23/04 3:07 PM Page 32
No display on LCD
when radio is turned
On
Batteries are exhausted
Batteries not installed
properly
Replace or recharge batteries
Remove batteries and
reinstall according to
polarity markings
NiMH batteries run
down quickly
Batteries are at the
end of their life
Replace with new batteries
Will transmit at
1
⁄2 watt, but not at
2 watts
Batteries are low
Selected channel is
limited to 1 watt
Replace or recharge
batteries
Switch to another channel
Will not transmit Selected channel is
limited to receive only
Switch to
another channel
No sound from speaker Volume level is too low Re-adjust volume
No response to
button press
Button Lock is On Press and hold High/Low
Power-Lock button
No answer to calls Out of range of
other station
Signal is blocked
by terrain
Switch to 2 watts
or move closer
Move until you have
a “line-of-sight” to
the other station
TroubleshootingMaintenance
34
English
Nothing comes close to a Cobra
®
35
Operating Your Radio Operating Your Radio
Problem Possible Cause(s) Solution(s)
Maintenance
•
Very little maintenance is required to keep your CobraMarine™VHF radio in
good operating condition.
■
Keep the radio and charger clean by wiping with a soft cloth and
mild detergent. Do not use solvents or harsh or abrasive cleaners,
which could damage the case or scratch the LCD screen.
■
If the radio is exposed to salt water, wipe with a soft, moist cloth at
least once a day to prevent build-up of salt deposits, which could
interfere with button operation.
■
If the radio will be stored for a long period, such as over the winter,
remove the batteries from the battery compartment and store them
in a separate package. This is especially so if you are using alkaline
batteries.
Troubleshooting
•
100VP-BR 6/23/04 3:07 PM Page 34
Declaration of Conformity
and CE Marking
Nothing comes close to a Cobra
®
37
Specifications
36
English
Declaration of Conformity
•
We, the Manufacturer/Importer
Cobra Electronics Europe Limited
Dungar House
Northumberland Avenue
Dun Laoghaire
County Dublin, Ireland,
Declare under our sole responsibility that the following product
Portable Marine Radio : MRHH100EU
To which this declaration relates, is in conformity with the
following standards and/or other normative documents.
Safety (R&TTE, Article 3.1a)
EN 60950 : 2000
(Identification of Regulations/Standards)
EMC (R&TTE, Article 3.1b)
EN301 843-1 V1.2.1 (2003-04)
EN301 843-2 V1.2.1 (2003-04)
(Identification of Regulations/Standards)
Radio Spectrum (R&TTE, Article 3.2)
EN301 178-1 V1.2.1 (2003-12)
EN301 178-2 V1.1.1 (2003-08)
(Identification of Regulations/Standards)
We hereby declare that the all essential radio tests suites have been carried out and
that the above named product is in conformity with all the essential requirements.
April 28, 2004
Manufacturer/Authorized Representative
Dublin Ireland
MIKE KAVANAGH
CE Marking
•
This radio is marked adjacent to the serial number.
That means that this radio:
1.
Complies with the essential requirements of the European Radio
and Telecommunication Terminal Directive 1999/5/EC.
2. May operate in some non-harmonised frequency bands and/or may
be subject to licensing conditions in the country of use.
The user should be sure to check that the model and programming of
this radio complies with his or her national licensing requirements.
Operating Your Radio Operating Your Radio
Specifications
•
General
Frequency Range: TX 156.025 to 157.425 MHz
Frequency Range: RX 156.050 to 163.275 MHz
Number of Channels All International, Canadian and U.S.
Channel Spacing 25 kHz
Modulation 16 KOF3E
Input Voltage 6 VDC
Battery Life: Alkaline Batteries:
5% TX, 5% RX, 90% Stand-by 20 Hours @ 2 Watts, 24 hours @ 1⁄2 Watt
Current Drain:
Stand-by 10 mA
Receive 35 mA
Transmit 700 mA @ High power 200 mA @ Low
Temperature Range -20˚C to 60˚C
Radio Dimensions W x D x H 54.1 mm x 30.5 mm x 222.8 mm
(including antenna)
Radio Weight 113.5 g (without batteries)
Receiver
Frequency Range 156.050 to 163.275 MHz
Receiver Type Double Conversion Super-Heterodyne
Sensitivity:
20 dB Quieting 0.35 uV
12 dB Sinad 0.30 uV
Adjacent Channel Selectivity -50 dB
Intermodulation and Rejection -60 dB
Spurious and Image Rejection -50 dB
AF Output 250 mW @ 8 Ohms
Transmitter
Frequency Range: TX 156.025 to 157.425 MHz
RF Output Power
1
⁄2 Watt and 2 Watts
Spurious Emissions -60 dB High -55 dB Low
Microphone Type Condenser
External Microphone Impedance 1000 Ohms
Frequency Stability +/-10 ppm
FM Hum and Noise -45 dB
0682
100VP-BR 6/23/04 3:07 PM Page 36
Loading...
