Introduction

Product Features

1. Antenna

2. External Speaker/ Microphone/Charge Jack

3. Backlit LCD Display

4. On/Off Power Button

5. Hi-Low Power Button

6. Channel Up/Down Buttons

7. Mode Button

8. Lock/Enter Button

10. Volume Up/Down Buttons

11. Light/Max Range Button

12. Talk Button

13. Call Button

14. Wrist Strap Connector

15. Belt Clip

16. Battery Compartment

17. Battery Door Latch

9. Speaker/Microphone

Introduction

Features

• 22 Channels

Seven shared with FRS/GMRS, seven FRS only, eight GMRS only

10 Channel NOAA

•

ALL Hazards Radio

• 142 Privacy Codes

(38 CTCSS codes/ 104 DCS codes)

Hands-Free

•

Operation (VOX)

• VibrAlert Silent Paging

• 10 Channel Memory

• Signal Strength Meter

• Scan Channels, privacy codes, memory

•

Selectable Hi•Med•Low Power

In GMRS

Backlit

•

LCD Display

• Button Lock

• Call Alert 10 selectable tones

Speaker/

•

Microphone/ Charge Jack

• Roger Beep Selectable on/off

Battery/

•

Power Saver

• Keystroke Tones Selectable on/off

Auto Squelch

•

• Maximum Range

Extender

• Belt Clip

Product Features

Backlit LCD Display

1516

11. Memory Location

12. Privacy Code

13. Receive/Transmit

14. Hi-Med-Low Power

15. Battery Low

16. Scan Icon

17. Power Saver Icon

18. Channel Numbers

1. Signal Strength Meter Icon

2. Call Alert and VibrAlert®Icon

3. Lock Icon

4. Keystroke Tones Icon

5. DCS Icon

6. Roger Beep Icon

7. VOX Icon

8. NOAA All Hazards Radio Icon

9. Memory Icon

10. CTCSS Icon

Maximum range may vary and is based on unobstructed line-of-sight communication under ideal conditions.

Important FCC Licensing Information

This radio operates on General Mobile Radio Service (GMRS) frequencies which require a Federal Communications Commission (FCC) license. See page 27 for licensing and other

elated information.

Number

Numbers

Icon

Icons

Indicator

Warranty and Trademark

Warranty

Limited One-Year Warranty on Radio(s) & Charger

For Products Purchased in the U.S.A.

Cobra Electronics Corporation warrants that its Cobra microTALK

radios and charger, and the component parts thereof, will be free of defects in workmanship and materials for a period of one year from the date of first consumer purchase. This warranty may be enforced by the first consumer purchaser, provided that the product is utilized within the U.S.A.

Cobra will, without charge, repair or replace, at its option, defective microTALK to the Cobra Factory Service department, accompanied by proof of the date of first consumer purchase, such as a duplicated copy of a sales receipt.

You must pay any initial shipping charges required to ship the product for warranty service, but the return charges will be at Cobra’s expense, if the product is repaired or replaced under warranty. This warranty gives you specific legal rights, and you may also have other rights which may vary from state to state.

Exclusions: This limited warranty does not apply: 1) T damaged by accident; 2) In the event of misuse or abuse of the product or as a result of unauthorized alterations or repairs; 3) If the serial number has been altered, defaced, or removed; 4) If the owner of the product resides outside the U.S.A.

All implied warranties, including warranties of mer fitness for a particular purpose are limited in duration to the length of this warranty. Cobra shall not be liable for any incidental, consequential or other damages; including, without limitation, damages resulting from loss of use or cost of installation.

Some states do not allow limitations on how long an implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you.

For Products Purchased Outside the U.S.A.

Please contact your local dealer for warranty information.

90-Day Warranty on Cobra Lithium Ion Rechargeable Batter

For products purchased in the U.S.A. and Canada.

Trademark Acknowledgement

Cobra®, microTALK®, Nothing Comes Close to a Cobra®, VibrAlert and the snake design are registered trademarks of Cobra Electronics Corporation, USA. Cobra Electronics Corporation™ is a trademark of Cobra Electronics Corporation, USA.

Acknowledgement

radios, chargers, products or component parts upon delivery

o any product

chantability and

y Packs

•

Assistance

Warranty

10293_LI7200WX_vB.qxd 9/5/07 10:55 AM Page 1

Introduction

peration

ustomer AssistanceWarranty

Caring for Your microTALK®Radio

Your microTALK®radio will give you years of trouble-free service if cared for properly. Handle the radio gently. Keep the radio away from dust. Never put the radio in water or in a damp place. Avoid exposure to extreme temperatures.

Remove Belt Clip

Rechargeable Battery Pack and Desktop Charger

To install or replace battery pack:

1. Remove belt clip by releasing belt clip

Pull Down Latch

latch and sliding clip up.

2. Pull down on the battery door latch to remove

the batter

y compartment cover.

3. Insert lithium ion battery pack. Position

Insert Battery Pack

battery pack as shown in radio.

4. Replace battery compartment cover

and belt clip.

Estimated operation time on full charge: 12 hours.

Rechargeable batter or disposed of properly in compliance with all

y packs must be recycled

applicable laws. They may not be thrown in the trash.

Certain states or municipalities require recycling and have established collection programs. Please contact your local waste removal authority for instructions, or return to Cobra for recycling.

Wrap battery packs carefully and mail postage prepaid to: Cobra Electronics Corporation, 6500 West Cortland Street, Chicago, IL 60707 USA, Attn: Battery Recycling.

Do not put battery packs into fire or expose to high heat. They may explode.

•

Assistance

Warranty

Assistance

Warranty

10293_LI7200WX_vB.qxd 9/5/07 10:55 AM Page 2

Introduction

Insert Radio(s)

Using Your Radio

For charging microTALK®radio(s) in desktop charger:

Insert radio(s) into desktop charger as shown.

2. Insert round connector of 120-volt adapter

into jack on back of charger.

3. Plug 120-volt adapter into electrical outlet.

If charging light is not on, check position of radio. Radio should be upright. The charge indicator light will stay is in the charging well

on as long as the radio

It normally takes about 15 hours to fully recharge battery pack. Battery pack will not be damaged if they stay in the charging well longer than that.

To charge a single radio, you can bypass the desktop charger and simply insert the wall adapter’s round connector directly into the speaker/microphone/charge jack located on the top of the radio.

Use only the supplied rechargeable batteries and charger for recharging your Cobra microTALK

radio.

Cobra recommends your radio is turned off while being charged.

Quick Start

1. Press and hold the Power button

to turn

on your radio.

2. Press the Channel Up or Channel Down

button to select a channel.

Both radios must be tuned to the same channel/privacy code to communicate.

3. Press and hold the Talk button while

speaking into the microphone.

4. When finished talking, release the Talk

button and listen for a response.

On/Off Power

Battery Low

Battery Save Mode

Talk Button

Two Inches (5 cm) from Mouth

Operation

Customer Assistance WarrantyIntroduction

Turning on Your microTALK®Radio

Press and hold the Power button until you hear a series of audible tones indicating the radio

on.

is Your microTALK

mode, ready to receive transmissions. The radio is always in Talk, Call, Mode or Power buttons are pressed.

radio is now in Standby

Standby mode, except when the

Battery Low

When battery power is low, the Battery Low icon will blink. Your batteries should be recharged.

Auto Battery Save

Your microTALK®radio has a unique circuit designed to extend battery life. If there are no transmissions for 10 seconds, the radio will automatically switch to

Power Saver icon will flash in the display.

the

Battery Save mode and

This will not affect the radio’s ability to receive incoming transmissions.

Communicating with Another Person

1. Press and hold the Talk button.

2. With the microphone about 2 inches

(5 cm) from your mouth, speak in a normal voice.

3. Release the Talk button when you are

finished talking and listen for a response.

You cannot receive incoming calls while pressing the

Talk button.

Both radios must be tuned to the same channel/privacy code to communicate.

•

Assistance

Warranty

Assistance

Warranty

Assistance

Warranty

Assistance

Warranty

Assistance

Warranty

10293_LI7200WX_vB.qxd 9/5/07 10:55 AM Page 4

Operation

Channel Buttons

hannel Number

Listening

Call Button

Light/Max Range

Using Your Radio

Channels

With the radio on, select any of the 22 channels by pressing the or Channel Down button.

Both radios must be tuned to the same channel to communicate.

Channels 1 through 7 are shared by FRS and GMRS. Channels 8 through 14 are FRS only Channels 15 through 22 are GMRS only.

See page 26 for FRS/GMRS frequency allocations and compatibility charts.

Listening for a Response

Release the Talk button to receive incoming transmissions. Your microTALK

Standby mode

in Call buttons are not pressed.

while the

Call Button

To alert another person that you are calling: – Press and release the Call button.

The other person will hear a two (2) second call tone. This tone is used only to establish voice communications.

See page 24 on how to select from 10 available call tone settings.

To Illuminate Display

Press and release the Light/Max Range button to illuminate the display for 10 seconds.

Channel Up

radio is always

Talk or

Operation

•

Talk Button

Time-out Timer

The Time-out Timer feature limits transmit time

Customer Assistance WarrantyIntroduction

•

to three (3) continuous minutes to extend battery life and prevent accidental operation. After three (3) continuous minutes of transmission, the radio will stop transmitting and will require a rest period of 30 seconds. During this time the display will flash on and off, and an error tone

Hi-Low Button

will sound if the

Selectable High•Medium•Low Power Output

When in close proximity to another party or during favorable conditions, you can switch from

•

Hi Power Icon

Medium to Low Power to extend battery life.

Push-to-Talk button is pressed.

•

High to

This feature applies to GMRS Channels 1 through 7 and 15 through 22 only. Channels 8 through 14 operate exclusively on low power.

•

Medium Power Icon

wer Icon

w P

•

To switch from high to medium to low power: – Press and release the Hi•Low button.

When in High Power and using Channels 1 through 7 and 15 through 22, the visible in the LCD display.

When in Medium Power and using Channels 1 through 7 and 15 through 22, the be visible in the LCD.

When in Low Power or while using channels 8 through 14, the display.

Low icon will be visible in the

Hi icon will be

Med icon will

When using an external speaker/ microphone accessory on channels 1-7 or 15-22, your microTALK only operate on medium or low power

radio will

Assistance

Warranty

10293_LI7200WX_vB.qxd 9/5/07 10:55 AM Page 6

Operation

Using Your Radio

Auto Squelch/Maximum Range

Your microTALK®radio is equipped with Auto Squelch, which automatically shuts due to terrain and conditions. This slightly reduces the

at which signals can be heard.

Range

off weak transmissions and unwanted noise

You can turn off auto squelch to allow all signals to be received and extend the maximum range of your radio.

Light/Max Range

To briefly turn off auto squelch: – Press the Light/Max Range button

for less than five (5) seconds.

If you hear two (2) beeps, you have turned the maximum range extender

To turn maximum range extender on: – Press and hold the Light/Max Range button

for at least five (5) seconds until you hear two (2) beeps which indicates the maximum range extender is

on. To turn maximum range extender off: – Press and release the Light/Max Range

button or change channels.

Lock Feature

The Lock feature locks the Channel, Mode, Hi•Low and Power buttons to prevent accidental operation.

Lock/Enter Button

To turn the lock feature on or off: – Press and hold the Lock/Enter button for

two (2) seconds.

A double beep sound is used to confirm your

on or off request. When in Lock mode,

lock

Lock icon will be displayed.

the

Lock Mode

Maximum

on (see below).

Operation

•

Speaker/Microphone/Charge Jack

Your microTALK®radio can be fitted with an external Speaker/Microphone, freeing your hands for other tasks. This same jack also serves as the connecting point for the wall charger/adapter.

Speaker/Microphone/ Charge Jack

To attach a speaker/microphone:

Open the speaker/microphone/charge tab on top of your microTALK

2. Insert the plug into the speaker/

microphone/charge jack. (See page 5 for power output settings while using speaker/ microphones.)

Customer Assistance WarrantyIntroduction

•

radio.

To connect a wall charger/adapter:

Open the speaker/microphone/charge tab on top of your microTALK

2. Insert the wall charger/adapter plug

into the speaker/microphone/charge jack.

Signal Strength

•

microTALK®Range

Signal Strength Meter

Your microTALK®radio has a Signal Strength Meter

that shows the strength of your incoming and outgoing transmissions. The ascending bars next to the signal strength indicate the strength of the signal. The greater the number of bars visible, the stronger the signal. The fewer number of bars visible, the weaker the signal.

Your range will vary depending on terrain and conditions.

Maximum Range

Reduced Range

In flat, open country your radio will operate at maximum range.

Buildings and foliage in the path of the signal can reduce the range of the radio.

Dense foliage and hilly terrain will further reduce the range of the radio.

On FRS channels 8 through 14, your radio automatically switches to low power will limit the range the radio can communicate.

Remember, you can achieve maximum

radio.

•

, which

range by using maximum range extender. See page 6 for details.

+ 11 hidden pages
