Cobra Electronics ESD-6050 User Manual

Radar/Laser Detector

Model ESD-6050

Operating Instructions for your Cobra® 6 Band® Extra Sensory Detection®

Nothing comes close to a Cobra™

Introduction

Congratulations! You have just purchased the most sophisticated RADAR/LASER DETECTOR available today.This booklet contains instructions and information designed so that you will be able to understand how the Cobra® ESD-6050 works and how radar and (LIDAR) laser are used. Enjoy your Cobra® ESD-6050 Radar/Laser Detector and

drive safely.

Federal Law Governing Use of Radar Detectors

It is not against Federal Law to receive radar transmissions on your COBRA® Radar Detector. The Communications Act of 1934 guarantees your right to receive radio transmissions on any frequency.Local laws that contravene the Communications Act of 1934, while illegal, may be enforced by your local law enforcement officials until and unless they are prohibited from doing so by Federal Court action.

WARNING: Before leaving your car,make sure that you conceal your radar detector.This will reduce the possibility of break-in and theft of your unit.

Included with your ESD-6050

1. Windshield Bracket

2. Hook and Loop Material

3. Power Cord

Use of this product is not intended to, and does not, ensure that the motorist and any passenger will not be involved in a traffic accident. It is only intended to alert the motorist that an emergency or service vehicle equipped with a CODE 3, or Cobra® Safety Alert Transmitter is in the area as defined by the range of the product. Please call your local Fire/Police department to verify if coverage exists in your area. Motorists are expected to exercise all due caution while using this product, and to observe and follow all applicable traffic laws. Operators of emergency or service vehicles are also expected to exercise all due caution while using this product, and to observe and follow all applicable traffic laws.

Thank you for purchasing the Cobra® ESD-6050 Radar/Laser Detector. Properly used,this Cobra® product will give you many years of reliable service.

Customer Support

Should you encounter any problems with the product or not understand its many features, please refer to this owner’s manual. If, after referring to the manual, you still need help, call Cobra® Customer Service at 773.889.3087.

Our Thanks to You

Cobra® Customer Service

Live operators are available M-F 8:00 am - 8:00 pm CST at: 773.889.3087

Automated Technical Assistance available 24 hours a day,seven days a week. E-mail questions to: productinfo@cobra.com

Cobra® on the Web: Frequently Asked Questions (FAQ) can be foundon-line at: www.cobra.com

Controls and Indicators

1. On/Off Volume Control

2. Mute Button

3. Audio Alerts Speaker

4. Highway/City Button

5. Band Indicators

6. Windshield Bracket

Mount

7. 12V DC Power Jack

How to Use Your Cobra

ESD

Radar/Laser Detector

Features of This Product

•Safety Alert® Traffic Warning System

•Separate Visual and Audio Alarms

•VG-2 Undetectable

•Auto and Manual Muting

•Superior Audio Volume

•Adjustable Windshield Mounting Bracket

Contents

Introduction..................................................................A1

Safety Alert® Federal Law Governing Radar Detectors Included Accessories

Controls & Indicators................................................A2

Our Thanks to You......................................................A3

Customer Support ...................................................A3

Features .............................................................................1

Installation.......................................................................2

Quick Start .......................................................................5

LED Displays..................................................................6

Operation..........................................................................7

Turning On ....................................................................7

Highway/City Mode ...................................................8

Detection ..........................................................................9

Band Detection............................................................9

Audible Alarm Indicator ...........................................9

Instant On Detection...............................................10

Radar .............................................................................10

Safety Alert .................................................................10

VG-2 Undetectable ..................................................11

Laser ..............................................................................11

Radar/VG-2/Laser Alerts.........................................12

Fac ts About Safety Alert®......................................13

Radar Frequencies....................................................14

Fac ts About Lidar (Laser).......................................14

Maintenance.................................................................15

Specifications...............................................................16

Limited One Year Warranty ...................................17

Optional Accessories................................................18

Order Form....................................................................19

If You Think You Need Service.............Back Cover

Installation

Attach cups to bracket.

Attach detector to bracket.

Plug power cord into detector.

Attach bracket to windshield.

Bend bracket for correct detection angle (if needed). Do not use the ESD-6050 to bend bracket.

Plug power cord into cigarette lighter.

Location

Selecting the proper location to mount the Cobra® ESD-6050 is very important for optimum performance. Both radar and laser transmissions pass through glass but not through other objects. For this reason the Cobra® ESD-6050 lenses must not be blocked. It is best to locate your detector as low on the front windshield as possible.

Examples of metal in the windshield area that can block or weaken incoming radar/laser signals:

1. Windshield wiper blades.

2. Mirrored sun screens.

3. Regular tinted glass does not affect radar reception, although the darker tint at the top of the tinted windshield prevents laser light from penetrating.

4. Heated windshields, currently available as an option for some Ford® (Instaclear) and GM® (Electriclear vehicles act as an impenetrable barrier to radar signals). If in doubt, check with your dealer to see if this applies to your vehicle.

Windshield Mounting

Location Windshield

Mounting
