Cobra Electronics 1153A User Manual

Nothing Comes Close to a Cobra

Making Life Easier and Safer

Secure your microTALK radio while on the go.

Carrying your microTALK when using the belt clip or optional wrist strap.

The belt clip easily attaches to your belt, purse, or backpack.

radio with you is easy

Owner’s Manual

Introduction

Staying in touch with your family and friends is convenient and easy when using your microTALK radio. Some of the many uses you will discover include:

Communicating with others while hiking, biking, and working; keeping track of family and friends at a crowded public event; checking with travel companions in another car; talking with neighbors; arranging meeting spots with others while shopping at the mall.

Belt Clip

Customer Assistance

For Assistance in Canada or the U.S.A.

In this user’s manual, you should find all the information you need to operate your microTALK reading this manual, Cobra Electronics offers the following customer assistance services:

Automated Help Desk

English. 24 hours a day, 7 days a week (773) 889 3087 (phone).

Customer Assistance Operators

9:00 a.m. to 5:00 p.m. Eastern Time, Monday to Friday (except holidays) (514) 683-1771, ext. 2-264 (phone).

Questions

Faxes can be received at (514) 683-5307 (fax).

Technical Assistance

English and French. www.cobra.ca (on-line: Frequently Asked Questions). English and Spanish. productinfo

For Assistance Outside Canada, the U.S.A. or in French

For more information or to

order any of our products,

please visit our website:

www.cobra.com

TWO-WAY RADIO MODEL

CXT345C

Nothing Comes Close to a Cobra

Printed in China

Part No. 480-852-P

English

Version G3

Contact Your Local Dealer

English

radio. If you require further assistance after

@cobra.com (e-mail).

6500 West Cortland Street

Chicago, Illinois 60707 USA

www.cobra.com

CXT345C_MANL_ENG_GIANT.indd 1-1 2/4/15 2:12 PM

Product Features

Introduction

Product Features

VOLUME

1. Antenna

2. External Speaker/ Microphone/Charge Jack

3. Mode/Power Button

4. Weather/Lock Button

5. Channel Up/Down Buttons

6. Backlit LCD Display

English

CALL

CHANNEL

MODE

7. Speaker/Microphone

8. Volume Up/Down Buttons

9. Light/Max Range Button

10. Talk Button

11. Call Button

12. Wrist Strap Connection

13. Belt Clip

14. Battery Compartment

15. Battery Door Latch

Warranty and Trademark

Introduction

Features

• 22 Channels

Seven shared with FRS/GMRS, seven FRS only, eight GMRS only.

• 10 Channel

Weather Radio

• Weather Alert

• 121 Privacy Codes

(38 CTCSS codes/

83 DCS codes)

• Hands-Free Operation

(VOX)

• Scan

Channels, privacy codes

• Backlit LCD Display

• Call Alert

Five selectable tones

• Button Lock

• Speaker/

Microphone/ Charge Jack

• Roger Beep

Selectable On/Off

• Battery/Power Saver

• Keystroke Tones

• Battery Level

Indicator

• Auto Squelch

• Maximum

Range Extender

• Belt Clip

English

Product Features

Backlit LCD Display

1. Battery Level

Indicator

2. VOX Icon

3. Scan Icon

4. Roger Beep Icon

5. Lock Icon

6. Low Power Icon

7. DCS/CTCSS Icons

Maximum range may vary and is based on unobstructed line-of-sight communication under ideal conditions.

This device complies with Industry Canada licence-exempt RSS standard(s):

Operation is subject to the following two conditions:

1) this device may not cause interference, and

2) this device must accept any interference, including interference that may cause undesired operation of the device.

«IC» before the equipment certification number signifies that the Industry Canada technical specifications were met. It does not guarantee that the certified product will operate to the user’s satisfaction.

Important FCC Licensing Information

This radio operates on General Mobile Radio Service (GMRS) frequencies which require a Federal Communications Commission (FCC) license in the U.S.A. See page 15 for licensing and other related information.

8. Weather Icon

9. Weather Alert Icon

10. DCS/CTCSS Privacy

11. Power Saver Icon

12. Channel Numbers

13. Receive/Transmit Icon

Code Numbers

6 9

Warranty

Limited One-Year Warranty on Radio(s)

For Products Purchased in Canada

Your new Cobra GMRS radios are covered by a one-year replacement warranty. If any manufacturing defect becomes apparent in this product within one year from the original date of purchase, it will be replaced. Please return the GMRS radio to your dealer with original or copy of dated proof of purchase. This warranty does not cover damages due to careless handling, negligence, accident, abuse or failure to follow operating instructions. Alteration of this product or defacing of the serial number cancels all obligations of this warranty. This warranty gives you specified legal rights. Additional warranty rights may be provided by law in some areas.

For Products Purchased in the U.S.A.

Cobra Electronics Corporation warrants that its Cobra GMRS radios and the component parts thereof, will be free of defects in workmanship and materials for a period of one year from the date of first consumer purchase. This warranty may be enforced by the first consumer purchaser, provided that the product is utilized within the U.S.A.

Cobra will, without charge, repair or replace, at its option, defective GMRS radios, products or component parts upon delivery to the Cobra Factory Service department, accompanied by proof of the date of first consumer purchase, such as a duplicated copy of a sales receipt.

You must pay any initial shipping charges required to ship the product for warranty service, but the return charges will be at Cobra’s expense, if the product is repaired or replaced under warranty. This warranty gives you specific legal rights, and you may also have other rights which may vary from state to state.

Exclusions: This limited warranty does not apply: 1) To any product damaged by accident; 2) In the event of misuse or abuse of the product or as a result of unauthorized alterations or repairs; 3) If the serial number has been altered, defaced, or removed; 4) If the owner of the product resides outside the U.S.A.

All implied warranties, including warranties of merchantability and fitness for a particular purpose are limited in duration to the length of this warranty. Cobra shall not be liable for any incidental, consequential or other damages; including, without limitation, damages resulting from loss of use or cost of installation.

Some states do not allow limitations on how long an implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you.

For Products Purchased Outside Canada or the U.S.A.

Please contact your local dealer for warranty information.

90-Day Warranty on Rechargeable Batteries

For products purchased in the U.S.A. and Canada.

Acknowledgement

Nothing Comes Close to a Cobra

•

CXT345C_MANL_ENG_GIANT.indd 2-17 2/4/15 2:12 PM

Introduction

Caring for Your microTALK® Radio

Your microTALK if cared for properly. Handle the radio gently. Keep the radio away from dust. Never put the radio in water or in a damp place. Avoid exposure to extreme temperatures.

Operation Customer Assistance Warranty

radio will give you years of trouble-free service

Installing Batteries

To install or replace batteries:

Remove Belt Clip

Pull Up Lock Latch

Insert Batteries

1. Remove belt clip by releasing belt clip

latch and sliding clip up.

2. Pull up on the battery door latch to remove the

battery compartment cover.

3. Insert the supplied three AA rechargeable

batteries or non-rechargeable alkaline batteries. Position batteries according to polarity markings.

4. Replace battery compartment cover and

belt clip.

• Do not attempt to charge alkaline batteries.

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc), or rechargeable (Ni-Cd, Ni-MH, etc.) batteries.

•

CXT345C_MANL_ENG_GIANT.indd 1 2/4/15 2:12 PM

Radio Charger Jack

To charge batteries in radio:

1. Check to see that the batteries have been

inserted properly.

2. Insert the cable into the charge jack located at

the top of the radio.

3. Plug the cable into USB-compatible power port.

Use only the supplied rechargeable batteries and charger for recharging your Cobra microTALK radio.

Cobra recommends your radio is turned off while being charged. Non-rechargeable alkaline batteries can also be used in your radio.

Nothing Comes Close to a Cobra

Operation

Using Your Radio

Operation

Customer Assistance WarrantyIntroduction

Battery Low

Quick Start

1. Press and hold the Mode/Power button to turn on your radio.

2. Press the Channel Up or Channel Down button to select a channel.

Both radios must be tuned to the same channel/privacy code to communicate.

3. Press and hold the Talk button while speaking into the microphone.

4. When finished talking, release the Talk button and listen for a response.

Battery Low

Auto Battery Save

Battery Save Mode

When battery power is low, the final bar in the Battery Low icon will blink and an audible tone will sound twice

before the radio shuts off. Your batteries should be replaced or recharged, if using rechargeable batteries.

The radio will display flashing battery icon while charging if the radio is on.

If there are no transmissions within 10 seconds, the radio will automatically switch to Power Save mode and the Power Saver icon will flash in the display. This will not affect the radio’s ability to receive incoming transmissions.

Communicating with Another Person

Turning on Your microTALK® Radio

LUME

Mode/Power

CALL

MODE

Press and hold the Mode/Power button until you hear

CHAN

a series of audible tones indicating the radio is on. Your microTALK

ready to receive transmissions. The radio is always in Standby mode except when the Talk, Call or Mode/Power buttons are pressed.

radio is now in Standby mode,

Battery Status Indicator

Battery Charge Status

English

The battery charge status is shown on the display. Four bars indicates fully charged.

•

Talk Button

Two Inches (5 cm) from Mouth

1. Press and hold the Talk button.

2. With the microphone about two inches (5 cm) from

your mouth, speak in a normal voice.

3. Release the Talk button when you are

finished talking and listen for a response.

You cannot receive incoming calls while pressing the Talk button.

To Select a Channel

Channel Button

CHANNEL

Channel Number

With the radio on, select any of the 22 channels by pressing the Channel Up or Channel Down button.

Channels 1 through 7 are shared with FRS/ GMRS. Channels 8 through 14 are FRS only. Channels 15 through 22 are GMRS only.

Both radios must be tuned to the same channel to communicate.

See page 14 for FRS/GMRS frequency allocations and compatibility charts.

Nothing Comes Close to a Cobra

•

CXT345C_MANL_ENG_GIANT.indd 2-3 2/4/15 2:12 PM

Operation

CHA

Using Your Radio

Listening for a Response

Listening

Release the Talk button to receive incoming transmissions. Your microTALK Standby mode while the Talk or Call buttons are not pressed.

To Adjust Volume

Volume Button

VOLUME

Volume Level

Call Button

CALL

Press the Volume Up or Volume Down button.

A double beep sound is used to indicate

CHANNEL

the minimum and maximum volume levels (1 through 8).

Press and release the Call button. The other person will hear a three second call

tone. This tone is used only to establish voice communications.

MODE

See page 12 on how to select between five call tone settings.

To Illuminate Display

Light/Max Range

Auto Squelch/Maximum Range

Your microTALK and unwanted noise due to terrain, conditions or if you’ve reached your Maximum Range limit.

You can temporarily turn off auto squelch or turn on maximum range extender, allowing all signals to be received and extending the maximum range of your radio.

English

Press and release the Light/Max Range button to illuminate the display.

radio will automatically shut off weak transmissions

radio is always in

Operation

•

Light/Max Range

To temporarily turn off auto squelch:

Press the Light/Max Range button for less than five seconds.

Customer Assistance WarrantyIntroduction

To turn maximum range extender on: – Press and hold the Light/Max Range button

for at least five seconds until you hear

•

two beeps which indicates the maximum range extender is on.

To turn maximum range extender off: – Press and release the Light/Max Range

button or change channels.

Lock Function

Lock Button

•

MODE

Lock Icon

The Lock function locks the Channel Up, Channel Down and Mode/Power buttons to prevent

accidental operation.

To turn the lock on or off: – Press and hold the Lock button for

two seconds.

A double beep sound is used to confirm your lock on or off request. When in Lock mode, the Lock icon will be displayed.

microTALK® Range

•

Your range will vary depending on terrain and conditions.

Maximum Range

V O L UM E

Reduced Range

In flat, open country your radio will operate at maximum range.

Buildings and foliage in the path of the

NNE A CH

C A L

signal can reduce the range of the radio. Dense foliage and hilly terrain will further

reduce the range of the radio. On FRS Channels 8 through 14, your radio

H C

automatically switches to low power, which

C A L

MOD

will limit the range the radio can communicate.

Remember, you can achieve maximum

H C

C A L

range by using maximum range extender. See page 4 for details.

Nothing Comes Close to a Cobra

•

CXT345C_MANL_ENG_GIANT.indd 4-5 2/4/15 2:12 PM

Operation

LUME

CHAN

Using Your Radio

Scrolling Through the Mode Function

By scrolling through the Mode function, you will be able to select or turn on preferred features of your microTALK scrolling through the Mode function, your radio features will be displayed in the same predetermined order:

UME

Mode/Power

CALL

CHA

Set CTCSS Privacy Codes

MODE

Set DCS Privacy Codes Set Vox On/Off Set Vox Sensitivity Set Channel Scan Set CTCSS Privacy Code Scan Set DCS Privacy Code Scan Set Call Tones Set Roger Beep On/Off

radio. When

Privacy Codes

Your microTALK radio incorporates two advanced coded squelch systems that can help to reduce interference from other users on any given channel. CTCSS (Continuous Tone Coded Squelch System) provides 38 privacy codes and DCS (Digitally Coded Squelch) provides 83 privacy codes. This provides a total of 121 Privacy Codes. Either system can be used on all channels, but both systems cannot be used on the same channel at the same time.

To successfully communicate using a privacy code, both the sending and receiving radios must be tuned to the same channel and to the same privacy code system (CTCSS or DCS) and privacy code number. Each channel will remember the last privacy code system and number you select.

The privacy code 00 is not a privacy code, but allows all signals to be heard on a channel that is set to 00 on both the CTCSS and DCS systems.

Operation

Set CTCSS Privacy Codes

•

Mode/Power

CALL

MODE

Privacy Code

Channel Button

CHANNEL

•

To select a CTCSS privacy code:

1. After selecting a channel, press

the Mode/Power button until the CTCSS icon appears and the small numbers next to the channel number flash on the display.

2. Press using the Channel Up or Channel Down

button to select a privacy code. You can hold the

Up or Down button for fast advance.

3. When your desired CTCSS privacy code is

displayed, choose one of the following: a. Press the Mode/Power button to enter the

new setting and proceed to other functions.

b. Press the Lock button to return to Standby

mode.

c. Do not press any buttons for 15 seconds

to enter the new setting and return to Standby mode.

Customer Assistance WarrantyIntroduction

If DCS is turned on at the channel selected, the display will flash the CTCSS icon and “OFF.” To switch from DCS to CTCSS, press the Channel Up or Channel Down button while the display is flashing “OFF.” The display will then show the small numbers flashing and you will then be able to proceed to step 2.

•

English

CXT345C_MANL_ENG_GIANT.indd 6-7 2/4/15 2:12 PM

Nothing Comes Close to a Cobra

Mode Functions

LUME

CHAN

Set DCS Privacy Codes

Mode/Power

CALL

DCS Privacy Code

Channel Button

2. Press using the Channel Up or Channel Down button to select a DCS privacy code. You can hold the Up or Down button for fast advance.

3. When DCS privacy code is displayed, choose one of the following: a. Press the Mode/Power button to enter the new setting and

proceed to other functions.

b. Press the Lock button to return to Standby mode. c. Do not press any buttons for 15 seconds to enter the new setting

and return to Standby mode.

To select a DCS privacy code:

MODE

1. After selecting a channel, press the Mode/Power

button until the DCS icon appears and the small numbers flash on the display (00 through 83).

If CTCSS is turned on at the channel selected, the display will flash the DCS icon and “OFF.” To switch from CTCSS to DCS, press the Channel Up or Channel Down button while the display is flashing “OFF.” The display will then show the small numbers flashing and you

CHANNEL

will then be able to proceed to step 2.

OperationOperation

•

Mode/Power

CALL

MODE

VOX Sensitivity Level

Channel Button

CHANNEL

To set VOX sensitivity:

1. Press the Mode/Power button until the VOX icon

flashes and the current sensitivity level is displayed.

2. Press the Channel Up or Channel Down

button to change the setting.

3. Choose one of the following: a. Press the Mode/Power button to enter the

selected setting and proceed to other functions.

b. Press the Lock button to return to Standby

mode.

Customer Assistance WarrantyIntroduction

The current VOX sensitivity level is displayed with letters “L” and a Number 1 through 5, with Number 5 being the most sensitive level and Number 1 being the least sensitive level.

Voice Activated Transmit (VOX)

In VOX mode, your microTALK® radio can be used “hands-free,” automatically

•

transmitting when you speak. You can set the VOX sensitivity level to fit the volume of your voice and avoid transmissions triggered by background noise.

UME

Mode/Power

CALL

VOX Icon

CHA

To turn VOX mode on or off:

MODE

1. Press the Mode/Power button until the VOX icon flashes on the display. The current On or Off setting is displayed.

2. Press the Channel Up or Channel Down button to turn VOX On or Off.

3. Choose one of the following:

Channel Button

CHANNEL

English

CXT345C_MANL_ENG_GIANT.indd 8-9 2/4/15 2:12 PM

a. Press the Mode/Power button to enter the

new setting and proceed to other functions.

b. Press the Lock button to return to Standby

mode.

Nothing Comes Close to a Cobra

+ 15 hidden pages
