Cobra INTELLILINK XRS R7, INTELLILINK XRS R9G Operating Instructions Manual
IntelliLink™ Wireless Remote Series
12-Band™ S-XRS™ Maximum Performance Digital Radar/Laser
Detector with Red Light/Speed Camera GPS Locator*
Important Information and
Introduction
Customer Assistance
Important Information
Safe Driving
Motorists are expected to exercise all due caution while using this product, and to obey
all applicable traffic laws. Do not attempt to change settings of the unit while the car is
in motion.
Federal Laws Governing the Use of Radar Detectors
It is not against federal law to receive radar transmissions with your Cobra
detector. The Communications Act of 1924 guarantees your right to receive radio
transmissions on any frequency. Local laws that contravene this Act, while illegal, may
be enforced by your local law enforcement officials until and unless they are prohibited
from doing so by federal court action.
Safety/Strobe Alert
Use of this product is not intended to, and does not, ensure that motorists or
passengers will not be involved in traffic accidents. It is only intended to alert the
motorist that an emergency vehicle equipped with a Cobra Safety Alert, 3M or Tomar
strobe transmitter is within range as defined by that product. Please call local fire and
police departments to learn if coverage exists in your area.
®
radar/laser
•
Some states and municipalities prohibit mounting any object on your windshield. If you
drive in these states or areas; you can mount the MDU on the dash.
Security of Your Vehicle
Before leaving your vehicle, always remember to conceal your Remote Display Unit
(RDU) in order to reduce the possibility of break-in and theft. Your Main Detector Unit
(MDU) has a two-position bracket that, when in the up position, presents a very discreet
profile from outside the vehicle.
Customer Assistance
Customer Assistance
Use your owner’s manual to learn about product features. Cobra Electronics offers the
following customer assistance services:
For Assistance in the U.S.A.
Automated Help Desk, English only. 24 hours a day, 7 days a week 773-889-3087.
Customer Assistance Operators, English and Spanish, 8:00 am to 6:00 p.m. Central
Time Mon. through Fri. (except holidays) 773-889-3087.
Questions, English and Spanish, Fax: 773-622-2269.
•
Technical Assistance, English only, www.cobra.com.
English and Spanish e-mail, Product info@cobra.com.
For Assistance Outside the U.S.A. Contact Your Local Dealer
English
A1
©2007 Cobra Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
™
Controls, Indicators
Introduction
and Connections
The XRS R7 provides detection capabilities for radar, laser and strobe signals.
The XRS R9G has all the features of the XRS R7 plus a GPSL module which
provides alerts when approaching photo-enforced intersections and roads
with fixed red light/speed cameras. The XRS R9G can store up to 1,000
additional user-programmable Location Alerts.
IntelliLink™Remote Display Unit (RDU)
Full-Color
Extreme Bright
DataGrafix
™
Display
Power
Button
Main Detector Unit (MDU)
Two-Piece,
Self-Adhesive
Fasteners
GPSL
USB Power Connector
for Recharging Battery
Connector
12V Power Connector
Optional GPSL for Model XRS R7 and Standard on Model XRS R9G
Global Positioning System Locator
(GPSL)
SURFACE
THIS
TOWARD S
SKY
MDU Connector
GPSL Cable
Speaker
English
A2
Introduction
In This Package
In This Package
12V Power Cord with In-line Fuse
for Hardwired Installation
12V to 5V USB Power Adapter
•
12V Power Cord with In-line Fuse
and Cigarette Lighter Plug
USB to Mini-USB Retractable Cable
RDU Holster and Vent/Visor Clips
Optional Hook and Loop Strips
for Mounting Holster
GPSL Cable (R9G Only)
MDU Power Cord Clips and Pre-cut
Adhesive Tapes
Nothing Comes Close to a Cobra
®
A3
Introduction
Contents
Introduction
Important Information . . . . . . . . . .A1
Customer Assistance . . . . . . . . . . .A1
Controls, Indicators and
Connections . . . . . . . . . . . . . . . .A2
In This Package . . . . . . . . . . . . . . .A3
Product Overview . . . . . . . . . . . . . . .2
Installation Overview . . . . . . . . . . . .4
Your Detector
Installation . . . . . . . . . . . . . . . . . . . .7
Controls and Display . . . . . . . . . . .15
Getting Started . . . . . . . . . . . . . . . .17
EasySet Programming . . . . . . . . . .21
Program Navigation . . . . . . . . . . . .22
Settings . . . . . . . . . . . . . . . . . . . . .24
Detection Alerts . . . . . . . . . . . . . . .29
Radar and Laser . . . . . . . . . . . . . . .32
Warranty
Warranty . . . . . . . . . . . . . . . . . . . . .37
User License
User License . . . . . . . . . . . . . . . . . .39
Customer Assistance
Product Service . . . . . . . . . . . . . . .41
Trademark Acknowledgement . . . .42
Optional Accessories . . . . . . . . . . .43
Accessories Order Info . . . . . . . . . .44
Maintenance . . . . . . . . . . . . . . . . . .35
Specifications . . . . . . . . . . . . . . . . .36
Nothing Comes Close to a Cobra
®
1
Introduction
Product Overview
Cobra XRS R7 and XRS R9G
WARNING
Modifications or parts not approved by Cobra Electronics Corporation
may violate FCC Rules and void authority to operate this equipment.
Read and understand the information in the Installation Overview and
Installation sections of this manual for best operation.
The XRS R7 consists of a Main Detector Unit (MDU) and a wireless Remote
Display Unit (RDU). The XRS R9G adds a Global Positioning System Locator
(GPSL) module, providing fixed red light/speed camera location-based alerts.
The XRS R7 can be upgraded with the optional Cobra GPSL to provide fixed
red light/speed camera location-based alerts.
Main Detector Unit (MDU)
The MDU is equipped with an adjustable, two-position bracket for detection
operation in the down (horizontal) position or in the up position for a less
visible profile from the outside. The MDU issues audible messages during
power-on and self-testing. The MDU is also equipped with an alternate power
button used to power the unit.
•
The MDU contains detection function sensors so proper mounting and
orientation are important.
English
2
Introduction
Product Overview
Remote Display Unit (RDU)
The RDU is a wireless remote controller/display module that shows alerts
detected by the MDU. The RDU display uses an Extreme Bright DataGrafix
(Organic Light Emitting Diode) Display to show large graphical alerts as
signals are detected.
The RDU uses a rechargeable lithium-ion (LiON) battery and is supplied with
a holster and clips for mounting on heating/air conditioner vents or sun visor.
12V to 5V USB Power Adaptor with cigarette lighter plug and USB to
Mini-USB Retractable Cable are supplied. The RDU can be charged in the
vehicle using these two components or by plugging the USB to Mini-USB
Retractable Cable to the USB port of your personal computer.
The normal Auto Dark screen is almost completely dark with only a moving
dot. The Auto Dark screen provides discreet usage and helps conserve RDU
battery life. The display color can be changed to match most dash
illumination.
™
Global Positioning System Locator (GPSL) (XRS R9G Only)
The GPSL module tracks vehicle location. It uses a database that provides
alerts as you approach photo-enforced intersections and roads with fixed red
light/speed cameras.
Use the GPSL functions to program alerts and store up to 1,000 user
programmable Location Alerts. Software will be available to update the
database and stay current with future photo enforced locations. The GPSL
module has no external controls and connects to the MDU with one cable.
Registering Your Detector
To register your Cobra XRS R7 or XRS R9G go to www.cobra.com. Click on
the Product Registration tab.
Nothing Comes Close to a Cobra
®
3
Introduction
Installation Overview
Mount Unit
Main Detector Unit (MDU)
Note: To power the MDU, use one of the two power cords provided
(See Page A3).
• 12V Power Cord with In-line Fuse for Hardwired Installation:
For connection to vehicle’s fuse box or battery, or
• 12V Power Cord with In-line Fuse and Cigarette Lighter Plug:
For connection to 12-volt vehicle accessory outlet (cigarette lighter
plug).
Fuse box hard wiring is recommended. Use this configuration to
provide a more discreet installation. If you are unsure about making
this connection yourself, contact a professional installer. Cobra
does not warrant any damages to the product or vehicle that may
occur as a result of improper installation.
On a negative grounded vehicle:
Figure A
ACC
1. Connect the positive wire [marked with a tag (+)] of the DC power cord
to an accessory 12V fuse that is controlled by the ignition switch
(Figure A).
2. Connect negative wire (-) to a chassis ground location (Figure A). Body
paint may need to be removed to assure a good ground connection.
English
4
Introduction
Installation Overview
Figure B
Figure C
Mount the MDU high on windshield to right of rear view mirror (Figure B).
The MDU must have a clear view through the windshield, be parallel to the
road (Figure C) and have clearance to snap into the “up” position.
Position the MDU for easy access to power switch, cable connections and for
mirror movement. Mount the MDU on the windshield close to the headliner.
(See page 7 for details.)
Figure D
External View
T
H
I
S
S
U
R
F
A
C
E
T
O
W
A
R
D
S
S
K
Y
MDU Lens
IMPORTANT: Do not block the MDU lens with the sun-shaded area of the
windshield (Figure D).
Heated windshields currently available on some vehicles (Instaclear for Ford,
Electriclear for GM), may block or weaken incoming signals. Consult your
automobile manufacturer.
Nothing Comes Close to a Cobra
®
5
Introduction
Installation Overview
Global Positioning System Locator (GPSL) - (XRS R9G Model Only)
Figure E
Internal View
Mount GPSL module close enough to the MDU for supplied cable to connect
both modules (Figure E). Mount GPSL with proper side (“This Surface
Toward Sky” wording embossed in unit case) attached to windshield and
exposed to the sky.
Figure F
Internal View
IMPORTANT: Some States and municipalities prohibit mounting any object on
the windshield. If you drive in these states or areas, mount the MDU on the
dash (Figure F).
IMPORTANT: The MDU will need to be flipped upside-down compared to a
windshield installation. Pay special attention to mount the GPSL unit with
proper side (
“This Surface Toward Sky”
wording embossed in unit case)
towards the sky.
English
6
Your Detector
Installation
Main Detector Unit (MDU)
1. Position MDU before actual
mount.
• Do not attempt to adjust
MDU bracket.
• Hold unit in place.
• Using non-permanent
pen, mark two opposite
corners.
2. Peel off film from two-piece
fastener strips. Align with
two corner markings made
in step 1. Press MDU
bracket against windshield.
• Fastener strips cannot
easily be removed.
Strength of adhesive
strips increases with
time.
• Do not pull on MDU for
first 20 minutes.
Nothing Comes Close to a Cobra
®
7
Your Detector
Installation
1. Loosen MDU (gray) bracket
adjust knob.
2. Adjust module to a position
parallel to the road.
3. Tighten knob to set proper
horizontal detection
position. The MDU
mounting bracket has two
detent positions:
Not In Use.
Stored/Concealed
Position.
Loosen
Lower to
Operating
Detection
Position.
Detection
Position
1
Bracket
Adjust Knob
2
3
English
8
• one for detection
operation (horizontal
position)
• one for storage or
concealment (up
position). Makes MDU
less visible from outside.
IMPORTANT:
MDU
will not provide any
radar/laser detection in
“Stored/Concealed”
position.
Tighten
Your Detector
Installation
4. Attach power cord to MDU.
Use power cord clips to
route to fuse box or
lighter/accessory outlet,
depending on the selected
power cord. Surfaces must
be clean and free of dirt,
oil and dust. Plug in the
power cord.
Internal View
Nothing Comes Close to a Cobra
®
9
Your Detector
Installation
Remote Display Unit (RDU)
Battery Installation
1. Turn RDU over and slide
battery cover off of RDU
body.
2. Carefully plug battery wire
connector into the battery
connection port in RDU.
Connector only fits one way.
3. Replace battery cover.
•
Battery Charging
The unit is shipped with a sealed lithium-ion (LiON) battery pack that is
rechargeable.
IMPORTANT: Avoid temperature extremes (hot and/or cold) to help prolong
battery life and performance. DO NOT leave RDU exposed to direct sunlight. If
the RDU is mounted on vent, clip must be on lower fin to avoid hot air
blowing on RDU battery compartment.
NOTE: When battery begins to discharge too quickly, it is time to
install a new battery.
English
10
Your Detector
Installation
1. Attach 12V to 5V
retractable USB power
cable to bottom of RDU
and to 12V power adapter.
2. Connect 12V power
adapter to vehicle
accessory outlet (cigarette
lighter plug).
3. Initial charge for battery is
two (2) hours.
(RDU may be used while
charging.)
WARNING
This lithium-ion (LiON) battery should only be recharged inside the
RDU. Do not substitute any other type of charging adapter or charging
base to charge the battery. Battery damage, fire or explosion may result.
NOTE: Lithium-ion (LiON) batteries are toxic. Please dispose of properly.
Some municipal waste disposal agencies have special provisions for
battery disposal.
NOTE: After battery is fully charged, unit can be operated without
retractable power cord until battery needs recharging.
Nothing Comes Close to a Cobra
®
11
Loading...
