Electric HedgeTrimmer
Models: H55E H60E
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, re and/or serious injury. Keep this manual
securely.
Summary:
1. Introduction ………………………………………………………………….........................5
2. Safety instructions .…………………………………………………………….....................6
2.1 Safety Symbols and Labels ……………………………………………........................6
2.2 Before using ...............…………………….…………………………………….............8
2.3 When using .............……………………………..……………………………...............9
2.4 After using .....................…………………………...………………..…….…………...10
3. Instructions for use ...…………………………...………………..…….…...........………...11
3.1 Preparation of the hedge trimmer ...………............……………………………..…...11
3.2 Using the hedge trimmer .....…………………………………………........................11
3.2.1 Starting the hedge trimmer ......………………………………………………....12
3.2.2 Stop the hedge trimmer .....…………………………………………………......12
3.2.3 Use of the rotary handle Only available on model H60E ................……………….....12
3.2.4 Tips for using hedge trimmer ..….………………………………………...........13
3.3 Cleaning, maintenance, transportation and storage …………………………..........13
3.3.1 Cleaning the electric hedge trimmer ………………………............................13
3.3.2 Maintenance of hegde trimmer ...……………………………………………….14
3.3.3 Transport and storage of the hedge trimmer .....………………………….......14
4. Specications ...……………………………………………………………………………..15
5. Problems and solutions …………………………………………………………………….16
6. Protection of the environment ....…………………………………………………………..17
7. After Sales Service ………………………………………………………………………....17
8. Guarantee ……………………………………………………………………………….......18
9. Declaration of Conformity ……………………………………………..............................19
4 / Instruction Manual H55E & H60E
Model H55E
H60E
Discription of Hedge Trimmer
1 Rear Handle 2 Rotary handle lock button
3 Front handle safety switch 4 Trigger switch
5 Front handle 6 Cutting blade
7 Cable hook
2
3
3
5
5
1
1
7
7
6
6
4
4
Accessories: Protective sleeve
Instruction Manual H55E/H60E / 5
1. Introduction
Thank you for choosing a quality engineered COBRA product.
We believe that, properly maintained, this unit will provide many years of trouble-free
operation.
This
product was designed and manufactured with the utmost care in accordance
with strict standards of safety, reliability and ease of use.
Please read this manual carefully. Familiaris
e yourself with all the controls of the
hedge trimmer before starting to use it for the first time.
Please follow all the comments, explanations and instructions in this manual for optimal
and safe use of this product.
6 / Instruction Manual YAT YT5307 & YT5308
2. Safety Instructions
Your electric hedge trimmer should always be used in accordance with this manual.
This
device is intended solely for cutting hedges in private gardens. Any other use not
expressly permitted in these instructions may result in damage and may pose a serious
hazard to the user and is not permitted.
In particular, the unit must never be used :
- On steep land,
- On a rainy day or in a humid environment,
- By children under 16,
- By people under the influence of any substance (alcohol or drugs) which might impair
vision, movement or judgment.
IMPORTANT : Some of the following symbols may be used on your tool. Be sure to study
them and learn their meaning.
Proper interpretation of these symbols will allow you to use the machine more effectively
and reduce the risk of accident.
2.1 Safety Symbols and Labels
Danger! Warning! Caution!
This symbol indicates a danger, warning or caution. It indicates that the
operator security is at stake.
Read the instruction manual
The instruction manual contains information designed to draw attention
to the possible problems of safety, the risk of damage to the machine
as well as useful tips for startup, operation and maintenance. Please
observe all notes, explanations and instructions in this manual extras for
optimal and safe use of this product.
Keep a safe distance
The operator is responsible for the safety of others present in the work
area of the machine. Never use the trimmer while others, especially
children, or even pets, are nearby.
Do not expose the unit to rain
Never expose the machine to rain or wet conditions.
Do not use this machine in the rain
Instruction Manual YAT YT5307 & YT5308 / 7
Wear protection
Wear eye and ear protection
Wear protection
Wear protective gloves
Wear protection
Wear shoes anti slip safety
Damaged power cord
Never use an appliance with the power cord is damaged or frayed. Do
not touch. Remove the plug on the power cord from the electrical outlet
immediately.
Electrical Hazard
This device operates with a dangerous voltage
Double insulation
For your safety, this appliance is equipped with a double electrical
insulation. Therefore it is not necessary that it be connected to a
grounded outlet.
230V~ 50Hz
Check that the voltage and frequency indicated on the nameplate
afxed to the device correspond to those of the power grid .
Maintenance of the machine
Remove the plug from the socket before all adjustment operations,
cleaning,
transport, maintenance or when you leave it unattended
Recycling
This product must not be disposed of with household waste. It should
be deposited at the collection site for the recycling and recovery of
electrical and electronic waste
8 / Instruction Manual
2.2 Before Using
- Study this manual thoroughly
- Familiarise yourself with the operation of the hedge trimmer and learn to use it
properly.
- Never allow others (especially children) who have not read the manual to use the
machine.
- If the unit must be given to other people, give them as this manual.
- Check that the voltage and frequency indicated on the specification label affixed to
the electrical hedge trimmer correspond to the mains electricity supply.
- Never remove the labels or security elements.
- To connect the hedge trimmer to the power, use only appropriate and compliant
power equipment in perfect condition. Us
e a flexible extension, brightly coloured for
outdoor use with a maximum length of fifty meters with conductors of at least 12mm.
- Keep the cord away from the radius of action of the machine and make sure it is not
subjected to tension. Move the cable from water, heat and sharp edges.
- Do not use the hedge trimmer if the trigger on / off does not work properly. If
necessary, contact your dealer for any repair.
- Never expose the electric hedge trimmer to rain or moisture. Never allow water or
other liquids enter the machine.
- Check the condition of the cutter blade, make sure it fastened and safe before each
use. Replace excessively worn or missing parts.
- Do not cut near other electrical machines.
- Do not operate hedge trimmer in an environment with flammable items such as
liquids, gases or dust. The sparks generated by the operation of the machine can
cause an explosion.
- Do not start cutting until the work area is cleared and cleaned. Keep the work area
clean and tidy to reduce the risk of accident.
- During the first use, it is recommended that the user be accompanied by an
experienced person.
Instruction Manual / 9
• Use the trimmer only in daylight or good artificial light.
• The use of power equipment can be regulated. Remember to comply with legal
regulations which may differ from one location to another.
• Do not use the machine if you are tired or ill. Also avoid use if you have consumed
alcohol or taken drugs.
•
When using, k
eep hair away from the machine. Never wear loose clothing or
accessories such as ties
, cords, scarves or jewellery that could get caught in the
machine or in the cutting system.
• Wear close-fitting clothing, convenient and protect you from cuts. Always wear long
trousers, sturdy and non-slip shoes, and protective equipment such as gloves,
goggles, a helmet with a visor and acoustic shield, etc
• Do not allow anyone to remain in the range of the electric hedge trimmer during use.
Keep people, children and animals away from work area. If it is a group work, keep
sufficient distance between people.
• Make sure that the handles are clean and dry. When the machine is running, always
firmly grip the front handle with your left hand and the rear handle with your right
hand.
•
Always work in a s
table balanced and firm position. Do not work on slippery or
unstable ground.
• Firmly hold the hedge trimmer with both hands. Put yourself in a position that allows
you to withstand the forces applied by a backlash. Do not drop the machine.
• Always begin cutting with the blades moving.
•
Take care during cutting: avoid trimmings and clippings c
ausing injury.
• Never carry the electric hedge trimmer above shoulder height when cutting.
•
Nev
er operate a damaged machine. Ensure repairs are completed by qualified technicians.
• Do not overload the machine. Always use the proper equipment for the job.
2.3 When Using
WARNING: To reduce the time of exposure to vibration and noise, it is preferable to use
the machine with frequent breaks, and limiting the duration of continuous work.
WARNING: The vibration level during actual use of the tool can differ from the
declared depending on how the tool is used total value, and the need to identify s
afety
measures to protect the operator are based on an estimate of the exposure in the actual
conditions of use, taking into account all parts of the user such as the times when the
tool is turned off and when it is running idle cycle.
10 / Instruction Manual
- Always unplug the unit before undertaking any adjustments or maintenance
-
Do not carry the hedge trimmer when it is not unplugged and completely stopped.
- Always follow the instructions provided for maintenance. After each use, check the
operation of safety devices, setting, tension and condition of parts. Maintain the unit.
Replace worn or damaged parts.
- Repair by qualified personnel only. For safety reasons, use only original parts
- Keep the electric hedge trimmer clean and keep it always disconnected in a dry
place, away from direct sunlight and out of reach of Children.
- Keep this manual carefully and consult it whenever you use the machine.
2.4 After Using
Instruction Manual / 11
3.1
Preparation of the hedge trimmer
3.2 Using the hedge trimmer
CAUTION: Do not plug the machine to the power source until you fully assemble and
set the machine.
CAUTION: Wear gloves when handling the trimmer to avoid accidents with the
cutter blades, whose teeth are extremely sharp.
3. Instructions for use
Unauthorised modifications can make your machine dangerous and lead to severe injury
during use. Cobra disclaims any liability in case of misuse or failure to comply with the
instructions and / or regulations in force.
- Unpack the unit carefully check the condition of all parts.
If in doubt, contact your dealer.
Before using, always check the presence and correct operation of safety devices. Also
check the status of the cutting system and its attachment. If necessary, replace or repair
defective components. Use only original parts or approved by Cobra.
WARNING: Never work with a damaged cutting blade or excessively worn because
y
ou might hurt yourself.
12 / Instruction Manual
3.2.1 Starting the hedge trimmer
3.2.2 Stop the hedge trimmer
3.2.3 Use of the rotary handle Only available on model H60E
- Fully unroll the power cord and use the cable hook to hang and connect it to the
machine as shown in Figure 1 below.
- Connect the extension cord to the power socket, taking care to not press any button
to prevent accidental starting.
- Remove the protective sleeve.
- Hold the hedge trimmer firmly with both hands and simultaneously squeeze the
trigger on the rear handle with your right hand and the left hand pressing the front
handle safety switch forward as shown in Figure 2 below.
- Release the front handle safety switch and / or rear handle trigger to stop the
machine
- The machine stops completely after a few seconds.
- Unplug the power socket for safety
- To facilitate the use of hedge trimmers in vertical sections, the rear handle is adjustable
to 45 ° and 90 ° to the right and left.
- Note: Unplug the machine before rotating the throttle grip.
- With your thumb, pull holding the lock button rearward to unlock the handle and
rotate to the right or to the left to the required position.
Fig 1
Fig 3
Fig 2
Instruction Manual / 13
- Do not use in the rain
- Preferably s
tart with the parts closest to the power supply, moving away slowly.
- When cutting, make sure that the extension cord is always drawn behind you the side
already done.
- Start the trimmer before making contact with the hedge to prevent the blade blocking.
- Alternately use the two sides of the blade.
- For efficiency, tilt the blade about 10 ° without poking the tip of the trimmer.
- For horizontal areas, go from the inside to the edge of the fence to cut down the
branches on the ground.
- If the height of the hedge is excessive, making several passes. Between each size,
cut large branches with pruning shears or a lopper.
- Work carefully near fences to avoid blocking the blade.
- In case of blade blocking, stop and discconnect the machine before the cleaning.
3.2.4 Tips for using the hedge trimmer
Fig 4
- Clean the hedge trimmer after each use.
- Maintain the surface of the unit with a s
oft damp cloth. Never clean plastic with a
chemical that may damage it.
3.3 Cleaning, maintenance, transportation and storage
3.3.1 Cleaning the electric hedge trimmer
CAUTION: All cleaning, transportation and maintenance must be done when machine
stopped and unplugged
CAUTION: Never immerse the of the trimmer electric wire in water or other liquids
for cleaning. Never clean the unit with strong high pressure or water .
14 / Instruction Manual
- The blade should be regularly cleaned to remove residual resin. Preferably use a mild
solvent for this purpose. Leave for a few minutes and wipe the blade with a cloth.
- To optimise the operation of hedge trimmer and avoid corrosion, oil the blade and
the guide rail after each use with an environmentally friendly lubricant.
- Always unplug the machine when storing or carrying.
- Store your trimmer
in a dry, secure loaction out of reach of children.
- For long-term storage, lightly oil the cutter blade.
- Do not carry the trimmer when it is not completely off and unplugged.
Sharpening blades:
For best results, do sharpen the cutting edges of the blade at least once a year at a
specialist workshop. For your local Cobra dealer www.cobragarden.co.uk
If necessary, replace the dull or damaged blade in a specialist workshop.
3.3.2 Maintenance of hegde trimmer
3.3.3 S Transport and storage of the hedge trimmer
CAUTION: Wear gloves when handling the trimmer to avoid any accidents related to the
blade, the teeth are extremely sharp.
Instruction Manual / 15
Model H55E H60E
Product name Electric Hedge Trimmer Electric Hedge Trimmer
Voltage 230V~ 50Hz 230V~ 50Hz
No load speed 3300/min 3300/min
Power 600w 710w
Blade length 550 mm 600 mm
Tooth space 20 mm 24 mm
Guaranteed sound power (
LwA)
100 dB(A) 103 dB(A)
Sound pressure level ( LpA) 90 dB(A) 91 dB(A)
Class of protection
Double protection / classe II /
IP20
Double protection / classe II /
IP20
Net weight 3,2 Kg 3,7 Kg
Vibration level 2,32 m/s² k=1,5m/s² 2,45 m/s² k=1,5m/s²
4. Specications
In keeping with our policy of continuous improvement, we reserve the right to change
the design and conguration of any product without notice. Thus, the text and images
of this manual and packaging are for illustrative purposes only and may not under any
circumstances be the basis for a legal claim or another.
16 / Instruction Manual
5. Problems and solutions
Malfunction Probable cause Troubleshooting
The unit does not
start or work.
There is no current.
Check the condition of the cord or
plug. If they are damaged, replace
them.
The switch is faulty or
defective.
Please contact your local dealer.
The carbon brushes
are worn and / or the
motor
has failed.
Please contact your local dealer.
The machine operates
intermittently.
The power cable is
damaged, switch is
faulty or defective.
Please contact your local dealer.
The cutting
performance is
decreased.
The blade teeth is blunt. Sharpen or replace the blades.
The blades get
heated excessively.
Dull blades.
Lack of lubrication
on the blades.
Sharpen the blades
Lubricate the blades with a little oil.
The motor rotates but
the blade does not
move.
The blade clutch is
defective.
The blade is blocked.
Please contact your local dealer.
Unplug the machine and remove the
object blocking the blade, or loosen
the screws on the cutter bar.
Strong vibrations of the
machine.
The blades and /
or transmission are
damaged.
Please contact your local dealer.
The machine is noisy.
Lack of grease in gear
box of transmission.
Please contact your local dealer.
Plants become yellow.
The blades are dull or
dirty.
Please contact your local dealer.
Instruction Manual / 17
6. Protection of the environment
To protect the environment, we recommend the following:
• Take care of your hedge trimmer regularly and replace damaged parts.
•
When your device is at the end of its life, ensure that it is disposed of appropriately.
Waste Disposal
According to the European Directive on the disposal of waste electrical and
electronic equipment, power tools that are no longer usable must be collected
and follow a path of appropriate recycling. Do not dispose of electric tools
together with household waste.
7. After Sales Service
For more information or for after sales service, contact your local Cobra dealer.
Use only original parts or approved by Cobra.
Call 0115 986 2161 or www.cobragarden.co.uk
18 / Instruction Manual
8. Guarantee
This Cobra product carries a guarantee of 12 months. If your product develops a fault within
this period, you should, in the first instance contact the retailer where the item was purchased.
This guarantee specifically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Use in contravention of the instructions.
- Use when the product has been subject to unauthorised modifications or alterations.
- Commercial use.
- Lack of routine maintenance
- Failure of consumable items
- Accidental damage
- Cosmetic damage
- Failure to follow the manufacturer’s guidelines
- A change in circumstances, leading to the customer no longer needing the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in the UK. For
any enquiries relating to the guarantee please refer to your retailer.
If the issue cannot be resolved over the telephone or by email, you may be referred to your
local approved service dealer.
Please keep your sales receipt as proof of purchase.
Instruction Manual / 19
9. Declaration of Conformity
We, the undersigned,
Cobra Garden,
Henton & Chattell Ltd., London Road, Nottingham NG2 3HW UK
Declare that
The following products are appropriate and consistent with the basic safety Health and
EC directives (see point 3), based on their design and type, as circulated by us.
This declaration relates exclusively to the machinery in the state in which they were
placed on the market and excludes added and / or components operations carried out
subsequently by the end user.
1. Description / Function : Electric Hedge Trimmer
2.
Type : H55E (5307)
H60E (5308)
3. EC directives : Directive machine 2006/42/EC
2006/95EC the low voltage
2004/108/EC on EMC
2000/14/EC the emission on noise
amended by directives 2005/88/EC
4. Harmonized standards :
EN 55014-1 ; EN 55014-2 ;
EN 61000-3-2 ; EN 61000-3-3
EN 60745-1 ; EN 60745-2-15
5.
Responsible for documentation : Peter J. Chaloner
Guaranteed sound power: H55E (5307) 100 dB(A)
H60E (5308) 103 dB(A)
Sound Pressure level : H55E (5307) 90 dB(A)
H60E (5308) 91dB(A)
Conformity assessment body :
JIANGSU TÜV Product Service Ltd, Shanghai Branch, N°88 Hengtong Road, Shanghai
200070 P.R.China
TÜV SÜD Product Service Gmbh – Zertizierstelle - Ridlerstrabe 65- 80339 München –
Germany
Date : 2013-07-01
Loading...
