Coban GPS106A, GPS106B User Manual
1
GSM/GPRS/GPS Vehicle Tracker
GPS106A/B User Manual
Preface
Thank you for purchasing the tracker. This manual shows how to operate the device smoothly
and correctly. Make sure to read this manual carefully before using this product. Please note
that specification and information are subject to changes without prior notice in this manual.
Any change will be integrated in the latest release. The manufacturer assumes no
responsibility for any errors or omissions in this document.
2
Contents
1. Function Introduction ................................................................................................................................. 4
2. Applications ................................................................................................................................................ 4
3. Hardware Description ................................................................................................................................. 4
4. Acessories ................................................................................................................................................... 5
5．Specifications ............................................................................................................................................ 6
6. Operating Instructions ................................................................................................................................ 6
6.1 Terminal Installation ................................................................................................................................. 6
6.2 SIM card installation................................................................................................................................. 8
6.3 Turn on the tracker device ........................................................................................................................ 8
6.4 GSM/GPS LED Indicator ......................................................................................................................... 8
6.5 Initialization .............................................................................................................................................. 8
6.6 Change Password ...................................................................................................................................... 8
6.7 Authorization ............................................................................................................................................ 9
6.8 Single Locating ......................................................................................................................................... 9
6.9 Auto track continuously ............................................................................................................................ 9
6.10Get location in absolute street address ................................................................................................... 10
6.11Get Location base station (LBS) ............................................................................................................ 10
6.12 View photos on cell phone
6.13 Monitor ................................................................................................................................................. 10
6.14 Modes switch between “track” & “monitor” ........................................................................................ 11
6.15 Storage .................................................................................................................................................. 11
6.16 Data Load ............................................................................................................................................. 11
6.17. Alarms .................................................................................................................................................. 12
6.17.1 Low battery alarm .............................................................................................................................. 12
6.17.2 Power off alarm ................................................................................................................................. 12
6.17.3 SOS .................................................................................................................................................... 12
6.17.4 Geo-fence ........................................................................................................................................... 12
6.17.5 Movement alarm ................................................................................................................................ 12
6.17.6 Over Speed Alarm.............................................................................................................................. 12
6.17.7 Fuel Alarm
6.17.8 Temperature Alarm
6.18 Cut off the Oil and Power System ........................................................................................................ 13
6.19 Resume the Oil and Power System ....................................................................................................... 13
6.20 Arm ....................................................................................................................................................... 14
6.21 Disarm .................................................................................................................................................. 14
6.22 Function of Remote Control (Option for model B) .............................................................................. 14
6.23. Alarms under Arm State ....................................................................................................................... 15
6.23.1 Door alarm ......................................................................................................................................... 15
6.23.2 Shock Sensor Alarm .......................................................................................................................... 15
6.23.3 ACC Alarm ........................................................................................................................................ 15
3
6.23.4 Photograph ......................................................................................................................................... 15
6.24. Silent Mode .......................................................................................................................................... 15
6.25 Alarms in GSM Blind Area ................................................................................................................... 16
6.26 Check the Vehicle State ........................................................................................................................ 16
6.27 Reset by SMS ....................................................................................................................................... 16
6.28 Check IMEI .......................................................................................................................................... 16
6.29 Terminal (local) Time Setting ............................................................................................................... 17
6.30 GPRS Setting ........................................................................................................................................ 17
6.31 Setting up APN ..................................................................................................................................... 17
6.32 GPRS User Name and password Setup ................................................................................................ 17
6.33 IP and Port Setup .................................................................................................................................. 17
6.34 Modes Switch between “SMS” and “GPRS” ....................................................................................... 18
6.35 Web platform and PC installation tracking software user manual ........................ 错误！未定义书签。
7. Cautions .................................................................................................................................................... 18
8. Faults & the Solutions .............................................................................................................................. 18
4
1. Function Introduction
1.1 This tracker is a new product based on the GSM / GPRS network and GPS satellite
positioning system, which set multiple functions of security, positioning, monitoring
surveillance, emergency alarms, photograph, fuel&temperature detection and tracking in
its entirety. It can track and monitor remote target by SMS or internet.
1.2 Features
1.2.1 Support both GPS / GSM station positioning ways.
1.2.2 Support SMS/GPRS/Internet Network data transmission (GPRS/Internet
instructions in CD enclosed).
1.2.3 Support GPRS on-line and GPRS re-connected automatically if GPRS drops
1.2.4 Compatible with the original vehicle anti-theft alarm, can be synchronized with the
events alarm and disarm from original car alarm system.
1.2.5 Support SMS / GPRS dual-mode switching
1.2.6 Support configure by remote terminal.
1.2.7 Support for point-to-point, point to group, group-to-group monitoring.
1.2.8 Set multiple functions of security, positioning, monitoring surveillance, emergency
alarms and tracking in its entirety.
2. Applications
Used widely for positioning and tracking vehicle and other moving objects.
3. Hardware Description
5
⑴. GSM antenna connector. ⑺. Backup battery switch
⑵. J4 Monitor microphone jack. ⑻. GPS antenna connector
⑶. LED indicator ⑼. Remote control receiver antenna（model B）
⑷. SIM card slot ⑽. J1 12PIN harness port
⑸. SIM card slot Pop-up switch ⑾. J2 Camera port
⑹.SD card slot ⑿. J3 Shock sensor port
4. Accessories
No.
Name
Note
1
GPS Antenna
3 meters
2 GSM Antenna
3 meters
3 Microphone
1.5 meters
4 Harness
12PIN
5
Relay
12V/40A or 24V/40A ，
depends on the vehicle
6
Shock sensor
Optional for Model A and B
7
Siren
Optional for Model A and B
8
Remote Control
Optional for Model B
6
9
Camera
Optional for Model A and B
10
Temperature Sensor
Optional for Model A and B
11
Fuel sensor
Optional for Model A and B
and different type depends
on vehicles
5．Specifications
Content
Specifications
DIM
85*71*26mm
Weight
170g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GSM/GPRS
Module
Simcom900B
GPS Module
SIRF3 chip
GPS Sensitivity
-159dBm
GPS Accuracy
5m
GPS Start Time
Cold status 45s
Warm status 35s
Hot status 1s
Applicable
vehicle power
12 V -24V
Backup Battery
Chargeable changeable 3.7V 800mAh Li-ion battery
Storage Temp
-40°C to +85°C
Operation
Temp.
-20°C to +65°C
Humidity
5%--95% non-condensing
6. Operating Instructions
6.1 Terminal Installation
