Coban GPS102B User Manual
GSM/GPRS/GPS Tracker User
Manual
Preface
Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and
correctly. Make sure to read this manual carefully before using this product. Please note that
specification and information are subject to changes without prior notice in this manual. Any change
will be integrated in the latest release. The manufacturer assumes no responsibility for any errors or
omissions in this document.
1
Contents
1. Summary ..................................................................................................................................................... 4
2. Applications................................................................................................ ................................................. 4
3. Hardware Description .................................................................................................................................. 4
4. Specifications .............................................................................................................................................. 4
5. Usage .......................................................................................................................................................... 5
5.1 SIM Card Installation ............................................................................................................................. 5
5.2 Battery and charger................................................................................................................................. 5
5.3 Startup ................................................................................................................................................... 5
5.4 Initialization ........................................................................................................................................... 6
5.5 Change the password ................................................................................................ .............................. 6
5.6 Authorization ......................................................................................................................................... 6
5.7 Set the contacts....................................................................................................................................... 7
5.8. 2.4G Attendance Management ( Model B) .............................................................................................. 7
5.9. The function of buttons .......................................................................................................................... 8
5.10 Single Locating .................................................................................................................................... 8
5.11 Auto track continuously ........................................................................................................................ 8
5.12. Location based service (LBS)................................ ............................................................................... 9
5.13 Absolute street address by SMS............................................................................................................. 9
5.14 GPS drift suppression ......................................................................................................................... 10
5.15 Track mode ........................................................................................................................................ 10
5.16 Monitor .............................................................................................................................................. 10
5.17 Call ................................ .................................................................................................................... 10
5.18 Speak ................................................................................................................................................. 10
5.19 Data logging ................................................................................................ ....................................... 10
5.20 Data load ............................................................................................................................................ 11
5.21. SOS Alert .......................................................................................................................................... 11
5.22. Shock Sensor Alarm .......................................................................................................................... 12
5.23. Geo-fence .......................................................................................................................................... 12
5.24. Multi-area management ..................................................................................................................... 13
5.25 Movement alarm ................................................................................................................................ 13
5.26 Over speed alarm ................................................................................................................................ 14
5.27 Low battery alert ................................................................................................................................ 14
5.28.GPS blind Spot alert ........................................................................................................................... 14
5.29 Sleep Mode ................................ ................................................................................................ ........ 14
5.30. Start Work on specific time ................................................................................................................ 15
5.31. Forward the third parties’ message ..................................................................................................... 15
5.32 Charges Inquiry .................................................................................................................................. 16
5.33 Check the Vehicle State. ...................................................................................................................... 16
5.34 Check IMEI........................................................................................................................................ 16
5.35 Terminal (local) Time Setting ................................................................ .............................................. 16
5.36 TCP/UDP Switch ................................................................................................................................ 17
5.37 Reset ................................................................................................................................ .................. 17
2
5.38 Configure parameters by USB ............................................................................................................. 17
5.39 GPRS setting ...................................................................................................................................... 17
5.40 Less GPRS traffic ............................................................................................................................... 18
5.41 Modes switch between “SMS” and “GPRS” ........................................................................................ 18
5.42 Setup monitor center number .............................................................................................................. 18
5.43 Web platform and PC installation tracking software ............................................................................. 19
6. Cautions .................................................................................................................................................... 19
7. Faults & The solutions................................ ................................................................................................ 19
3
Content
Specifications
Dim.
8.6×4.6×1.8cm
Weight
60g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS sensitivity
-159dBm
GPS accuracy
5m
Time To First Fix
Cold status 45s
Warm status 35s
Hot status 1s
Charging Voltage
110－220V input
5V output
USB Port
GSM,GPS,
Power indicator
SOS Button
MIC
Speaker
Call contact 2
ON/OFF
SIM Card
Call contact 3
Call contact 1
1. Summary
Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and
monitor any remote targets by SMS or internet.
2. Applications
Protect child / the old / the disabled / Personnel Management
3. Hardware Description
3.1 Side 3.2 Front 3.3 Side
4. Specifications
4
Charging Voltage
Chargeable changeable 3.7V 900mAh Polymer battery
Battery Standby
180hours
Storage Temp.
-40°C to +85°C
Operation Temp.
-20°C to +70°C
Humidity
5%--95% non-condensing
5. Usage
5.1 SIM Card Installation
5.1.1Make sure that there is no call transfer and call display is on, and PIN code off. The SMS
message must in Text format, can’t be identified for PDU format.
5.1.2 Lift the soft plastic buckle of the SIM Card slot, the SIM card is placed correctly if heard
the sound of lock, and then put the buckle back. the SIM will automatically pop up if press it
gently.
5.2 Battery and charger
Do charge the battery to capacity in 8 -12 hours for first time. Please use the battery and charger
provided by the manufacturer. Polymer battery is the standard battery, and it can normally standby
180 hours after fully charged.
Cautions
A：For its Li-ion battery, which contains harmful chemicals and may burst, please don’t bump,
puncture it violently and keep it from fire.
B：Please charge the battery in time to keep it working normally.
5.3 Startup
5.3.1 Load the SIM card and take it outdoors to turn it on.
5.3.2 For first use, please initialize the unit and restore it to default setting.
5.3.3 In 10 or 40 seconds, the unit will begin to work after acquire the GSM signals as well as the
GPS signals.
5
5.3.4 When this unit receives GPS signals normally, you can use it and do any setting as the
instructions of this manual.
5.3.5 Status indicator: The green indicator keep flashing 1 time every second after acquire GSM
signal; and every 3 seconds under GPRS state.
The red indicator keeps on when charging and turn off after fully charged.
The blue indicator keep flashing 1 time every second after acquire GPS signal.
5.4 Initialization
Send “begin+password” in SMS to the unit, it will reply “begin ok” and initialize all the settings.
(Default password: 123456)
For example, send SMS “begin123456” to the tracker via a cell phone, if succeeded, if will reply
“begin ok”.
5.5 Change the password
5.5.1 Set Password: Send sms: “password+old password+space+new password” to the unit to change
the password.
For Example, pls send sms: “password123456 888888” to terminal device, it will reply sms:
“password OK”. New password 888888 changed in success.
5.5.2 Be sure to keep the new password in mind, you have to upload the software to restore the
original setting in case of losing the new password.
5.5.2 Attention: Make sure the new password is in 6 digits Arabic numbers, or else the tracker cannot
recognize the password.
5.5.3The “+” in the command, please don’t type “+”, space means press the space keyboard on your
cell phone.
5.6 Authorization
There are 5 numbers to be allowed to authorize in the tracker at most. Be sure to set the authorization
phone number before use. Only after setting the authorization phone number can receive SMS alarm
and call the authorization phone number by SOS button on tracker.
5.6.1 Call the tracker for 10 times continuously and get position correctly, then it will make the cell
phone number as the authorized number automatically.
5.6.2 Send SMS：“admin+password+space+cell phone number” to set up a authorized number. The
other authorized numbers should be set by the first authorized number. If the number is
6
