Cobalt Digital Inc.
9275-4C
9275-8C
HD/SD-SDI Analog Audio De-Embedders
User Manual
9275-4C8C-OM
Version: 1.2
9275-4C / 9275-8C User Manual •••• (V 1.2) Page i
9275-4C / 9275-8C •••• Analog Audio De-Embedder User Manual
• Cobalt Digital Inc. Part Number: 9275-4C8C-OM
• Document Version: 1.2
• Printed in the United States.
• Last Author: CGG
• Printing Date: 12/15/11
The information contained in this manual is subject to change without notice or obligation.
Copyright
© 2011 Cobalt Digital Inc.. All rights reserved.
Contents of this publication may not be reproduced in any form without the written permission of
Cobalt Digital Inc.. Reproduction or reverse engineering of copyrighted software is prohibited.
Patents
This product is protected by the following US Patents: 4,205,346; 5,115,314; 5,280,346;
5,561,404; 7,034,886; 7,508,455. This product is protected by the following Canadian Patents:
2039277; 1237518; 1127289. Other patents pending.
Notice
The material in this manual is furnished for informational use only. It is subject to change without
notice and should not be construed as commitment by Cobalt Digital Inc.. Cobalt Digital Inc.
assumes no responsibility or liability for errors or inaccuracies that may appear in this manual.
Trademarks
• is a registered trademark of Ross Video Limited.
•
All other product names and any registered and unregistered trademarks mentioned in this
manual are used for identification purposes only and remain the exclusive property of their
respective owners
is a registered trademark of Cobalt Digital Inc.
Page ii 9275-4C / 9275-8C User Manual •••• (V 1.2)
Important Regulatory and Safety Notices
Before using this product and any associated equipment, refer to the “Important Safety
Instructions” listed below to avoid personnel injury and to prevent product damage.
Products may require specific equipment, and/or installation procedures to be carried out to satisfy
certain regulatory compliance requirements. Notices have been included in this publication to call
attention to these specific requirements.
Symbol Meanings
This symbol on the equipment refers you to important operating and maintenance
(servicing) instructions within the Product Manual Documentation. Failure to heed this
information may present a major risk of damage or injury to persons or equipment.
Warning — The symbol with the word “Warning” within the equipment manual
indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
Caution — The symbol with the word “Caution” within the equipment manual
indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury. It may also be used to alert against unsafe practices.
Notice — The symbol with the word “Notice” within the equipment manual indicates a
situation, which if not avoided, may result in major or minor equipment damage or a
situation which could place the equipment in a non-compliant operating state.
ESD Susceptibility — This symbol is used to alert the user that an electrical or
electronic device or assembly is susceptible to damage from an ESD event.
Important Safety Instructions
Caution — This product is intended to be a component product of the 8300 series
frame. Refer to the 8300 series frame User Manual for important safety instructions
regarding the proper installation and safe operation of the frame as well as its
component products.
9275-4C / 9275-8C User Manual •••• (V 1.2) Page iii
Warning — Certain parts of this equipment namely the power supply area still
present a safety hazard, with the power switch in the OFF position. To avoid electrical
shock, disconnect all AC power cards from the chassis’ rear appliance connectors
before servicing this area.
Warning — Service barriers within this product are intended to protect the operator
and service personnel from hazardous voltages. For continued safety, replace all
barriers after any servicing.
This product contains safety critical parts, which if incorrectly replaced may present a
risk of fire or electrical shock. Components contained with the product’s power supplies
and power supply area, are not intended to be customer serviced and should be
returned to the factory for repair. To reduce the risk of fire, replacement fuses must be
the same time and rating. Only use attachments/accessories specified by the
manufacturer.
Warning —This product includes an “Ethernet Port” which allows this product to be
connected to a local area network (LAN). Only connect to networks that remain inside
the building. Do not connect to networks that go outside the building.
EMC Notices
United States of America
FCC Part 15
This equipment has been tested and found to comply with the limits for a class A Digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
Notice — Changes or modifications to this equipment not expressly approved by
Cobalt Digital Inc. could void the user’s authority to operate this equipment.
CANADA
This Class “A” digital apparatus complies with Canadian ICES-003.
Cet appariel numerique de la classe “A” est conforme a la norme NMB-003 du Canada.
EUROPE
This equipment is in compliance with the essential requirements and other relevant provisions of
CE Directive 93/68/EEC.
INTERNATIONAL
This equipment has been tested to CISPR 22:1997 along with amendments A1:2000 and
A2:2002, and found to comply with the limits for a Class A Digital device.
Page iv 9275-4C / 9275-8C User Manual •••• (V 1.2)
Notice — This is a Class A product. In domestic environments, this product may
cause radio interference, in which case the user may have to take adequate measures.
Maintenance/User Serviceable Parts
Routine maintenance to this Cobalt Digital Inc. product is not required. This product contains no user
serviceable parts. If the frame does not appear to be working properly, please contact Technical
Support using the numbers listed under the “Contact Us” section on the last page of this manual. All
Cobalt Digital Inc. products are covered by a generous 5-year warranty and will be repaired without
charge for materials or labor within this period. See the “Warranty and Repair Policy” section in this
manual for details.
Environmental Information
The equipment that you purchased required the extraction and use of natural resources for its
production. It may contain hazardous substances that could impact health and the environment.
To avoid the potential release of those substances into the environment and to diminish the need for the
extraction of natural resources, Cobalt Digital Inc. encourages you to use the appropriate take-back
systems. These systems will reuse or recycle most of the materials from your end-of-life equipment in
an environmentally friendly and health conscious manner.
The crossed-out wheeled bin symbol invites you to use these systems.
If you need more information on the collection, reuse, and recycling systems, please contact your local
or regional waste administration.
You can also contact Cobalt Digital Inc. for more information on the environmental performances of
our products.
9275-4C / 9275-8C User Manual •••• (V 1.2) Page v
Contents
Introduction 1-1
In This Chapter .......................................................................................................................1-1
Overview.................................................................................................................................1-2
Functional Block Diagrams.....................................................................................................1-3
Documentation Terms and Conventions.................................................................................1-4
Installation 2-1
In This Chapter .......................................................................................................................2-1
Before You Begin...................................................................................................................2-2
Installing the 9275...................................................................................................................2-3
Cabling for the 9275...............................................................................................................2-4
A Word of Thanks....................................................................................................1-1
9275 Overview .........................................................................................................1-2
Features.....................................................................................................................1-2
Static Discharge........................................................................................................2-2
Unpacking.................................................................................................................2-2
Rear Modules for the 9275-4C.................................................................................2-3
Rear Modules for the 9275-8C.................................................................................2-3
Installing a Rear Module...........................................................................................2-3
Installing the 9275....................................................................................................2-4
9275-4C Cabling Overview......................................................................................2-4
9275-8C Cabling Overview......................................................................................2-5
User Controls 3-1
In This Chapter .......................................................................................................................3-1
Card Overview........................................................................................................................3-2
Control and Monitoring Features............................................................................................3-3
Status and Selection LEDs on the 9275....................................................................3-3
Reference Compatibility.........................................................................................................3-5
Frame Rate Compatibility.........................................................................................3-5
Operation Notes......................................................................................................................3-6
Audio Proc Amp Controls ........................................................................................3-6
Minimum Delay Overview .......................................................................................3-6
Menus 4-1
In This Chapter .......................................................................................................................4-1
SNMP Monitoring and Control...............................................................................................4-2
DashBoard Menus for the 9275..............................................................................................4-3
Status Tabs................................................................................................................4-3
Setup Menus.............................................................................................................4-5
Input Status Menus...................................................................................................4-7
Analog Outputs Menus.............................................................................................4-8
Embedded Outputs Menus........................................................................................4-8
vi •••• Contents 9275-4C / 9275-8C User Manual •••• (V 1.2)
Alarm Enables Menus...............................................................................................4-9
Card-edge Menu System.......................................................................................................4-11
Navigation..............................................................................................................4-11
Card-edge Menus....................................................................................................4-11
Menu Descriptions..................................................................................................4-12
Specifications 5-1
In This Chapter.......................................................................................................................5-1
Technical Specifications.........................................................................................................5-2
Channel Status Data Table......................................................................................................5-2
Passing the Status Bytes ...........................................................................................5-3
Service Information 6-1
In This Chapter.......................................................................................................................6-1
Troubleshooting Checklist ......................................................................................................6-2
Bootload Button .......................................................................................................6-2
Warranty and Repair Policy....................................................................................................6-3
9275-4C / 9275-8C User Manual •••• (V 1.2) Contents •••• vii
Introduction
In This Chapter
This chapter contains the following sections:
• Overview
• Functional Blo ck Diagrams
• Documentation Terms and Conventions
A Word of Thanks
Congratulations on choosing a 9275 HD/SD-SDI Analog Audio De-Embedder. The Cobalt Digital
Inc. line includes video decoders and encoders, audio embedders and de-embedders, distribution
amplifiers, format converters, and much more. Cobalt Digital Inc. modular conversion gear will meet
your signal conversion needs now, and well into the future.
Should you have a question pertaining to the installation or operation of your 9275, please contact us at
the numbers listed on the back cover of this manual. Our technical support staff is always available for
consultation, t raining, or service.
9275-4C / 9275-8C User Manual •••• (V 1.2) Introduction •••• 1-1
Overview
The 9275-4C and 9275-8C HD/SD-SDI Analog Audio De-Embedders offer various configuration
options, including internally generated patterns and tones, are available for audio and video output
scenarios should a loss of input occur.
9275-4C / 9275-8C Overviews
The 9275-4C and 9275-8C de-embed up to either four or eight analog audio channels (respectively)
from an HD/SD-SDI signal.
The 9275-4C and 9275-8C include audio proc control on each channel that allows for audio processing
with gain of +/– 10dB, audio delay up to 1 second, and channel invert. The 9275-4C and 9275-8C
support any channel assignment to the discrete inputs and can re-map any of the existing embedded
channels.
Features
The following features make the 9275-4C and 9275-8C ideal solutions for de-embedding four or eight
analog audio sources from and HD/SD-SDI signal:
• Supports HD-SD SDI SMPTE 292M, 1.5Gbps and SMPTE 259M, 270Mbps
• Audio de-embedding for all popular formats 480i, 576i, 720p, and 1080i
• 9275-4C provides four analog outputs
• 9275-8C provides eight analog outputs
• Audio controls such as gain, invert, and delay
• Analog gain control done entirely in the analog domain
• Assign any embedded channel to any discrete audio output
• Ability to re-map channels in embedded video stream
• Programmable video output on SDI input loss
• Silence output on loss of audio input
• Programmable silence detection and timeout thresholds
• No audio breakout cable required
• Reports status and configuration remotely via the DashBoard Control System™
• Fits 8300 series frames
• Fully compliant with openGear specifications5-year transferable warranty
1-2 •••• Introduction 9275-4C / 9275-8C User Manual •••• (V 1.2)
Functional Block Diagram
This section provides functional block diagram for the 9275-4C and 9275-8C.
Figure 1.2 9275-4C and 9275-8C — Simplified Block Diagram
9275-4C / 9275-8C User Manual •••• (V 1.2) Introduction •••• 1-3
Documentation Terms and Conventions
The following terms and conventions are used throughout this manual:
• “Frame” refers to 8300 series frame that houses the 9275-4C or 9275-8C, as well as any
openGear frames.
• All references to the 8300 series frame also includes all version of the 10-slot and 20-slot
frames and any available options unless otherwise noted.
• “Operator” and “User” refer to the person who uses the 9275-4C and 9275-8C.
• “Board”, and “Card” refer to openGear terminal devices within openGear frames,
including all components and switches.
• “System” and “Video system” refer to the mix of interconnected production and terminal
equipment in your environment.
• “-line mode ” refers to broadcast situations using NTSC composite (analog) signal
reference inputs.
• “-line mode ” refers to broadcast situations using PAL-B composite (analog) signal
reference inputs.
• “PAL” refers to PAL-B, or PAL-G unless otherwise stated.
• “Operating Tips” and “Note” boxes are used throughout this manual to provide additional
user information.
1-4 •••• Introduction 9275-4C / 9275-8C User Manual •••• (V 1.2)
Installation
In This Chapter
This chapter provides instructions for installing the Rear Modules for the 9275-4C or 9275-8C,
installing the card into the frame, cabling details, and updating the card software.
The following topics are discussed:
• Before You Begin
• Installing the 9275-4C or 9275-8C
• Cabling for the 9275-4C or 9275-8C
9275-4C / 9275-8C User Manual •••• (V 1.2) Installation •••• 2-1
Before You Begin
Static Discharge
Whenever handling the 9275-4C or 9275-8C and other related equipment, please observe all static
discharge precautions as described in the following note:
ESD Susceptibility — Static discharge can cause serious damage to sensitive
semiconductor devices. Avoid handling circuit boards in high static environments such as
carpeted areas and when synthetic fiber clothing is worn. Always exercise proper grounding
precautions when working on circuit boards and related equipment.
Unpacking
Unpack each 9275-4C or 9275-8C you received from the shipping container, and check the contents
against the packing list to ensure that all items are included. If any items are missing or damaged,
contact your sales representative or Cobalt Digital Inc. directly.
Note: In this section, “9275” refers to either the 9275-4C or 9275-8C.
2-2 •••• Installation 9275-4C / 9275-8C User Manual •••• (V 1.2)
Installing the 9275-4C or 9275-8C
This section outlines how to install a Rear Module in a 8300 series frame. The same procedure applies
regardless of the frame or card type. However, the specific Rear Module you need to install depends on
your application and the openGear frame you are using.
Rear Modules for the 9275-4C
When installing the 9275-4C:
20-slot frame — The RM20-9275-4C-B Full Rear Module (R2C-8259) is required.
Rear Modules for the 9275-8C
When installing the 9275-8C:
20-slot frame — The RM20-9275-8C-B Full Rear Module (R2C-8259) is required.
Installing a Rear Module
If the Rear Module is already installed, proceed to the section “Installing the 9275”.
Use the following procedure to install the rear module in an 8300 series frame:
1. Locate the card frame slots on the rear of the frame.
2. Remove the Blank Plate from the slot you have chosen for the 9275 installation.
3. Install the bottom of the Rear Module in the Module Seating Slot at the base of the
frame’s back plane. (Figure 2.1)
Figure 2.1 Rear Module Installation in a 8300 Series Frame (9275 not shown)
9275-4C / 9275-8C User Manual •••• (V 1.2) Installation •••• 2-3
4. Align the top hole of the Rear Module with the screw on the top-edge of the frame back
plane.
5. Using a Phillips screwdriver and the supplied screw, fasten the Rear Module to the back
plane of the frame. Do not over tighten.
6. Ensure proper frame cooling and ventilation by having all rear frame slots covered with
Rear Modules or Blank Plates.
This completes the procedure for installing a Rear Module in your 8300 series frame.
Installing the 9275-4C or 9275-8C
This section outlines how to install the 9275 in a 8300 series frame. Use the following procedure to
install the 9275 in a 8300 series frame:
1. Locate the Rear Module you installed in the procedure “Installing a Rear Module”.
2. Hold the 9275 by the edges and carefully align the card-edges with the slots in the frame.
3. Fully insert the card into the frame until the rear connection plus is properly seated in the
Rear Module.
4. Affix the supplied Rear Module Label to the BNC area of the Rear Module.
This completes the procedure for installing the 9275 in a 8300 series frame.
Cabling for the 9275
9275-4C Cabling Overview
The 9275-4C is used with the following Rear Modules:
RM20-9275-4C-B Rear Module — Each card occupies one slot and provides one SDI input,
one SDI output, and four analog outputs. (Figure 2.3)
Figure 2.3 Cable Connections for the 9275-4C
2-4 •••• Installation 9275-4C / 9275-8C User Manual •••• (V 1.2)
9275-8C Cabling Overview
In the 20-slot frames, the 9275-8C is used with the following Rear Modules:
RM20-9275-8C-B Rear Module— Each card occupies one slot and provides one SDI input,
one SDI output, and eight analog outputs. (Figure 2.4)
Figure 2.3 Cable Connections for the 9275-8C
9275-4C / 9275-8C User Manual •••• (V 1.2) Installation •••• 2-5
2-6 •••• Installation 9275-4C / 9275-8C User Manual •••• (V 1.2)
User Controls
In This Chapter
This section provides a general overview of the user controls available on the 9275.
The following topics are discussed:
• Card Overview
• Control and Monitoring Features
• Reference Compatibility
• Operation Notes
Note: In this section, “9275” refers to either the 9275-4C or 9275-8C.
9275-4C / 9275-8C User Manual •••• (V 1.2) User Controls •••• 3-1
Card Overview
This section provides a general overview of the 9275 components. The configurations outlined in
this section should be performed before installing the card in the frame, but may be repeated as
required. For information on the LEDs available on the card-edge, refer to the section “Control
and Monitoring Features”.
Figure 3.1 9275 —Card-edge Components
1) Function Select Switch (SW2) 2) Mode Select Switch (SW3) 3) Bootload But ton (SW1)
1. Function Select Switch (SW2)
Use SW2 to select general operation functions and menu items and works in conjunction with
the Mode Select Switch (SW3).
2. Mode Select Switch (SW3)
Use SW3 to enable, disable, and select specific configurations within the operational function
modes menu (selected first with SW2).
4. Bootload Button (SW1)
SW1 is used for factory service in the unlikely event of a complete card failure. Do not press
this button unless instructed to do so by Cobalt Technical Support personnel.
For More Information...
• on using the SW2 and SW3 switches, refer to the section “Card-edge Menu
System”.
• on the LEDs located on the card-edge, refer to the section “Status and Selection
LEDs on the 9275”.
3-2 •••• User Controls 9275-4C / 9275-8C User Manual •••• (V 1.2)
Control and Monitoring Features
This section provides information on the card-edge LEDs for the 9275.
Figure 3.2 9275 Card-edge Controls
Status and Selection LEDs on the 9275
The front-edge of the 9275 has LED indicators for the power, video input status and
communication activity. Basic LED displays and descriptions are provided in Table 3.1.
Table 3.1 LEDs on the 9275
LED Color Display and Description
When lit green, this LED indicates that the card is functioning
normal and that no anomalies have been detected. The following
conditions must be satisfied:
OK/ERROR
Green
Flashing Green
Flashing Green
and Orange
Orange When lit orange, this LED indicates the card is powering on.
Red When lit red, this LED indicates the card is not operational.
Off When off, this LED indicates there is no power to the card.
• a valid input signal is present
• a valid reference signal is present when a reference is required,
and that the reference standard matches the input standard.
When flashing green, this LED indicates the bootloader is waiting
for a software upload.
When lit green with flashing orange, this LED indicates there is a
signal error such as a missing or invalid input or reference.
9275-4C / 9275-8C User Manual •••• (V 1.2) User Controls •••• 3-3
LED Color Display and Description
Green When lit, this LED indicates that the video input is valid.
VIDEO OK
REF OK
AES 1 OK
AES 2 OK
AES 3 OK
AES 4 OK
AES 5 OK
AES 6 OK
Flashing Green
When flashing, this LED indicates that video is present, but the
input format is unsupported.
Off When unlit, this LED indicates the absence of an input signal.
Green When lit green, this LED indicates a valid reference signal.
Flashing Green
Off
Green
Green
Green
Green
When flashing, this LED indicates that the reference signal is
present but the format is invalid.
When unlit, this LED indicates that a reference signal is not
present, or is not compatible with the input format.
When lit, this LED indicates the presence of the embedded audio
Group 1 on the video input.
When lit, this LED indicates the presence of the embedded audio
Group 2 on the video input.
When lit, this LED indicates the presence of the embedded audio
Group 3 on the video input.
When lit, this LED indicates the presence of the embedded audio
Group 4 on the video input.
Green This LED is not implemented.
Green This LED is not implemented.
AES 7 OK
AES 8 OK
Green This LED is not implemented.
Green This LED is not implemented.
3-4 •••• User Controls 9275-4C / 9275-8C User Manual •••• (V 1.2)
Reference Compatibility
It is important to remember that if you are using Frame 1 or Frame 2 as the reference, the input
video frame rate must match the reference frame rate.
Frame Rate Compatibility
Refer to Table 3.2 for frame rate compatibility.
Table 3.2 Compatible Video Formats
Reference
480i/59.94
720p/59.94
1080i/59.94
576i/50
720p/50
1080i/50
Output
480i/59.94 720p/59.94 1080i/59.94 576i/50 1080i/50 720p/50
99999
99999
99999
99
99
99
99
99
99
9
99
9
99
9
99
99999
99999
99999
99
99
99
99
99
99
9
99
9
99
9
99
9275-4C / 9275-8C User Manual •••• (V 1.2) User Controls •••• 3-5
Operation Notes
This section provides brief notes when operating the 9275.
Audio Proc Amp Controls
The 9275 includes Processing Amplifiers (Proc Amps) for the audio inputs on the card. Note that
these features are not available when using the card-edge controls.
Proc Amp adjustments are applied in the following order:
1. Delay — This option enables you to adjust the delay of the audio channel. If you have
enabled the Delay Lock feature, changing the delay value for one channel automatically
changes the value for the other channel.
2. Gain — This option provides a +/- 20dB gain range in 1dB increments. If you have
enabled the Gain Lock feature, changing the gain value for one channel automatically
changes the value for the other channel. When using the 9275-C, the gain range is +/10dB.
3. Invert — This option enables you to invert the polarity of the audio signal for the
selected channel.
Minimum Delay Overview
The line buffer stores incoming video in relation to the incoming video clock timing. The video
data is then read out in relation to the reference timing. This allows the input video to be switched
between sources that may not be perfectly timed without timing glitches. Video source timing must
remain within the buffer window to properly switch between sources. Table 3.3 provides
information on the buffer window available depending on how the Minimum Delay feature is
configured in DashBoard.
Table 3.3 Minimum Delay
If the option is... Format Minimum Delay Maximum Delay
Disabled
Enabled
HD 1/4 line 1/2 line
SD 1/4 line 1/2 line
HD 1/64 line 1/32 line
SD 1/32 line 1/16 line
3-6 •••• User Controls 9275-4C / 9275-8C User Manual •••• (V 1.2)
Menus
In This Chapter
This chapter provides a summary of the menus available for the 9275.
The following topics are discussed:
• SNMP Monitoring and Control
• DashBoard Menus for the 9275
• Card-edge Menu System
9275-4C / 9275-8C User Manual •••• (V 1.2) Control and Monitoring •••• 4-1
SNMP Monitoring and Control
The Network Controller Card in the 8300 series frame provides optional support for remote monitoring
of your frame and the using Simple Network Management Protocol (SNMP), which is compatible with
many third-party monitoring and control tools.
Refer to your 9275 Management Information Base (MIB) file for a breakdown of SNMP controls on
this card. Refer to the 8300 Series User Manual and the MFC-8300 Series User Manual for
additional information on SNMP Monitoring and Control.
4-2 •••• Control and Monitoring 9275-4C / 9275-8C User Manual •••• (V 1.2)
DashBoard Menus for the 9275
This section briefly summarizes the menus, items, and parameters available from the DashBoard
Control System™ for the 9275. Parameters marked with an asterisk (*) are the factory default values.
The DashBoard Control System™ enables you to monitor and control openGear frames and cards from
a computer. DashBoard communicates with other cards in the 8300 series frame through the Network
Controller Card.
Status Tabs
Table 4.1 summarizes the Status tab parameters available in DashBoard for the 9275.
Table 4.1 Status Tab Items
Menu Item Parameters Description
Product
(Readonly)
Hardware
(Readonly)
Product
Supplier Cobalt Digital Inc.
Board Rev ##
Rear Module # Type of rear module in the slot
Board S/N ###### Indicates the card serial number
Software Rev ##.## Indicates the software version
Firmware Rev #.### Indicates the firmware version
Daughter Card Type*## Indicates if a daughter card is installed.
HW Status
Voltage (mV) # Supply Voltage
Current (mA) # Current consumpt i on of card
9275-4C
9275-8C
OK
FPGA load invalid
Incomp I/O Module
Current out of spec
Internal Error
Analog Audio De-Embedder; 4-Ch
Analog Audio De-Embedder; 8-Ch
Indicates any problems with the card
hardware components
CPU Headroom # Processing power available
RAM Available #/## On-board processing memory available
Uptime (h) #
Displays the number of hour s si nce the last
reboot of the card
Hardware
(Read-
Configuration Bank # Stor age count
only)
*
This field is not available when using a 9275-A.
9275-4C / 9275-8C User Manual •••• (V 1.2) Control and Monitoring •••• 4-3
Menu Item Parameters Description
OK
Invalid Format
Incompatible
Signal
(Readonly)
Signal Status
Audio Status
Non-Sync Video
Group Not Present
Group Channel
Silent
OK
Source Missing
Source Async
PCM-Silent
Group 4 Reduced
to 20bit
†
OK
No Ref - Video
Indicates when the channel is functioning
normally or if anomalies are detected
Indicates the status of the audio source
Indicates that a valid reference source is
present
The following conditions are occurring:
• Card reference is set to Frame 1 or Frame
2
• A valid reference signal is not present
• Card has gone to Video Timing Mode
Reference Status
The following conditions are occurring:
• Card reference is set to Frame 1 or Frame
2
No Ref - Free Run
• A valid reference signal is not present
• A valid video signal is not present
• Card has gone to Free Run Mode
‡
Invalid Format Video
†
This parameter indicates that there are more than 3 groups of 24bit SD embedded audio sources.
‡
Refer to the section “Reference Compatibility” for a complete list of supported references.
4-4 •••• Control and Monitoring 9275-4C / 9275-8C User Manual •••• (V 1.2)
Card has detected an invalid
format and has switched to Video Timing
Mode
reference
Menu Item Parameters Description
The following conditions are occurring:
• Card has detected an invalid
format
• Input video is missing or invalid
• Card has switched to Free Run Mode
Signal
Reference Status
Input Format # Indicates the input video format
Reference Format # Indicates the reference video format
Invalid Format Free Run
(Readonly)
Output Format # Indicates the output video format
PCM
No Input
b
reference
Embedded A udio
Status - Group #
PCM-Silent
Indicates the presence of input
Non-PCM
Async
Mixed
Setup Menus
Table 4.2 summarizes the Setup Menu options available in DashBoard for the 9275.
Table 4.2 Setup Menu Items
Menu Item Parameters Description
Frame 1*
Setup
Reference
Minimum Delay
Frame 2
Video
Checkbox selected*
Checkbox unselected
Selects the reference source
Provides the shortest video delay
through the card . When using SD,
the delay is 7us. When using HD,
the delay is 1.5us.
The total vi deo delay through t he
card will be the values above plus
half a video line
Black
Loss of Input
Blue
9275-4C / 9275-8C User Manual •••• (V 1.2) Control and Monitoring •••• 4-5
Sets the output to Black in the event
of a loss of video input
Sets the output to Blue in the event
of a loss of video input
Menu Item Parameters Description
Sets the output to a custom color in
Custom*
the event of a loss of video input.
Use the Y, Cr, and Cb sliders to
configure the color.
Setup
Loss of Input
Test Pattern
Y slider
Cr slider
Cb slider
None
100% Color Bars
Frequency Sweep
Black
Blue
Matrix Pathological
Luma Ramp
Y/C Ramp
75% SMPTE Bars
Sets the luminance component of the
Loss of Input Custom video signal.
Sets the Cr component of the Loss
of Input Custom video signal.
Sets the Cb component of the Loss
of Input Custom video signal.
Specifies the type of test pattern to
output
Specifies the type of test pattern to
output
SD Audio
Silence Threshold
(dB)
Silence Timeout
(sec)
Analog Ou tput
Input # - DeEmphasis
20 Bit* Embeds 20bit audio
24 Bit Embeds 24bit audio
Auto
-96 to 0
1 to 60
Off*
On
Auto
Embeds 20-24bit audio depending
on the source and number of bits
Audio below the specified threshold
value is considered silent
Audio silent for longer than the
specified value raises an alarm
Analog de-emphasis is always
disabled
Analog de-emphasis is always
enabled
Analog de-emphasis is enabled
depending on the channel status
emphasis bits
4-6 •••• Control and Monitoring 9275-4C / 9275-8C User Manual •••• (V 1.2)
Menu Item Parameters Description
All menu options are unlocked and
can be edited.
All menu items, except this one, are
locked and read-only.
Resets the parameters in the
Embedded Audio Outputs tab to
factory defaults
Resets all parameters to factory
defaults.
Setup
Unlocked
Edit Permission
Locked
All Audio Reset
Factory Defaults
Reset
Input Status Menus
Table 4.3 summarizes the Timing Menu options available in DashBoard for the 9275..
Table 4.3 Input Status Menu Items
Menu Item Parameters Description
Video
Input &
Embed
Input Format (readonly)
CRC Errors (re adonly)
#
#
Displays the format of the video
input
Displays the count of the CRC
errors on the video input. This 14bit
counter is reset on loss of video, or
by user request. The counter is nonlatching, and will roll over from
maximum count to zero.
• For SD formats, it displays both
active picture and full frame
errors.
• For HD formats, it displays the
total count of errors.
Error Count Reset Resets the CRC Errors field
PCM
No Input
Embedded
Audio –
Ch # Status (readonly)
Group #
Channel #
Word Length (readonly)
9275-4C / 9275-8C User Manual •••• (V 1.2) Control and Monitoring •••• 4-7
PCM-Silent
Non-PCM
Async
Mixed
#bit Displays the number of bits of audio
Displays the status of the Channel A
input
Analog Outputs Menus
Table 4.5 summarizes the Analog Outputs Menu options available in DashBoard for the 9275-4C
and 9275-8C.
Table 4.5 Analog Inputs Menu Items
Menu Item Parameters Description
Mute
Source
Group # Channel #
#Hz
Selects the source of the analog
output.
#kHz
Adjusts the audio delay for the
specified input
Adjusts the audio gain for the
specified input
Inverts the audio signal of the
channel
Output #
Delay (ms) 0* to 1000
Gain (dB) -10 to +10
Checkbox selected
Invert
§
Checkbox unselected* The audio signal is not inverted
Input Reset
Resets the parameters for the
selected input to the default values
Embedded Outputs Menus
Table 4.6 summarizes the Embedded Outputs Menu options available in DashBoard.
Table 4.6 Embedded Outputs Menu Items
Menu Item Parameters Description
Enable
Checkbox selected*
Checkbox unselected
Mute
Ch # Source
Group #
Group# Ch#
#kHz Tone
Group # Reset
All Groups Reset
§
The default value is 0.
4-8 •••• Control and Monitoring 9275-4C / 9275-8C User Manual •••• (V 1.2)
Determines if the group is inserted
in the output or not
Configures the Primary Source that
is inserted in to the embedded group
if present
Resets the specific group sources to
the default values
Resets all groups to the default
values
Alarm Enables Menus
Table 4.7 summarizes the Alarms Menu options available in DashBoard.
Table 4.7 Alarms Menu Items
Menu Item Parameters Description
Video
Input &
Reference
Alarm
No Input
Invalid Input
Incompatible Input
Non-Sync Video
No Reference
Checkbox selected*
Checkbox unselected Disables the alarm
Checkbox selected*
Checkbox unselected Disables the alarm
Checkbox selected*
Checkbox unselected Disables the alarm
Checkbox selected*
Checkbox unselected Disables the alarm
Checkbox selected*
Checkbox unselected Disables the alarm
Signal Status field reports a loss of
input
Input Format field displays an alarm
when the input video is a format that
is not supported
Input Format field reports when the
frame rate is not the same as the
reference input
Signal Status field reports if the
video input is asynchronous to the
reference
Reference Status field reports loss of
input conditions
Reference Format field reports when
Hardware
Embedded
Input
Audio -
Invalid Reference
Incompat Rear
Module
Incompat Daughte r
Card
Group not present
Checkbox selected*
Checkbox unselected Disables the alarm
Checkbox selected*
Checkbox unselected Disables the alarm
Checkbox selected
Checkbox unselected Disables the alarm
Checkbox selected*
Checkbox unselected Disables the alarm
the reference is a format that is not
supported
Hardware Status field reports when
a rear module is not compatible with
the card
HW Status field reports when using
an incompatible daughter card
Signal Status field reports when a
group is not present on the input
Group #
9275-4C / 9275-8C User Manual •••• (V 1.2) Control and Monitoring •••• 4-9
Menu Item Parameters Description
Signal Status field reports when the
Checkbox selected*
Channel # Silent
Checkbox unselected Disables the alarm
Checkbox selected*
Source Missing
specified channel is detected as
silent
Audio Status field reports when the
selected output is not present or is
silent
Analog
Outputs Output #
Embedded
Outputs Group #
Source Async
Source Missing
Source Async
SD 24Bit
Checkbox unselected Disables the alarm
Audio Status field reports when the
Checkbox selected*
Checkbox unselected Disables the alarm
Checkbox selected*
Checkbox unselected Disables the alarm
Checkbox selected*
Checkbox unselected Disables the alarm
Checkbox selected*
Checkbox unselected Disables the alarm
selected output is asynchronous to
the input video
Embedded Audio Status field
reports when the selected source is
not present or is silent
Embedded Audio Status field
reports when the selected source is
asynchronous to the input video
Audio Status field reports when the
selected configuration would embed
4 groups of 24bit audio in an SD
output. Group 4 is down-sampled to
20bit audio
All Alarms Set Enables all alarms
All Alarms Clear Disables all alarms
4-10 •••• Control and Monitoring 9275-4C / 9275-8C User Manual •••• (V 1.2)
Card-edge Menu System
This section summarizes the Card-edge Menu system of the 9275 and how to navigate the menus and
options using the SW2 and SW3 switches on the 9275 card-edge. A list of the available menus and
parameters is provided in Table 4.8.
Navigation
Use the following procedure to navigate the card-edge menus of the 9275:
1. Rotate SW2 to the required menu.
2. Toggle SW3 to select the required parameter.
This completes the procedure for navigating the Bank Menus of the 9275.
Note — Do not power down the card before ensuring that all edited parameters are
saved. Saving edited parameters can take up to 10 seconds.
Card-edge Menus
Table 4.8 lists all the menus, and menu items, available using the card-edge controls. To activate some
of these parameters, it may be necessary to toggle SW3 in either direction, or it may require that SW3
be held in either direction for a few seconds. Default values are indicated with an asterisk (*). Refer to
the section “Menu Descriptions” for a brief summary of the menus available on the card-edge.
Menu
Select
0
1
2
3
4
Table 4.8 Card-edge Menus and Items
Card-Edge Menu
Label
9275-X slot # Home
Fact Def Factory Default n/a Factory Default
Ref Src Reference Source
LOI Loss of Input
Test Patt Test Pattern
Menu Name
Card-Edge Item
Label
Fr 1* Frame 1 Reference
Fr 2 Frame 2 Reference
Vid Video
Black
Blue
Custom*
None*
75% SMPTE Bars
YC Ramp Y/C Ramp
L Ramp Luma Ramp
Matr Path Matrix Pathological
Blue Flat Field Blue
Black Flat Field Black
Item Name
9275-4C / 9275-8C User Manual •••• (V 1.2) Control and Monitoring •••• 4-11
Menu
Select
5
6
7
8
9
A
Card-Edge Menu
Label
Grp Sel Group Select
Grp Enbl Group Enable
Ch1 Src Channel 1 Source
Ch2 Src Channel 2 Source Same as above
Ch3 Src Channel 3 Source Same as above
Ch4 Src Channel 4 Source Same as above
Menu Name
Card-Edge Item
Label
Frq Swp Frequency Sweep
100% 100% Full Field Bars
Grp 1 Group 1
Grp 2 Group 2
Grp 3 Group 3
Grp 4 Group 4
Enabled*
Disabled
Mute
T4k 4kHz Tone
T2k 2kHz Tone
T1k 1kHz Tone
T.5k 500Hz Tone
G1C1 - G4C4
Item Name
Group 1, Channel 1 to Group 4,
Channel 4
B
Alg Sel (9275-4C) Analog Channel Select 1-4 Alg1 - Alg4 Analog 1 to Analog 4
Alg Sel (9275-8C) Analog Channel Select 1-8 Alg1 - Alg8 Analog 1 to Analog 8
Source (9275-4C) Analog Source G1C1 - G4C4
C
Source (9275-8C) Analog Source G1C1 - G4C4
D
ChB Src (9275-A) Channel B Source G1C1 - G4C4
Group 1, Channel 1 to Group 4,
Channel 4
Group 1, Channel 1 to Group 4,
Channel 4
Group 1, Channel 1 to Group 4,
Channel 4
Menu Descriptions
This section briefly summarizes the menu parameters available in the card-edge display.
0 — Home
This read-only menu displays the product name and the slot the card is installed in the frame.
1 — Factory Defaults
This function enables you to return all controls to their factory default values. Use the following
procedure to reset the card parameters to factory default values using the card-edge controls:
4-12 •••• Control and Monitoring 9275-4C / 9275-8C User Manual •••• (V 1.2)
1. Rotate SW2 to 1. The Four Character Display displays “Fact Def”.
2. Toggle SW3 down and hold for 3 seconds.
3. Release SW3.
2 — Reference Source
This menu enables you to select where the card will look for a reference. The choices are Frame
Reference 1 (Fr 1), Frame Reference 2 (Fr 2), and Video (Vid). Refer to the section “Reference
Compatibility” for a list of supported formats.
3 — Loss of Input
Use this menu to select what type of video displays at the system’s outputs when the input video signal
is lost or invalid.
4 — Test Pattern
This menu enables you to specify the type of test pattern to output. Note that this setting is not retained
on power down.
5 — Group Select
This menu enables you to select the embedded group before enabling the group, assigning sources to
the channels, and backup sources. This menu is used in conj unction with Menus 6 to E.
6 — Group Enable
Use this menu to determine if the selected group is embedded in the output or not.
7, 8, 9, A — Channel # Source
Use Menus 7 to A to configure the source that is inserted into the embedded group if present. These
menus are used in conjunction with Menu 5 (Gr oup Select). The following are the default values based
on the group selected:
Group 1 — When Menu 5 is set to Grp1, the default value of Menu 7 is G1C1.
Group 2 — When Menu 5 is set to Grp 2, the default value of Menu 8 is G2C2.
Group 3 — When Menu 5 is set to Grp 3, the default value of Menu 9 is G3C3.
Group 4 — When Menu 5 is set to Grp 4, the default value of Menu A is G4C4.
9275-4C / 9275-8C User Manual •••• (V 1.2) Control and Monitoring •••• 4-13
Specifications
In This Chapter
This chapter provides technical specification details on the 9275. Note that specifications are subject to
change without notice.
The following topics are discussed:
9275 Technical Specifications
Channel Status Data Table
9275-4C / 9275-8C User Manual •••• (V 1.2) Specifications •••• 5-1
Technical Specifications
This section includes the technical specifications for the 9275-4C and 9275-8C.
Table 5.2 9275-4C and 9275-8C Technical Specifications
Category Parameter Specification
Number of Inputs 1 HD-SDI input
SDI Data Rates and SMPTE Standards Accommodated SMPTE 292M, SMPTE 259M
SDI Input
SDI Output
Impedance 75ohm
Return Loss > -15dB to 1.5GHz
Equalization
Connector Type BNC
Number of Outputs 1 HD-SDI output
SDI Data Rates and SMPTE Standards Accommodated SMPTE 292M, SMPTE 259M
Impedance 75ohm
Return Loss > -15dB to 1.5GHz
Signal Level 800mV, +/- 10%
DC Offset <50mV
Rise and Fall Time (20-80%)
Overshoot <10%
Minimum Video Delay
Connector Type
Number of Outputs
Automatic
600ps typical @ SD rates
120ps typical @ HD rates
HD: 2.2us
BNC
9275-4C: 4 outputs
9275-8C: 8 outputs
Analog Audio
Outputs
Environmenta
Power
Maximum Output Level
Frequency Response
Signal to Noise Ratio
THD
Amplitude Linearity
Crosstalk
Operating Range 5°C to 40°C ambient
Total Power Consumption
+ 27dBu
± 0.07dB 22Hz to 20Hz @ Fs = 48kHz
-90dB
> -76dB
< 0.5dB @ -100dBFS
<-80dB (20Hz to 20kHz)
9275-4C: 8W
9275-8C: 9W
Channel Status Data Table
The following table shows the channel status bit information that is used for all output audio.
5-2 •••• Specifications 9275-4C / 9275-8C User Manual •••• (V 1.2)
Table 5.3 Channel Status Data
Byte Bit Function Transmitted
Professional or Consumer use of Channel Status
0
Block
1 Normal Audio or Non-Audio Mode Normal Audio (0)
0
2-4 Emphasis No Emphasis (100)
5 Lock Indication Locked (0)
6-7 Sampling Rate 48kHz (01)
0-3 Channel Mode 2 channel stereo (0001)
1
4-7 User Bit Mode 192-bit (0001)
0-2 Auxiliary Bit Usage 20-bit audio sample, Aux bits undefined (000)
3-5 Sample Word Length 20- or 24-bits (101)2
6-7 Alignment Level Not Indicated (00)
3 0-7 Multi-channel Modes Undefined (0)
0-1 Digital Audio Reference Signal Not a Reference (0)
2 Reserved 0
4
3-6 Sampling Frequency Not Indicated (0000)
7 Sampling Frequency Scali ng Flag No Scaling (0)
5 0-7 Reserved Unused (0)
6-9 ASCII Source ID Unused (0)
10-13 ASCII Destination ID Unused (0)
Professional (1)
14-17 Local Sample Address Unused (0)
18-21 Time of Day Unused (0)
22 0-7 C data reliability
23 0-7 CRC Calculated CRC
Only the first 5 Status Bytes are marked as Reliable. All
other Status Bytes are marked as Unreliable.
Passing the Status Bytes
The 9275 replaces Channel Status Bytes according to Table 5.3 or passes Status Bytes through fr om
input to output. In order for the Channel Status Bytes on the incoming embedded stream to be reembedded, t he outgoing Data Word Length must match the specified word length in the Channel Status
bits.
9275-4C / 9275-8C User Manual •••• (V 1.2) Specifications •••• 5-3
Service Information
In This Chapter
This chapter contains the following sections:
• Troubleshooting Checklist
• Warranty and Repair Policy
6-1 •••• Service Information 9275-4C / 9275-8C User Manual •••• (V 1.2)
Troubleshooting Checklist
Routine maintenance to this openGear product is not required. In the event of problems with your 9275,
the following basic troubleshooting checklist may help identify the source of the problem. If the card
still does not appear to be working properly after checking all possible causes, please contact your
openGear products distributor, or the Cobalt Digital Inc. Technical Support department at the numbers
listed under the Contact Us section at the end of this manual.
1. Visual Review – Performing a quick visual check may reveal many problems, such
as connectors not properly seated or loose cables. Check the module, the frame, and
any associated peripheral equipment for signs of trouble.
2. Power Check – Check the power indicator LED on the distribution frame front panel
for the presence of power. If the power LED is not illuminated, verify that the power
cable is connected to a power source and that power is available at the power main.
Confirm that the power supplies are fully seated in their slots. If the power LED is
still not illuminated, replace the power supply with one that is verified to work.
3. Reseat the Card in the Frame – Eject the card and reinsert it in the frame.
4. Check Control Settings – Refer to the Installation and Operation sections of the
manual and verify all user-adjustable component settings.
5. Input Signal Status – Verify that source equipment is operating correctly and that a
valid signal is being supplied.
6. Output Signal Path – Verify that destination equipment is operating correctly and
receiving a valid signal.
7. Card Exchange – Exchanging a suspect card with a card that is known to be
working correctly is an efficient method for localizing problems to individual cards.
Bootload Button
In the unlikely event of a complete card failure, you may be instructed by a Cobalt Digital Inc.
Technical Support specialist to perform a complete software reload on the 9275.
Use the following procedure to perform a software reload on the 9275:
1. Eject the card
2. Press and hold the Bootload button, while re-inserting the card into the frame.
3. Release the button.
The PWR LED will flash GREEN while the card is waiting for a new software load.
If a new software load is not sent to the card within 60 seconds, the card will attempt to
restart with the last operational software load.
Software can be uploaded to the 9275 via DashBoard. Refer to your DashBoard Control System
Software User Manual for further instructions.
9275-4C / 9275-8C User Manual •••• (V 1.2) 6-2 • Service Information
Warranty and Repair Policy
Cobalt Digital Inc. Limited Warranty
This product is warranted to be free from defects in material and workmanship for a period of five (5)
years from the date of shipment to the original purchaser, except that 4000, 5000, 6000, 8000 series
power supplies, and Dolby
material and workmanship for a period of one (1) year.
Cobalt Digital Inc.'s (“Cobalt”) sole obligation under this warranty shall be limited to, at its option, (i)
the repair or (ii) replacement of the product, and the determination of whether a defect is covered under
this limited warranty shall be made at the sole discretion of Cobalt.
This limited warranty applies only to the original end-purchaser of the product, and is not assignable or
transferrable therefrom. This warranty is limited to defects in material and workmanship, and shall not
apply to acts of God, accidents, or negligence on behalf of the purchaser, and shall be voided upon the
misuse, abuse, alteration, or modification of the product. Only Cobalt authorized factory
representatives are authorized to make repairs to the product, and any unauthorized attempt to repair
this product shall immediately void the warranty. Please contact Cobalt Technical Support for more
information.
To facilitate the resolution of warranty related issues, Cobalt recommends registering the product by
completing and returning a product registration form. In the event of a warrantable defect, the
purchaser shall notify Cobalt with a description of the problem, and Cobalt shall provide the purchaser
with a Return Material Authorization (“RMA”). For return, defective products should be double boxed,
and sufficiently protected, in the original packaging, or equivalent, and shipped to the Cobalt Factory
Service Center, postage prepaid and insured for the purchase price. The purchaser should include the
RMA number, description of the problem encountered, date purchased, name of dealer purchased from,
and serial number with the shipment.
®
modules (where applicable) are warranted to be free from defects in
Cobalt Digital Inc. Factory Service Center
2406 E. University Avenue Office: (217) 344-1243
Urbana, IL 61802 USA Fax: (217) 344-1245
www.cobaltdigital.com Email: info@cobaltdigital.com
THIS LIMITED WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE AND OF ALL OTHER OBLIGATIONS OR
LIABILITIES ON COBALT'S PART. ANY SOFTWARE PROVIDED WITH, OR FOR USE WITH,
THE PRODUCT IS PROVIDED “AS IS.” THE BUYER OF THE PRODUCT ACKNOWLEDGES
THAT NO OTHER REPRESENTATIONS WERE MADE OR RELIED UPON WITH RESPECT TO
THE QUALITY AND FUNCTION OF THE GOODS HEREIN SOLD. COBALT PRODUCTS ARE
NOT AUTHORIZED FOR USE IN LIFE SUPPORT APPLICATIONS.
COBALT'S LIABILITY, WHETHER IN CONTRACT, TORT, WARRANTY, OR OTHERWISE, IS
LIMITED TO THE REPAIR OR REPLACEMENT, AT ITS OPTION, OF ANY DEFECTIVE
PRODUCT, AND SHALL IN NO EVENT INCLUDE SPECIAL, INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS), EVEN IF IT HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
6-3 •••• Service Information 9275-4C / 9275-8C User Manual •••• (V 1.2)
Contact Us
Contact Cobalt Digital Inc.
•
General Business Office
and Technical Support
217.344.1243
PHONE
Fax
General Information
217.344.1245
Info@cobaltdigital.com
E-MAIL
Sales@cobaltdigital.com
2406 East University Avenue
Urbana, IL 61802 USA
POSTAL
Sales Information
Cobalt Digital Inc.
SERVICE
Visit us at the Cobalt Digital Inc. website.
http://www.cobaltdigital.com/
• Online catalog
• Related products and full product lines
• Trade show information
• Dealer information
• Cobalt Digital Inc. news
9275-4C / 9275-8C User Manual •••• (V 1.2) 6-4 •
