ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
Fine Furniture for every stage of life
Page 2
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
2. This product is for home use only and not intended for commercial establishments.
ASSEMBLY TIME 30 MINUTES
PARTS IDENTIFICATION
B1 ( BOX 1) B3 ( BOX 3)
A GLASS TOP 1PCS E BASE 2PCS
B2 ( BOX 2)
B TOP FRAME 1PCS
C LEG 2PCS
D CROSSBAR 1PCS
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
PAGE 2 OF
5
Page 3
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the
store immediately.
2. This product is for home use only and not intended for commercial establishments.
HARDWARE IDENTIFICATION
Z-B2 (BOX 2) - HARDWARE PACK IS LOCATED IN 107871 (B2)
1 FLAT WASHER D20*2 18PCS
2
SHORT BOLT
(M8*70mm)
8PCS
3 ALLEN WRENCH 1PCS
4
SHORT BOLT
(M8*40mm)
8PCS
5 GLASS REST 6PCS
6 LEVELER 8PCS
7
SHORT BOLT
(M8*140mm)
2PCS
Hardware pack is located in 108811 B2
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
PAGE 3 OF 5
Page 4
ASSEMBLY INSTRUCTIONS
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6
PAGE 4 OF 5
STEP 1
Page 5
PAGE 5 OF 5
