Page 1
300549 (B1-B3)
DAYBED
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
www.coastercompany.com
PAGE 1 OF 6
REVISION 0: 05/18/2018
Page 2
ITEM :
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instrutions in the same sequence as numbered to assure fast & easy assembly.
300549 (B1-B3)
Warning!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the
store immediately.
2. This product is for home use only and not intended for commercial establishments.
ASSEMBLY TIME 30 MINUTES
ASSEMBLY INSTRUCTIONS
PARTS IDENTIFICATION
B1 (BOX 1)
PART NAME FIGURE QTY
LEFT
A
SIDE PANEL
RIGHT
B
SIDE PANEL
ROLL SLAT
C
(7PCS)
LEGD
B2 (BOX 2)
1PC
1PC
4SETS
4PCS
B3 (BOX 3)
TRUNDLE
H
SIDE PANEL
TRUNDLE
I
BACK PANEL
J
TRUNDLE
FRONT PANEL
K
CASTER WITH
SCREW
2PCS
1PC
1PC
6SETS
BACKREST
E
FRONT RAIL
F
BACK RAIL
G
1PC
1PC
1PC
www.coastercompany.com
PAGE 2 OF 6
Page 3
ITEM :
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instrutions in the same sequence as numbered to assure fast & easy assembly.
300549 (B1-B3) ASSEMBLY INSTRUCTIONS
Warning!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the
store immediately.
2. This product is for home use only and not intended for commercial establishments.
HARDWARE IDENTIFICATION
Z-B2 (BOX 2)-HARDWARE PACK IS LOCATED IN 300549 (B2)
HARDWARE NAME FIGURE QTY
1
2
3
SHORT BOLT
(M8 x 20MM - RBW)
LONG BOLT
(M6 x 50MM - RBW)
LOCK WASHER
1/4" x 12MM - RBW)
(Ø
16PCS
8PCS
4PCS
4
FLAT WASHER
1/4" x 19MM - RBW)
(Ø
4PCS
www.coastercompany.com
PAGE 3 OF 6
Page 4
ITEM :
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instrutions in the same sequence as numbered to assure fast & easy assembly.
300549 (B1-B3)
Warning!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the
store immediately.
2. This product is for home use only and not intended for commercial establishments.
ASSEMBLY INSTRUCTIONS
HARDWARE IDENTIFICATION
Z-B2 (BOX 2)-HARDWARE PACK IS LOCATED IN 300549 (B2)
HARDWARE NAME FIGURE QTY
5
6
7
FLAT HEAD SCREW
(M4 x 32MM - RBW)
SMALL ALLEN WRENCH
(M4 x 65MM - BLK)
BIG ALLEN WRENCH
(M5 x 65MM - BLK)
16PCS
1PC
1PC
NOTE : PHILLIPS HEAD SCREW DRIVER IS REQUIRED IN THE ASSEMBLY PROCESS;
HOWEVER, MANUFACTURER DOES NOT PROVIDE THIS ITEM.
www.coastercompany.com
PAGE 4 OF 6
Page 5
ITEM :
STEP 1 STEP 2
300549 (B1-B3)
ASSEMBLY INSTRUCTIONS
1
A
D
6
2
STEP 3 STEP 4
A
B
7
G
F
E
C
4
3
2
6
5
www.coastercompany.com
PAGE 5 OF 6
Page 6
ITEM :
STEP 5 STEP 6
300549 (B1-B3)
ASSEMBLY INSTRUCTIONS
J
K
H
I
STEP 7 STEP 8
COMPLETE
1
I
J
H
7
5
C
PAGE 6 OF 6
www.coastercompany.com
