Coaster 215681KE Assembly Guide

215681KE (B1 - B3)

EASTERN KING BED

ASSEMBLY INSTRUCTIONS

COASTER FINE FURNITURE

www.coastercompany.com

PAGE 1 OF 6

REVISION 0: 05/25/2018

ITEM :

ASSEMBLY TIPS:

1. Remove hardware from box and sort by size.

2. Please check to see that all hardware and parts are present prior to start of assembly.

3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.

!

215681KE (B1 - B3)

Warning!

1. Don't attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.

2. This product is for home use only and not intended for commercial establishments.

ASSEMBLY TIME 15 MINUTES

ASSEMBLY INSTRUCTIONS

PARTS IDENTIFICATION

B1 (BOX 1 )

A

PART NAME

HEADBOARD PANEL

FIGURE QTY

1PC

B

C

D

E

B2 (BOX 2 )

F

G

B3 (BOX 3 )

H

I

HEADBOARD BOTTOM RAIL

LEFT HEADBOARD LEG

RIGHT HEADBOARD LEG

HEADBOARD FINIAL 2PCS

FOOTBOARD PANEL

FOOTBOARD FINIAL

BED RAIL

BED SLAT 5PCS

1PC

1PC

1PC

1PC

2PCS

2PCS

J

HB

FB

BED SLAT SUPPORT 10PCS

WITH LEVELER

215681KE (B1) 1PC

FROM BOX 1

HEADBOARD COMPLETE

215681KE (B2) 1PC

FROM BOX 2

FOOTBOARD COMPLETE

www.coastercompany.com

PAGE 2 OF 6
