Coaster 205131KE Assembly Guide

205131KE (B1-B3)

EASTERN KING SIZE BED

ASSEMBLY INSTRUCTIONS

COASTER FINE FURNITURE

www.coastercompany.com

PAGE 1 OF 5

REVISION 0: 04/19/2017

ITEM:205131KE (B1-B3) ASSEMBLY INSTRUCTIONS

ASSEMBLY TIPS:

1. Remove hardware from box and sort by size.

2. Please check to see that all hardware and parts are present prior to start of assembly.

3. Please follow attached instructions in the same sequence as numbered to assure fast and easy assembly.

Warning!

1.Don't attempt to repair or modify parts that are broken or defective. Please contact the
store immediately.

2.This product is for home use only and not intended for commercial establishments.

ASSEMBLY TIME 15 MINUTES

PARTS IDENTIFICATION

B1 (BOX 1)

A

B

C

D

B2 (BOX 2)

E FOOTBOARD 1PC

B3 (BOX 3)

G BED RAIL 2PCS

H

I CENTER RAIL 1PC

J 3PCS

K 10PCS

HEADBOARD PANEL 1PC

LEFT HEADBOARD

L

LEG
RIGHT HEADBOARD

R

LEG
HEADBOARD BOTTOM

RAIL

FOOTBOARD LEGF 2PCS

ROLL SLAT
(13PCS)

CENTER RAIL SUPPORT
WITH LEVELER

BED SLAT SUPPORT
WITH LEVELER

1PC

1PC

1PC

1SET

HARDWARE IDENTIFICATION

Z-B1 (BOX 1)­205131KE (B1)

1 8PCSBOLT

2 8PCSLOCK WASHER

3 8PCSFLAT WASHER

4 1PCALLEN WRENCH

Z-B2 (BOX 2)-Hardware pack is located in
205131KE (B2)

5 8PCSBOLT

6 8PCSLOCK WASHER

7 8PCSFLAT WASHER

8 1PCALLEN WRENCH

Z-B3 (BOX 3)-Hardware pack is located in
205131KE (B3)

9 11PCSSCREW

Hardware pack is located in

FB

205131KE (B1)
FROM BOX 1
HEADBOARD COMPLETE

205131KE (B2)
FROM BOX 2
FOOTBOARD COMPLETE

NOTE: PHILLIPS HEAD SCREW DRIVER IS REQUIRED IN THE ASSEMBLY PROCESS;
HOWEVER, MANUFACTURER DOES NOT PROVIDE THIS ITEM

1PCHB

1PC

PAGE 2 OF 5

www.coastercompany.com
