ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
FINE FURNITURE
204190KW (B1 ~ B4)
CALIFORNIA KING SIZE STORAGE BED
PAGE 1 OF 4
REVISION 0 : 11/14/2016
Page 2
HARDWARE IDENTIFICATION
ASSEMBLY TIPS:
1 . Remove hardware from box and sort by size.
2 . Please check to see that all hardware and parts are present prior to start of assembly.
3 . Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
Warning !
1 . Don't attempt to repair or modify parts that are broken or defective. Please contact the
store immediately.
2 . This product is for home use only and not intended for commercial establishment.
ASSEMBLY TIME
HB
D
204190KW (B1)
HEADBOARD COMPLETE
* FROM BOX 1
204190KW (B1)
FOOTBOARD
* FROM BOX 1
1PC
1PC
PARTS IDENTIFICATION
HEADBOARD PANEL 1PC
1PC
1PC
1PC
NOTE : PHILLIPS HEAD SCREW DRIVER IS REQUIRED IN THE ASSEMBLY
PROCESS; HOWEVER MANUFACTURER DOES NOT PROVIDE THIS ITEM.
N
B1 (BOX 1)
A
B
D
C
B2 (BOX 2)
E
G
I
K
L
M
LEFT HEADBOARD LEG
RIGHT HEADBOARD LEG
FOOTBOARD
BED SLAT WITH 3 HOLES
3PCS
ROLL SLAT (5PCS)
2SETS
CENTER RAIL SUPPORT
WITH LEVELER
3PCS
STORAGE FOOTBOARD
SUPPORT LEG
2PCS
RIGHT BED RAIL
1PC
RAIL TOP
2PCS
F
LEFT BED RAIL
1PC
www.coastercompany.com
FINE FURNITURE
R
B3 (BOX 3)
DRAWER BOX
O
2PCS
B4 (BOX 4)
DRAWER BOX
P
2PCS
H
DRAWER SLAT 2PCS
30 MINUTES
ASSEMBLY INSTRUCTIONSITEM : 204190KW (B1 ~ B4)
PAGE 2 OF 4
J
Z - B1 (BOX 1) - HARDWARE PACK IS
LOCATED IN 204190KW (B1)
Z - B2 (BOX 2) - HARDWARE PACK IS
LOCATED IN 204190KW (B2)
BOLT
1
LOCK WASHER
2
FLAT WASHER
3
ALLEN WRENCH
4
6PCS
6PCS
6PCS
1PC
10
4PCS
5 5PCS
1PC
11
1PC
9
43PCS
6
12
8PCS
SHORT FLAT HEAD SCREW
LONG BOLT
SMALL ALLEN WRENCH
LONG FLAT HEAD SCREW
SHORT BOLT
BIG ALLEN WRENCH
LOCK WASHER
7
FLAT WASHER
8
8PCS
8PCS
BOTTOM CROSS BAR
3PCS
CENTER RAIL 1PC
Page 3
STEP 2
HB
F
D
E
204190KW (B1) - BOX 1
STEP 1
204190KW (B1 & B2) - BOX 1 & BOX 2
STEP 2.3
9
H
STEP 3
204190KW (B1 & B2) - BOX 1 & BOX 2
11
J
5
H
STEP 3.1
STEP 3.2
9
M
F
ASSEMBLY INSTRUCTIONSITEM : 204190KW (B1 ~ B4)
www.coastercompany.com
FINE FURNITURE
R
PAGE 3 OF 4
12
STEP 2.1
STEP 2.2
A
C
B
Headboard & Leg
"R" Marking behind the
B
"L" Marking behind the
Headboard & Leg
**Please take note the marking on the leg and headboard**
4
1
2
3
Page 4
O
STEP 4
204190KW (B1 ~ B4) - BOX 1 TO BOX 4
J
H
STEP 5
O
P
P
STEP 4.1
STEP 4.3
J
STEP 5.3
J
'T' Runner
STEP 4.2
H
5
L
K
G
STEP 5.1
11
K
STEP 5.2
K
M
9
NOTE : ( for STEP 4.2 )
i) Fully insert the drawer box (N,O) until touch
to the black frame.
ii) Screw the T-Runner to the drawer slat (H).
10
Leveler
O P
/
O P
/
Leveler
ASSEMBLY INSTRUCTIONSITEM : 204190KW (B1 ~ B4)
www.coastercompany.com
FINE FURNITURE
R
PAGE 4 OF 4
N
9
F
I
11
STEP 5.4
687
N
