Cnib TIM-230-520-2030 Instructions Manual

INSTRUCTIONS FOR VOICE CONTROLLED TALKING ALARM CLOCK

TIM-230-520-2030

User Instructions:

Note: When the clock is connected to the provided AC Adapter, the Voice
Trigger mode must be active. This will enable you to use the command, "Hello

Moshi" to identify the time, date, temperature and much more. After following

the instructions below, check that the "Voice Trigger" switch is in the 'on' position.

When using the clock on battery power, the voice trigger mode is disabled
and the screen must be pressed to activate all voice interactive commands.

This clock has four different alternating color backgrounds for speaking,
listening and temperature. The night light will alternate in 6 colors.

The display turns red when the inside temperature is 90 F and above,
or if a function is not working properly.

The display turns green when the inside temperature is between 70
and 89 F, or when the clock is listening.

The display turnss light blue when the inside temperature is between
60 and 69 F.

The display turns dark blue when the inside temperature is 59 F and
below, or when the clock is talking.

Activation List of Spoken Commands:

To start using the clock either when using the provided AC Adapter or while
using the batteries, please begin your interaction with the clock with the

following steps:

1. Say “Hello Moshi”, then the clock will will respond with:
“Welcome, command please"

Use any of the following voice commands:

“Time” – The clock will respond “the time is (current time)."

“Set Time” – The clock will respond “tell me the current time" and, on first
usage or after an error.

Here is an example of how to correctly say the time:

Respond with the current time to set the clock (for example, say “six
o’clock pm”). The clock will then confirm “the time is now set to six o’clock

pm."

“Alarm” – The clock will respond “the alarm is set to" (alarm time) and say

whether the alarm is on or off. Then it will play the current alarm wake-up
sound you have chosen.

“Set Alarm” – The clock will respond “tell me the time you want the alarm to
sound” and on first usage or after an error.

Here is an example of how to correctly say the alarm time:

Respond with the time you want the alarm to sound (for example, “seven

thirty am”). The clock will respond “the alarm is now set to seven thirty

am.”

“Alarm Sound” – The clock will respond “to choose an alarm sound, say
‘alarm one’ (chime), ‘alarm two’ (chirp), or ‘alarm three’ (bell)."

Respond with your desired sound (for example, “alarm one”). The clock will
respond confirming the chosen alarm sound.

“Turn off the Alarm” – During the silences between alarm sounds, use the
command “turn off the alarm” to silence the alarm. This command will turn

off the alarm until the next day. The alarm will turn off and the clock will

respond “today is (current day, date, time and temperature").

“Sleep Sound” – The clock will respond “to choose a sleep sound, say ‘sound
one’ (water), ‘sound two’ (birds), or ‘sound three’ (waterfall). Respond with
the desired sound (for example, “sound one”). The clock will respond

confirming the chosen sound. The clock can play 5 minutes of three
different soothing sleep sounds.

“Play Sleep Sounds” – The clock will play the current sleep sound
programmed. Press the display to turn off the sleep sound.

“Today’s Date” – The clock will respond “today is (current date)."

“Temperature” – the clock will respond “the temperature is (current inside
temperature).”
