CNET CWR-854 User Manual

1
54Mbps Wireless-G Router
CWR-854
User’s Guide
2
FCC CAUTION..........................................................................................................................................3
SAFE SEATING GESTURES ............................................................................................................... 3
CE STATEMENT OF CONFORMITY................................................................................................ 3
CHAPTER-1 INTRODUCTION................................................................................................................. 4
1.1 PACKAGE CONTENT ....................................................................................................................4
1.2 SPECIFICATION.................................................................................................................................... 5
1.3 FEATURES............................................................................................................................................6
1.4 LED INDICATOR...................................................................................................................................7
1.5 REAL PANEL DESCRIPTION.................................................................................................................8
CHAPTER-2 INSTALLATION................................................................................................................... 9
2.1 HARDWARE INSTALLATION................................................................................................................... 9
CHAPTER-3 WEB CONFIGURATION............................................................................................... 16
3.1.1.Operation Mode .................................................................................................................... 17
3.1.2 Time Zone Settings.............................................................................................................. 18
3.1.3 LAN Interface Setup............................................................................................................. 19
3.1.4 WAN Interface Setup............................................................................................................ 20
3.1.5 Wireless Basic Settings...................................................................................................... 21
3.1.6 Wireless Security Setup ..................................................................................................... 22
3.3.1 Basic Settings ....................................................................................................................... 24
3.3.2 Wireless Advanced Settings.............................................................................................. 26
3.3.3 Security................................................................................................................................... 28
3.3.4 Access Control...................................................................................................................... 33
3.3.5 WDS Settings......................................................................................................................... 34
3.3.6 Site Survey............................................................................................................................. 35
3.3.7 WPS.......................................................................................................................................... 36
3.4.1 LAN Interface......................................................................................................................... 37
3.4.2 WAN Interface........................................................................................................................ 39
3.5.1 Port Filtering.......................................................................................................................... 47
3.5.2 IP Filtering .............................................................................................................................. 48
3.5.3 MAC Filtering......................................................................................................................... 49
3.5.4 Port Forwarding.................................................................................................................... 50
3.5.5 URL Filtering.......................................................................................................................... 51
3.5.6 DMZ..........................................................................................................................................52
3.6.1 Status....................................................................................................................................... 53
3.6.2 Statistics................................................................................................................................. 54
3.6.3 DDNS ....................................................................................................................................... 55
3.6.4 Time Zone Settings.............................................................................................................. 56
3.6.5 Denial of Service (DoS Prevention) ................................................................................. 57
3.6.6 Event Log................................................................................................................................ 58
3.6.7 Upgrade Firmware................................................................................................................ 59
3.6.8 Save / Reload Settings ........................................................................................................ 60
3.6.9 Password................................................................................................................................ 61
APPENDIX A: TROUBLESHOOTING................................................................................................... 62
APPENDIX B: FREQUENTLY ASKED QUESTIONS.......................................................................... 65
3
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference
that may cause undesired operation.
Safe Seating Gestures
The user have to choose an adjustable chair, comfortable is the key. You should follow the manufacturer’s instructions for adjusting the backrest to fit your
body properly. Following is the explanation of the picture.
Shoulders relaxed, and forearms and hands in a straight line. Lower back support and thighs tilted slightly. Top of the screen at or slightly below eye level. Screen positioned to avoid reflected glare. Clearance under work surface. Feel flat on the floor. The distance between you and the monitor should be 45~70 cm（18~28
inch）
CE Statement of Conformity
Our product has been tested in typical configuration by Ecam Sertech Corp and was found to comply with the essential requirement of “Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility” (89/336/EEC; 92/31/EEC; 93/68/EEC)
4

Chapter-1 Introduction

Thank you for choosing the CNet Wireless series product. CWR-854 is an ideal Wireless-G Router for the small office or home networking environments. Setting SOHO and enterprise standard for high performance, secure, manageable and reliable WLAN. CWR-854 is not only a Wireless Router but also supports AP Client / Bridge and WDS (Wireless Distributed System) mode to satisfy all kinds of the application from different networking environment. The WPS (Wi-Fi Protected Setup) function could help you establish a wireless home network easily and securely.
CWR-854 also provides step-by-step installation for both Internet setting as well as LAN and Wireless connection. For Wireless security that the router supports WEP, WPA and WPA2 (TKIP/AES), and CWR-854 also equipped with advanced MAC address, IP/Port Filtering and URL Filtering to safe and secure home or office network.
This router can be easily configured without other utility install. You could just follow this user manual to setup your Wireless Network with the embedded GUI browser.

1.1 Package Content

The package of CWR-854 includes the following items,
1 x CWR-854 1 x Power Adapter 1 x Documentation CD 1 x RJ-45 Cable Line 1 x Detachable Antenna 1 x Cradle 1 x QIG
Notes: If any of above items are missing, please contact with your supplier as soon as possible.
5

1.2 Specification

Standard
IEEE 802.11G/B
Frequency Band
2.400GHz ~ 2.484GHz
Radio Type
IEEE 802.11g: OFDM (64-QAM, 16-QAM, QPSK, BPSK) IEEE 802.11b: DSSS (CCK/DQPSK/DBPSK)
Data Rate (Wireless)
802.11g: 54 / 48 / 36 / 24 / 18 / 12 / 9 & 6Mbps
802.11b: 11 / 5.5 / 2 & 1 Mbps with auto-rate fall back
Access Protocol
CSMA/CA
Number of Operation Channel
2.412~2.462GHz (Canada, FCC) / 11 Channels
2.412~2.484GHz (Japan, TELEC) / 14 Channels
2.412~2.472GHz (Euro, ETSI) / 13 Channels
Operation Mode
AP AP Client (ad-hoc and infrastructure) Client Bridge (point-to-pint and point-to-multipoint) WDS (Wireless Description System)
Security
64/128bit WEP WPA (TKIP with IEEE 802.1x) WPA2 (AES with IEEE 802.1x)
RF Output Power (Typical)
802.11g: up to 14 ± 1 dBm
802.11b: up to 17 ± 1 dBm
Sensitivity
-68dBm @ 802.11g
-80dBm @ 802.11b
Antenna
One detachable 5dbi antenna
Dimension (L x W x H)
165 x 118 x 27mm (6.49 x 4.65 x 1.06inch)
Weight
245g
Operation Temperature
0°C ~ 40°C (32° ~ 104°F)
Storage Temperature
-20°C ~ 60 °C (-4° ~ 140°F)
Humidity
10% ~ 90% (Non-condensing)
Connector
One antenna connector One RJ-45 port for WAN Four RJ-45 LAN ports Reset to default button WPS button Power jack
Power requirement
12V DC, 1A
6

1.3 Features

802.11b/g compliant with 54Mbps high-speed data rate Operation modes: AP, AP client, Client, Bridge, WDS DHCP Server/Client Four Ethernet ports for broadband sharing Virtual DMZ, Port Forwarding Dynamic DNS TCP/UDP/ICMP/ARP protocol stack Firewall, URL/IP/Port/MAC filtering Wireless users access control Wireless security – 64/128bit WEP, WPA/WPA2, 802.1x and 802.11i Support PPPoE, VPN pass-through with multiple sessions, PPTP and L2TP Universal Plug and Play, no complicated installation necessary Quick and easy setup with Web-based management utility Detachable antenna allows user to replace higher gain antenna Supports WPS, 64-bit and 128-bit WEP, WPA, WPA2 encryption/decryption
7

1.4 LED Indicator

LED Indicator
State
Description
POWER
ON
The WLAN Broadband Router is powered on
OFF
The WLAN Broadband Router is powered off
WLAN
Flashing
Data is transmitting or receiving on the antenna
OFF
No data is transmitting or receiving on the antenna
WAN
Flashing
Data is transmitting or receiving on the LAN interface
ON
Port linked
OFF
No link
LAN 1~4
Flashing
Data is transmitting or receiving on the WAN interface
ON
Port linked
OFF
No link
WPS
ON
WPS function is waiting for the registration from client side
OFF
WPS function is off
8

1.5 Real Panel Description

Interfaces
Description
Antenna (Fixed / SMA)
The Wireless LAN Antenna.
Reset
Push continually the reset button 5 ~ 10 seconds to reset the configuration parameters to factory defaults.
WPS
Push continually the WPS button 5 ~ 10 seconds to enable the WPS feature.
LAN
The RJ-45 sockets allow LAN connection through Category 5 cables. Supports auto-sensing on 10/100M speed and half / full duplex, and comply with IEEE 802.3 / 802.3u respectively.
WAN
The RJ-45 socket allows WAN connection through a Category 5 cable. Supports auto-sensing on 10/100M speed and half / full duplex, and comply with IEEE
802.3/ 802.3u respectively.
Power
The power jack allows an external power supply connection.
9

Chapter-2 Installation

2.1 Hardware Installation

1. Place the Wireless LAN Broadband Router to the best optimum transmission location. The best transmission location for your WLAN Broadband Router is usually at the geographic center of your wireless network, with line of sign to all of your mobile stations.
2. Connect the WAN port on the router to a Cable/DSL modem, Ethernet Server, or hub.
3. Connect one or more client PCs to the LAN port(s).
4. Connect the power adapter to the wall outlet and the power jack on the router.
5. Turn your PCs on.
10

2.2 Preparing the Networking

This chapter covers the things that need to be done before configuring the router. The first thing is to set all computers on the network for TCP/IP networking and also gather necessary information from the Internet Service Provider (ISP).

2.3 Collecting ISP Information

The following information needs to be gathered from the ISP before configuring the router:
․IP Assignment from ISP: Are IPs assigned dynamically or you have a fixed IP address? If fixed,
what are the IP address, Subnet Mask, Default Gateway as well as the DNS addresses for this account?
․Connection Type: Is this a PPPoE or PPTP connection? If PPPoE, what are the username and
password associated with this account? If PPTP, the server IP address as well as user authentication information is required.
Please contact your ISP if you’re not sure of the answers to these questions.

2.4 Configuring Windows for IP Networking

Each computer on the network and connecting to the router should be configured for TCP/IP networking. The router is by default a DHCP server and if you plan to use DHCP (recommended). Each computer must be configured to receive an IP address automatically. See the procedure below. If fixed IP addresses are to be used on the network, you’ll need to manually assign an IP address to each computer and make sure that they are in the same subnet as the router. Refer to your Windows documentation for instructions on IP assignment.
To configure TCP/IP in Windows:
Configuring Windows 98 and millennium PCs
1. Click the Start button go to Settings and click on Control Panel. In Control Panel, double-click the Network icon.
2. Under the Configuration tab, select the TCP/IP line for the applicable Ethernet adapter. Do not choose a TCP/IP entry whose name mentions DUN, PPPoE, VPN, or AOL. If the word TCP/IP appears by itself, select that line. Click the Properties button.
11
3. Click the IP Address tab. Select Obtain an IP address automatically.
4. Now click the Gateway tab, and verify that the Installed Gateways field is Blank. Click the OK button.
5. Click the OK button again. Windows may ask for original Windows installation CD or additional files. Check for the files at c:\windows\options\cabs, or insert your Windows CD-ROM into the CDROM drive and enter the correct file location, e.g., D:\win98, D:\win9x, etc. ( “D” is the drive letter of the CD-ROM drive).
6. Windows may ask to restart the PC. Click the Yes button. If Windows does not prompt to restart, restart the computer anyway.
12
Configuring Windows 2000 PCs
1. Click the Start button go to Settings and click on Control Panel. In Control Panel, double-click the Network and Dial-up Connections icon.
2. Select the Local Area Connection icon for the applicable Ethernet adapter (usually it is the
first Local Area Connection listed). Double-click the Local Area Connection and Click the Properties button.
3. Make sure the box next to Internet Protocol (TCP/IP) is checked. Highlight Internet Protocol (TCP/IP), and click the Properties button.
13
4. Select Obtain an IP address automatically and click the OK button. Click the OK button again to complete the PC configuration.
5. Restart your computer.
14
Configuring Windows XP PCs
The following instructions assume you are running Windows XP with the default interface (Control Panel looks different then previous versions of Windows). If you are using the Classic View (where icons and menus look similar to previous Windows versions), please follow the instructions for Windows 2000.
1. Click the Start button and then the Control Panel icon. Click the Network and Internet Connections icon. Then click the Network Connections icon.
2. Select the Local Area Connection icon for the applicable Ethernet adapter (usually it is the first Local Area Connection listed). Double-click the Local Area Connection and click the Properties button.
3. Highlight Internet Protocol (TCP/IP), and click the Properties button.
15
4. Select Obtain an IP address automatically and click OK. Click the OK button again to complete the PC configuration.
Configuring Windows XP PCs
16

Chapter-3 Web Configuration

This chapter describes how to access the router through the web browser. Please be noted that in order to access the router’s admin page, a computer must be connected to one of the LAN ports on the router.
The WLAN Broadband Router is delivered with the following factory default parameters on the Ethernet LAN interfaces.
Default IP Address: 192.168.1.254 Default IP subnet mask: 255.255.255.0 WEB login User Name: <empty> WEB login Password: <empty>

3.1 Setup Wizard

After a successful log-in to the router, the setup page will be shown as the below picture.
The router’s configuration menu provides a Setup Wizard for basic configuration of the router. For more advanced feature settings. Users have to choose different menu items, and then click “Next” to proceed with Setup Wizard.
17

3.1.1.Operation Mode

This page followed by Setup Wizard page to define the operation mode. CWR-854 supports three kinds of operation mode for the different application and environment. CWR-854 can be presented a NAT Router, Bridge or Wireless ISP Client.
18

3.1.2 Time Zone Settings

Users can synchronize the local clock on the router to an available NTP server (optional). To complete this setting, enable NTP client update and select the correct Time Zone.
Enable NTP client update: Enable time zone update function Time Zone Select: Select the time zone this router is used in. NTP server: Select from the list of NTP servers by clicking the down arrow key or
manually enter time server IP address.
Cancel: To skip the current settings and jump to the Setup Wizard page. Back: To skip the current settings and go back to the last page. Next: Go to the next page.
After completing the time zone settings, click “Next” to proceed to the LAN Interface Setup page.
19

3.1.3 LAN Interface Setup

In the LAN interface Setup page, users can change the LAN IP address and Subnet Mask of the router. Most Users will not need to change these values.
IP Address: Current IP address of the Wireless-G Router, not WAN IP address. Subnet Mask: Current subnet mask for the Wireless-G Router, not WAN subnet
mask address
Cancel: To skip the current settings and jump to the Setup Wizard page. Back: To skip the current settings and go back to the last page. Next: Go to the next page.
After typing in the IP Address and Subnet Mask, click “Next” to move on the WAN interface setup page.
20

3.1.4 WAN Interface Setup

In this screen users must identify and configure the connection type used for connecting to their Internet Service Provider (ISP).
WAN Access Type: CWR supports 4 kinds of access type to connect the ISP –
Static IP, DHCP Client, PPPoE, PPTP.
Cancel: To skip the current settings and jump to the Setup Wizard page. Back: To skip the current settings and go back to the last page. Next: Go to the next page.
After all items are set, click “Next” to advance to the next screen, Wireless Basic Settings page.
21

3.1.5 Wireless Basic Settings

In the Wireless Basic Settings page, users can configure the operating “Band” and “Mode” as well as “Network Type”, ” SSID”, “Channel Number” and if required MAC address cloning.
Operating Band: 802.11B/G, 802.11G or 802.11B Operating Mode: AP, Client, WDS and AP+WDS. Network type: when operating mode is “Client” mode, users can select the
network type as “infrastructure” or “Ad-hoc”.
SSID: The SSID differentiates one WLAN from another, therefore, all wireless
access points/routers and all wireless devices attempting to connect to a specific WLAN must use the same SSID. It is case-sensitive and must not exceed 32 characters
Channel Number: The number of channels supported depends on the region this
Wireless-G Router is used in. All stations communicating with this Wireless-G Router must use the same channel. (Note: not supported in client mode)
Enable Mac clone: when operating mode is “Client” and only one Ethernet client
exists, users can enable the Mac clone feature to easily connect to the wireless station.
Cancel: To skip the current settings and jump to the Setup Wizard page. Next: Go to the next page. Back: To skip the current settings and go back to the last page.
Loading...
+ 49 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
