CGS-500 FIVE PORT GIGABIT SWITCH
TOTAL NETWORK SOLUTIONS
www.cnetusa.com
Cnet is proud to continue its efforts to strengthen the market transition to Gigabit Ethernet through the addition of
another all Giga ports switch CGS-500. This new product provides enterprise and SMB customers with Gigabit
Ethernet for deployment of intense applications without breaking budget.
FEATURES
•= Auto-MDI/MDI-X on All Ports for Simple Setup and Troubleshooting.
•= Flow-control Reduces Re-transmissions in the Networks.
•= Deliver Robust Performance and Build Quality to Ensure Reliable Operation.
•= Auto-negotiation Function for Compatibility among 10/100/1000Mbps.
•= Non-blocking Performance Improves Access to Network Resources.
PRODUCT SPECIFICATIONS
Model CGS -500
Standards
Ports
Media Support
Bandwidth
Forwarding/Filtering Rate
MAC Addresses
Buffer Memory
Duplex Modes
Crossover
LED Indicators
External Power Adapter
Power Consumption
Environment
Certifications
Dimensions
IEEE 802.3: 10Base-T
IEEE 802.3u: 100Base-TX
IEEE 802.3ab: 1000Base-T
IEEE 802.3x: Flow-control support
Five 10/100/1000Base-T TP Copper Ports
10Base-T: CAT 3, 4 or 5 TP
100Base-TX/1000Base-T: CAT 5 TP
1000Base-T: 10/20/100/2000/2000 Mbps
1488095 packets/second per port @ 1000Mbps maximum
148810 packets/second per port @ 100Mbps maximum
14881 packets/second per port @ 10Mbps maximum
8K Self-learning
2M bits
Support MDI/MDI-X and Auto-negotiation function.
Auto-crossover function
One for Power (Green)
Per port for display 1000M Link/Act (Green)
Per port for display 100/10M Link/Act (Green/ Orange)
Per port for display Full-duplex mode or collision status (Half –Duplex) (Green)
Output 5VDC, 2.5Amp (Input according to country)
Up to 12.5 watt
Operating Temperatu re: -20° ~ 70°C (-4° ~ 158°F)
Storage Temperature: -40° ~ 80°C (-40° ~ 176°F)
Humidity: 10% ~ 90% Non-condensing
FCC Class A
CE Mark
6.89” x 4.33”x1.18” (175mm x 110mm x 30mm)
Specifications are subject to change without notice Trademarks & Trade Names belong to their owners
ORDERING INFORMATION
Model Description
CGS-500 (A)
•= 5-port Gigabit Switch
Specifications are subject to change without notice Trademarks & Trade Names belong to their owners
