CGS-1600—16-PORT GIGABIT SWITCH
TOTAL NETWORK SOLUTIONS
www.cnetusa.com
CNet in continuation of its efforts to strengthen the market transition to Gigabit Ethernet is proud to introduce the
addition of CGS-1600 to its Gigabit Switch product line. CGS-1600, CNet’s new Gigabit switch is especially designed
for small and medium businesses to meet their heavy bandwidth demands for graphic and multimedia applications on
the network.
KEY FEATURES
Auto-MDI/MDI-X on All Ports for Simple Setup and Troubleshooting
Flow-control Reduces Re-transmissions in the Networks
Deliver Robust Performance and Build Quality to Ensure Reliable Operation
Auto-negotiation Function for Compatibility among 10/100/1000Mbps
Non-blocking Performance Improves Access to Network Resources
SPECIFICATION
Model
Standards
CGS-1600
IEEE 802.3: 10 Base-T
IEEE 802.3u: 100 Base-TX
IEEE 802.3ab: 1000 Base-T
IEEE 802.3x: Flow-control support
Ports
Media Support
Sixteen 10/100/1000 Base-T TP Copper Ports
10 Base-T: Category 3, 4 or 5 TP
100 Base-TX/1000 Base-T: Category 5 TP
Bandwidth
Forwarding Rate
1000 Base-T 10/20/100/200/2000Mbps
14881 packets/second per port @ 10Mbps maximum
148810 packets/second per port @ 100Mbps maximum
1488100 packets/second per port @ 1000Mbps maximum
Latency
75 µsec @ 10Mbps minimum
11 µsec @100Mbps minimum
2.2µsec @1000Mbps minimum
Duplex Modes
LED Indicators
Support Auto-MDI/MDI-X and Auto-negotiation Functions
One Green LED displays Power status
One Green LED per port displays 1000 Mbps Link/Act status
One Green/Orange LED per port displays 10/100 Mbps Link/Act status
One Green LED per port displays Full-duplex/Collision (Half –duplex) status
Power Supply
Full Range Auto-switching
Input Voltage: 100 ~ 240 +-10% VAC/ 50 ~ 60Hz
Environment
Operating Temperature: -20° ~ 70°C (-4° ~ 158°F)
Storage Temperature: -40° ~ 80°C (-40° ~ 176°F)
Humidity: 10% ~ 90% Non-condensing
Certifications
FCC
CE
Dimensions
442 x 184 x 44mm (17.40 x 7.24 x 1.73inches)
Specifications are subject to change without notice Trademarks & Trade Names belong to their owners
ORDERING INFORMATION
Model Description
CGS-1600 (B) 16-Port Gigabit Switch
Specifications are subject to change without notice Trademarks & Trade Names belong to their owners
